Udoo NEO User manual

____________________________________________________________________________________________
_________________________________________________________
STEP BY STEP UIDE
W H A T I S I T ?
UDOO NEO is an
all - in - one open
hardware low - cost
computer
The board is ideal
to create robots, drones
and rovers as well as
any Mobile IoT project
you can imagine.
S O S M A L L S O S M A R T
S T A R T I N F R O M $ 49.90
W H A T D O Y U N E E D ?
use it as a headless IoT device use
it as a computer
59
mm
89 mm
UDOO
NEO
MICRO SD Card
(at least 8GB)
or
USB Wall Charger 5V
with Micro USB
Data Cable
12V 2A
Power supply
1)
2)
3)
1) 2) 3) or
UDOO
NEO
MICRO SD
Card
(at least 8GB)
USB
Data Cable
Power
Supply
4)
5)
6)
Monitor or TV
Keyboard
Mouse

_________________________________________________________
STEP BY STEP UIDE
_________________________________________________________
Create a
bootable
MicroSD
card
Use as a
headless
IoT device
Use as a
computer
1 2 3
Very
first
start
Download any official Micro SD
image from the image section of
the website.
a )
b )
Extract the .img file from the
.zip file you downloaded into
any folder.
c )
Follow the instructions below
for the OS you use: Windows,
Mac OS X, Linux.

_________________________________________________________
STEP BY STEP UIDE
_________________________________________________________
Create a
bootable
MicroSD
card
Use as a
headless
IoT device
Use as a
computer
1 2 3
Very
first
start
F o r W i n d o w s
Extract the downloaded zip file, so you ' ll
have a .img image file.
Use 7 - zip or similar
to decompress the zip file.
Download the Win32DiskImager
software and unzip it.
Connect the Micro SD Cart to the PC.
If the PC has a slot for SD cards
simply insert the card. If not,
insert the card into any SD card
reader and then connect it to the
PC..
Run the file named
Win32DiskImager.exe right - clicking it
and selecting “ Run as administrator ” ..
Select the correct drive identifier
Be careful! If you use the wrong
identifier you may lose all data in
your PC.
In the Image File box, choose the
downloaded .img file and click “ Write ” .
Click yes in case a warning
message pops up.
The Micro SD card is now ready to be used.
Simply insert it in the board ’ s Micro SD Card slot and
boot the system.
1.
2.
3.
4.
5.
6.

_________________________________________________________
STEP BY STEP UIDE
_________________________________________________________
Use as a
headless
IoT device
Use as a
computer
1 2 3
Very
first
start
Create a
bootable
MicroSD
card
F o r M a c O S X
F o r L i n u x U b u n t u
http: // www.udoo.org / docs -
neo / etting _ Started / Create _
a _ bootable _ MicroSD _ card _ fo
r _ UDOO _ Neo.html
Click the link, choose
" Linux " and follow the
instruction.
If you have problems, have
a look to the video
tutorial.
Click the link, choose
" Linux " and follow the
instruction.
If you have problems, have
a look to the video
tutorial.
http: // www.udoo.org / docs -
neo / etting _ Started / Create _
a _ bootable _ MicroSD _ card _ fo
r _ UDOO _ Neo.html

_________________________________________________________
STEP BY STEP UIDE
_________________________________________________________
Use as a
headless
IoT device
Use as a
computer
123
Very
first
start
Create a
bootable
MicroSD
card
W H A T Y O U N E E D RECAP
UDOO
NEO
Bootable
MICRO SD
Card
USB Data
Cable
W H A T Y O U C A N D O
USB HEADLESS DEVICE NETWORK
CONNECTED
HEADLESS DEVICE
WIRELESS NETWORK CONNECTED
HEADLESS DEVICE
Insert the Micro SD in the
specific slot.
Connect the Micro USB
Cable to Udoo Neo and then
to your PC: Udoo Neo will
take its power from USB port.
If its the first time you
proceed this way, configure
your PC as described in the
configure Usb Direct
Connection
Udoo Neo is available at the
address 192.168.7.2.
Insert the Micro SD in the
specific slot.
Connect to your Network
via Ethernet Cable.
Turn on by applying
power, either via Micro
USB or DC - in
Udoo Neo will be available
in your Network
Insert the Micro SD in the
specific slot.
Activate your Wifi: go to
configuration, select your
Wifi Network and write the
password.
You can just power up
Udoo Neo using a power
supply.
ENJOY
YOUR EXPERIENCE !

_________________________________________________________
STEP BY STEP UIDE
_________________________________________________________
Use as a
headless
IoT device
123
Very
first
start
Create a
bootable
MicroSD
card
Use
as a
computer
W H A T Y O U C A N D O
W H A T Y O U N E E D RECAP
UDOO
NEO MicroSD
Card USB
Data
Cable Monitor Keyboard Mouse
+
LI HTWEI HT DESKTOP PC
YOUR EXPERIENCE !
ENJOY
Micro HDMI to
HDMI Cable Power
Supply
Insert the Micro SD in the
specific slot of the UdooNeo.
Plug the Micro HDMI to
HDMI Cable.
Plug wireless keyboard and
mouse.
If you have not wireless
keyboard and mouse you can
get an additional USB port by
using a Micro USB to USB adapter.
Power up the UdooNeo by
the power supply.
The first boot will take slightly longer
than the following onece.
reen light means that it works.

_________________________________________________________
STEP BY STEP UIDE
_________________________________________________________
Use as a
headless
IoT device
123
Very
first
start
Create a
bootable
MicroSD
card
Use
as a
computer
More information about Udoo Neo
Watch video tutorials
Find other versions of the
Udoo family
http: // www.udoo.org / docs -
neo / Hardware _ Reference / Board % 20v
ersions.html
http: // www.udoo.org / tutorial / creating -
a - bootable - micro - sd - card - using -
windows - from - image /
http: // www.udoo.org / docs -
neo / etting _ Started / Use _ as _ a _ headl
ess _ IoT _ Device.html
http: // www.udoo.org / docs -
neo / etting _ Started / Use _ as _ a _ Light
weight _ Desktop _ PC.html
step 1.
step 2.
step 3.
http: // www.udoo.org / docs -
neo / Introduction / Introduction.html
Y O U R
EXPERIENCE
!
E N
JOY
