Uface 5 Lite User manual
PRODUCT
BOOKLET
Uface 5 Lite
( OS-A6CC1 )
Parts list
No. Quantity
Name
Unit: mm
䎂〵/鲱⟝乼⡲霹僈 1 / 2
Instruction
11Host
71Warranty card
81Hexagon screw-driver
Power adapter 12
31Wall-mounting bracket
41Wall-mounting installation sticker
15 User manual
61&HUWLƪFDWH
92Expansion pipes
10 2Cross self-tapping screws
Dear customer,
Thank you for using our product. For better use, please carefully read this instruction. If you have any
issues not mentioned here, please contact the provider. All parts of this booklet are reserved by our
company, including words, pictures and graphics. Without written permission, no unit or individual
shall extract, copy, translate or edit the content in this instruction.
Device introduction
Parts list
Dimensional drawing
Platform/Software
Operating Instruction
Appearance description
Illumination intensity
Position
Height
Steps
Wiring connection
Features
FAQ
Installation
Product description
Warranty description
Product warranty
Dimensional Drawing
Platform/Software Operating Instruction
The software carried by the product divides into 2 versions: GS (WO platform, provides the secondary
development) and LAN (LAN Client System, provides the secondary development). Please mark the need
for software version when place the order. Please contact the customer service for another version if
UHTXLUHG)RUPRUHGHWDLOHGSODWIRUPVRIWZDUHLQVWUXFWLRQPDQXDOSOHDVHORJLQLQWRWKHRƬFLDOZHEVLWHWR
download or contact the customer services.
Appearance description
RGB camera
,QIUDUHGƪOOLQJOLJKW
Infrared camera
:KLWHƪOOLQJOLJKW
RJ45-3 (black)
RJ45-6 (yellow)
RJ45-1 (blue)
RJ45-2 (orange)
H1: Net mouth H2: Alarm input
GND (black)
ALARM_KEY (yellow)
ALARM_DOOR (blue)
H3: Wiegand output
WG-OUT_D1 (black)
WG-OUT_D0 (white)
GND (grey)
DOOR_NC (red)
DOOR_COM (orange)
DOOR_NO (white)
H4: Relay output H5: Power input
Outside_GND (black)
Inside_12V+ (red)
11 2Cross machine screws
12 1Hexagon machine screw
H5
H1
H2
H3
H4
±
±±
±
3 / 4
When the sunlight shines indoor through the window, the face
recognition terminal device shall not be installed in shown black
shadow area, instead, shall be installed in place with little
sunlight impact, no side-light and no backlight. (Glass window
can be deemed as no walls)
Sunlight shines indoor
If the room has glass wall, there is no shield for sunlight, then it
is suggested to hang curtains over the window, and install the
GHYLFHLQSODFHZLWKVKLHOGWRDYRLGGLUHFWVXQOLJKWLQƫXHQFLQJ
the recognition. (Glass window can be deemed as no walls)
Glass window
Illumination intensity
Test object
Light source
Device
/LJKWLVVXHVPD\OHDGWRELJGLƩHUHQFHVEHWZHHQVLWH
image and registered image; backlight, side-light and
VWURQJOLJKWZLOOLQƫXHQFHWKHUHFRJQLWLRQH[SHULHQFH
(Analysis: from the view of human eyes, the color
changes on face skin may result in wrong recognition
of identity; unclear exposure area, no matter large or
small, may result the identity judgement.)
The test standard is as shown on the picture:
the angle between dotted line A and dotted line
B is 90 ° , the test adopts the common light
meter with full spectrum, and applies U30 stan-
dard light source, adjust the distance between
source light and test object, subject to the
illumination intensity of the object face at this
time.
Illumination intensity in actual scenarios
Reference to intensity
Intensity test
The recognized face, of which, the illumination
intensity（“intensity” in short) shall not be lower
than 30 Lux7KHGHYLFHKDVƪOOLQJOLJKWLWVHOIVR
when the device put in a totally dark environ-
ment, the face illumination intensity, 0.5m
distance to the device, is about 100 Lux. The
nearer to the device, the higher the intensity is.
If there is overexposure on the face, the face
characteristics will be unable to be extracted
and may lead to hard recognition.
500Lux,
overexposure
30 Lux, dim
100 Lux, bright
50 Lux, normal
300 Lux,
slight exposure
Back light
Side light
Light source is near to the object
Device stands between the light
source and object
Object stands between the
device and light source
Side-light may lead to uneven
light on the face
Backlight may make the
face too dark
Direct strong light may
cause overexposure
Strong light
1. Install the device in a place with little impact
from light source.
2. Add a registered image according to the site
condition, and it is suggested to use this product
to enroll images.
3. Properly lower the threshold value according to
usage.
Improvements
Device shall be installed in places avoiding backlight, side-light and strong light.
Position
This place, 3m away from the window, or does not
LQƫXHQFHGE\VXQOLJKWFDQEHFRQVLGHUHGIRULQVWDOODWLRQ
Backlight, side-light or direct strong light,
not suitable for installation.
Other areas, install in suitable places according
to actual light impact. Glass window (same as the semi-outdoor scene
with no walls)
Device Light
DoorWall
Person
Curtain
Indoor
Door
Light
Wall/Shields
Indoor
Door
Light
Wall/Shields
Indoor
Door
Door
Wall/Shields
Indoor
Door
Wall/Shields
Light
Light
Glass wall
Sunlight shines through the door, the device shall be installed at
the place with shields and little light impact. Glass window can
be deemed as no shields, the device shall be installed at the side
without glass window or with curtain hung.
Sunlight shines through the door, with glass window
at one side
Sunlight shines through the door, the device shall be installed at
the place with shields and little light impact.
Sunlight shines through the door
FOV(V)
Height
Camera vertical wide-angle Camera horizontal wide-angle
Wall
1.4m
Device
Gate
User
2m
Recognition area
FOV(H)
Suggested installation height
(distance between the screen
and the ground) is 1.4m, as the
recognizable body height
range, 0.5m distance away
from the device, is 1.3m-1.7m;
the recognizable body height
range, 1m distance away from
the device, is 1m-2m. (There
are some deviations)
5 / 6
Steps
Wall-mounting sticker
Outlet hole
1.4M
2Move the bracket, align holes on the bracket and on the wall. Thread tail lines out of the
KROHDQGXVHVHOIWDSSLQJVFUHZƪ[WKHEUDFNHWRQWKHZDOO
1Paste the installation sticker horizontally on the wall. According to the on-site position,
choose suitable place for drilling. For narrow edge, choose upper and lower installation. 3
Wall-mounting sticker
Connect the tail lines with the host, move the device to up-down align the bracket slot. Use
VFUHZVWRƪ[WKHGHYLFHDQGEUDFNHW
Wiring for magnetic door Wiring for automatic door Installation notes
7 / 8
1. When arrange the wires, if the 12V power supply cable of the host does not adopt the “Special power
strip” and is in long distance, resulting in large resistance, then abnormal phenomena may occur easily such
DVLQVXƬFLHQWYROWDJHƦ9UHSHDWUHVWDUWV\VWHPFUDVKDQGVRRQ:LULQJFRQQHFWLRQRIYROWDJH
metering is shown as follow.
2. The power adapter is put together with the device which is optional, such as EU standard, American
standard, UK standard, and so on.
System installation schematic
drawing for magnetic door
Wiring schematic drawing for touching
switch of magnetic door
System installation schematic
drawing for automatic door
Wiring schematic drawing for mechanical
switch of magnetic door
Wiring schematic drawing for sensor
switch of automatic door
Access control
relay interface
~220V
DC12V Ethernet
Host
Power (access control)
Door exit
(inside)
Magnetic lock
Host
Access control
relay interface
~220V
Ethernet
PUSH
GND
12V
COM
NC
NO
12V
GND
NO
NC
COM
12V
12V
Power (access control)
Door exit
Magnetic lock
Ethernet
NO
COM
Host
12V
GND
Power Relay
Opening signal PUSH
Public end GND
12V
Controller of auto-door (only used terminals will be listed)
Ethernet
DC+
DC-
NO
COM Sensor
DC+
DC-
NO
COM
NO
COM
Host
12V
GND
Power Relay
NO
NC
COM
Door exit
PUSH
GND
12V
COM
NC
NO
NO
COM
12V
12V
Host
Power (access control)
Magnetic lock
12V
GND
Ethernet
Power Relay
Power
GND
12V
Cable equivalent
resistance1
Cable equivalent
resistance 2
Voltage meter
V
Host
Wiring connection
Auto-door controller
+ assembly units Sensor (inside)
•
•
•
•
([WHQVLRQRISRZHUFDEOHZHDNFXUUHQWFDQQRWH[FHHGPRWKHUZLVHLWPD\FDXVHLQVXƬFLHQW
power supply for the host end, and abnormal phenomena like repeat restart, system crash may
occur. If the power is far away from the device, the power cable can be extended (strong current).
,IXVHRWKHUSRZHUDGDSWHU9$DVDQH[DPSOHWKHQLQVXƬFLHQWYROWDJHDQGWRRZHDNFXUUHQW
may cause repeat restart.
7KH FDEOH FDQQRW EH WRR ƪQH VXFK DV QHWZRUN FDEOH DQG ƪQH OLQH LW LV VXJJHVWHG WR FRQQHFW
multi-strand cable in parallel or use copper core bold cable, to ensure voltage >11V.
Attention: If use network cable, the extension cable use 4-strand cable as positive pole and 4-strand cable as negative pole.
If not clear with how to extend, please contact the provider to change “Special power strip”.
9 /10
•Secondary development (integrated)
Supports interface in HTTP method;
supports 232 serial-port output, as well as
Wiegand 26 and 34 output, custom the
FRQƪJXUDWLRQRIRXWSXWFRQWHQW
•Complete functions
6XSSRUWVUHFRJQLWLRQGLVWDQFHFRQƪJXUD-
tion; supports stranger detection; supports
saving the site images of face recognition
and stranger detection.
•High extensibility
Supports deployment methods like public
network and LAN; supports screen display
FRQWHQWFRQƪJXUDWLRQEXLOWLQFDUGUHDGHU
access.
• Try to restart and reset
When the device stops in some interface for a
long time, users can plug out the power
switch, power-on reset and then restart. If it
GRHVQRWWDNHHƩHFWWKHQFDQORQJSUHVV
RESET button for 8-12s to restart the device.
%HVLGHVXVHUVFDQFRQWDFWRXUVWDƩDQG
make some feedback.
• Dustproof & Waterproof
IP54, can prevent dust from invading the
device and water from all directions.
• Drop resistance
Please avoid operations such as falling,
breaking, bending, heavily pressing and so on.
• Cleaning
Please use soft cloth or such materials, lightly
wipe the display screen or panel, and to avoid
scrubbing with water and cleaner.
• Low-temperature environment
The normal working temperature for this
device is -10˫~60˫, if the actual tempera-
WXUHH[FHHGVWKLVUDQJHWKDWPD\LQƫXHQFH
the normal use of the device.
油Do not dirty or damage the display
screen with oil-water or sharp objects
Do not use unknown power adapter to
avoid burning out the device
(a) Face detection takes around 120ms, (b)
Face feature extraction takes around
150ms, (c) Face comparison takes 10ms
(with 100,000 face database, take the
average value after multiple comparison).
• Quick recognition speed
Features FAQ
• Characteristics
1LJKWLQIUDUHGDQG5*%GXDOƪOOLQJOLJKW
completely resolve image frauds in all kinds of
carriers with dynamic dual-camera anti-forg-
ery; face database is 10000, the 1:N
recognition accuracy is 99.99% under 0.1%
false accept rate.
• Store records in local
(a) Device using cloud platform supports
storing 3 thousand pieces of face images
(smaller than 400KB), 50-thousand pieces of
recognition records (0.45KB) and about
15-thousand pieces of site capture images;
(b) Device using LAN support storing
3-thousand pieces of face images (each
image by 100KB) and 50-thousand pieces of
recognition records (including the latest
15-thousand pieces of site capture images)
Dear customer,
Thank you for purchasing and using this product. To better guarantee your satisfaction, please carefully
read this warranty clauses after purchase.
1. Warranty service
,IWKHGHYLFHIROORZLQJWKHXVHUPDQXDODQGRSHUDWLQJLQVWUXFWLRQVWLOOEUHDNVGRZQFRQWDFWDIWHUVDOHVVWDƩ
at once, as they will judge the causes on basis of customer description and give remote
guidance; if the guidance does not work, then the customer can send back the device for maintenance and
WHVWLIWKHGHYLFHLVXQDEOHWREHVHQWEDFNFRQWDFWDIWHUVDOHVVWDƩLQDGYDQFHDQGDVNWKHPWRKHDGIRU
WKHVLWHWRGRWKHƪHOGPDLQWHQDQFH+RZHYHULIWKHGHYLFHSUREOHPVIRXQGDUHQRWUHVXOWHGE\KDUGZDUHRU
VRIWZDUHV\VWHPRIRXUFRPSDQ\DIWHUWKHƪHOGPDLQWHQDQFHWKHQFXVWRPHUVKDOOSD\WKHH[WUDIHH
incurred by the onsite service.
2. Instruction
7KHUHLVDSLHFHRISURGXFWERRNOHWLQVLGHWKHGHYLFHSDFNDJHDQGFXVWRPHUFDQFRQWDFWDIWHUVDOHVVWDƩ
and ask for installation guidance.
3. Warranty period
All products carry a 1-year guarantee period since the delivery date.
4. Warranty scope
Device breakdown caused by following conditions is not included within the warranty scope:
• Any damages caused by incorrect use, maintenance or storage, as not follow the user manual;
• Damages caused by falling, water intaking, improper storage or any other man-mad malicious damages;
• Malfunction caused by force majeure such as natural disasters and external causes such as abnormal
voltage;
• Damages caused by shipment, please contact the department of transportation;
• Malfunction or damages caused by unfavorable operating environment, such as too high or too low tempera-
ture, poor condition, abnormal power system and so on;
• Parts (power adapter, cables, screws) are not within the warranty scope. If parts are lost or damaged,
SOHDVHFRQWDFWRXUVWDƩWRSXUFKDVH
5. Maintenance period
:KHQUHFHLYHWKHSURGXFWWREHUHSDLUHGDIWHUVDOHVVWDƩVKDOOFRPSOHWHWKHPDLQWHQDQFHDQGVHQGLWEDFN
within 5 working days. Further communication can be carried out if there are special circumstances.
6. Supplemental instruction
• Product damages, caused by natural disasters, external factors or improper operations, are not included
ZLWKLQZDUUDQW\VFRSH2XUFRPSDQ\ZLOOPDNHWKHƪQDOMXGJHPHQWRIZKHWKHUWKHGDPDJHLVFDXVHGE\
above mentioned terms. Users open the product secretly without permission, and cause certain damage,
which is also not included within replacement or warranty scope.
• If the device expires the warranty period or not meets the warranty conditions, users may pay for the
maintenance cost and shipping cost.
• If the device is sent back without communication, it will not be maintained or repaired normally or will not
be refunded, damages caused by this issue will not be compensated.
Warranty description
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
NOTE 1: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates uses
and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
NOTE 2: Any changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
This manual suits for next models
1
Table of contents
