UK 4AA-AN2 Operating manual

CLASS I
|
DIV 2
HAZARDOUS LOCATIONS
•Incredibly Bright
and Compact
•Watertight and Dustproof
•Bezel Rotation Switch
THE WORLD’SBEST SELLING HELMET LIGHT
High-Intensity
Work Light
FEATURES
Big reflector Brightness
with a Compact Design
Corrosion Proof
Non-Conductive
•Twist ON/OFF Bezel
Switch
Ultra-High Impact
ABS Construction
•Quick Load
Battery System
Passes FM 6 Foot
Drop Test
•Mounts to All
Work Helmets
SPECIFICATIONS
POWER 2.1 Watts
BURN TIME 4-5 Hours
BATTERY 4 Alkaline AA/LR6
PEAK LUMENS 38 Lm
LAMP High-Intensity Xenon
CASE ABS / Polycarbonate
SIZE 6.1” x 1.6” x 1.4”
14819
Universal
Helmet Clip
14818
Stainless
Adjustable
Helmet Clip
14816
Nylon Belt Pouch
14808
Safety
Wand
14802
Stainless Fixed
Helmet Clip
UNDERWATER KINETICS
13400 Danielson Street
Poway, CA 92064 USA
1-800-327-7388
www.uwkinetics.com
CHECK OUT THESE ACCESSORIES
CERTIFICATIONS
CL I, DIV 2, GP A,
B, C, D, CL II,
DIV 2 GP G, CL III,
DIV 2 T2A
CL I, DIV 2, GP A,
B, C, D, T2, CL II,
DIV 2, GP F, G,
CL III, DIV 2, T3C
IMPORTANT: READ ENCLOSED INSTRUCTIONS
OTHER LIGHT MODELS AND COLORS
WITH XENON LAMPS
14101 UK 4AA W/ SWITCH CI, D1
14102 UK 4AA W/ SWITCH CI, D1
14103 UK 4AA W/ SWITCH CI, D1
14107 UK 4AA W/ SWITCH CI, D2
14108 UK 4AA W/ SWITCH CI, D2
14109 UK 4AA W/ SWITCH CI, D2
14110 UK 4AA W/O SWITCH CI, D2
THE WORLD’SBEST SELLING HELMET LIGHT
INDUSTRIAL
IMPORTANT: READ ENCLOSED INSTRUCTIONS

Limited Lifetime
Warranty
Underwater Kinetics prod-
ucts are engineered for maxi-
mum performance and dura-
bility. All products carry a
Limited Lifetime Warranty to
the original retail purchaser
to be free from defective
material and workmanship
under normal and intended
use. In addition, the
Underwater Kinetics Limited
Warranty covers materials
used in its products to the
original purchaser, from the
date of purchase, as follows:
plastics for 10 years; fabrics
and rubber for 3 years and
lamps for 30 days (batteries
and lamps are not manufac-
tured by Underwater
Kinetics).
In the event the original
retail purchaser detects a
defect in the material or work-
manship, the product along
with proof of purchase date
should be returned to an
authorized Underwater
Kinetics dealer or directly to
Underwater Kinetics with the
postage prepaid. Underwater
Kinetics agrees to repair or
replace at Underwater
Kinetics' sole discretion any
product found to be defective
in material or workmanship
within the time period speci-
fied above. For the complete
Limited Lifetime Warranty
write to Underwater Kinetics.
Address all correspondence
and returns to:
Underwater Kinetics
13400 Danielson Street
Poway, CA 92064
Battery Installation
To install batteries, hold the
case in the position shown.
Drop the batteries one by one
into the case in the order
shown. Make sure that the
(+) end of the battery is down
for 1 and 2 and up for batter-
ies 3 and 4. Next insert the
lamp module into the case.
Place the bezel over the lamp
module and screw it onto the
case.
ON/OFF
To operate the UK4AA, turn
the bezel clockwise until the
lamp comes ON. Turn the
light OFF with at least 1 1/2
counterclockwise turns of the
bezel.
O-Ring Seal
Lightly lubricate the O-ring
with silicone grease. Do not
use tools to remove the O-
ring.
Pressure Equalizing Vent
Air and gas from battery
leakage can pass freely in and
out of the UK4AA through a
vent in the rear of the light.
Do not allow dirt or grease to
accumulate on the vent or it
will not operate properly.
UK4AA-AN2 HIGH INTENSITY WORK LIGHT
Instructions & Important Information
Congratulations on
the purchase of your
Underwater Kinetics
all environment work
light! It is tough
enough for use in rain,
snow, smoke, dust or
hazardous locations
(see listing). The high
intensity xenon lamp
outperforms lights
many times its size.
Batteries can vent hydrogen gas and
possibly cause an explosion if they
are (1) installed without the proper
polarity, (2) not the same type, brand
name and age or (3) completely
discharged.
> Load batteries according to the
diagram.
> Discard all batteries as soon as
they are drained or no longer
produce light.
> Do not mix batteries of different
type, brand or age.
To maintain certification use only
lamp modules marked 14801 and
have a black contact insulator.
Care and Maintenance
■Keep area around the O-
ring clean.
■For longer lamp life, turn
the light on for several min-
utes after loading fresh batter-
ies to “age” the batteries.
■If the light floods, empty it
immediately, rinse with fresh
water and dry completely
before reassembly.
■Replace the reflector/lamp,
which contains a hydrogen
absorbing catalyst, if it gets
wet.
■Do not store batteries in
the light for long periods of
time; they may leak and dam-
age the light.
Bezel
14801
Xenon Lamp Module
4 Alkaline AA-cell batteries
O-Ring
UK4AA-AN2 Case
Vent
2
1
3
4
Z171294 rev 12/31/03
Certification
FLASHLIGHT FOR USE IN
HAZARDOUS LOCATIONS. USE ONLY
WITH 14801 LAMP AND FOUR
DURACELL MN1500/PC1500,
ENERGIZER E91/EN91 OR RAYOVAC
AL-AA/815 1.5 V SIZE AA ALKALINE
BATTERIES.
CL I, DIV 2, GP A, B, C, D,
CL II, DIV 2 GP G,
CL III, DIV 2 T2A
CL I, DIV 2 GP A, B, C, D, T2
CLII, DIV 2, GP F, G,
CLIII, DIV 2, T3C
Note: The UK4AA
will not light if the
batteries are not
inserted with the
polarity as shown.
