Ultra-Aire SD12 User manual

Dehumidifier
Part Number: 4033175
Blower: 406 CFM @ 0.0" WG
374 CFM @ 0.2" WG
348 CFM @ 0.4" WG
Power: 160 Watts @ 80°F and 60% RH
Supply Voltage: 115 VAC – 1phase – 60 Hz
Current Draw: 1.4 Amps
Transformer Protection: Push Button Reset (located near power cord)
Circuit Requirement: 15 Amps
Energy Factor: 3.1 L/kWh
Operating Range: 49°F Min, 95°F Max (Inlet Air Temperature)
Sized For: Up to 4,000 Square Feet
Minimum Performance: 80°F and 60% RH 70°F and 60% RH
Water Removal: 184 Pints/Day 150 Pints/Day
Sensible Cooling: 4,300 BTUs/Hour 5,100 BTUs/Hour
Eciency: 6.6Pints/kWh 6.0Pints/kWh
Duct Connections: 6" Round Inlet; 10" Round Inlet; 10" Oval Outlet
Air Filter: MERV-13, Standard Pleat
Eciency: 90%ASHRAEDustSpot
Size: 16" x 20" x 2"
Optional Air Filters:
MERV-11, Standard Pleat
Eciency: 65%ASHRAEDustSpot
Size: 16" x 20" x 2"
 MERV-14,EmbossedPleat(willneedlterhousing)
Eciency: 95%ASHRAEDustSpot
Size: 20" x 24" x 4"
Power Cord: 9', 115 VAC, Ground
Internal Insulated Cabinet: Yes
Drain Connection: 3/4" Threaded Female NPT
Line Set Requirements: 50 Feet (maximum)
Liquid Line: 1/4"
Gas Line: 3/8"
Dimensions: Unit With Collars Unit Without Collars Shipping
Width: 20 1/4" 20 1/4" 35"
Height: 21 3/4" 21 3/4" 44"
Length: 41 1/2" 37 3/4" 44"
Weight: 110 lbs. 109 lbs. 225 lbs.
Optional Accessories
4028539 DEH 3000 Control
4028407 DEH 3000R Control (with remote)
4039391 MERV-13 Filter (16" x 20" x 2")
4037733 MERV-13 Filters 4-Pack
4037734 MERV-13 Filters 12-Pack
4021475 MERV-11 Filter (16" x 20" x 2")
4027420 MERV-11 Filters 4-Pack
4027424 MERV-11 Filters 12-Pack
4025287 MERV-14 Filter Housing
4024370 MERV-14 Filter (20" x 24" x 4")
4029087 MERV-14 Filters 3-Pack
4028614 Pump Kit
4036685 Hang Kit
4023672 6" Motorized Damper
4026859 6" Flex Duct 25'
4020128 6" Flex Insulated Duct 25'
4020656 6" Inlet Hood
4024375 10" Gravity Damper
4026969 10" Flex Duct 25'
4022126 10" Flex Insulated Duct 25'
4028399 10" Oval to Round Adapter
SpecicationData
[phone] | www.Ultra-Aire.com
Condenser
Part Number: 4033192
Power: 1080 Watts @ 80°F and 60% RH
Supply Voltage: 115 VAC – 1phase – 60 Hz
Current Draw: 9.7 Amps
Minimum Circuit Ampacity: 20 Amps
Maximum Fuse / Breaker: 20 Amps
Refrigerant Type: R410A
Refrigerant Amount: 36 oz.
Operating Range: 40°F Min, 115°F Max
Dimensions: 10"W x 25.5"H x 33"L - 75 lbs.
Power Cord: Hard-Wired
FRONT VIEW
20 1/4”
21 3/4”
21 3/4”
41 1/2”
37 3/4”
21 3/4”
21 3/4”
BACK VIEW
20 1/4”
6” Diameter
10” Diameter
10” Diameter
FRONT VIEW
20 1/4”
21 3/4”
21 3/4”
41 1/2”
37 3/4”
21 3/4”
21 3/4”
BACK VIEW
20 1/4”
6” Diameter
10” Diameter
10” Diameter
Ultra-Aire™SD12 Split Dehumidifier
SIDE VIEW FRONT VIEW
33”
25 1/2”
25 1/2”
10”
Condenser
4033170
Dehumidifier
FRONT VIEW
20 1/4”
21 3/4”
21 3/4”
41 1/2”
37 3/4”
21 3/4”
21 3/4”
BACK VIEW
20 1/4”
6” Diameter
10” Diameter
10” Diameter
ID #510XXX
ID #51102120
YEAR
FULL WARRANTY
YEAR
FULL WARRANTY
PATENTS:
D570,988
8,069,681
9,052,132

Outdoor
Condensing Unit
Air Handler
HVAC Supply
Dedicated Ultra-Aire 90 Return to A/C Supply
HVAC Return
Fresh Air Intake
(Optional)
Motorized
Damper
Indoor
Air Return Ultra-Aire
Supply
Backdraft
Damper
Recommended Installation
Dedicated Return to HVAC Supply
•CreateaseparatereturnfortheUltra-AireSD12
in a central area of the building.
•DuctthesupplyoftheUltra-AireSD12totheair
supply of the HVAC system with a backdraft damper.
•SupplyalinesetsuitableforusewithR410Arefrigerantto
connect the indoor unit to the outdoor unit. The maximum
allowable length of the line set is 50 feet. Braze the lines
tothedehumidierandthecondensingunit.
Outdoor
Condensing
Unit
A/C Return to A/C Supply
Air Handler
HVAC Supply
HVAC Return
Backdraft
Damper
Optional Check Damper
(no HVAC fan needed)
Fresh Air Intake
(Optional)
Motorized
Damper
Ultra-Aire
Supply
HVAC Return to HVAC Supply
•CheckDampershouldbeinplacebetweentheReturnand
Supplyconnectionsofthedehumidier.
•IfCheckDamperisnotinplace,theHVACfanmustturnon
whenthedehumidierisinoperation.
•SupplyalinesetsuitableforusewithR410Arefrigerantto
connect the indoor unit to the outdoor unit. The maximum
allowable length of the line set is 50 feet. Braze the lines
tothedehumidierandthecondensingunit.
Outdoor
Condensing
Unit
Air Handler
HVAC Supply
Dedicated Ultra-Aire 90 Return to A/C Return
HVAC Return
Fresh Air Intake
(Optional)
Motorized
Damper
Indoor
Air Return
Ultra-Aire
Supply
Dedicated Return to HVAC Return
•CreateaseparatereturnfortheUltra-AireSD12inacentral
area of the building.
•InstallingthesupplyairfromtheUltra-AireSD12inthe
return of the HVAC system requires the HVAC fan to run
when the Ultra-Aire SD12 is operating.
•SupplyalinesetsuitableforusewithR410Arefrigerantto
connect the indoor unit to the outdoor unit. The maximum
allowable length of the line set is 50 feet. Braze the lines
tothedehumidierandthecondensingunit.
Air Handler HVAC
Supply
A/C Return to A/C Return
HVAC Return
Fresh Air
Intake
(Optional) Motorized
Damper
Optional Check Damper
(no HVAC fan needed)
Ultra-Aire
Supply
Outdoor
Condensing
Unit
HVAC Return to HVAC Return
•CheckDampershouldbeinplacebetweentheReturnand
Supplyconnectionsofthedehumidier.
•IfCheckDamperisnotinplace,theHVACfanmustturnon
whenthedehumidierisinoperation.
•SupplyalinesetsuitableforusewithR410Arefrigerantto
connect the indoor unit to the outdoor unit. The maximum
allowable length of the line set is 50 feet. Braze the lines
tothedehumidierandthecondensingunit.
[phone] | www.Ultra-Aire.com Rev 6/1/18
Alternative Installations
Ultra-Aire™SD12 Split Dehumidifier
