ULTRA BRIGHT UB-425TT Series User manual

LIGHT CHARACTERISTICS
Light Source 12-Ultra High Intensity White LEDs
Lumens output 5/10/15/20/25/30/35 *Varies with
Brightness Levels
Available LED Colors White
Light Mode Constant *7-Brightness levels
Visible Range 100m-200m+ (Depending on Settings)
Horizontal Output (degrees) 360°
Vertical Divergence (degrees) 180°
LED Life Expectancy (hours) > 100,000 hrs
ELECTRICAL CHARACTERISTICS
Circuit Protection Integrated / Overcharge / Over
Discharge / Constant Current
Nominal Voltage (v) 2.4v Battery, 4v Solar
Power / Brightness Levels 7Levels, User Adjustable with Magnet
Autonomy (hours) 10-140hrs *On full Charge
* Varies with brightness
Temperature Range 14-158°Fahrenheit
SOLAR CHARACTERISTICS
Solar Module Type Tempered Glass + Monocrystalline Cell
Power (watts) 0.80 Watts
Solar Module Efficiency (%) 18 % Super High Efficiency Cells
POWER SUPPLY
Battery Type NiMh
Battery Size 2pcs AA 1.2v
Battery Capacity (mAh) 1,200 mA
Nominal Voltage (v) 2.4v
Battery Service Life 1-3 years *(Varies with local
Environment)
Battery Service Access Yes: User Changeable / Replaceable
PHYSICAL CHARACTERISTICS
Body Material High Performance ASA
Lens Material Bayer UV Stabilized Poly Carbonate
External Lens Design Smooth / Clear
Internal Lens design NA
WaterProof Rating IP 68
Base Options: (Post Sizes) 4.25”x4.25” for TimberTech Brand
Radiance Rail Express Deck Posts
Height 2.55” (65mm)
Width / Width 5.5” x 5.5” (140 mm)
Weight 1.1 lbs.
OTHER
Other Options & Sizes Please Contact
1yr Limited Warranty * Information subject to change without notice
Solar Post Cap:
Ultra Bright's Solar Post Cap Light is the most
advanced, powerful, robust, solar fence post light
available. Add safety, elegance and ambience to your
deck without the hassle of electrical wiring! Patented
magnet technology allows users to easily adjust
between 7-brightness levels to meet seasonal
performance, brightness, & run preference.
Each side of the light has ultra-high intensity
downward shining White LEDs that automatically turn
on at dusk and turn off at dawn. Swipe the magnet
quickly over the solar panel to adjust between 7
brightness levels or "OFF”.
Copyright Protected Design
PATENTS PENDING
Ultra Bright Tech
P.O. Box 414
105 W. Simon St.
Laotto, IN 46763
Phone: [phone]
Fax: [phone]
E-mail [e-mail]
www.ultrabrighttech.com
SOLAR POST CAP
See www.ultrabrighttech.com for other color & size options
4-Season Rated
UB-425TT-X
Pictured in white

1.0-Watt Tempered Glass
Solar Panel: Rated at 15+yrs
Automatic night
activation
Set Screw
36 Super High
Intensity LEDs
36-White LEDs
IP 68 Fully Sealed &
WaterProof Electronics
*Various size base
post adaptors
4-10X More Powerful Solar Panel
5-20X Brighter Light
10x Longer Service Life
Changeable LED Colors
Lithium Phosphate Battery
7 Adjustable Brightness Levels
IP 68 Waterproof Electronics
Ultra-Bright White LEDs
UV Stabilized ASA Plastic
* NOTE: Information is a general reference in comparison to the best solar fence post lights we were able to find on the market.
Copyright Protected Design
PATENTS PENDING 4-Season Rated
Vapor Vent
Magnet Switch
Adjustable Brightness Levels
Ultra Bright Tech
P.O. Box 414
105 W. Simon St.
Laotto, IN 46763
Phone: [phone]
Fax: [phone]
E-mail [e-mail]
www.ultrabrighttech.com
SOLAR POST CAP

4-1/4”
Ultra Bright Tech
P.O. Box 414
105 W. Simon St.
Laotto, IN 46763
Phone: [phone]
Fax: [phone]
E-mail [e-mail]
www.ultrabrighttech.com
4-1/4”
Dimensions: (In.)
BASE OPTIONS AVAILABLE FOR THIS MODEL
Ultra Bright Base Option Fits General Post Size *Various Popular Brands / Series
UBT-500 5.00” x 5.00” Inch General 5x5 Post Covers
UBT 500-TT 5-1/16 x 5-16 Timber Tech ONLY Timber Tech Post Covers ONLY
NOTE: These Solar Post Caps are for TimberTech
Radiance Rail Express Posts ONLY. The flat sides will
measure approximately 4.25x4.25”. If you have
TimberTech Radiance Rail Post covers, please make sure
to order the correct base size.
4-1/4”
4-1/4”
Fits TimberTech Radiance Rail Express
Post Covers ONLY
UBT-425-TT

Use a screwdriver to remove the battery
cover & connect the battery: NOTE: Align
the connectors before joining.
Tighten all screws to ensure a waterproof seal.
SOLAR POST CAP
4
Ultra Bright Tech
P.O. Box 414
105 W. Simon St.
Laotto, IN 46763
Phone: [phone]
Fax: [phone]
E-mail [e-mail]
www.ultrabrighttech.com
3
Phillips Screwdriver
12
Phillips Screwdriver
Place the solar Post Cap on the post. Mark both
holes on the post. Use an appropriate drill bit to
make a small pilot hole for the provided screws.
Use the provided screws to secure your solar
post light to the post.

•TESTING: Place entire light in a dark room. Light should turn on, if not,
swipe the magnet over the solar panel until light turns on.
•Run times will vary significantly based on factors such as; Sun Exposure,
Season, Angle of Sunlight, Geographic Location, Shading, Installed
Location/Position, Battery Condition, and most importantly, the Brightness
Setting in comparison to the yearly season.
•The following run times should only be used as a general reference and are
not guaranteed. Consider your local environment
•Lower brightness settings use less power and leave more reserve power for
cloudy days where less recharging takes place.
NOTE: RUN TIMES ARE BASED ON A FULL CHARGE: MANY FACTORS MAY PREVENT A FULL
CHARGE SEE BELOW
Wave the magnet over the solar panel at NIGHT until you
find the activation area which changes the brightness level.
This operation only works at NIGHT or in absence of light.
Make a quick up & down motion over this area to change
between brightness levels & OFF.
NOTE: moving too
slowly may activate
the magnet switch
multiple times going
through multiple
levels at once. A quick
motion will help.
BRIGHTNESS SWITCH 4-Season Rated ! Adjustable Power & Run Times.
SOLAR POST CAP
5
Ultra Bright Technologies 1-Year Limited Warranty
The retailer warrants the Solar Lights to be free from defects in workmanship and material present at time of shipment from the factory for a period of one year after the date of purchase by the original
purchaser. We agree to correct such defects without charge or at our option replace with a comparable or superior model if the product is returned to the retailer. To obtain warranty service, you must
present a copy of the receipt as proof of purchase. All costs of removing and reinstalling the product are your responsibility. Damage to any part such as by accident or misuse or improper installation or
by affixing any accessories, is not covered by this warranty. There is no other express warranty. The retailer hereby disclaims all warranties, including but not limited to, those of merchantability and
fitness for a particular purpose to the extent permitted by law. The duration of any implied warranty, which cannot be disclaimed, is limited to the time period as specified in the express warranty. Some
states do no allow limitation on how long an implied warranty lasts, so the above limitation may not apply to you. The retailer shall not be liable for incidental, consequential, or special damages arising
out of or in connection with product use or performance except as may otherwise be accorded by law. Some states do not allow the exclusion of incidental or consequential damage, so the above
exclusion or limitation may apply to you. This warranty gives specific legal rights, and you may also have other rights, which vary from state to state. This warranty supersedes all prior warranties.
PRODUCT & WARRANTY REGISTRATION: Visit www.ultrabrighttech.com/registration
