Ultra Plus X-9200HD PVR User manual

Full HD DigitalTwinTuner PVR
User's Manual
X-9200HD PVR

3
INDEX
INDEX...................................................................................................................................3
Precautions.........................................................................................................................5
1. Important Safety Instructions......................................................................................................5
2. Notice .........................................................................................................................................5
3. Copyright....................................................................................................................................6
4. Disclaimer...................................................................................................................................6
5. Trademarks ................................................................................................................................6
Before You Begin................................................................................................................7
1. Main Features ............................................................................................................................7
2. Accessories................................................................................................................................8
Hardware Description.........................................................................................................9
1. Front Panel Configuration ..........................................................................................................9
2. VFD(Vacuum Fluorescent Display)............................................................................................9
3. Rear Panel Configuration.........................................................................................................10
4. Remote Control Unit.................................................................................................................13
5. Multi-Brand IR Remote Controller Setting................................................................................16
Connecting diagram .........................................................................................................17
1. Receiver to A/C power..............................................................................................................17
2. Receiver to TV with Digital A/V Output.....................................................................................17
3. Receiver to TV with Analog A/V Output....................................................................................18
4. Receiver to TV and VCR..........................................................................................................19
5. Connecting to Antenna Cable ..................................................................................................20
5.1 In case of S2 + S2 (Satellite + Satellite) tuners................................................................20
5.2 In case of T(T2) + T(T2) (Terrestrial + Terrestrial) tuners.................................................21
5.3 In case of C + C (Cable + Cable) tuners..........................................................................21
5.4 In case of S2 + T(T2) (Satellite + Terrestrial) tuners ........................................................22
5.5 In case of S2 + C (Satellite + Cable) tuners.....................................................................22
5.6 In case of T(T2) + C (Terrestrial + Cable) tuners .............................................................22
Guide of Functions ...........................................................................................................23
1. Selecting a Service...................................................................................................................23
1.1 Using CH UP/DOWN buttons..............................................................................................23
1.2 Using Service List ...............................................................................................................23
1.3 Using Simple Service List ...................................................................................................23
1.4 Using Recent Service List...................................................................................................24
2. Information Window..................................................................................................................24
3. Multi-Picture Display.................................................................................................................24
4. Electronic Program Guide (EPG).............................................................................................24
5. Favorite Group .........................................................................................................................25
6. Volume Control.........................................................................................................................25
7. Pause .......................................................................................................................................25
8. Subtitle......................................................................................................................................26
9. Audio Control............................................................................................................................26
10.Teletext.....................................................................................................................................27
11. PIP (Picture in Picture).............................................................................................................27

4
PVR (Personal Video Recorder) Function.......................................................................29
1. Recording.................................................................................................................................29
1.1 Recording methods.............................................................................................................29
1.2 Recording Edit.....................................................................................................................31
1.3 Long Time recording ...........................................................................................................31
1.4 Pause during recording.......................................................................................................31
2. Time Shifting.............................................................................................................................33
3. Playback (Play List)..................................................................................................................34
3.1 Recorded Files....................................................................................................................34
3.2 Imported Files .....................................................................................................................35
3.3 Music...................................................................................................................................35
3.4 Photo...................................................................................................................................35
4. Bookmark .................................................................................................................................36
5. Trick mode................................................................................................................................37
Menu Map..........................................................................................................................38
Main Menu of Guide.......................................................................................................... 39
1. System Tools............................................................................................................................39
1.1 Storage Manager.................................................................................................................39
1.2 Timer Settings .....................................................................................................................40
1.3 Service List Manager ..........................................................................................................40
1.4 Data Transfer.......................................................................................................................42
2. Configuration............................................................................................................................43
2.1 Recording Option ................................................................................................................43
2.2 Parental Control ..................................................................................................................44
2.3 Display Setting ....................................................................................................................44
2.4 Time Setting ........................................................................................................................46
2.5 Language Setting................................................................................................................46
2.6 A/V Output Setting ..............................................................................................................47
3. Installation ................................................................................................................................48
3.1 Dish Setting.........................................................................................................................49
3.2 Positioner Setting................................................................................................................50
3.3 Service Search....................................................................................................................51
3.4 Network Setting...................................................................................................................55
3.5 System Recovery................................................................................................................56
3.6 System Information .............................................................................................................56
4. Utility.........................................................................................................................................57
4.1 Calculator............................................................................................................................57
4.2 Calendar..............................................................................................................................57
4.3 CAS (Conditional Access System)......................................................................................57
4.4 Plugin ..................................................................................................................................59
4.5 YouTube..............................................................................................................................60
Troubleshooting................................................................................................................62
Specifications.................................................................................................................... 63
Code Table for Universal Remote Control Unit............................................................... 66
1. Key Table..................................................................................................................................66
2. TV Brands ................................................................................................................................68
3. VCR Brands .............................................................................................................................75
4. DVD Brands .............................................................................................................................80

5
Precautions
1.Important Safety Instructions
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with dry cloth.

Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
Do not alter the mains plug in any way. If the provided plug does not fit consult an electrician for
replacement of the obsolete outlet.
Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
Only use attachments/accessories specified by the manufacturer.
Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid
injury from tip-over.
Unplug this apparatus during lightning storms or when unused for long periods of time.
Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate
normally, or has been dropped.
WARNING : ToPreventfireorshockhazarddonotexposethesettorainormoisture.
2.Notice
These servicing instructions are for use by qualified service personnel only. To reduce the risk of
electric shock, do not perform any servicing other than that contained in the operating instructions
unless you are qualified to do so.
The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids,
such as vases, shall be placed on the apparatus.
The mains plug is used as the disconnect device. The disconnect device shall remain readily operable.

6
To reduce the risk of electric shock, do not remove
the cover (or back).
No user serviceable parts are inside.
Refer servicing to qualified service personnel.
The Lightning Flash with arrowhead symbol
within an equilateral triangle, is intended to
alert the user to the presence of un-insulated
"dangerous voltage" within the product
enclosure that may be of sufficient magnitude
to constitute a risk of shock to persons
The exclamation point within an
equilateral triangle is intended to alert
the user to the presence of important
operating and maintenance
(servicing) instructions in the
literature accompanying the product
3.Copyright
This manual is protected by copyright laws.
Copy, use and reproduction of this manual in part or whole without s prior written
approval are prohibited.
4.Disclaimer
The manufacturers, distributors and agents are not liable to any kind of damage caused by the
use of theinformation containedin this manual.
The instruction and descriptions which this manual contains are based on the time of this
manual'sproduction.
The manufacturer constantly updates it with new functions and technology.
All the specifications aresubject to change without priornotice.
5.Trademarks
HDMI, the HDMI logo and High-Definition Multimedia Interface are
trademarks orregistered trademarks of HDMI Licensing LLC
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby Laboratories.

7
Before You Begin
1.Main Features
With DVB-S/S2 Tuner(s) Installed
Supports MPEG4 /MPEG2- HD/SD and FullyDVB-S2 /DVB-S Compliant
IntelligentBlind Scan forboth SD and HDTV & Multi-SatelliteSearch
Multi-LNB Controlled byDiSEqC Control Version 1.0, 1.1,1.2 and USALS
With DVB-C Tuner(s) Installed*
Supports MPEG4 /MPEG2 - HD/SDand Fully DVB-C Compliant
With DVB-T Tuner(s) Installed*
Supports MPEG4 /MPEG2 - HD/SDand Fully DVB-T Compliant
With DVB-T2 Tuner(s) Installed*
Supports MPEG4 /MPEG2 - HD/SDand Fully DVB-T2 Compliant
Common features
ChangeableTwinTuner Full HDTVPVR Receiver ( DVB-S/S2, DVB-C, DVB-T, DVB-T2)*
Supports MPEG4 /MPEG2 - HD/SD(H.264/ MPEG4HD )
Powerful compatibility through Embedded LinuxOS
Time Shifting, Recording& Playback with Internal HDD (SATA) / External HDD (e-SATA or USB 2.0)
SimultaneouslyRecords 3 Services and allows Watching of 2 others (PIP)
PowerfulExtendedEPG supportedwith EventRecording
3 USB 2.0 Host ports (MP3 Player &JPEG Viewer)
Xvidfileplay backsupported
External SATA connection supported (Separate power is needed for Ext.HDD drive)
Ethernet port Supported
IntelligentBlind Scan for both SD and HD TV& Multi-Satellite Search
Premium Grade White VFD Display (12 DigitAlphanumeric)
Premium Grade Universal remote control unit
Multi-LNB Controlled byDiSEqC Control Version 1.0, 1.1,1.2 and USALS
Full HDOn-Screen Display
FavoriteServiceGroups
Powerful ServiceControl byFavorites, Lock, Skip, Moveand Delete
Service sorting by Name, Transponderand CAS
User Friendly & Multi-language Supported (OSD & Menu)
Teletext /Subtitles Supported
Supports upto10,000 Services
PIP(Picture-in-Picture)
Parental Lock / SystemLock / InstallationLock
HDMI Video& Audio Output (576i, 576p,720p, 1080i, 1080p)
Supports Y/Pb/Pr(component) Output in HD
CVBS(composite) Video& Audio Output via RCA
CVBS, RGB, Y/CVideo & Audio Output viaTV SCART
Optical Output for Digital Audio(SPDIF)
Software & Service channel Database upgrade viaUSB & RS-232C port
2 Smart card readers and 2 Common Interface Slots
1WStand-byPowerConsumption
*Tuner availabilityisdependenton geographicregion.

8
2.Accessories
User'sManual
AAAsizeBatteriesX2
LoopthroughCable(Option)
RemoteControl
HDMICable(Option)
ACPowerCord

9
Hardware Description
1.Front Panel Configuration
1. POWERBUTTON : Press to switch between STANDBY and POWER ON modes.
2. Vol Up/Down BUTTON :Press to change audio volume in normal mode or to navigate menu in
menu mode.
3. CH Up/Down BUTTON :Press to change services in normal mode, or to move highlighted-bar in
menu mode.
4. RemoteSensor : Receives signal from remote controller.
5. VFD Display : The VFD display allows 12 alpha numeric characters to be displayed. These characters
are used to display the current status of the receiver e.g.service name, service information and so on.
6. USB(Front) : Used to connect external USB storage devices.
7. SMARTCARD READER : Insert smart card for encrypted service access.
8. PCMCIA : To receive other pay-tv services you need a CA-Module (Viaccess, Irdeto, Nagravison, etc.)
and a smart card from the service provider.
2.VFD(Vacuum Fluorescent Display)
1. Remote Indication LED : The LED indicates when a
key on the Remote Controller is pressed.
2. Information : Display information including service
name and other information.

10
3.Rear Panel Configuration
1. VCRSCART : Connects to a VCR or DVD recorder using a SCART cable.
2. TVSCART : Connects to the TV using a SCART cable.
3. SPDIF : Connects to the audio system using a S/PDIF cable. (digital audio)
4. VIDEO : Connects to theTV orVCR using a RCAcable.(Composite video output /Yellow)
5. AUDIO L/R : Connects to theTV orVCR using a RCAcable. (Stereo audio output / White, Red)
6. Component : Connects to theTV or VCR using a component cable. (YPbPr)
7. USB : Used to connect to external USB storage devices or WiFi adaptors.
8. HDMI : Connects to a TV using an HDMI cable for the best quality picture and audio.
9. RS-232C : Serial port for firmware update and data transfer.
10. Ethernet : Local area network port for direct computer connection.
11. e-SATA : Connects to the external HDD via an e-SATAcable.
12. A/CSwitch : Power switch
13. A/Cpowercablesocket : Connects toA/C power cord.
Two tuners can be installed in different combinations as follows.
Professional installation of thesetuners is recommended please consult your
dealer. Tuner availability is dependent ongeographic region

11
Incaseof S2 + S2
[TUNER 1 ]
1. LNB IN(Caution : LNB1in on theleft bottom)
Satellite IF signal input socket of the first tuner (TUNER 1).
Connects a satellite antenna LNB cable.
2. LNBOUT
Satellite IF signal output socket of the first tuner (TUNER 1).
Connects to a second tuner (TUNER 2) for loop-through.
[TUNER 2 ]
3. LNB IN(Caution : LNB2in on theright bottom)
Satellite IF signal input socket of the second tuner (TUNER
2). In the case of a loop-through configuration a short
cable connects LNB Out from the first tuner (TUNER 1) to this connector.
4. LNBOUT
Satellite IF signal output socket of the second tuner (TUNER 2). Can be used to connect to another STB.
Incaseof T(T2) + T(T2)
[TUNER 1 ]
1. ANTIN
Terrestrial signal input socket of the first tuner (TUNER 1).
Connects to a UHF aerial.
2. LOOPOUT
Terrestrial signal output socket of the first tuner (TUNER 1).
Connects to a second tuner (TUNER 2) for loop-through.
[TUNER 2 ]
3. ANTIN
Terrestrial signal input socket of the second tuner (TUNER
2). In the case of a loop-through configuration a short
cable connects Loop Out from the first tuner (TUNER 1) to
this connector.
4. LOOPOUT
Terrestrial signal output socket of the second tuner (TUNER 2). Can be used to connect to another STB.
Incaseof C+ C
[TUNER 1 ]
1. CABLEIN
Cable signal input socket of the first tuner (TUNER 1).
Connects to a cable TV network.
2. CABLEOUT
Cable signal output socket of the first tuner (TUNER 1).
Connects to a second tuner (TUNER 2) for loop-through.
[TUNER 2 ]
3. CABLEIN
Cable signal input socket for the second tuner (TUNER 2).
In the case of a loop-through configuration a short cable
connects Cable Out from the first tuner (TUNER 1) to this connector.
4. CABLEOUT
Cable signal output socket of the second tuner (TUNER 2). Connects to another STB or Cablemodem.

12
Incaseof S2+ T(T2)
[TUNER 1 ]
1. LNB IN(Caution : LNB1in on theleft bottom)
Satellite IF signal input socket of the first tuner (TUNER 1).
Connects a satellite antenna LNB cable.
2. LNBOUT
Satellite IF signal output socket tof the first tuner (TUNER
1). Connects to another STB for loop-through.
[TUNER 2 ]
1. ANTIN
Terrestrial signal input socket of the second tuner (TUNER
2). Connects to a UHF aerial.
2. LOOPOUT
Terrestrial signal output socket of the second tuner (TUNER 2). Can be used to connect to another STB.
Incaseof S2+ C
[TUNER 1 ]
1. LNBIN(Caution:Socketon theleft bottom)
Satellite IF signal input socket of the first tuner (TUNER 1).
Connects a satellite antenna LNB cable.
2. LNBOUT
Satellite IF signal output socket tof the first tuner (TUNER
1).Connects to another STB for loop-through.
[TUNER 2 ]
3. CABLEIN
Cable signal input socket of the second tuner (TUNER 2).
Connects to a cable TV network.
4. CABLEOUT
Cable signal output socket of the second tuner (TUNER 2).
Connects to another STB or Cablemodem.
Incaseof T(T2) +C
[TUNER 1 ]
1. ANTIN
Terrestrial signal input socket of the first tuner (TUNER 1).
Connects to a UHF aerial.
2. LOOPOUT
Terrestrial signal output socket of the first tuner (TUNER 1).
Can be used to connect to another STB
[TUNER2 ]
3. CABLEIN
Cable signal input socket of the second tuner (TUNER 2).
Connects to a cable TV network.
4. CABLEOUT
Cable signal output socket of the second tuner (TUNER 2). Connects to another STB or Cablemodem.

13
4.Remote Control Unit
1. POWER :Turns the STB On/Off.
2. MUTE :Turns the sound On/Off.
3. UniversalButtons
a. TV: Change the mode of the Remote Controller to TV Mode.
b.STB : Change the mode of the Remote Controller to STB Mode.
c. DVD: Change the mode of the Remote Controller to DVD Mode.
4. MODE
a. V.Format :You can switch the Display Format (4:3 / 16:9)
b.Sleep :To adjust the sleep timer.
c. TV/RADIO : Switches betweenTV and Radio.
d.Resolution : To select the resolution format. Each time you press the Resolution button, the
resolution changes in the following sequence: 576i > 576p >720p> 1080i >1080p
5. Playback Control Buttons
a. Rewind : Rewinds at high speed. Each time you press this button the rewind speed is increased.
b.FastForward : Fast forwards at high speed. Each time you press this button the speed is increased.
c. Previous File : To play the previous MP3 file in MP3 play mode. This button is also used to jump
back to beginning of recording during a playback.
d.Next File : To play the next file. This button is also used to jump to end of recording during a
playback.
e. Play / Time shift : Display the progress bar during playback when no progress bar is displayed. It
starts playback atnormal speed. It also returns to normal speed from trick mode.
f. Recording :To start Recording.
g.Repetition (*):This key is used to play back a recording repeatedly.
h.Pause:This key is used to pause the video. Press once more to resume the video.
i. STOP:To stop time shifting, play back or recording.
NOTE : (*) This Repetition may not be available until a new firmware version is installed.

14
6. ColorButtons
a. RED : Used for special functions in the menu. The RED key is used to sort lists in the service list or
go to previous day search in the EPG or make/delete the current position as a bookmark.
b.GREEN : Used for special functions in the menu. The GREEN key is used to set the favorites setting
in the service list or go to the next bookmark position.
c. YELLOW : Used for special functions in the menu. Yellow key is used to find services in the service
list or change the audio track..
d.BLUE : Used for special functions in the menu. The Blue key is used to set service list options in the
service list or display Multi-Picture.
7. Information : Shows the information about the current program. If you press it twice, the detailed
information box will be shown.
8. Recall: Moves to previous service.
9. ARROW Buttons
a. Up&DownKey :To change the value of a selected item with preprogrammed values in the menu.
b.Left&Right Buttons :To move the cursor left and right in the menu.
10.OK or Service List : Show the service list in non-menu mode and select an item or confirm in menu
mode.
11.Menu :To enter the main menu or to move to the previous menu.
12.EXIT : Exit from the menu or pop-up window.
13.Page Up& Down : Move to the next or previous page if more than one page are available. This button
is also used to change the location of the sub picture in PIP.
14.Favorite:To display the satellites programmed into the receiver and the favorite groups.

15
15.Volume Up &Down :To change theVolume.
16.ChannelUp&Down:To change the TV or Radio channel.
17.EPG(ElectronicProgramGuide) : Show the TV/Radio program guide.
18.PlayList:To show the file list for the SATAHDD or USB Storage Device.
19.PIPButtons
a. PIP(Picture in Picture) :To activate the PIPwindow.
b.PIPSwap : Switching between main-picture and sub-picture
c. PIP(Picture inPicture) Service List :To show the sub-picture service list.
20.Numeric :Allows numerical data entry and changing of services directly.
21.Subtitle:To show subtitles.
22.Teletext: To show the digital teletext.

16
5.Multi-Brand IR Remote Controller Setting
NOTE : If there is no input for 10 seconds after selecting set mode, set mode is
canceled.
1. DirectCodeEntry
Step1 :Turn on the DEVICE what you want to setup (TV / DVD / VCR)
Step2 : Press the DEVICE and OK buttons at the same time for about 2 seconds.
DEVICE LEDwillblink twice.
Step3 : Input the 3 digit code number applicable to you device.
(Refer to Code Table for Universal Remote Control Unit intherearsectionofthismanual)
DEVICE LEDwillblink twiceandthe DEVICEturns off.
Ifyouenter a wrongDEVICE code,DEVICE willblinkonce
Step4 : If your DEVICE turns off, press OK button.
DEVICE LEDwillblink twice.
2. AutoCodeSearch
Step1 :Turn on the DEVICE what you want to set up (TV/ DVD /VCR)
Step2 : Press the DEVICE and OK buttons at the same time for about 2 seconds.
DEVICE LEDwillblink twice.
Step3 : Press the UP or Down buttons within 10 seconds to enter the Search mode.
Step4 : Press the UP or Down buttons until the DEVICE turns off.
Step5 : If your DEVICE turns off, press OK button.
DEVICE LEDwillblink twice.
3. CodeNo.Checking(NumberCall)
Step1 : Press the DEVICE and OK buttons at the same time for about 2 seconds.
DEVICE LEDwillblink twice.
Step2 : Press the INFO button within 3 seconds.
LED willblink according tothe codenumber ofthedevice.
( Case of digit '0', it blinks 10 times.)

17
Connections diagram
1.Receiver to AC power
Connect the power cord between the AC power cord socket of receiver and the AC outlet.
2.Receiver to TV with Digital A/V Output
Connect theHDMI Cable to the HDMI Connector of the TV.
Connect the SPDIF Cable to the Digitalaudio inputof the Digital AudioEquipment.
NOTE : Depending on the A/V equipment you own, there are various ways you can connect
the STB. To choose the best connection option, please refer to the manual of the
equipment you would like to connect to. To get High Definition playback of High
Definition content, we recommend that you connect your high definition display
with a HDMI cable. HDMI supports standard, enhanced or high-definition video
and multichannel audio in a single cable.

18
3.Receiver to TV with Analog A/V Output
Connect the TV SCART to the SCART input of the TV.
Connect the Component to the Component input of the TV.
Connect the Composite to the Composite input ofthe TV.
NOTE : HDMI or component (YPbPr) is recommended for Digital TVs.
The SCART cable connection is recommended for analogue TVs or VCRs
The composite connection(RCA cable) is recommended for analogue TVs
You cannot view high definition video with the SCART and the composite video
connector.

19
4.Receiver to TV and VCR
Connect the TV SCART to the SCART input of the TV.
Connect the VCRSCART to the SCART inputofthe VCR.

20
5.Connecting to Antenna Cable
5.1 In case of S2 + S2(Satellite + Satellite) tuners
Connecting one dish to both tuners by Loop through
Connecting each Dish to each Tuner
Connecting multiple dishes to each Tuner via a Multi-switch
