UltraFire UBH1RF User manual

Radio-Interlinked Heat Alarm
USER MANUAL
UBH1RF HEAT ALARM
WITH RADIO-INTERLINK
UBH1RF

Index
Index
Overview.................................................................................... 1
Product Specication................................................................. 2
Suitability.................................................................................... 3
Silence / Do Not Disturb Mode.................................................. 4
AlarmSignals............................................................................. 5
Status Indicators / Installation.................................................... 6
Placement.................................................................................. 7
Installation Procedure................................................................ 8
Radio-Interlink............................................................................ 9
Interlink - User Guide................................................................. 10/11
Interlink - Clear Interlink Code................................................... 12
Maintenance.............................................................................. 13/14
Troubleshooting......................................................................... 15
Fire Safety Advice...................................................................... 16
What to Do in Case of Fire........................................................ 17
Warranty Information................................................................. 18/19
Contact Information................................................................... 20

1
Overview
This heat alarm is a re detection
and alarm device which gives o󰀨
an audible and visual warning
when the ambient temperature
reaches 54°C to 70°C. These
temperatures are abnormal in
a typical setting and thus are
likely to be caused by an actual
re. Heat alarms are ideal for
areas with a risk of re but
where traditional smoke alarms
would experience regular false
alarms, such as in kitchens and garages. A heat alarm is not suitable for
bathrooms and other excessively humid rooms.
During standby, the LED will ash every 32 seconds to indicate normal
operation. When in alarm mode the LED ashes approximately once per
second and the alarm enters into one of the alarm patterns described in
the Alarm Signals section.
Overview

2
Product Specication
• Sensor Type: Fixed Temperature
•Class: A2 (Trigger Temperature 54°C
– 70°C)
• Battery Specication:
◦Voltage: DC 3V
◦ Type: 2x AA alkaline
◦ Recommended:
•Gold Peak Group GP 15A
•Dimensions (HxDia): 40x102mm
• General Operating Temperature:
4°C - 38°C
•Humidity Range: 10% to 95% RH
•Operating Current:
◦Standby: <50µA
◦Alarm: <90mA
•Alarm Volume: >85dBA at 3 metres
•Heat Sensitivity: 54°C - 70°C
•Silence Time: Approx. 10 minutes
•Do Not Disturb Time:
Approx. 8-10 hours (see Additional
Features)
•Wireless Frequency: 868MHz
•Wireless Range:
◦Clear Line of Sight: 200m
◦Typical Indoors: 35m
•Wireless Limit: 50 devices
•Useable Lifespan: 10 years
•Disposal: Not for general waste;
see local electronic waste disposal
guidelines.
•Suitable for: BS 5839-6 Grade F2
Product Specication

3
Suitability
UltraFire’s range of battery-powered re detection and alarm devices are
designed to meet BS 5839-6 Grade F2 requirements. Even if interlinked
as a network with multiple sensor types, these alarms are only intended
for use in single household premises which are permitted to use battery-
powered alarms.
Local Building Regulations, legislation, or other requirements may
specify mains-powered alarms, in which case this product is not suitable.
Multi-household domestic premises and commercial premises usually
require more advanced re detection and alarm systems.
Suitability

4
Alarm Silence Mode
WARNING: Before silencing an active alarm you must ensure the
environment is safe. Do not silence the alarm in the event of an actual
re, as this may prevent other occupants from evacuating.
When in alarm mode, pushing the test button will silence the unit for
approximately 10 minutes. The red LED will ash as per the Status
Indicators section to indicate that the alarm has been silenced.
The alarm will automatically reset after approximately 10 minutes. If after
this period there are still signs of a potential re then the alarm will sound
again. The alarm silence mode can be repeated.
Do Not Disturb Mode
When the alarm is indicating any kind of fault it will chirp as per the
Status Indicators section. Pressing the silence button at this time will
silence the warning for approximately 8 to 10 hours, ideal for postponing
corrective action overnight.
The alarm will still continue to monitor for signs of a potential re during
this time, providing the fault does not prevent normal operation, so it may
go into alarm mode. The alarm’s Do Not Disturb Mode only prevents the
fault warning chirp.
Silence / Do Not Disturb Mode

5
Alarm Signals
Alarm Signals
Test Alarm
Pattern
Heat Detected
Alarm Pattern
Wireless Alarm
Pattern
1. Chirp 3 times with red
LED ash
1. Chirp 3 times with red
LED ash
1. Chirp 2 times with red
LED ash
2. Pause 1.5s 2. Pause 1.5s 2. Pause 1.2s
3. Chirp 3 times with red
LED ash
3. Repeat from the
beginning
3. Repeat from the
beginning
4. The alarm will reset
after 60 seconds without
further wireless activation
signal from other alarms
3. Repeat from the
beginning

6
Status Indicators
• During standby operation the red LED will ash once every 32
seconds.
• When the battery fails or a low battery is detected, the alarm will chirp
once every 32 seconds in conjunction with the red LED ashing.
• When a fault is detected the alarm will chirp once every 32 seconds
with red LED ash.
• If the alarm has been silenced, the red LED will ash once every 8
seconds for aproximately 10 minutes.
Installation
Location
Heat alarms are recommended for kitchens, generator rooms, garages,
utility rooms, loft spaces, or other rooms which typically su󰀨er false
alarms.
Do Not Install in the Following Places:
• On walls, shelves, or cupboards
• Where the alarm is likely to be exposed to liquids
• At the very apex of pitched ceilings
• In the corner of the ceiling
• Within 30cm of a wall, light tting, or other obstruction
• In bathrooms and other rooms that will be exposed to steam
• Where the ambient temperature regularly exceeds 4°C to 38°C range
Status Indicators / Installation

7
Placement
UltraFire Wireless Heat Alarms
must be installed on the ceiling, at
least 30cm from the nearest wall,
light tting, or other obstruction.
These alarms should be installed no
more than 150mm vertically below
the apex of a pitched ceiling. Where
the depth from apex to eaves is
600mm or less the ceiling should be
treated as at.
Try to ensure that the alarm is within reach without taking any undue
risks, so that you can perform routine maintenance and replace the
batteries.
Above all else you must ensure that you follow local building regulations,
legislation, and o󰀩cial standards.
NOT IN
THIS AREA
25mm
DO NOT INSTALL
PEAK CEILING
ANYWHERE IN
THIS AREA
DEAD AIR
150mm
Placement
CEILING
300mm
MINIMUM
BEST
HERE NEVER
HERE

8
Installation Procedure
Installation Procedure
WARNING: The label on the alarm must not be removed as it shows
important information about the product.
1. Check the desired installation position for wires, pipes or other
obstructions that would be dangerous to drill into.
2. Hold the baseplate against the ceiling at the
desired installation position.
3. Mark the installation holes with a pencil.
4. Drill the two installation holes as previously
marked using a 5mm diameter drill bit.
5. Stirke the two included plastic rawl plugs into the
holes with a hammer.
6. Align the baseplate to the plastic rawl plugs and
x in place using the provided screws.
7. Fit the batteries into the alarm (please note the
battery polarities).
8. Follow the instructions in the radio-Interlink
section.
9. Line the alarm up to the baseplate and turn the
alarm head clockwise, until securely attached.
10. After mounting, test the alarm as described in
the Maintenance section.

9
Radio-Interlink
Radio-Interlink
UltraFire radio-interlinked alarms are designed to be wirelessly
interlinked as a network with up to 50 products. These alarms need to
be “learned in” or interlinked in order to communicate with each other. If
one alarm activates, all other interlinked alarms will also sound. They are
not designed to communicate with wireless alarms from other ranges or
manufacturers.
Note: Obstructions such as steel reinforcement in concrete could block
or impede the wireless signal. While the wireless range is over 200m
in open spaces, the e󰀨ective range may be reduced by walls and other
obstructions within a building. It is recommended not to exceed 35m as
the maximum distance between the alarms in a network.

10
Interlink - User Guide
Interlink - User Guide
1. Ensure all alarms have batteries tted and are turned on
2. Pick one alarm to be the Master unit; mark this alarm for future
reference
3. On the Master unit, press the test button 3 times in quick
succession
a. The red light should be on continuously
b. Master mode will time out in 10 seconds if no other alarms
attempt a connection
4. On all other alarms, one at a time, press the test button 3 times in
quick succession
a. If successful the red light on each alarm should ash rapidly
for a short period of time
b. If not successful try again
5. Once all other alarms are connected the Master unit can be put
into normal operation
a. Either wait 10 seconds or press the test button once

11
Interlink - User Guide
Interlink - User Guide
6. When all alarms are connected and in normal operation the system
should be tested:
a. Pick one alarm and hold the test button; this one should
sound almost immediately
b. Continue holding the test button until the other alarms start
sounding
c. It may take approximately 30 - 45 seconds for all alarms to
sound
d. If any alarms do not sound, put the marked alarm back into
Master mode (steps 2 & 3) and try to reconnect the silent
alarm(s) according to steps 4 & 5

12
Interlink - Clear Interlink Code
Clear Interlink Code
It may be necessary to remove an alarm from the network in some
situations, for example if troubleshooting an alarm that does not respond
to the test signal.
1. Turn the alarm head anti-clockwise and remove it from the
baseplate.
2. Take the batteries out from the battery compartment.
3. Press and hold the test button while reinserting the batteries. If
successful, the red LED will turn on for about 3 seconds, otherwise
repeat accordingly.
4. Once the LED turns o󰀨, release the test button.
5. Press and release the test button again when the LED turns back
on.
6. The LED will turn o󰀨 and the alarm will chirp, indicating success.
7. The alarm is now in standby operation as a standalone unit, no
longer interlinked with any other alarms.

13
Maintenance
Maintenance
Testing
Test your alarms to ensure proper operation once per week by pressing
the test button. If there is no sound output it means that the alarm is
faulty, the batteries are at, or that the installation procedure may not
have been followed correctly. Please try replacing the batteries and
reinstalling the alarm head. If the alarm still fails to react to the test
button, please read the Troubleshooting section of this manual.
WARNING: The test button accurately tests the alarm’s components
and functions. Do not expose the alarm to an open ame. You may
contaminate and damage the sensor, preventing the alarm from
providing adequate protection from real res, and invalidate the warranty.
Note: When testing a single alarm, because the alarm transmits a
wireless signal, other connected alarms should also sound. You may
need to hold the test button for up to 30 seconds for the alarm to sound.
Once the test button has been released, the other alarms will silence
within 1 minute.
Repairing
Do not attempt to repair the alarm yourself; dismantling the alarm will
a󰀨ect your warranty. If the alarm is not operating properly, and it is still
under warranty, contact the retailer who sold you the product or the
manufacturer.

14
Maintenance
Maintenance
Cleaning
Do not paint smoke or heat alarms. Your alarms should be cleaned every
month, using a vacuum cleaner tted with the soft brush attachment.
WARNING: Do not attempt to remove the cover to clean inside. This will
a󰀨ect the warranty.
Battery Replacement
1. Twist the alarm anti-clockwise to remove it from the baseplate.
2. Remove the old battery.
3. Connect and insert a new battery, ensuring correct polarity.
4. Place the alarm back on the baseplate, twisting clockwise.
5. Hold the test button until the test pattern sounds. This may take
5 - 10 seconds.
6. See the Troubleshooting section if the alarm does not sound.

15
Troubleshooting
Troubleshooting
Problem Action
Alarm does not sound when
tested.
Remove alarm head from
baseplate. Check batteries are
installed properly and have
power.
Alarm chirps with the red LED
ash about every 32 seconds.
Replace batteries as described
in the Maintenance section.
Please note the battery
polarities.
Heat alarm sounds unwanted
alarm intermittently.
1. Problems caused by high
humidity can be resolved
by drying the alarm head.
2. Move the alarm to a new
position in the room.
Heat alarm fails to interlink to a
network.
Follow the steps to clear the
interlink code and try to interlink
the alarm again using a di󰀨erent
alarm as the master.

16
Fire Safety Advice
Fire Safety Advice
Familiarise yourself with and follow the national and local regulations
regarding selection and installation of the di󰀨erent kinds of smoke and
heat alarms.
Plan Your Escape
If an alarm sounds but you did not push the test button and it is not a
fault tone then it is likely a dangerous situation has developed in the
property. To prepare for such occurrences, it is recommended that
you develop escape plans for the premises and discuss them with all
occupants. Regular practice of your emergency plans can be vital to a
successful evacuation.
1. Familiarise everyone with the alarm patterns of all alarm devices
and explain what they represent.
2. Identify all exits from each room and plan an escape route to the
outside from each exit.
3. Teach all occupants to carefully touch doors and to use alternate
exit when the door is hot; instruct them not to open the door if the
door is hot.
4. Teach occupants to crawl along the oor, to stay below dangerous
fumes and gases.
5. Identify a safe meeting place for all occupants outside the building
and make sure everyone is aware of it.

17
What to Do in Case of Fire
What to Do in Case of Fire
1. Calmly leave the premises as quickly as possible. Follow your
personalised Escape Plan if possible; otherwise:
a. Carefully touch doors to ensure they are not hot before
opening them.
b. Use an alternate exit if necessary.
c. Crawl along the oor to avoid smoke.
d. Do not stop to collect anything.
2. Meet at a pre-arranged meeting place outside the building if there
are multiple occupants. Check if anyone is missing, but do not
re-enter the premises.
3. Call the re service from outside the building; do not delay your
escape to contact the emergency services.
4. Do not go back inside a burning building for any reason. Wait for
the re service to arrive.
NOTE: These guidelines will assist you in the event of a re; however,
UltraFire cannot predict the exact situation of any home re. Creating
your own escape plan based on your specic premises and occupants
is the best way to ensure safe evacuation. Follow re safety guidance
and legislation to reduce the chance that res will start and prevent
hazardous situations.

18
Warranty Information
Warranty Information
Safelincs warrants to the original purchaser that its enclosed UBH1RF
battery-powered radio-interlinked alarm, under normal domestic use
and service, will operate as described and be free from material and
workmanship defects for a period of ve years from the date of purchase.
Safelincs hereby warrants that during the warranty period, commencing
from the date of purchase, Safelincs, at its discretion, agrees to repair or
replace the unit free of charge. The warranty on any replacement alarm
will last for the remainder of the period of the original warranty in respect
of the alarm originally purchased – that is from the date of original
purchase and not from the date of receipt of the replacement product.
Safelincs reserves the right to o󰀨er an alternative product similar to that
being replaced if the original model is no longer available or in stock.
This warranty applies to the original retail purchaser from the date of
original retail purchase and is not transferable. Proof of purchase is
required.
This warranty does not cover damage resulting from accidents,
misuse, abuse, disassembly, lack of reasonable care of the product,
or applications not in accordance with the user manual. Consumables
such as batteries are also not covered by this warranty. In no case shall
Safelincs be liable for any incidental or consequential damages or any
other warranty, express or implied.
