ASSEMBLY & OPERATING INSTRUCTIONS:
KT2
Adjustable Height &
Angle Keyboard Tray
IMPORTANT: Before using your KT2:
Read and clearly understand the contents of this manual
Understand how to adjust KT2correctly
Practice adjusting KT2with nothing on it.
KT2allows you to easily adjust the height & angle of your keyboard to optimize your typing posture.
IMPORTANT: BEFORE using KT2or placing a keyboard & mouse on KT2, practice adjusting KT2’s height & angle.
2
1
A B C
D
Have Questions? Need Help?
Out A+ customer support team is here to help:
EMAIL: hello@UncagedErgonomics.com
PHONE: 240-583-0517
A
2. Align the Rail (A) with the edge of your desk 3. Use 8Escrews to connect the Rail (A) to the bottom of your desk.
3
E
G
8 Black M6 Nuts
E
6 Silver M6x16 Screws H
8 Black M6x14 Screws
1. Remove the ARM (B) from the Rail (A).
A. Remove two Stopper Screws from the front edge of the Rail (A).
B. Slide the ARM (B) off of the Rail (A)
C. Re-install the two Stopper Screws after completing the installation.
1
A
B
Stopper Screws
www.UncagedErgonomics.com
ASSEMBLY & OPERATING INSTRUCTIONS:
KT2
Adjustable Height &
Angle Keyboard Tray
2
4
G
H
4. Attach the Keyboard Panel (C) to the mounting
panel with 4 H Screws & 4 G nuts.
7
7. Press down to tilt the Mouse Pad and adjust its’ angle.
If the mouse pad is too loose, tighten the 2
screws on the mouse pad mounting bracket.
9
9. KT2 is adjustable from below your desk to above your desk. For fast adjusting:
remove your mouse, release the lever (8A) & squeeze the handle (8B).
When you’ve reached the perfect height, release the handle and then tighten the
lever.
8. The Keyboard Tray slides in/out by pushing/pulling.
8A.To adjust the KeyboardTray’s angle, release the lever under the keyboard tray.
8A
8B
8B.To raise/lower the Keyboard tray, squeeze the handle under the front of the
keyboard tray. Release it to lock the keyboard tray in place.
8
6
6. The Mouse Pad (D) attaches to the right or left side of the Keyboard
Tray (C). Release the thumb screw on the attachment to move the Mouse
Pad closer to or farther away from the Keyboard tray.
D
C
5
5. Connect the metal Mouse Pad Bracket to the keyboard tray
using 2 H Screws & 2 G Nuts.
5A. Connect the Mouse Pad to the Mouse Pad Bracket
using 2 H Screws & 2 G Nuts.
5A
G
H
