Step 1: Hardware Installation Guide
Step 2: Software Installation Guide

To Ensure Safe Use
Installation
What’s Included
Hardware Installation
Step 1: Mounting Bracket
Step 2: Sensor Insert
Step 3: Connection
Step 4: Connection Status
Trouble Mats
Software Installation
Calibration Guide
Calibrating Instructions
Without Trouble Mats
With Trouble Mats
Club Sticker Placement
Club Sticker Application
Appendix
Club Data
Ball Data
Speccations
Links
EYE XO2 USER MANUAL 2
TABLE OF CONTENTS
3
5
6
7
8
9
10
11
12
13
17
20
21
21
24
26
28
28
31
35
36

EYE XO2 USER MANUAL 3
To Ensure Safe Use
Improper handling or operation of this machine may result in injury
or damage to property. Points which must be observed to prevent
injury or damage are described as follows.
Used for instructions intended to alert
the user to the risk of injury or material
damage should the unit be used
improperly. Material damage refers
to damage to home, furnishing, or
anything within the unit’s vicinity.
This symbol alerts the user to items
that should never be carried out.
Used for instructions intended to alert the
user to the risk of severe injury should the
unit be used improperly.
Safety
WARNING
Caution
NEVER

EYE XO2 USER MANUAL 4
To Ensure Safe Use - Cont
Never attempt to disassemble, repair, or
modify shock, or injury. Entrust repairs to
a trained technician.
Never use outside or in any location where
exposure to water or high humidity may occur.
Do not touch the power cord or electrical
outlet with wet or dirty hands. Doing so may
result in electrical shock.
Be aware of your surroundings and
use cautiously with children around.
Swinging the club during play without
being aware will result in serious injury
or death.
Conduct play in a clean and brightly lit
location. Operating in a dark or cluttered
space may lead to accidents.
Install in a level and stable location.
Failure to do so may result in falling of
the machine, leading to injury.
Safety
This is a heavy machine.
WARNING!

EYE XO2 USER MANUAL 5
* AMD: 3rd gen Ryzen or higher and AMD Ryzen 3600 or higher (AMD 2700 is not compatible).
Installation Environment
Category Requirement
CPU Intel i5 8400 or higher*
RAM 8 GB
Graphics Card GeForceGTX 1060 or higher
Operating System Windows 10 (64bit) Version 1803 or higher
Resolution 1920 x 1080
Connectivity Ethernet Port Required

Trouble Mats
EYE XO2 USER MANUAL 6
Club Stickers
Ethernet LAN
Cable Level
USB Ethernet
Adapter
What’s Included
The following items are included with the sensor. Make sure
they are all present and accounted for.
Bracket Calibration ChartEYEXO2 Sensor
Bar
Power Cable
Power
ConnectorPower Adapter
M4 32mm screws M6 15mm screws M6 15mm low screws M6 15mm high screws

EYE XO2 USER MANUAL 7
Hardware Install
Used for instructions intended to alert
the user to the risk of injury or material
damage should the unit be used
improperly. Material damage refers
to damage to home, furnishing, or
anything within the unit’s vicinity.
This symbol alerts the user to items
that should never be carried out.
Used for instructions intended to alert the
user to the risk of severe injury should the
unit be used improperly.
Ladder Phillips
Screwdriver
M4 32mm
Screw x9
Bracket Sensor Bar
NECESSARY TOOLS NECESSARY PARTS
WARNING
WARNING
CAUTION
Bunker Mat Rough Mat

EYE XO2 USER MANUAL 8
Hardware Install
Mounting Bracket
The EYE XO2 Sensor and
bracket come attached together
in the box. Slightly loosen the
black M6 15 mm screws that
are holding the sensor to the
bracket so you can remove it.
Please make sure you have
measured 3.5 feet from the front
and middle of the sensor to your
tee position. Do NOT align to the
bracket.
1
Place the ladder under the
location on the ceiling where the
bracket will be mounted. Place
the bracket at against the
ceiling with the hinges facing
down toward the ground. The
longer side of the hinges must
be closet towards the impact
2
With the bracket in position,
grab the 10 silver M4 32mm
screws and screw them in the
locations below in the diagram.
3
Step 1: Mount Bracket

EYE XO2 USER MANUAL 9
Hardware Install
Insert Sensor
Step 2: Insert Sensor
After the bracket has been rmly mounted to the ceiling, you will install
the sensor bar.
The sensor bar comes with 6 black M6 15mm screws already inserted; 3
screws in the front and 3 screws in the back. Make sure all 6 screws are
about halfway into the bar and even in length.
1
Slide the sensor bar with the 6 screws up and over through the bracket
hinges. Make sure the screws are secured in the hook part of the hinges.
Once the sensor is secured in the bracket hinges, tighten the 6 screws to
the bracket.
2
The tilt of the sensor can be adjusted with the high and low M6 15mm
screws. The regular M6 15mm screws are already screwed into the
sensor. You can change this out with the M6 155 High or Low screws to
adjust the angle/ tilt.
3
M6 High 15mm
M6 Low 15mm
M6 15mm

EYE XO2 USER MANUAL 10
Hardware Install
Connection
Take out the Ethernet LAN cable from the box. Connect the end with the
tag that reads “Connect this side of LAN cable to Sensor ONLY” to the
sensor. Connect the other end DIRECTLY to your PC ethernet port and
NOT the USB adapter.
1
Take out all 3 components of the power source: power cable, power
adapter, and power connector. Connect all 3 accordingly and connect the
“Power Connector” end directly to the sensor as shown below. Turn on red
switch.
2
Step 3: Connection
Note: The plug must be plugged into a matching outlet that is properly installed
and grounded in accordance with all local codes and ordinances.
An extra green grounding wire is provided on the end of the power connector in
case your outlet is not grounded.
**Make sure to check the connection status before you start the software
installation process.
Ethernet LAN
Cable
Power Cable Power
Connector
Power
Adapter
NECESSARY PARTS
Power
Connector
Ethernet
LAN

EYE XO2 USER MANUAL 11
Tech Requirements
LAN Cable
(Ethernet)
Sensor
It is important before you start the network setup process, that you have
the sensor bar powered on and connected to your PC with the LAN cable
provided to you in the shipping box.
Make sure the LAN cable is DIRECTLY connected to your PC in the back
Ethernet port. Do NOT have it connected to the USB Adapter or a hub.
Hardware Install
Step 4: Connection Status
Page 14 Diagram 1 - EYE-MINI Manual Diagrams
*Not sure about this computer graphic...
we could buy a stock image or I can
make one if we want to replace it
PC

Disclaimer:
Uneekor Inc. does not assume responsibility for any damage caused to your
hitting mat or any injury that may occur when creating an insert in for the
Trouble Mats.
EYE XO2 USER MANUAL 12
Rough Bunker
You will need to create an insert in your current hitting mat or hitting turf. Please
reference the dimensions below or use your Trouble Mats as a reference for
creating an insert in your hitting area. The Trouble Mats can be placed anywhere
in the hitting zone. When calibrating your EYE XO2, you’ll have the optionto move
the calibration box left or right where your Trouble Mats are inserted, as long as
it is in the hitting zone of 28” W x 21” L.
For those who wish to use their own hitting mat with the trouble mats. We
recommend using a hitting mat at least 1.5” deep to support the base of the
trouble mats.
Hardware Installation
Trouble Mats
* Both trouble mats are the same length x width
25 mm 37 mm 30 mm
30 mm30 mm 50 mm50 mm
Rough Bunker
300 mm 230 mm

EYE XO2 USER MANUAL 13
Software Installation Warning
Please make sure the connection
statuses are clear and everything
is paired. Failure to do will result in
installation issues.
Please make sure PC requirements
are met from section 1 “Installation
Environment,” before the installation
process. Failure to do will result in
installation issues and slow gameplay.
WARNING
WARNING

EYE XO2 USER MANUAL 14
Software Installation
Uneekor Launcher
To begin the software installation for your EYE XO2. Please download
the Uneekor Launcher found under the resources tab of Uneekor.com or
use the link below.
Uneekor Launcher
For further information on using the Uneekor Launcher, please see below.
Overview Guide
1
After downloading the launcher,After downloading the launcher,
create an account by clickingcreate an account by clicking
“Create your Uneekor Account.” If“Create your Uneekor Account.” If
you already have an account, selectyou already have an account, select
2
Go to the “Install” tab on the left side
of the launcher and select the EYE
XO2, then continue.
For the remainder of the software
installation, please follow the step-by-
step guide on the Launcher.
If you have any issues with
installation, please see the next two
3

Software Installation - Cont
Uneekor Launcher
Ensure your EYE XO2 is plugged into
the power and the CAT6 cable is
connected from the EYE XO2, directly
into the Ethernet port on your PC. If
connected using the USB 3.0 adaptor,
you’ll run into issues using the EYE XO2.
If these conditions are met, click
“Continue.”
4
If you onloy have one Ethernet port
on your PC, then you should only
have one option for the selection of
Ethernet ports.
If you have 2 or more Ethernet ports,
select the Ethernet port your EYE XO2
is connected to in the drop down and
click “Select.”
Once the proper Ethernet port is
selected, press “Continue”
5
EYE XO2 USER MANUAL 15

Software Installation - Cont
Uneekor Launcher
EYE XO2 USER MANUAL 16
6
You will see your EYE XO2 here. Click
“Select” and then “Continue” on the
bottom.
If you do not see your EYE XO2 press the
“Refresh” button.
If your EYE XO2 still does not appear
return to step 5 and select a different
Ethernet port and click “Select.”
If you continue having issues, please
power off your EYE XO2. Then ensure
your EYE XO2 is connected properly
connected to your PC and power outlet,
and then close and reopen the Uneekor
Launcher to start the installation process
over.
7
You may enter license keys manually using
the box under 1. (Swing Optix, Rene/+, and
Balance Optix)
Under 2. your 3rd Party Connector, View, and
Rene+ 30-Day Trial will already be present.
Individually select which licenses you would like
to activate using the box on the left or you can
press the “Select Keys for Current Device” to
activate all keys associated with your EYE XO2.
Make sure to press “Activate” under 3. and then
press “Continue.”
Harware installation is now complete. The next
steps will walk you through calibration.

EYE MINI USER MANUAL 17
CALIBRATION GUIDE
Level
Tool required
Calibration Chart
Parts required
Uneekor Launcher
Software required

EYE XO2 USER MANUAL 18
To Ensure Safe Use
The mounting position of the EYE XO2
sensor must be perfectly aligned 3 feet
6 inches in front of your tee position and
between 9 - 10 feet for the ceiling height.
Failure to meet these requirements will
result in accuracy issues.
Conrm you have successfully nished
the hardware and software installation
before you begin the calibration process.
WARNING
WARNING

EYE XO2 USER MANUAL 19
Calibrating
During the installation process of the EYE XO2 using the launcher, it will automatically pull
up the calibration tool.
Please follow the prompts on the launcher to calibrate your EYE XO2. If you have any issues
calibrating your device using the instructions on the launcher, please see the next page.
Prior to calibrating your EYE XO2. Ensure you have the Trouble Mats inserted correctly. Each
side of the Trouble Mats should be touching with no gaps or space between each Trouble Mat.
Trouble Mats can be placed on either left or right side of the hitting zone (when calibrating
with Trouble Mats, you are able to slide the calibration boxes for the Trouble Mats to the area
your Trouble Mats are inserted).
