US-24, US-48 Quick Start Guide
https://dl.ui.com/qsg/US-24_US-48/US-24_US-48_EN.html
1/13
Power Cord Rack-Mount Brackets (Qty.
2)
Bracket Screws (Qty. 8)
Mounting Screws (Qty. 4) Cage Nuts (Qty. 4) Rubber Feet (Qty. 4)
Package Contents
US-24
OR
US-48
Installation Requirements
Phillips screwdriver
Standard-sized, 19" wide rack with a minimum of 1U height available
For indoor applications, use Category 5 (or above) UTP cabling approved for
indoor use.
For outdoor applications, shielded Category 5 (or above) cabling should be
used for all wired Ethernet connections and should be grounded through the
AC ground of the power supply.
We recommend that you protect your networks from harmful outdoor
environments and destructive ESD events with industrial-grade, shielded
Ethernet cable from Ubiquiti. For more details, visit: ui.com/toughcable
Note: Although the cabling can be located outdoors, the UniFi Switch itself
should be housed inside a protective enclosure.
US-24, US-48 Quick Start Guide
×
Click for
Table of Contents

2022/09/01 23:59
US-24, US-48 Quick Start Guide
https://dl.ui.com/qsg/US-24_US-48/US-24_US-48_EN.html
2/13
System LED
RJ45 Link/Speed/Activity LED
SFP+ Link/Speed/Activity LED (US-48 only)
SFP Link/Speed/Activity LED
System Requirements
Linux, Mac OS X, or Microsoft Windows 7/8/10
Java Runtime Environment 1.6 (1.8 or newer recommended)
Web Browser: Google Chrome (Other browsers may have limited functionality.)
UniFi Network Application v4.8.5 or newer (available at: ui.com/download/unifi)
Hardware Overview
Click here for detailed descriptions.
Off No Link
Amber
Link Established at 10/100 Mbps
Flashing Indicates Activity
Green
Link Established at 1000 Mbps (1 Gbps)
Flashing Indicates Activity
Off No Link
Green
Link Established at 1 Gbps
Flashing Indicates Activity
White
Link Established at 10 Gbps
Flashing Indicates Activity
Off No Link
US-24, US-48 Quick Start Guide
×
Click for
Table of Contents

2022/09/01 23:59
US-24, US-48 Quick Start Guide
https://dl.ui.com/qsg/US-24_US-48/US-24_US-48_EN.html
3/13
RJ45 Ports
SFP+Ports (US-48 only)
SFP Ports
Reset Button
Console Port
DC Input
Green Link Established at 1 Gbps
Flashing Indicates Activity
RJ45 ports support 10/100/1000 Ethernet connections.
Hot-swappable SFP+ ports support 10 Gbps connections.
Hot-swappable SFP ports support 1 Gbps connections.
This button serves two functions for the UniFi Switch:
Press and release the Reset button to restart the device.
Press and hold the Reset button (for at least five seconds) to restore the
device to its factory default settings.
Back Panel Ports
RJ45 serial console port for Command Line Interface (CLI) management. Use
an RJ45-to-DB9, serial console cable, also known as a rollover cable, to
connect the Console port to your computer. Then configure the following
settings as needed:
Baud rate 115200
Data bits 8
Parity NONE
Stop bits 1
Flow control NONE
The 25VDC input can connect a redundant or stand-alone DC power source
(not included) with minimum power: 25W (US-24) or 56W (US-48), 25 to 16V,
US-24, US-48 Quick Start Guide
×
Click for
Table of Contents

2022/09/01 23:59
US-24, US-48 Quick Start Guide
https://dl.ui.com/qsg/US-24_US-48/US-24_US-48_EN.html
4/13
Power Port
and 2.5 mm DC power inline connector.
Note: You can use the redundant DC power source as a hot spare; if
the internal AC/DC power supply no longer provides power, then the
UniFi Switch will switch to the DC power source without interrupting
its operation.
Connect the included Power Cord to the Power port.
Hardware Installation
Mounting in a Rack (Optional)
1.
2.
US-24, US-48 Quick Start Guide
×
Click for
Table of Contents

2022/09/01 23:59
US-24, US-48 Quick Start Guide
https://dl.ui.com/qsg/US-24_US-48/US-24_US-48_EN.html
5/13
OR
US-24, US-48 Quick Start Guide
×
Click for
Table of Contents

2022/09/01 23:59
US-24, US-48 Quick Start Guide
https://dl.ui.com/qsg/US-24_US-48/US-24_US-48_EN.html
6/13
Connecting Power
1.
2.
US-24, US-48 Quick Start Guide
×
Click for
Table of Contents

2022/09/01 23:59
US-24, US-48 Quick Start Guide
https://dl.ui.com/qsg/US-24_US-48/US-24_US-48_EN.html
7/13
Connecting Ethernet
1.
2.
US-24, US-48 Quick Start Guide
×
Click for
Table of Contents

2022/09/01 23:59
US-24, US-48 Quick Start Guide
https://dl.ui.com/qsg/US-24_US-48/US-24_US-48_EN.html
8/13
Using SFP Ports
1.
2.
US-24, US-48 Quick Start Guide
×
Click for
Table of Contents

2022/09/01 23:59
US-24, US-48 Quick Start Guide
https://dl.ui.com/qsg/US-24_US-48/US-24_US-48_EN.html
9/13
3.
For information about compatible fiber SFP modules, visit:
community.ubnt.com/unifi
Specifications
US-24
Dimensions 443 x 43 x 221 mm (17.44 x 1.69 x 8.70")
US-24, US-48 Quick Start Guide
×
Click for
Table of Contents

2022/09/01 23:59
US-24, US-48 Quick Start Guide
https://dl.ui.com/qsg/US-24_US-48/US-24_US-48_EN.html
10/13
US-24
Weight
Rack-Mount Brackets Included 2.60 kg (5.70 lb)
Rack-Mount Brackets Excluded 2.51 kg (5.53 lb)
Enclosure Characteristics SGCC Steel
Max. Power Consumption 24W
Total Non-Blocking Line Rate 26 Gbps
Power Method
AC 100-240 VAC / 50-60 Hz Universal Input
DC DC 25W, 25 to 16V, with 2.5 mm
DC Power Inline Connector
Power Supply AC/DC Internal 20W DC
ESD/EMP Protection Air ± 24 kV, Contact ± 24 kV
Operating Temperature -5 to 40° C (23 to 104° F)
Operating Humidity 5 to 95% Non-Condensing
Shock and Vibration ETSI300-019-1.4 Standard
Interfaces
Networking (24) 10/100/1000 Mbps RJ45 Ethernet Ports
(2) 1 Gbps SFP Ethernet Ports
Management (1) RJ45 Serial Out-of-Band, Ethernet In-Band
LEDs Per Port
RJ45 Data Ports Speed/Link/Activity
SFP Data Ports Speed/Link/Activity
Rack Mount Yes, 1U
Certifications CE, FCC, IC
US-48
Dimensions 443 x 43 x 286 mm (17.44 x 1.69 x 11.26")
Weight
Rack-Mount Brackets Included 3.65 kg (8.06 lb)
Rack-Mount Brackets Excluded 3.56 kg (7.85 lb)
Enclosure Characteristics SGCC Steel
Max. AC Power Consumption 56W
Total Non-Blocking Line Rate 70 Gbps
Power Method
AC 100-240 VAC / 50-60 Hz Universal Input
DC DC 56W, 25 to 16V, with 2.5 mm
DC Power Inline Connector
Power Supply AC/DC Internal 56W DC
US-24, US-48 Quick Start Guide
×
Click for
Table of Contents

2022/09/01 23:59
US-24, US-48 Quick Start Guide
https://dl.ui.com/qsg/US-24_US-48/US-24_US-48_EN.html
11/13
US-48
ESD/EMP Protection Air ± 24 kV, Contact ± 24 kV
Operating Temperature -5 to 40° C (23 to 104° F)
Operating Humidity 5 to 95% Non-Condensing
Shock and Vibration ETSI300-019-1.4 Standard
Interfaces
Networking (48) 10/100/1000 Mbps RJ45 Ethernet Ports
(2) 1/10 Gbps SFP+ Ethernet Ports
(2) 1 Gbps SFP Ethernet Ports
Management (1) RJ45 Serial Out-of-Band, Ethernet In-Band
LEDs Per Port
RJ45 Data Ports Speed/Link/Activity
SFP Data Ports Speed/Link/Activity
Rack Mount Yes, 1U
Certifications CE, FCC, IC
Safety Notices
1. Read, follow, and keep these instructions.
2. Heed all warnings.
3. Only use attachments/accessories specified by the manufacturer.
WARNING: Failure to provide proper ventilation may cause fire hazard. Keep at
least 20 mm of clearance next to the ventilation holes for adequate airflow.
WARNING: To reduce the risk of fire or electric shock, do not expose this product to
rain or moisture.
WARNING: Do not use this product in location that can be submerged by water.
WARNING: Avoid using this product during an electrical storm. There may be a
remote risk of electric shock from lightning.
Electrical Safety Information
1. Compliance is required with respect to voltage, frequency, and current requirements
indicated on the manufacturer’s label. Connection to a different power source than those
specified may result in improper operation, damage to the equipment or pose a fire
hazard if the limitations are not followed.
2. There are no operator serviceable parts inside this equipment. Service should be
provided only by a qualified service technician.
3. This equipment is provided with a detachable power cord which has an integral safety
ground wire intended for connection to a grounded safety outlet.
US-24, US-48 Quick Start Guide
×
Click for
Table of Contents

2022/09/01 23:59
US-24, US-48 Quick Start Guide
https://dl.ui.com/qsg/US-24_US-48/US-24_US-48_EN.html
12/13
a. Do not substitute the power cord with one that is not the provided approved type.
Never use an adapter plug to connect to a 2-wire outlet as this will defeat the continuity
of the grounding wire.
b. The equipment requires the use of the ground wire as a part of the safety certification,
modification or misuse can provide a shock hazard that can result in serious injury or
death.
c. Contact a qualified electrician or the manufacturer if there are questions about the
installation prior to connecting the equipment.
d. Protective earthing is provided by Listed AC adapter. Building installation shall provide
appropriate short-circuit backup protection.
e. Protective bonding must be installed in accordance with local national wiring rules and
regulations.
Limited Warranty
ui.com/support/warranty
The limited warranty requires the use of arbitration to resolve disputes on an individual basis,
and, where applicable, specify arbitration instead of jury trials or class actions.
Compliance
FCC
Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions.
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operations of this equipment in a residential
area is likely to cause harmful interference in which case the user will be required to correct
the interference at his own expense.
ISED Canada
CAN ICES-3(A)/NMB-3(A)
Australia and New Zealand
Warning: This equipment is compliant with Class A of CISPR 32. In a residential
environment this equipment may cause radio interference.
CE Marking
US-24, US-48 Quick Start Guide
×
Click for
Table of Contents

2022/09/01 23:59
US-24, US-48 Quick Start Guide
https://dl.ui.com/qsg/US-24_US-48/US-24_US-48_EN.html
13/13
CE marking on this product represents the product is in compliance with all directives that
are applicable to it.
WEEE Compliance Statement
Declaration of Conformity
Online Resources
