Uni-ram UR007 User manual

USER MANUAL
RECLAIMING SAND BLASTERS
MODELS
UR007
UR007-YEXP
UNI-RAM CORPORATION • ONTARIO • CANADA
Revised 2023-05

2
MANUAL - RECLAIMING SAND BLASTERS - UR007 SERIES Revised 2023-05
CONTENTS
INTRODUCTION ................................................................................................................................... 3
CAUTIONS AND WARNINGS .............................................................................................................. 3
PREPARATION ..................................................................................................................................... 4
NOTES ON USE AND OPERATION ...................................................................................................... 4
MAINTENANCE ..................................................................................................................................... 5
TROUBLESHOOTING .......................................................................................................................... 5
FEATURES AND SPECIFICATIONS ..................................................................................................... 5
REPLACEMENT PARTS ....................................................................................................................... 6
WARRANTY ............................................................................................................................................ 7

3
MANUAL - RECLAIMING SAND BLASTERS - UR007 SERIES Revised 2023-05
INTRODUCTION
Uni-ram holds many patents on designs used in its innovative products. Every machine is rigorously
tested for compliance with stringent Quality Assurance standards. Follow the notes on preparation, use
and operation to operate this machine safely and eff ectively. Ensure that this manual is readily available
to the operator at all times. If you have any questions about the operation of this machine, contact:
North America:
Uni-ram Technical Service
1-800-417- 9133
Other Continents:
Contact Your Supplier
CAUTIONS AND WARNINGS
• Wear safety glasses and follow all local safety regulations.
• Do not leave the unit unattended when plugged in. Unplug from outlet when not in use and before
servicing.
• To reduce the risk of electric shock, do not use outdoors or near water or wet surfaces.
• Do not use with a damaged Power Cord or Plug. If the unit is not working as it should or if it has been
dropped, damaged, left outdoors or emersed into water, contact Uni-ram for service instructions.
• Keep the Power Cord away from heat.
• Do not use without a fi lter.
• Turn off the Power Switch before unplugging.
• Use only a properly installed, grounded outlet.
• The fi lter is water resistant and washable in water. Do not use high pressure air or solvents to clean it.
Cleaning with a soft brush is recommended.

4
MANUAL - RECLAIMING SAND BLASTERS - UR007 SERIES Revised 2023-05
PREPARATION
Note: Item numbers given below refer to the parts listing on page 6.
1. Check for transportation or handling damage.
2. Lay the carton on its side and wheel the unit out. Do not stand it back up until Step 9.
2. Make sure all parts and accessories are included.
3. Remove all packing material.
4. Remove the Vacuum Head Assembly and the Debris Container.
5. Remove the two items stored underneath the Debris Container during shipping: Tubular Handle,
Gun+Head Assembly.
6. Install the Tubular Handle with the nuts and screws provided (see picture on Page 6).
7. Remove the Hose Assembly from the bag and insert the Abrasive Hose (the smaller of the two
hoses), which protrudes past the Vacuum Hose, through the hole at the back of the unit. Connect it to
the air outlet underneath the base of the unit.
8. Connect the Vacuum Hose to the connecting outlet on the container. Stand the unit back up.
9. Pour 20-40 LB (11-18 kg) of abrasive through the strainer at the bottom into the Abrasive Container
underneath. It is not necessary to remove the strainer.
10. Connect the Vacuum Hose and Abrasive Hose to the Blast Head and the Air Line to the Blast Gun.
Use the white clamp provided for the Abrasive Hose.
11. Re-insert the Debris Container.
12. Re-install the Vacuum Head and clamp in position.
13. When ready to operate, connect the Power Cord and turn on the Power Switch.
NOTES ON USE AND OPERATION
1. Use Air Pressure between 75 and 100 PSI depending on the surface to be cleaned.
2. Air Volume should be between 8 to 22 CFM (optimum: 16-20 CFM).
3. Use one hand to hold the Blast Gun and the other to hold the Blast Head as shown below.
4. Do not press downwards - the brush’s function is to reduce the escape of abrasive and to maintain a
vacuum for the effi cient recycling of the abrasive.
5. Move both hands in the same direction.
6. The blast area may be varied by lengthening or shortening the nozzle with the Lock Bolt (Item 30,
Page 6).
7. Careful placement of the brush over the area to be cleaned is very important. The bristles
should be spread out so that the abrasive spray inside does not impact the bristles. This precaution
will preserve the bristles, improve the vacuum eff ect, create better coverage and utimately result in
better savings, safety and results.
8. The fl at 1-1/4” brush (Part No. 27-611) is supplied with the unit. Four additional specialty brushes are
available. The same precautions should be followed when using these brushes.
9. When working on a 90° corner, alin the gun at a 45° angle to reach the deepest area. Move the gun in
a slow rotating motion for the best results.
FILTER PART NO.
27-180 STANDARD
27-172 HEPA

5
MANUAL - RECLAIMING SAND BLASTERS - UR007 SERIES Revised 2023-05
MAINTENANCE
1. After each use, knock the dust off the fi lter and after one hour of continuous use, lift off the Vacuum
Head and check for dust accumulation. Clean the fi lter with a soft brush, vacuum or low-pressure air.
MODEL UR007 (YJ/YZ) UR007-YEXP
VOLTAGE 100-120V 200-240V
WATTAGE 1350W 1350W
FREQUENCY 50/60 HZ 50/60HZ
SHIP SIZE (WDH) 20X18X45” 20X18X45”
STANDARD HOSE 8.5 FT (2.5m) 8.5 FT (2.5m)
FILTRATION CARTRIDGE CARTRIDGE
SHIP WEIGHT (LB/KG) 69/31 69/31
FEATURES AND SPECIFICATIONS
Uni-ram Reclaiming Sand Blasters allow sandblasting without personal breathing apparatus, face
masks or separate dust removal. The abrasive media are recovered and re-used continuously for
a 92% reduction in media consumption.
• Can be used with most abrasives including: • Air fl ow: 8-22 CFM
glass beads, metal shot, aluminum oxide, • Air pressure: variable to 150 PSI
nut shells, plastic pearls, baking soda etc. • Fume grade fi lter standard, HEPA available
• Uses standard air fi ttings • Motor Speed: 19,600 RPM
SYMPTOM CAUSE AND REMEDY
Decrease in blast performance Low air presure. Check compressor and hose connections for
leaks. Check CFM and PSI input.
Moisture in the abrasive.
The air supply must be clean and dry.
Abrasive is worn or too fi ne and does not cut the surface.
Vacuum Filter needs cleaning; debris collects with the media.
Gun blockage. Disconnect air and power, unscrew nozzle, use a
paper clip or thin wire to clear the passageway.
Decrease in vacuum performance Filter needs cleaning.
Check vacuum lines for blockage or leakage.
Check CFM input.
Abrasive escapes from between
bristles of brush
Air pressure is too high.
Check vacuum lines for blockage or leakage.
TROUBLESHOOTING

6
MANUAL - RECLAIMING SAND BLASTERS - UR007 SERIES Revised 2023-05
REPLACEMENT PARTS
GUN + HEAD
ASSEMBLY
27-500
OPTIONAL
BRUSHES
ITEM PART NO. DESCRIPTION
1 Z9852 Moulding, Head Cover
2 20-101-Y Head Cover
3 27-100S Vac Head Assy, Complete, 120V
4 110-313 Pull Handle
5 27-129* Motor Brush
6 KIT-26123 Vac Motor Kit, 1350W, 120V
6.1 KIT-26127 Vac Motor Kit, 1350W, 240V
6.2 KIT-26125 Vac Motor Kit, 1350W, 100V
6a 27-151 Power Cord Assembly, 16’, CSA
7 27-103 Gasket Motor Mount
8 27-131 Power Switch 120V
8.1 27-132 Power Switch 240V
9 27-141 Neon Lamp 100-120V
9.1 27-142 Neon Lamp 220V
10 27-112 Thermal Separator Plate
11 27-193 Vacuum Head Seal Gasket
12 27-218 Rim Clamp
13 27-180 Filter, Regular
13.1 27-172 HEPA Filter
14 25-215 Debris Container
15 27-217 Tubular Handle
16 27-710 Vacuum Hose Assy (8 )
16.1 27-712 Vacuum Hose Assy (10 FT)
16+18 27-700 Complete Hose Assembly, 8’
17 27-721 Hose End Cuff , 1.5”
18 27-731 Abrasive Feeder Hose (8 FT)
18.1 27-732 Abrasive Feeder Hose (10 FT)
19 27-230 Abrasive Screen
20 Included with screen
21 27-390 Wheel, 6” Heavy Duty Industrial
22 27-381 Axle Shaft 1/2” x 18” ZP
23 Wheel Cap, included with wheel
24 27-378 Swivel Caster, 2” Wheel
25 20-250 Impeller Assembly
26 20-210-Y Body Tube Assembly
27 U5047 Blast Gun Assembly
27+31 27-500 Blast Gun+Head (U5047+27-570)
28 51-252 Air Jet, 1/8” ID for Blast Guns
29 52-055 Steel Blast Nozzle
29.1 52-020 Ceramic Blast Nozzle
29.2 52-010 Carbide Blast Nozzle
30 27-513 Lock Bolt, 1/4” x 1/2”
ITEM PART NO. DESCRIPTION
31 27-570 Blast Head incl. Brush (27-611)
32 27-571 Blast Head without Brush
33 27-512 O Ring, D330
34 27-611 Flat Brush 1-1/4”, Standard
34.1 27-612 Flat Brush 1-3/4”, Optional
36 27-621 Inside Corner Brush (90º Male)
37 27-631 Outside Corner Brush (90º Female)
38 27-650 Brush and Holder (for thin edges)
27-914 Abrasive, #60, 25 LB Pail
51-270 Valve Stem Assy for U5047
* For units purchased before 2005-12, call before ordering

7
MANUAL - RECLAIMING SAND BLASTERS - UR007 SERIES Revised 2023-05
Full Product Warranty
These Uni-ram products have been engineered and manufactured to high performance
standards. Each unit has been subjected to detailed factory testing before shipment.
This product comes with a one-year full warranty from the date of purchase. Uni-ram
Corporation reserves the right to repair or replace the unit, free of charge, to the original
purchaser if a part is found to be defective in material or workmanship as determined
by factory service personnel. The items listed below under “Conditions of Warranty” as
consumables are not covered.
Uni-ram reserves the right to direct the customer to ship the unit collect to the Uni-ram
factory or to an approved Service Center for repair using the Uni-ram Return Goods
Procedure or to repair the unit on-site. To prevent damage in transport, the purchaser
must ship the unit in the original packaging or use alternate adequate packaging. All
units must be shipped clean and free of solvent.
Conditions of Warranty:
As Uni-ram Corporation has no control over the working conditions or circumstances
under which the purchaser stores, handles or uses the product, Uni-ram makes no war-
ranty or claim, either expressed or implied with respect to this product’s fi tness for any
purpose or the result to be obtained from its use. This condition applies to the sale of all
products and no representative or distributor of Uni-ram Corporation has the authority to
waive or change these conditions.
This warranty applies only to the original purchaser and does not apply if the unit has
been misused, overloaded, neglected, altered or used for any purpose other than those
specifi ed in the operating and installation instructions. Deterioration due to normal wear
is not covered by this warranty. Damage due to accident, transportation, fi re, fl oods
or acts of God is also not covered. Units whose serial numbers have been altered or
removed are not covered. The warranty is invalid if unauthorized abrasives are used in
this unit. Unauthorized attempts at self-repair or alterations by the owner also invalidate
this warranty. Interior or exterior fi nishes are not covered by this warranty.
Consumable Items are not covered by this warranty.
This warranty replaces all other warranties expressed or implied by statute or otherwise.
To make a claim, call Uni-ram Service at 1-800-417-9133 and quote the serial number
of the unit.
