USER MANUAL(UG - 230)
Double Safety System Against Fire
Electric Shock Prevention System
Human Detection System
Imaginary Code System to prevent
exposure secret code
1. To touch [Numeric Keypad]
Touch the [Numeric Keypad]
2.To enter the secret code
Double security mode
Success : "Biriri"
Success : "Biriri"
Press [*] button after enter the secret
code being light on all the numerickey pad
The secret code should enter after numeric lamp turns on,
and if numerice lamp off during entering code, then
please touch [Touch Keypad] and enter secret code again.
After wrong codes are entered 3times in a the keypad will
become inactive for half a minute with a alram "Biriri Biriri Biriri"..
Press [*] button after
enter the secret code being
light on all the numeric keypad
The light comes on any 3 numeric
button, then just press them regardless
in oreder
Fail : "Biribiri"
Fail : "Biribiri"
"Bibi"
CAUSION
Note
"Biriri"
Normal mode
Warning
For safety precaution is to ensure the safety of the user
due to accident, property damage and prevent inconvenience.
Please should read before use it.
Do not clean the product with flammable
materials such as alcohol, benzene or
thinners. Such materials may damage the
surface or cause a fire.
Pleae change all the batteries within 7 days
after hear first melody to change battery.
Product composition may be subject to change depending on the installation environment.
Note
"Biririk" "Biriririk"
"Bibi"
"Biriri"
Close the door by Electronic 1. Press [Register] Button
3. Finish to Register
Close the door by Mechanical
Open the door by Electronic
Open the door by Mechanical
Press [Open/Close] button to open
being deadbolt locked
Turn manual knob
to open being deadbolt locked
Press [Open/Close] button
to lock the door in manual mode
after closed the door
Press [Register] button shortly after
open the battery cover.
Press [Register] button to set on
Turn manual knob
to close after the door closed
User Manual/ Product Warranty / Installation
Template / AA LR6 Battery 4pcs / Screw
As this is a keyless digital door lock, damage may occure to parts of
the dead lock system if it is not used according to the manual,
Users should be fully aware of the manual and how to operate this
product.
Touch registered the digital key or the smart tag at the touch plate or tag touch
point where on the front ass'y
The product set to double security mode from origianlly purchased.
Please refer "how to set double security mode" if you want to change
normal mode.
Back Ass'y
Sensor Ratch
Deadbolt
Manual Knob
Press [Register]
button shortly afte
open the battery cover.
Enter a new secret
code(3~20 digits)
Press [Register]
button to set on
Open/Close Button
Auto/Manual
Switch
Volume Switch
Register Button
Double Lock Button
For the Emergency use : if Open/Close
button is not working, then just turn to
open by finger
Press slightly battery cover and push to the direction of the arrow to open.
please use secret code over 6 digits to prevent exposuresecret code
(Can be used the numeric 0 ~ 9 only).
Do not exposed secret code to any 3rd person. For this, you
should change secret code regularly.
Automatically delete existing secret code after registering a
new secret code
You should check what a new secret code is register
properly or not before close the door.
It can be registered several smart tags, you should touch
continuously smart tag within 7second after starting to register
first digital smart tag, and it will set up automatically after 7 seconds.
To confirm the register properly or not with the door open.
It will be automaticall deleted all existing digital keys or smart tags if register
new one, therefore you should register in once time up to 50pcs each of them
The secret code can register between 3 to 20 digits and 1 secret code can use
Strike & Strike Spacer
Mounting Plate
CAUSION
Touch registered the dingital key or smart tag key on the teg
touch point affer that door open you may open
To Open theDoor From Outside
(Smart Tag)
1. Press [Register] Button 2. Enter a New Secret Code 3. Finish to Register
If the smart tag have problem with automatic recognition
on the touch plate, then please touch again after Touch Keypad
Caution for Safety
Do not disassemble or alter the lock.
Do not install where the distance over
5mm between the door and door
frame.
Please do not expose the secret code
and change the secret code in regularly.
Batteries should npt be exposed
directly to heat sources or flames, or
submerged in water, because they may
leak or explode, resulting in severe
damage. Please do not use damaged
batteries.
Do not press using sharp tools or press
numeric button excessively
Please do not mix old with new batteries or
use different types.
Always use new alkaline batteries.
Please make sure the batteries are inserted
correctly(+/-) as indicated in the battery
component. Otherwise, it ay cause a leaks
or explosions.
Product Composition
To Open/Close the Door From Inside
Specification(Front Ass'y)
Specification(Back Ass'y)
Register Secret Code
To Register Digital Key / Smart Tag
Note
To Open the Door From Outside (Secret Code)
Diecasting Alloy
High Quality Individual Lighting
Touchpad
Double Security System
To Open the Battery Cover
UG-230 :Secret Code + Digital Touch Key (2W)
UG-230S :Secret Code + Smart Card (2W)
UNICOR HIGHTECH CO., LTD www.unicor.co.kr
UG230S
UG230
Front Ass'y Front Ass'y
Success : "Biriri"
Fail : "Biribiri"
Numeric Keypad
Emergency power
supply Terminal
Touch
Point
2.Touch Digital Key or Smart Tag
Touch the digital key or smart tag at the
touch plate or touch point

Mute Mode Function
External Forced Locking Set/Release
Warning/Emergency Sound Release
To Set/Release Double Locking
Human Body Detection Function Set/Release
Intrusion/Breakage Alarm Function
High Temperature Warning System
Product Specifications
This function is any of the three numbers to authenticate after enter
registered secret code for exposure secret code to the other person
To set
To release
External Forced
Locking Set
External Forced
Locking Release
1. Touch [Numeric Pad] 2. Press [#]
3. Enter Secret Code 4. Press [*]
Fees
Within a month after purchase
Within a year after purchase
Same defect repeats 4times
Can not repair by Manufacturer
No failure product
Destroyed product
due to lost secret code
Consumer's error
and carelessness
Wrong battery inserted
Product failure ordamage
due to the use of the
product other than
original purpose.
Re-install product by
door deflection or wrong
installation
Requests check
whether over product
without apparent failure
symptoms
No failure product Consumer's error
and carelessness
Repair with fee
Due to water infiltration,
moisture condensation,
chemical injection, and in
case of a circuit failure
inside the product
Failure and damage
caused by natural
disasters such as fire,
flood, salt.
Consumer's error and carelessness
Wrong installation and other
Our warranty valadity is a year from product purchasing date.
We will charge you even warranty period if in case of repair with
charge( Service Call Charge + Royalties + Components Cost).
When you apply for a service, you should present the product warranty,
installation information listed.
If you don't have product warranty, you can replace purchase receipt,
card slips, cash receipt(Simplified receipt disapproval)
If it can not prove the date of purchasing, then it will be recognized by
date of manufacture + Expiration date(6 months)
Within warranty
Replacement
Free Repair
Free Repair
Replacement
Repare with fee
Replacement
Repare with fee
Over warranty
Press [0] after touched
numeric pad in the locking
state.
It will release automatically if
using registered digital key or
smart tag and secret code from
outside
1. Press [Register]button 2.Press [5]
2. Press [8]
3. Press [Register] button
1. Press [Register] button
3. Press [Register] button
To
Set
General
Compe-
nsation
Consumer's
mistake and
on purpose
To
Release
4. Enter secret code again
Description
Consumer's Erro and Carelessness Detailes
About Product Warranty
When replace the beep melody comes on
How to replace the battery
How to use emergency power
Purchasing square battery(6F22 / 9V),
Maual Auto
The [Manual/Auto] switch position
ishould be at [Manuall] or [Auto]
"bibi"
"bibi"
"bi"
"bi"
"bi"
"bi"
("biriri") ("bi~")
"bi" "bi"
"bi"
"bi"
Division
Front Ass'y
Back Ass'y
Strike
Battery 1.5V AA LR6 Alkaline 4pcs
AL Alloy Diecasting Distance of Sensor : 2cm
Up to 50pcs Register
Battery life span is for 10 months
based on 10 times to use a day.
Specification Remarks
Power : DC6V
Operating Temperature
: -20 ~ 60℃
Sensor Activate : at 60℃
"bi"
"bi"
Press [5] button
Press [8] button Press [Register] button
to end
Press [Register] button
to end
Press "6" button
In case you accidentally double locking set on, it can be released
double locking mode from outside.
It is designed to be totally silent during operation so as not to disturb the neighbor
It makes strengthen security in case of long-term outing.
It will be alarming if operate the device indoor side.
Remove out battery after opening the battery cover or touched
smart tag or enter secret code with press [*]
Double locking function is the door can not open from outside.
※The factory mode is original set(Release)
Press [Register] button
after open battery cover
Press [Register] button
after open battery cover
※The battery valadity can vary depending on batterymanufacturer, production date, using
environment andfrequency.
- If this system detect high temperatures, then it will activate an
alarm, and release door locking function to evacuate peoples
quickly(This function is basic system, therefore there is no setting or
releasing the function). It will activate at 60℃, it can vary depending on
the installation environment.
It will open the door within 5 seconds and alarm for 5 minutes
when it detect the high temperature(It will normal operation
when the temperature down normally).
* The door can be opened/closed by only human hands due to capacitive touch type
Press [4] button
The factory is not set up this function, please use after set up
The door is locked automatically or manually when the door closed
It can be control the beep volume when the door lock or unlock
- It will stop the system, if not change the batteries after the beep sounded
When it is time to replace the battery, and continue without replacing
the battery, the battery is discharged and the door lock not functioning
normally.
- Using alkaline battery only
While contacting the external emergency
power terminal with a 9V(6F22) square
battry, enter the secret code or contact
smart card
It will notice to replace the battery when those batteries getting
low voltage.
After the first beep is sounded, please replace all the batteries to
new batteries within 7 days.
Press [Register] button to
release double security system
Press [Register]
button after open the
battery cover
Press [Register]
button after open the
battery cover
Press [Register] button to
set up double security system
[4] button : Realse
[4] button : Realse
[6] button : Ste up
Double
Locking Set
Press [Doublelock]
button 3 seconds while the
door is closing
Turn [Manual Knob]to open
or press [open/close] button
Release
Double
Locking
[6] button : Ste up
Notice in danger state by alarm for 3 minutes due to remove out the
lock device by forced or breakage by abnormal way in door locked.
Others
CAUSION
5. Press [ ]
To Set/Release Double Security
To Set Auto/Maual Locking
Auto Locking : Automatically locking the door within 3 seconds
after the door closed
-
Manual Locking : Press [Open/Close] button after closed the door
in manual mode
-
To Set/Release Volume
To Replace Battery
The battery life span may differ according to manufacturer,date of
manufacture, using environment
(AA, Alkaline 1.5V 4pcs, Lifes pan :10 ~12 months if 10 times to
use per day )
Please check the batteries every 6 months to see if the
batteries are leaking, in this case , the product will be damaged
It can not change secret code, digital key, smart card after
battery replacement beep is sounded until replace new battery.
To Use Emergency Power(Battery)
Control the volume switch after open the battery cover
_
[0] = Mute(warning sound is keeping)
[1] = Mids, [2] = High
_
To Release Double Security from Outside
2. Enter Secret Code1. Touch[Numeric Pad] 3. Press [#]
(will apply depreciation rate)
KDL-230S
KDL-230S
Smart Tag 4pcs
UNICOR HIGHTECH CO., LTD
62 EunCheong Street, Namdong-Gu, Incheon, Korea (zip : 405-817)
http://www.unicor.co.kr
