Unicor UN-6500 Series User manual

•
The lifetime of the batteries is based on the result of the tests by the company and is not an absolute
measurement.
It will vary depending on the temperature and humidity of the installed locations as well as
depending on the frequency of usage and the quality of batteries.
•
The functions, design, and composition of the product may change without prior notification for the
purpose of improving its quality.
The precautionary measures are for the safety of the user, for the prevention of property
damage, and for the avoidance of any inconveniences due to an accident. These must be read
and followed properly.
Back ass’y and front ass’y Pads for the back ass’y and front ass’y
Touch keypad
Deadbolt
Latch Bolt
Data cable
※
Connect the cable according to the
indicated direction for the connection
terminal on the back ass’y.
※ Connect the cable according to the
indicated direction for the connection
terminal on the back ass’y.
※ They are assembled basically for the
right-hand mode. When the left-hand
mode is used, the user needs to
loosen the 2 fixing bolts and reverse
them at 180degrees and insert them
and fasten them again.
Handle
Mortise cable
Ratchet bolt fixing bolts
Emergency power terminal
Battery cover
The handle is a one-touch type product
developed by the company. When it is
installed successfully, the user just needs to
swing it down to open the door safely and
conveniently when moving from the inside
area to the outside area.
Battery insertion area
registration button
Volume switch
Manual knob
Safety plug (Sold separately)
Strike Handle Shaft Handle Shaft Stopper
User manual Installation manual
Installation manual
Product warranty
Mortise Battery 4pcs Assembly bolts
•Do not disassemble or alter the lock.
•Do not install where the distance over
5mm between the door and door frame.
•Please do not expose the password and
change the password in regularly.
•Batteries should not be exposed directly to
heat sources or flames, or submerged in water,
because they may leak or explode, resulting in
severe damage. Please do not use damaged
batteries.
•Do not press using sharp tools or press
numeric button excessively.
•Make sure the door is completely locked when
going out.
•Place the batteries carefully and correctly according
to their polarity (+/-). If the batteries are inserted
in a wrong way, differently from the indicated
direction or polarity, leakage or rupture could occur.
Pay attention to it.
•Please do not mix old with new batteries or use
different types.
Always use new alkaline batteries.
•Do not clean the product with flammable materials
such as alcohol, benzene or thinners.
Such materials may damage the surface or cause
a fire.
•Replace the current batteries with new ones within
1 week after the battery replacement notification
melody sounded off for the first time.
Safety precautions
Product composition
Front ass'y
Mortise
Back ass’y
Locking the door from the outside.
Locking the door from the inside
Registering and changing thepassword
Warning
Caution
▶
When the auto lock function isset
▶
Opening the door byusing the password
▶
When the manual lock function isset
Caution Caution
Caution
Caution
Attention
Attention
Upon shipment, the function is set to default. When the door isclosed, it willbe automatically
locked within 3secondsdue to the function ofthe auto lock sensor.
Touch the keypad. Then, the door willbe locked.
Touch the keypad and enter the password and press the [*]button. Then, the door willbeopened.
Warning alarm
When an incorrect password or unregisteredsmart tag is entered 3timesor more, the security alarm
function will beactivated, generating an alarmsound of80dB or higher for 30 secondsand stopping
the systemoperation for 30 seconds.
Deleting the smart tag (card)
①Open the battery cover and short press the [Registration]button one time (A short signal sound
“Bibi”will be generated).
②Press the number [0] button ofthe front ass’y keypad for 5seconds.
③Then, asound “Biriri”will be generated for notifying that the deletion is completed.
※ When the smart tag (card)that the user currently carriesisregistered againfollowing loss ofthe
previousone, the previousone will be deleted while only the currentlyregistered one can be used.
Auto re-lock function
If the user doesnot enter the premise within 7secondsafter unlocking the door fromthe outside by
using the password or the key, or ifthe user doesnot go out within 7secondsafter unlocking the
door by pushing the door handle down, the auto re-lock function will be activated, causing the door
to be automatically locked.
•When it is needed to check the password, it isrequired to keep the door open and touch
the keypad to let the deadbolt come out. In thisstate, when the user entersthe registered
(new)password, the deadbolt will be retrieved as long as the door lock isin normal
condition.
•If no password isentered within 7secondsafter the [Registration]button ispressed, the
registration process will be cancelled while an error sound “Biriri~”isgenerated.
•Upon shipment, the password “1234” isset to default. Once the product isinstalled,
the password must be replaced with anew one for using the door lock.
•Do not let othersknow thepassword. Change it periodically.
•In preparation for an emergency situation in which there isno way to enter the locked
premise due to loss ofthepassword, it isrecommended to carrythe smart tag
(card)(Required to register it)always, or keep it in asafe area(in acar).
• Even when apassword ischanged, the existing smart tags(cards)can be used without
going through an additional change process.
• When the batteriesare replaced, the existing password willnot be deleted due to the
function ofmemory.
• When anew password isregistered, the previousone will be automatically deleted.
•
•
It ispossible to register up to 50pcsofsmart tag (card)in the door lock.
When userswant to purchase additional smart tags(cards), they can purchase themfromthe
selling shopsor the company’scustomer support center and register them.
The wait time for registering asmart tag (card)isabout 7seconds. When 7 secondspass,the registration
sound will not be generated, requiring the user to go through the registration process again(Example:When
there are 4pcsofkey, they need to be registered consecutively).
I•
•
fthe user lost any one ofthe smart tags(cards) that the user currently carries, the user isimmediately
required to utilize the function ofdeleting or neutralizing the smart tag (card)to prepare for possible
securityaccidents.
Usersare wholly responsible for all the damage due to exposure or loss ofthe password
the smart tag (card). Usersneed to take extraprecautionsinkeeping them safe.
•Once the [Registration]button ispressed, ifthe smart tag(card)isbrought into contact within
7seconds, an error sound “Biriri~”will be generated,cancelling the registration process.
When the registration iscompleted, while the door isopened, the user must check whether
the door lock worksnormally.
• If an error sound isgenerated, during the registration process, for notifying that the time
limit isexceeded, it isrequired to start the registration process fromthe initial stage.
Right-hand door: Opening the door from the outside by pushing or pulling it with the right hand.
Left-hand door: Opening the door from the outside by pushing or pulling it with the left hand.
※
Upon shipment, the right-hand door mode is set to default, meaning that there is no need to go
through the setting process when installing it for a right-hand door. If the door is a left-hand type,
it is required to change the direction of the ratchet bolt of the mortise. Otherwise, the door will not
be closed.
1. Press the [Registration]button1. Press the [Registration]button
While the door isopened, open the battery
cover ofthe back ass’y, and press the [Register]
button one time (A short starting sound
“Bibi~”will be generated).
While the door isopened, open the battery
cover ofthe back ass’y, and press the [Registration]
button one time (A short starting sound
“Bibi~”will be generated).
Press the [Registration]button after entering
the password. Press the [Registration]button after registering
allsmart keys.
Enter the new password through the keypad
ofthe front ass’y. 3~20 digitsofnumbers,
except for the [*]and [#]buttons.
When the password isregistered normally,
amelody “Biriri” willbe generated, completing
the registration.When the password isregistered normally,
amelody “Biriri”will be generated, completing
the registration.
3. Press the [Registration]button 3. Press the [Registration]button
2.Enter the new password for registration
(3–20 digits).
4. Complete the registration. 4. Complete the registration.
Bring smart tags(cards) into contact at the touch
plate ofthe front ass’y in order. When each of
themisregistered normally, ashort signal sound
“Bibi~” willbe generated.
2.Register new smart tags(cards).
▶
Opening the door byusing the smart tag (card)or Mechanial keycylinder.
Registering(again) the smart tag (card)
※ The Smart tag need to be purchased separately.
Keyhole for the Emergency key
For UN-6500K & UN-6500 SK
model only
Open Close Close Open
Touch plate UN-6500 S / SK
* The smart tag needed to be
purchased separately.
Panic release function with handle
After 3 seconds
Insert the keyinto the keyhole
and turn it to open the door.
Bring the registered smart tag into contact
atthe touch plate.
UN-6500 Series User manual
UNICOR HIGHTECH CO., LTD
www.unicor.co.kr
As this is a keyless digital door lock, damage may occur
to parts of the dead lock system if it is not used according
to the manual. Users should be fully aware of the manual
and how to operate this product.
Caution
-This manual may change without notice in case of product improvement.
-This manual may not be edited or changed without the manufacturer’s prior permission
- Product specifications are subject to change without prior notice.
UN-6500N
UN-6500SK UN-6500K
UN-6500S

12
11
10
789
Locking the door from theinside Setting theauto/manual lock function Warning the jam of the deadbolt
High-temperature warning system in
Volume control
Mute function
Opening the door from theinside
Setting and releasing the double security mode
Forced lock from the inside
Forced lock from the outside
Auto setting of the handtype
*The lifetime ofthe batteriesis based on the result ofthe testsbythe company and is not an absolute
measurement. It will vary depending on the temperature and humidity ofthe installed locationsas well
as depending on the frequencyofusage and the quality ofbatteries.
*The functions, design, and composition ofthe product may change without prior notification for the
purpose ofimproving itsquality.
▶ When the auto lock function isset ▶ When setting the auto lock function
▶ High-temperature warning
▶ Releasing the high-temperature warning
▶ Opening the door by using the handle
▶ Setting
▶ Setting
▶ Activated
▶ Setting
▶ Releasing
▶ Unsetting
▶ Unset
▶ Unsetting
▶ When the manual lock function isset
▶ When setting the manual lock function
▶ Opening the door by using the manual knob
Open the battery cover and press
the [Registration]button.
Open the battery cover and
press the [Registration]button.
Press the number [6] button.
Press the number [4] button.
Button 4: General mode
Button 6: Double security mode
Press the [Registration]button
to set the double security mode.
Press the [Registration]button
to set the general mode.
After 3 seconds
MuteGeneral
soundHigh-pitched sound
When the door isclosed, it will
be automatically locked within
3secondsdue to the function
ofthe auto lock sensor.
①Short press the [Registration]button one time (a short signal sound “Bibi”willbe generated).
②Press the number [7] button.
③Press the [Registration]button.
④Then, the auto lock function willbe set while asound “Bi” isgenerated for notifying
ofcompletion (*Upon shipment, the function is set to default).
①Short press the [Registration]button one time (a short signal sound “Bibi” willbe generated).
②Press the number [9] button.
③Press the [Registration]button.
④Then, the manual lock function will be set while asound “Bi”isgenerated for notifying
ofcompletion.
Pull the handle ofthe back ass’y down
slightly. Then, the anti-panic function will
be activated, disabling the locked state and
opening the door.
Each time the user turnsthe manual knob to the left
or right direction, the door will be opened and closed
accordingly.
The double security mode preventsapassword frombeing exposed. In thismode, the user needsto get 3
additional randomnumbersauthenticated after entering the initial password
(*Upon shipment, the mode isnot set. It isrequired to set the mode before using the product.)
While the door isin the auto lock mode, if the door is
opened, this function willnotify ofthe opened state
to the user. A signal sound “Bibi~”will be generated
two timeswith an interval of7 secondsto notify ofthe
opening.
While the door islocked, open the battery cover ofthe back
ass’y and press the [Registration]button for 3seconds.
Then, the function willbe set while asetting sound “Biriri”
will be generated.
1. Fromthe inside
Pull the handle down fromthe inside. Then, the panic release function
will be activated, making it possible for the user to exit by opening
the door normally while the forced lock function isautomatically disabled.
Press the [Registration]button for 2secondsor longer. Then, the forced lock
function can be also disabled.
While the door islocked, touch the keypad ofthe front ass’y,
and press the [*]button and press the number [0] button for
5seconds. Then, the forced lock function will be set while a
setting sound “Biriri~”will be generated.
While the door isclosed, ifsomeone triesto enter
illegally or break in, causing some change in the locked
state or in the normal installed state, the function will
be activated.
1. The alarmwill be disabled when going through the
authentication process using the registered Password or
smart tag (card).
2. The alarmwill be also disabled when the power isreset.
If the door is unstable due to impuritiesin the door frame, the deadbolt may come out
while the door isnot closed completely, causing an unauthorized entry alarmto be set off.
Considering this, usersmust check the operating state ofthe deadbolt ofthe digital door
lock before opening and closing the door. Usersneed to understand how to disable the
unauthorized entry and damage alarm.
There isno need to go through an additional registration process when installing the product initially
or relocating it. When the batteriesare removed and placed back again, the product will recognize
the hand type automatically, making it easy to set the function completely.
When the registered secret code isentered, or when the registered
smart tag (card)isbrought into contact, opening the door normally,
the forced lock function willbe automatically disabled.
2. Fromthe outside
In preparation for asituation in which elderly people or kidsset the forced lock function fromthe inside
accidently, there isa function available for unsetting the forced lock mode fromthe outside.
①Touch the keypad and press the [
*
]button →② Enter the registered secret code.
→③ Press the [#]button→④ Enter the registered secret code again →⑤ Press the [
*
]button
Then, door will be opened, disabling the force lock function.
Turn the manual knob to the left or right direction.
Then, the door will be opened.
Open Close Close Open
M
a
n
u
a
l
k
n
o
b
Open Close Close Open
M
a
n
u
a
l
k
n
o
b
“Bi”“Bi”
What isthe manual lock function?
The function will be very useful for officeswhere people enter and exit frequently. In thismode,
the door will not be locked even when the door isclosed. While the mode ismaintained, userscan
lock the door by pressing the [*]button to lock the when leaving the office for abusiness trip or leaving
for home, and theycan enter the office byopening the door by entering the secret codesor using the
digital touch keysor smart tags(cards) when coming back fromabusiness trip or showing up for the day.
It isalso possible to shift to the auto lock mode easily at any time.
What is the mute function?
The mute function isto temporarilycontrol the operating sound to open
the door quietly when needed to use the door at an apartment or a
common housing by entering the secret code without causing other people
to suffer fromthe operating sound at night.
Information
65°C±5°Cis not an absolute measurement for deciding whether the current
temperature is high or low. The reference value may vary depending on the mechanical
conditions. When the high-temperature warning systemisactivated, the door will be
automatically opened even when the forced lock function is set.
Open the battery cover and shift the volume switch to 0, 1and or2
individually for mute, general sound and high-pitched sound.
※
Upon shipment, level 1for general sound isset to default.
In asituation where the door cannot be locked normallyeven
when it is closed because ofthe jam ofthe deadboltwhile coming
out due to abnormal installation andirregularitieswith the door,
this function will notify ofthe problem to the user. If the user keeps
failing to lockthe door 3times, amelody“Biriri~ Biriri~ Biriri”
willsound off.
What is the high-temperature warning system?
When the product detectstemperature of65°C±5°C due to afire inside the locked premise, a
warning sound of80dB or higher will be generated and the door willbe automaticallyopened
within 5seconds. In addition, the manual knob is mounted according to the KS standards, making it
possible for people to escape the locked premise by using it simply in an emergency situation like a
fire with enhanced safety.
What isthe forced lock fromthe inside?
When all the family membersare already in the house, thisfunction makesit possible to maximize
the level ofsecurity bystopping the operation ofthe front ass’ytemporarily in order to enhance security.
-
When the function isset, it will be impossible to open the door fromthe outside even by using
the registered password or smart tag (card).
※ In preparation for an emergency situation, it isstill possible to open the door fromthe outside by
using the emergency keyeven when the forced lock function is set.
What isthe forced lock fromthe outside?
Thisfunction helpsenhance the level ofsecurity when the user has to leave the premise for along
period oftime. If someone triesto drill ahole in the entrance door or the fireproofdoor and insert
some instrument inside the premise to move the anti-panic handle down or operate the manual
knob to enter the premise illegally, apowerful warning sound of80dB or higher will be generated to
prevent the unauthorized entry ifit isattempted.
Trespass /Breakage alarm
What isthe forced lock fromthe inside?
While the door isclosed, ifsomeone triesto break in or enter illegally by opening up agap in the
door, causing the deadbolt to be removed forcibly fromthe auto locking sensor, thisfunction will
generate avery powerfulalarmsound of80dB or higher for 3minutesto notify ofthe dangerous
situation.
The function will be activated when the temperature sensor, which isinstalled on the back ass’y,
detectsheat (About 65°C).
The operating state will varydepending on the environment and state ofthe installation.
The warning state will be disabled when 3minutespass after the alarmsound isgenerated initially,
or when the power isreset.
Caution
*Details of mistakes and mishandling by the user
Types of consumer damage Content of compensation
Within the warranty period After the warranty period
The product
is used in
normal
conditions
Failure occurs within 1 month from date of purchase
Failure occurs within 1 year from date of purchase
Same failure occurs 4 times or more
The repair parts are not available at the main office
Product replacement
Free-of-charge repair
Free-of-charge repair
Product replacement
Paid repair
Replacement after depreciation
based on a fixed rate.
Mistakes and
mishandling
by the user
Not the case of failure
Mistakes and mishandling by the user
Defective installation, and other reasons
Paid repair
Not the case of failure
Mistakes and mishandling by the user
Other reasons
When needed to break the
product due to the loss of
secret code.
When the door is sagging,or
installation is defective,requiring
the product to be reinstalled.
Request for checking the product
for possible problems while
there is no specific symptom of
a failure.
Problems in operation occur after
the user installs the product
directly.
A visit for repair is needed as
there are mistakes and mishan
dling by the user such as mistakes
in replacing batteries and unskill
ful use of the product.
Defective operation due to poorly
inserted batteries and use of
defective batteries.
Failure and breaking due to the
use of the product for other
purposes.
Failure and breaking caused by
the user on purpose or from an
external impact.
Failure and damage due to natu
ral disasters such as fires, floods,
and damage from sea water.
Penetration by water, condensa
tion and injection of chemicals,
requiring the internal circuits to
be replaced,and causing failures.
How to use
Touch the keypad and then press the [#]button, the secret code and the [*]button in order to set
the mute function that willprevent the operating sound frombeing generated.
Example ofusage:When the secret code is 1234.
•Normal mode: Touch the keypad and then press the secret code and press the [*]button.
Then, the door willbe opened with amelody.
•Mute function: Touch the keypad and then press the [#]button, the secrete code and the [*]button.
Then, the door willbe opened quietlywithout amelody.
Standard of the product
Front ass’y
(Front body)
Back ass’y
(Main body)
Smart tag (card)
Battery
Remarks
Rated voltage: DC 6V
Working temperature: -20
℃
to 65
℃
Sensor working temperature
(High temperature): 65
℃
73W X 170H X25D mm
73W X 170H X30D mm
Purchase separatly / Possible to register up to 50pcs
Will run for about 10 months when used
10 times a day (6–8 months in case of card
models)register up to 50pcs
1.5V AA LR6 alkaline battery x 4
▶How to use the
function
After entering
78945 Enter 1234
Information
Entering trick numberstoprevent
exposurepassword
Even when another person iswatching nearby, thisfuction makesthe user to enter an trick
numbersbefore entering the real password.
When the password is 1234 the user
just needs to enter the real password
1234 at the end, after the trick munbers,
78945 is entered.
The total entering number of digits combining the trick munber and real password
should be 3~20 digits.
When the batteries need to be replaced, a melody“Open the east, east,east gate~ Open the
south, south,south gate” will sound off when operating the product.The melody lets the user
know about the need for replacing batteries
If the melody sounds off when operating the system,it is required to immediately open the battery
cover of the back ass’y, and replace all the batteries (4pcs) with new genuine 1.5V LR6AA alkaline
batteries that can be purchased at nearby stationary stores or convenience stores.
Must use general batteries, not rechargeable ones.
Take precautions in placing the batteries in the compartment in order to prevent leakage
or rupture that could occur when they are placed wrongly.
Must replace the old batteries all with new ones, not partially. Do not use new ones with
discharged ones together.
It is designed to operate with the rated voltage 6V.If low voltage (4.2±0.3V) is detected,
a melody will sound off.
After the replacement, if the door lock stops working in a short period of time or the batteries
are discharged, the batteries could be defective.It is required to contact the shop where the
user purchased batteries and get new ones as replacement ones.
Caution
External Emergency Power Supply
When the batteries of the door lock are completely discharged, making it impossible to open the
door from the outside by using the password digital touch key, or the card key,this function will
help supply the emergency power by using a 9V battery from the outside.
1) Purchase a 9V battery in a rectangular shape from nearby stationary
stores or convenience stores.
2) Bring the battery into contact at the 9V battery input terminal at the
bottom of the front ass’y, and the press the [
*
] button while maintaining
the contact. If thepower is supplied normally, a sound“Bibi~” will be
generated and the keypad will be turned on.
3) Enter the password and then press the [
*
] button, or bring the
registered digital touch key or smart tag (card) into contact.Then,the
door will be opened.
It isOK to bring a9V battery as an emergency power into contact regardless ofthe + and – polarities.
When it comesto akey type model, it ispossible to enter byusing an emergencykeyeven in thissituation.
That iswhy it isrecommended to carrythe emergency key usually or keep it in asafe place (in acar).
The emergency power can be supplied when keeping the 9V battery into contact at the input terminal
(not rechargeable)
Replace all the discharged batteries right after supplying the emergency power.
Information
Emergency key 2pcs (For UN-6500SK only)
UNICOR HIGHTECH CO., LTD
62 EunCheong Street,Namdong-Gu, Incheon,Korea (zip code. 21643)
http://www.unicor.co.kr
Warranty
◎The warranty period for all of the company’s products is 1 year from the date of purchase indicated
on the warranty certificate.
◎Even during the warranty coverage,users need to pay (the cost for trip,technical support and parts)
for some services if they are in the category of chargeable services.
◎User generally submit the warranty certificate or other methods that contains the installation
information when needed to request a service.
◎If the warranty certificate is not available,users need to submit a receipt, a credit card receipt or
a cash receipt instead (Except for a simple receipt)
◎If it is impossible to show the purchase date,the warranty period will be applied by taking into
consideration the product’s manufactured date + expiration period (6 months)
◎For products pruchased outside of Korea, please consult your local distiriboutor or reseller as warranty
policies vary from country to country.
