Uniden DECT2080 Series User manual

sheet 1
UNIDEN
CORDLESS
TELEPHONES
DECT2080 and
DECT2882 Series
UC536BV(DECT2080-2) OM.indb 1 3/24/2008 4:53:43 PM

1
Table of Contents
Welcome.......................................................................4
Accessibility.............................................................4
Terminology Used in this Manual.............................5
Manual Conventions................................................5
Product Overview........................................................6
Features...................................................................6
Answering System Features....................................6
Parts of the Phone...................................................7
Using the Interface......................................................9
Reading the Display.................................................9
Using the Four-way Function Key..........................10
Using the Handset Menus .....................................10
Entering Text from Your Handset........................... 11
Installing the Phone ..................................................12
Choosing the Best Location...................................12
Installing the Battery..............................................13
Installing the Belt Clip............................................14
Connecting the Base and Charging the Handset ..14
Connecting to the Phone Line ...............................15
Changing the Dial Mode........................................15
Wall Mounting the Base.........................................16
Basic Setup................................................................17
Selecting a Language............................................17
Activating Personal Ring........................................17
Activating the Key Touch Tone...............................18
Activating the Caller ID Phonebook Match............18
Expanding Your Phone .............................................19
Adding Accessory Handsets..................................19
Setting Up the Phonebook........................................22
Creating Phonebook Entries..................................22
Finding a Phonebook Entry ...................................23
Editing an Existing Phonebook Entry.....................24
Storing Caller ID or Redial Numbers in the
Phonebook.......................................................24
Deleting Phonebook Entries..................................24
Copying Phonebook Entries to Another Handset ..25
Using the Voice Mail Service....................................26
Resetting the Voice Message Waiting Indicator.....26
Customizing Your Phone..........................................26
Changing the Handset Banner ..............................26
Selecting a Ring Tone (Handset only)....................27
Activating AutoTalk.................................................27
Activating Any Key Answer....................................27
UC536BV(DECT2080-2) OM.indb 1 3/24/2008 4:53:43 PM

2
Using Your Phone......................................................28
Making a Call from the Phonebook........................29
Chain Dialing from the Phonebook........................29
Switching to the Handset Speakerphone
During a Call ....................................................29
Using Caller ID, Call Waiting, and Redial Lists.......30
Using the Caller ID List .........................................30
Making a Call from a Caller ID Record..................30
Deleting Caller ID Numbers...................................31
Using Call Waiting..................................................31
Redialing a Number...............................................31
Deleting a Redial Record.......................................32
Adjusting the Ringer, Earpiece and
Speaker Volume................................................32
Adjusting the Ringer Volume .................................32
Adjusting the Earpiece Volume..............................32
Adjusting the Speaker Volume...............................32
Adjusting the Audio Tone .......................................33
Finding a Lost Handset.............................................33
Using Hold, Conference and Transfer.....................33
Placing a Call on Hold ...........................................33
Conferencing .........................................................34
Transferring a Call .................................................34
Using Special Features.............................................35
Privacy Mode.........................................................35
Using the Intercom.................................................35
Muting the Ringer (One call only)..........................36
Muting the Microphone..........................................36
Seven-Digit Dialing................................................36
Tone Dialing Switch Over.......................................37
Line Mode Setup (Base only) ................................37
Installing the Optional Headset..............................37
Setting Up the Answering System...........................38
Using the Answering System Setup Menus...........38
Recording a Personal Greeting .............................38
Selecting a Greeting..............................................39
Deleting Your Personal Greeting ...........................39
Selecting the Language.........................................39
Setting the Number of Rings..................................40
Setting the Day & Time..........................................40
Setting the Record Time (or Announce only).........40
Activating the Message Alert .................................41
Activating Call Screening.......................................41
Setting a Security Code or
Personal Identication Number (PIN)...............41
Using the Answering System...................................42
Turning Your Answering System On and Off .........42
Reviewing Messages.............................................43
Screening Calls......................................................44
Turning Off the MessageAlert Tone.......................44
UC536BV(DECT2080-2) OM.indb 2 3/24/2008 4:53:43 PM

3
Operating the Answering System While You Are
Away from Home..............................................45
Maintenance...............................................................46
Specications.........................................................46
Battery Replacement and Handling ......................46
Cleaning the Battery Contacts...............................47
Low Battery Alert ...................................................47
Battery Life.............................................................47
Power Failures.......................................................47
Troubleshooting ........................................................48
Resetting the Handset...........................................48
Resetting the Handset Without the Base...............49
Traveling Out of Range..........................................49
Common Issues.....................................................50
Weak or Hard to HearAudio .................................51
Noise or Static on the Line.....................................52
Liquid Damage.......................................................53
Precautions! ..............................................................54
Rechargeable Nickel-Metal-Hydride Battery
Warning ...........................................................54
The FCC Wants You To Know ..............................55
I.C. Notice..............................................................56
One Year Limited Warranty.......................................57
Index...........................................................................58
Remote Operation Card............................................60
UC536BV(DECT2080-2) OM.indb 3 3/24/2008 4:53:44 PM

4
Welcome
Thank you for purchasing a Uniden Multi-Handset phone.
Note: Illustrations in this manual are used for explanation purposes. Some illustrations in this manual may differ
from the actual unit.
As an Energy Star®Partner, Uniden has determined that this product or product models meets
the Energy Star® guidelines for energy efciency. Energy Star®is a U.S. registered mark.
Uniden is a registered trademark of Uniden America Corporation.
Accessibility
Uniden provides a customer service hotline for accessibility questions. If you have a disability and need customer
service assistance or if you have any questions about how Uniden’s products can accommodate persons with
disabilities, please call the accessibility voice/TTY line: 1-800-874-9314.
Our customer care hours as well as accessibility information can be found on our website, www.uniden.com, under
the “Accessibility” link. If your call is received outside of our business hours, you can leave us a message and we will
call you back.
UC536BV(DECT2080-2) OM.indb 4 3/24/2008 4:53:44 PM

5
Terminology Used in this Manual
Standby The handset is not in use. If it is off the cradle, no line has been activated. No dial tone is present.
CID Caller ID is available from your Telephone provider and is offered to users on a subscription basis.
With this service, you will be able to see the incoming caller information such as name and phone number.
CID/CW or
CIDCW Caller ID with Call Waiting is available by subscription from your Telephone provider. With this service, you will be able to view incoming caller information while on a call with another user.
Base The main part of the phone that connects to your phone line and lets you make and receive calls.
Charger A cradle that comes with an accessory handset and charges the handset battery.
It connects to power but does not connect to a phone line.
Accessory
Handsets Additional handsets that can register to the base, allowing you to add handsets without connecting another phone line. This base supports a total of six cordless handsets; see page 19 for Compatible Handsets.
Global
Settings
This term relates to feature settings that will apply to all registered handsets and the base.
These features are available by selecting "GLOBAL SETUP" in the handset menu. Only one handset can
change global settings at a time, and you have to make sure the phone is not currently being used. If you
have multiple bases, the different bases have each global settings; select the base before changing the global
setting (see Selecting the Base on page 21).
Talk A telephone line has been activated on the handset or base, enabling a dial tone.
Manual Conventions
This manual uses several different type styles to help you distinguish between different parts of the phone:
Bold text with “[ ]” indicates a key or button on the phone
ALL CAPITALS indicates text on the display, such as menu options, prompts, and conrmation messages
lower case bold text indicates a status light on the phone
ALL CAPITALS BOLD indicates a connection jack on the base or charger
•
•
•
•
UC536BV(DECT2080-2) OM.indb 5 3/24/2008 4:53:44 PM

6
Product Overview
Features
1.9GHz DECT6.0 Expandable System
Expands up to 6 Handsets
Integrated Digital Answering System
Caller ID/Call Waiting with phonebook match
Store 30 Caller ID Numbers
Advanced Phonebook Features:
Store 70 Phonebook Entries
Alphabetical Search
Personalized Ring by Party
Transfer Single Listing or Entire Phonebook
•
•
•
•
•
••
•
•
•
Speakerphone on Handset
7 Ringer Options on Handset (3 Tones/4 Melodies)
Last 5 Number Redial
Bilingual Menu Displays
(for US models: English and Spanish,
for Canadian models: English and French)
Call Transfer
Conferencing
Intercom
•
•
•
•
•
•
•
Digital Tapeless Recording
Up to 14 Minutes of Recording Time
Call Screening
Personal or Pre-recorded Outgoing Messages
Bilingual Voice Prompts
(for US models: English and Spanish,
for Canadian models: English and French)
•
•
•
•
•
Day and Time Announcement
Remote Message Retrieval
Toll Saver
Message Alert
Records Up to 59 messages
•
•
•
•
•
Answering System Features
UC536BV(DECT2080-2) OM.indb 6 3/24/2008 4:53:44 PM

7
Parts of the Phone
The following illustrations show you all of the different parts of your phone.
Handset
1
2
3
5
6
7
8
9
10
11
12
15
19
20
21
16
18
17
13
4
14
22
Headset jack cover
Belt clip hole
Speakerphone speaker and ringer
Handset battery compartment
new message LED
Handset earpiece
LCD display
[Clear/Int’com] key
[ ] key (up)
[ /Flash] key (talk/ash)
[ ] key (phonebook/left)
[
*
/tone] key
[Redial/Pause] key
[Menu/Select] key
[ /Mute] key (messages/mute)
[ ] key (caller ID/right)
[ ] key (end call)
[ ] key (down)
[#] key
[ ] key (speaker)
Handset microphone
Handset charging contacts
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
21.
22.
UC536BV(DECT2080-2) OM.indb 7 3/24/2008 4:53:46 PM

8
23
26
24
27
28
29
30
31
32
33 34 35
25
36 37
Base charging contacts
charge LED
Base microphone
Base speaker
[volume +/-] keys
message counter LED
[greet] key (record/select greeting)
[ ] key (skip)
23.
24.
25.
26.
27.
28.
29.
30.
[ ] key (delete)
[ ] key (play/stop)
[nd hs] key (nd handset)
[ ] key (repeat)
[answer on/off] key (answering system on/off)
DC IN 9V jack
TEL LINE jack
31.
32.
33.
34.
35.
36.
37.
Base
UC536BV(DECT2080-2) OM.indb 8 3/24/2008 4:53:47 PM

9
Using the Interface
Reading the Display
Handset ID and banner
Number of new
Caller ID calls received
Call duration
In standby During a call
The ringer off icon indicates that the ringer is turned off.
The voice mail icon appears when you have messages waiting in your voice mailbox.
The privacy icon appears when the Privacy Mode is turned on.
The speaker icon appears when the speaker phone is in use.
The mute icon appears while the microphone is muted.
The battery icon indicates the handset battery status: full, medium, low, and empty.
UC536BV(DECT2080-2) OM.indb 9 3/24/2008 4:53:50 PM

10
Using the Four-way Function Key
Your handset has a four-way function key that
allows you to move the cursor or pointer on the
display and access the most commonly used
features at the touch of a button. By moving this
key to the left, you open the phonebook. Move the
key to the right to access Caller ID information. To
use this four-way key, place your thumb over the
key on the handset and move to the four positions
to get the feel of how it moves and operates.
Using the Handset Menus
To open the menu, press [Menu/Select]. Highlight the option you want by pressing the four-way function key. This
will move the cursor; the option currently highlighted has a triangle beside it. Activate the highlighted option by
pressing [Menu/Select]. To go back to the previous screen, press [left] on the four-way function key. To exit the
menu and return to standby, press [ ].
If you do not press a key within thirty seconds, the phone will time out and exit the menu. When setting the day and
time, the time-out period is extended to two minutes.
Note: For ANSW. SETUP and GLOBAL SETUP menu options, make sure the line is not in use and the handsets
are within range of the base.
View the
phonebook
Four-way
Function Key
Up
View the
Caller ID
Down
View the
phonebook
Four-way
Function Key
Up
View the
Caller ID
Down
UC536BV(DECT2080-2) OM.indb 10 3/24/2008 4:53:51 PM

11
Entering Text from Your Handset
You can use the number keypad on your handset to enter text by referring to the letters printed on each number
key. When you press the number key in a text entry eld, the phone displays the rst letter printed on the number
key. Press the number key twice to display the second letter and three times to display the third. Capital letters are
displayed rst, then lower case letters, and then the number on the key.
If two letters in a row use the same number key, enter the rst letter, then use [right] on the four-way function key to
move the cursor to the next position to enter the second letter.
For example, to enter the word “Movies”:
Press [6] once to enter M.
Use [right] on the four-way function
key to move the cursor to the right.
Press [6] six times to enter o.
Press [8] six times to enter v.
Press [4] six times to enter i.
Press [3] ve times to enter e.
Press [7] eight times to enter s.
Press [Menu/Select] to end your text
entry.
If you make a mistake while entering a
name, use [right] or [left] on the four-
way function key to move the cursor to the
incorrect character. Press [Clear/Int’com] to erase the wrong character, and then enter the correct character. To
delete all characters, press and hold [Clear/Int’com].
Note: When you enter the text, you can also use [#] to move the cursor to right and [
*
/tone] to move the cursor to
left.
1)
2)
3)
4)
5)
6)
7)
8)
UC536BV(DECT2080-2) OM.indb 11 3/24/2008 4:53:51 PM

12
Installing the Phone
Choosing the Best Location
When choosing a location for your new phone, here are some important guidelines you should consider:
The location should be close
to both a phone jack and a
continuous power outlet (one
which is not connected to a
switch).
For optimum range and
reception, place the base in an
open area, as high as possible.
If your home has wired alarm
equipment connected to a phone
line, be sure that installing the
system does not disable your
alarm equipment. If you have
questions about what will disable
alarm equipment, contact your
telephone company or a qualied
installer.
Note: For maximum range:
Keep both the base and handset antennas free of obstruction.
When the handset is not in use, place the handset in an upright position.
Metal and reinforced concrete may affect cordless telephone performance.
•
•
•
•
•
•
Avoid television sets
and other electronic
equipment
Choose a central location
Avoid sources of electrical
noise such as motors,
microwave ovens, and
fluorescent lighting
Avoid excessive moisture,
extremely low
temperatures, dust,
mechanical vibration, or
shock
Avoid personal computers
Avoid other cordless telephones
Avoid heat sources, such
as radiators, air ducts,
and sunlight
Avoid noise sources such
as a window by a street
with heavy traffic
UC536BV(DECT2080-2) OM.indb 12 3/24/2008 4:53:52 PM

13
Installing the Battery
Use only the Uniden BT-1008 rechargeable battery pack supplied with your cordless telephone.
Follow the steps below to install the handset battery.
Press in on the handset battery case cover (use the nger
indention for a better grip) and slide the cover downward
to remove.
Plug the battery cable into the battery jack. Be sure to
match the red and black wires to the label near the jack.
The cable should snap into place. Gently pull on the
battery cable. If the battery connector comes loose, try
connecting again until the battery snaps into place.
Place the battery case cover back on the handset and
slide it upwards until it clicks into place.
1)
2)
3)
UC536BV(DECT2080-2) OM.indb 13 3/24/2008 4:53:52 PM

14
Installing the Belt Clip
Line up the holes on each side of the handset. To attach the belt clip, insert into
the holes on each side of the handset. Press down until it clicks.
To remove the belt clip, pull either side of the belt clip to release the tabs from
the holes.
Connecting the Base and Charging the Handset
Route the AC adapter cord through the “LOOP” of base’s back as shown.
Connect the AC adapter to the DC IN 9V jack.
CAUTION: To avoid risk of re and shock, only use the
Uniden AD-800 AC adapter.
Connect the AC adapter to a standard 120V AC wall outlet.
DO NOT use anAC outlet controlled by a wall switch.
Place the handset in the base with the LCD screen facing
forward.
Make sure that the charge LED illuminates. If the LED does
not illuminate, check to see that the AC adapter is plugged
in and the handset makes good contact with the charging
contacts.
Charge your handset at least 15 to 20 hours before plugging
into the phone line.
1)
2)
3)
4)
5)
6)
Route the cord.
To AC outlet
To DC IN 9V
AC adapter (supplied)
Route the cord.
To AC outlet
To DC IN 9V
AC adapter (supplied)
UC536BV(DECT2080-2) OM.indb 14 3/24/2008 4:53:53 PM

15
Connecting to the Phone Line
Once the battery pack is fully charged, route the telephone
cord through the “LOOP” of base’s back as shown, and
connect the telephone cord to the TEL LINE jack.
Connect the telephone cord to a telephone wall jack.
Testing the Connection
Try making a call. If your call does not connect or you cannot
get a dial tone, try the following steps:
Make sure the AC adapter cord is securely connected to
the DC IN 9V jack and a standard power outlet.
Check to make sure the battery is fully charged. (If you
don’t see the “battery full” icon, check to make sure the
battery is properly connected).
Change the dial mode.
Changing the Dial Mode
Your phone can communicate with the telephone network in two different ways: tone dialing or pulse dialing. These
days, most base networks use a method called tone dialing, so your phone comes programmed for tone dialing. If
your phone company uses pulse dialing, you will need to change your phone’s dial mode. If you don’t get a dial tone
or can’t connect to the telephone network, please follow the steps below to modify your phone’s settings:
Press [Menu/Select]. Select the GLOBAL SETUP menu, and then the
DIAL MODE submenu.
Scroll [ ] to highlight PULSE.
Press [Menu/Select]. You will hear a conrmation tone.
If you ever need to change the dial mode back to tone dialing, follow the same procedure, but select TONE in step 2.
Note: If you have multiple bases, select the base before changing the dial mode (see Selecting the Base on
page 21).
1)
2)
1)
2)
3)
1)
2)
3)
To telephone wall jack
To TEL LINE
Telephone cord
(supplied)
Route the cord.
To telephone wall jack
To TEL LINE
Telephone cord
(supplied)
Route the cord.
Dial Mode
Tone
Pulse
Dial Mode
Tone
Pulse
UC536BV(DECT2080-2) OM.indb 15 3/24/2008 4:53:54 PM

16
Wall Mounting the Base
This phone can be mounted on any standard wall plate.
Snap the wall mount adapter into the notches on the base’s back.
Plug the AC adapter into the DC IN 9V jack.
Plug the AC adapter into a standard 120V AC wall outlet.
Plug the telephone cord into the TEL LINE jack.
Route the telephone cord through the hole of the wall mount
adapter as shown.
Plug the telephone cord into the telephone wall jack.
Align the mounting slots on the base with the mounting posts on
the wall. Then push in and down until the phone is rmly seated.
Notes:
DO NOT use anAC outlet controlled by a wall
switch.
To mount the phone directly on the wall, insert two
#10 screws (minimum length of 1 3/8inches, not
supplied) into the wall, 3 15/16 inches apart; leave
the screw heads 1/8inch away from the wall to allow
room for mounting the phone. Be sure the wall is
capable of supporting the weight of the phone, and
use the proper type of anchoring device for the
wall material. No need to route the telephone cord
through the hole of the wall mount adapter when
mounting directly on the wall.
1)
2)
3)
4)
5)
6)
7)
•
•
AC adapter (supplied)
Wall plate
AC outlet
Route the cord.
AC adapter (supplied)
Wall plate
AC outlet
Route the cord.
UC536BV(DECT2080-2) OM.indb 16 3/24/2008 4:53:55 PM

17
Basic Setup
Selecting a Language
Your phone supports two languages: English and Spanish for US models
or English and French for Canadian models. Once you select a language,
the menus on the handset will display in that language. The default
language is English.
Press [Menu/Select]. Select the HANDSET SETUP menu, and then
the HANDSET LANGUAGE submenu.
Move the cursor to choose a language.
for US models: Choose ENGLISH or ESPAÑOL (Spanish).
for Canadian models: Choose ENGLISH or FRANÇAIS (French).
Press [Menu/Select]. You will hear a conrmation tone.
Activating Personal Ring
You can assign special ringer tones to anyone in your phonebook. When your phone gets a call, it looks up the
Caller ID information in your phonebook. If you’ve assigned a personal ringer to that number, the phone uses it so
you know who is calling. To turn the personal ringing on or off, follow these steps:
Press [Menu/Select]. Select the HANDSET SETUP menu, and then
the PERSONAL RING submenu.
Move the cursor to select ON or OFF.
Press [Menu/Select]. You will hear a conrmation tone.
1)
2)
3)
1)
2)
3)
Handset Language
English
Espaﾂol
Handset Language
English
Espaﾂol
Handset Language
English
Franﾕais
Handset Language
English
Franﾕais
Personal Ring
On
Off
Personal Ring
On
Off
for US models
for Canadian models
UC536BV(DECT2080-2) OM.indb 17 3/24/2008 4:53:56 PM

18
Activating the Key Touch Tone
Key Touch Tone is the tone your keypad makes when keys are pressed. You can turn this tone on or off.
Press [Menu/Select]. Select the HANDSET SETUP menu, and then
the KEY TOUCH TONE submenu.
Move the cursor to select ON or OFF.
Press [Menu/Select]. You will hear a conrmation tone.
Activating the Caller ID Phonebook Match
If you subscribe to Caller ID service, the phone can display the name from your phonebook instead of the name
received with the Caller ID data. When a call is received, the phone compares the received phone number to the
phone numbers stored in your phonebook. If the phone number matches one in your phonebook, the phone will use
the name stored in the phonebook for the Caller ID display.
To turn the CID Phonebook Match on or off, follow these steps:
Press [Menu/Select]. Select the GLOBAL SETUP menu, and then the
CID/PHBK MATCH submenu.
Move the cursor to select ON or OFF.
Press [Menu/Select]. You will hear a conrmation tone.
1)
2)
3)
1)
2)
3)
Key Touch Tone
On
Off
Key Touch Tone
On
Off
%+&2JDM/CVEJ
1P
1HH
%+&2JDM/CVEJ
1P
1HH
UC536BV(DECT2080-2) OM.indb 18 3/24/2008 4:53:56 PM

19
Expanding Your Phone
Adding Accessory Handsets
Your phone supports a total of six cordless handsets. You can now place a fully-featured cordless handset anywhere
AC power is available to connect the handset charger. All the handsets ring when a call is received.
Compatible Handsets
Your phone is compatible with the DCX200, DWX207 and DCX300 accessory handsets. If you purchased an
accessory handset separately, you must register the handset to the base before use. Accessory handsets will not
operate until they are registered.
Charging Accessory Handsets
The handset’s battery recharges automatically when the handset is
placed in the charger.
Use the AC adapter that was supplied with your handset to
connect the DC IN 9V jack to a standard 120V AC outlet.
Set the charger on a desk or tabletop, and place the handset in
the charger with the LCD screen facing forward.
Make sure that the charge LED illuminates. If the LED does
not illuminate, check to see that the AC adapter is plugged
in and the handset makes good contact with the charging
contacts.
Charge the handset battery pack for at least 15-20 hours
before using your new handset for the rst time.
1)
2)
3)
4)
To AC outlet To DC IN 9V
AC adapter (supplied)
Route the cord.
Caution: Use only the AC adapter supplied
with the accessory handset.
UC536BV(DECT2080-2) OM.indb 19 3/24/2008 4:53:57 PM
