Uniden EXI2926 User manual

†To activate the Caller ID features, you must
subscribe through your telephone company.
EEXXII22992266
900MHz
CORDLESS
with caller id/call waiting†
owner’s manual
EXI2926 ENG Resize 9/4/01 2:02 PM Page i

The EXI2926 features include
AAuuttooTTaallkk
TT MMand
AAuuttooSSttaannddbbyy
TT MM. AutoTalk allows you to
answer a call by just removing the handset from the base so you don´t have to waste
time pushing buttons or flipping switches. AutoStandby allows you to hang up by simply
returning the handset to the base.
The
UUllttrraaCClleeaarrPPlluuss
TT MMtrue compander circuitry virtually eliminates background noise.
This innovative technology, together with 40 different channels, provides you with the
best possible reception during all your conversations.
To protect you against misbilled calls which might result from your phone being
activated by other equipment, the EXI2926 has
RRaannddoommCCooddee
TT MMdigital security which
automatically selects one of over 65,000 digital security codes for the handset and
base. Also, the
AAuuttooSSeeccuurree
TT MMfeature electronically locks your phone when the handset is
in the base.
BBeessuurreettoovviissiittoouurrwweebbssiittee::wwwwww..uunniiddeenn..ccoomm
Uniden®is a registered trademark of Uniden America Corporation.
AutoTalk, AutoStandby, UltraClear Plus, Random Code, and AutoSecure are trademarks of Uniden America Corporation.
Welcome
Features
Congratulations on your purchase of the Uniden EXI2926 cordless telephone.
This phone is designed and engineered to exacting standards for reliability, long life
and outstanding performance.
NNoottee::SSoommeeiilllluussttrraattiioonnssiinntthhiissmmaannuuaallmmaayyddiiffffeerrffrroommtthheeaaccttuuaalluunniittffoorr
eexxppllaannaattiioonnppuurrppoosseess..
• 900 MHz Extended Range
• 2-Line Operation with Intercom
• Caller ID and Call Waiting Caller ID
• 80 Number Caller ID Memory
(40 for each line)
• 30 Number Memory
• 32 Digit Redial
• Flash and Pause
• Tone/Pulse Dialing
• 14 Day Standby Battery Life
• 7 Hour Talk Time
• Handset Earpiece and Ringer Volume Control
• Speakerphone
• 3-Way and 4-Way Conference Operation
EXI2926 ENG Resize 9/4/01 2:02 PM Page ii

Contents
4-way conferencing 19
Using your EXI2926 intercom 20
Transferring calls 20
Using the speakerphone 20
Memory Features
Storing a phone number in memory 21
Making calls with memory dialing 22
Chain dialing 22
Editing a stored name and/or phone number 23
Erasing a stored name and phone number 24
Caller ID Features
Caller ID 25
When the telephone rings 25
Viewing the Caller ID message list 26
Using the Caller ID list 26
Deleting information from the Caller ID list 27
Using CIDCW (Caller ID with Call Waiting) 28
Additional Information
Changing the digital security code 29
Installing the beltclip 29
Headset installation 29
Note on power sources 30
Maintenance 30
Troubleshooting 31
General information 32
Technical information 32
Index 34
Welcome/Features
Controls and Functions 2, 3
Getting Started
Read this first 4
Step 1: Checking the package contents 5
Step 2: Setting up the phone 6
Step 3: Mounting the Base unit on a wall 9
Step 4: Setting Caller ID options 11
Entering your Area Code 12
Basics
Making and receiving calls 13
Terminology 13
Adjusting the handset ringer and earpiece volume 14
Redial 14
Tone dialing switch-over 15
Traveling out-of-range 15
Selecting a different channel 15
Using the page feature 15
Flash and call waiting 16
Answering a call from the base 16
Answering a call from the handset 16
Making a call from the base 16
Making a call from the handset 17
Placing a call on hold 17
Using the speakerphone mute feature 17
2-Line Features
2-Line operation 18
3-way conferencing 18
EXI2926 ENG Resize 9/4/01 2:02 PM Page iii

CONTROLS AND FUNCTIONS[ 2 ]
Controls and Functions
1. Handset Antenna
2. Optional Headset Jack
3. Handset Battery Compartment
4. Handset Earpiece
5. LCD Display
6. Line 1 Key
7. Down Cursor
▼ /Character Select/
Conference Key
8. Tone/*(
t ) Left Cursor
9. Caller ID/Hold Key
10. Select/Volume Key
11. Handset Microphone and Ringer Speaker
12. Memory Key (m)
13. Line 2 Key
14. Up Cursor
▲ /Character Select/
Intercom Key
15. #(
s ) Right Cursor
16. Delete/Flash Key
17. Redial/Pause Key (P)
18. Channel Key (chan)
19. Handset Charging Contacts
1
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
2
3
EXI2926 ENG Resize 9/4/01 2:02 PM Page 2

CONTROLS AND FUNCTIONS [3]
20. Handset Retainer Clip
21. Line 1 Status LED
22. Status LED
23. Memory Key
24. Intercom Key
25. Redial/Pause Key
26. Flash Key
27. Base Charging Contacts
28. Tone Key/*
29. Base Speaker
30. Line 1 Key
31. Conference Key
32. Line 2 Key
33. Line 2 Status LED
34. Hold Key
35. Mute Key
36. Base Antenna
37. Base Speaker Volume Control
38. Base Microphone
39. Ring Volume Switch (2nd Line)
40. Ring Volume Switch (1st Line)
41. Pulse-Tone Switch
42. DC Power Input
43. Phone Jack (2nd Line)
44. Phone Jack (1- and 2- Line)
20
21
22
23
24
25
26
27 28
29
30
31
32
33
34
35
36
37
38
39 40 41 42 43 44
EXI2926 ENG Resize 9/4/01 2:02 PM Page 3

GETTING STARTED[ 4 ]
Read This First
This cordless telephone must be set up before use. Follow these steps:
AAbboouutttthheeddiiggiittaallsseeccuurriittyyccooddee
This cordless telephone uses a digital
security code to prevent unauthorized
access to your base unit. This security code
prevents other cordless handsets from
making calls through your base unit.
A random security code will be assigned
automatically between your base unit and
handset when you charge the battery pack
for the first time.
If you want to reset the security code, see
page 29.
SStteepp11((ppaaggee55))
Unpack the telephone and accessories.
SStteepp22((ppaaggee66))
Next, choose the best location
to set up the base unit.
SStteepp33((ppaaggee77ttoo1100))
Then, insert the battery pack into
the handset. Connect the base unit.
You must charge the battery pack for
1155--2200hhoouurrssbbeeffoorreepplluuggggiinnggiinnttootthhee
tteelleepphhoonneelliinneeaanndduussiinnggtthheepphhoonnee..
SStteepp44((ppaaggee1111ttoo1122))
Finally, set the Caller ID options and store
your area code in the memory to use the
Caller ID service.
NNoottee::Skip the area code setting if your
calling area requires 10-digit dialing.
tip
To realize the full capabilities of your two-line
phone, contact the phone company requesting
a two-line subscription.
EXI2926 ENG Resize 9/4/01 2:02 PM Page 4

GETTING STARTED [5]
GETTING STARTED
Checking the Package Contents
Make sure you have received the following items in the package. If any of these items are missing or damaged,
contact the Uniden Parts Department (see below).
••TThhiissOOwwnneerr´´ssMMaannuuaall
••QQuuiicckkRReeffeerreenncceeGGuuiiddee
••PPrreeccaauuttiioonnssaannddIImmppoorrttaanntt
SSaaffeettyyIInnssttrruuccttiioonnss
••RReeggiissttrraattiioonnCCaarrdd
••BBaasseeuunniitt••HHaannddsseett••AACCaaddaapptteerr((AADD--442200))••RReecchhaarrggeeaabblleebbaatttteerryyppaacckk
((BBTT--990055))
••TTeelleepphhoonneelliinneeccoorrdd
LLoonnggccoorrddiiss22lliinneeccaappaabbllee
••BBeellttcclliipp••WWaallllmmoouunnttaaddaapptteerr
Uniden Parts Department at [phone]
Hours: M-F 7:00 a.m. to 5:00 p.m. CST.
We can also be reached on the web at www.uniden.com
EXI2926 ENG Resize 9/4/01 2:02 PM Page 5

GETTING STARTED[ 6 ]
Setting up the Phone
DDootthheeffoolllloowwiinnggsstteeppss::
A. Choose the best location C. Connect the base unit
B. Install the battery pack D. Choose the dialing mode
AA..CChhoooosseetthheebbeessttllooccaattiioonn
Before choosing a location for your new phone, read the INSTALLATION CONSIDERATIONS included in the PRECAUTIONS AND
IMPORTANT SAFETY INSTRUCTIONS brochure. Here are some important guidelines you should consider:
• The location should be close to both a phone jack and a continuous power outlet which is not switchable.
• Keep the base and handset away from sources of electrical noise such as motors, microwave ovens, and fluorescent lighting.
• Be sure there is sufficient space to raise the base antenna to a vertical position.
• The base can be placed on a desk, tabletop, or mounted on a standard wall plate.
• If your second phone line has a separate modular jack, place your phone so you can access both jacks.
AAvvooiiddeexxcceessssiivveemmooiissttuurree,,
eexxttrreemmeellyylloowwtteemmppeerraattuurreess,,
dduusstt,,mmeecchhaanniiccaallvviibbrraattiioonn,,oorrsshhoocckk
AAvvooiiddhheeaattssoouurrcceess,,ssuucchhaassrraaddiiaattoorrss,,
aaiirrdduuccttss,,aannddssuunnlliigghhtt
AAvvooiiddtteelleevviissiioonnsseettssaanndd
ootthheerreelleeccttrroonniicceeqquuiippmmeenntt
AAvvooiiddnnooiisseessoouurrcceessssuucchhaassaawwiinnddooww
bbyyaassttrreeeettwwiitthhhheeaavvyyttrraaffffiicc
AAvvooiiddmmiiccrroowwaavveeoovveennss
AAvvooiiddppeerrssoonnaallccoommppuutteerrss
AAvvooiiddootthheerrccoorrddlleesssstteelleepphhoonneess
CChhoooosseeaacceennttrraallllooccaattiioonn
EXI2926 ENG Resize 9/4/01 2:02 PM Page 6

GETTING STARTED [7]
GETTING STARTED
BB..IInnssttaalllltthheebbaatttteerryyppaacckk
CChhaarrggeetthheebbaatttteerryyppaacckkffoorraattlleeaasstt1155--2200hhoouurrssbbeeffoorreepplluuggggiinnggtthheepphhoonneelliinneeiinnttooyyoouurrpphhoonnee..note
• Use only the
Uniden Battery
(BT-905) supplied
with your phone.
Replacement
batteries are also
available through
the Uniden Parts
Department (See
page 5).
1) Press in on the battery cover release and slide the cover down until it comes off.
2) Connect the battery pack connector observing correct polarity (black and red wires)
to the jack inside the battery compartment.
Do not exert any force on this connection. It could cause damage to the battery or
handset. The plastic connector will fit together only one way. Once you are certain
that you have made a good connection, then insert the battery pack into the battery
compartment. Do not pinch the wires.
3) Securely close the battery compartment cover by sliding it up until it snaps into place.
4) Place the handset on the base unit. Remove the beltclip, if attached, for face up charging.
BBaatttteerryyuusseettiimmee((ppeerrcchhaarrggee))
From fully charged
• Seven hours continuous use.
• Fourteen days when the handset is in the standby mode.
LLoowwbbaatttteerryyaalleerrtt
When the battery pack is very low and needs to be charged, the phone is programmed to
eliminate functions in order to save power. If the phone is not in use, "Low Battery"
appears on the LCD and none of the keys will operate.
If the phone is in use, "Low Battery" flashes and the handset beeps. Complete your
conversation as quickly as possible and return the handset to the base unit for charging.
• Even when the
battery pack is
not being used,
it will gradually
discharge over a
long period of
time. For optimum
performance, be
sure to return the
handset to the
base unit
after each
telephone call.
• If you must replace
the battery pack
during a telephone
call, complete the
replacement of the
battery pack
within 30 seconds,
and you can
return to the
original call.
The last number dialed in the redial memory is retained for up to 30 seconds. The handset
memory backup can hold names and numbers stored in the memory locations even if the battery
pack is completely discharged.
note
EXI2926 ENG Resize 9/4/01 2:02 PM Page 7

GETTING STARTED[ 8 ]
Place the power cord
so that it does not
create a trip hazard
or where it could
become chafed and
create a fire or
electrical hazard.
!
CClleeaanniinnggtthheecchhaarrggiinnggccoonnttaaccttss
TToommaaiinnttaaiinnaaggooooddcchhaarrggee,,iittiissiimmppoorrttaannttttoocclleeaanntthheebbaatttteerryyccoonnttaaccttssoonntthhee
hhaannddsseettaannddbbaasseeuunniittwwiitthhaaddrryyccllootthhoorraappeenncciilleerraasseerraabboouuttoonncceeaammoonntthh..
DDoonnoottuusseeaannyylliiqquuiiddssoorrssoollvveennttss..
CC..CCoonnnneecctttthheebbaasseeuunniitt
1) Connect the AC adapter to the DC IN 9V jack and a standard
120V AC wall outlet.
2) Set the base on a desk or tabletop, and place the handset on
the base unit as shown. Remove the beltclip, if attached for
face up charging. (For wall mounting, see "Mounting the Base
Unit on a Wall", on page 9 and 10).
3) Raise the antenna to a vertical position.
4) Make sure the status LED lights. If the LED does not light,
check to see that the AC adapter is plugged in and the
handset makes good contact with the base charging contacts.
After installing the battery pack in the handset, cchhaarrggeeyyoouurrhhaannddsseettaatt
lleeaasstt1155--2200hhoouurrssbbeeffoorreepplluuggggiinnggiinnttootthheepphhoonneelliinnee. Once the handset
battery pack is fully charged, connect the telephone line cord to the base
and telephone wall outlet.
note
•The handset can
be placed face up
or face down in
the base for
charging.
• You must remove
the beltclip, if
attached, for face
up charging.
• Use only the supplied AD-420 AC adapter. Do not use any other AC adapter.
• Connect the AC adapter to a continuous power supply.
• Place the base unit close to the AC outlet so that you can unplug the AC adapter easily.
note
5) Connect the telephone line cord to the TEL LINE 1 jack and a telephone outlet
once the handset is fully charged.
MMoodduullaarr
tip If your telephone outlet isn´t modular,
contact your telephone company for assistance.
EXI2926 ENG Resize 9/4/01 2:02 PM Page 8
