UT075Z_PMR446MR-2CK_1 2/16/2016 15:24:41 PM
Channels 8 channels
Sub Codes 38 Sub-Audible Tones
83 DCS Codes
Power Source NiMH Battery Pack
Operating Frequency
446.00625 - 446.09375 MHz
Range Up to 8 Km
Battery Life 16 Hours typ. -
NiMH Battery Pack
(5/5/90 duty cycle)
SPECIFICATIONS
DECLARATION OF CONFORMITY
For sales and service please contact
Printed in Vietnam
U01UT075ZZZ(0)
Talking on Your Radio
To talk to others using the radio:
1) Press and hold the PTT button and speak in a
clear, normal voice about 5-10 cm away from
the microphone. While you are transmitting, the
icon appears on the display. To avoid cutting
off the first part of your transmission, pause
slightly after pressing the PTT button before you
start talking.
2) When you have finished speaking, release the
PTT button. You can now receive incoming calls.
While receiving, the icon appears on the
display.
Monitor Mode Feature
Your radio allows you to listen for weak signals on
the current channel at the press of a key.
To turn ON the Monitor Mode:
• For brief listening, press MON button. The
icon blinks.
• Press and hold MON button for 2 seconds until
two beeps sound for continuous listening. The
receiver circuit stays open, letting both the noise
and weak signals be heard.
To turn OFF Monitor Mode:
Press MON button to return to "Normal" mode,
and the icon stops blinking and disappears.
Navigating through the Menu
Use the MENU key to access your radio's
advanced functions.
1) To enter the Menu, press the MENU/ key.
2) Additional presses of the MENU/ key
advance you through the Menu until exiting to
"Normal" operating mode.
3) Other methods of exiting the Menu function are:
a. Press and hold the MENU/ key again.
b. Press the PTT, MON, or CALL/LOCK key
c. Wait 10 seconds until the unit automatically
returns to “Normal” mode.
Voice Operated Transmission
Your
To select a call tone:
1) Press MENU/ repeatedly until the call
icon and Call Tone start to blink on the
display.
2) Press CH / CH to move through the
available call tones. Each tone will be heard
through the speaker but will not be transmitted.
Cycle through these tones and stay on the tone
you want to select.
3) Exit Call Tone to set the selected tone.
radio is equipped with a user selectable Voice
Operated Transmitter (VOX) that can be used for
automatic voice transmissions. The VOX feature is
designed to be used with a headset with a
microphone. Transmission is initiated by speaking
into the remote microphone instead of pushing the
PTT button.
To select the VOX level:
1) Enter the Menu. Advance through the Menu until
the vox icon blinks on the display. The current
level (OFF, 1-5) will be indicated. Level oF (OFF)
disables VOX, while levels 1-5 set the sensitivity
of the VOX circuit.
2) Press either the CH or key to the desired
VOX sensitivity level. Use level 1 for increased
sensitivity to voice in normally quiet environments,
and use a higher level to reduce undesired
activation in very noisy environments.
Transmitting a Call Tone
Your radio is equipped with 10 selectable call tones
that are transmitted when the CALL/LOCK key is
pressed.
To transmit the selected call tone, press the CALL/
key. The selected tone will automatically be
transmitted for a fixed length of time. Call Tone will
be cancelled when the PTT button is pressed.
Key Lock
Press and hold the CALL/LOCK
CALL/LOCK
key until the the
icon appears.
To exit Keylock on mode, press and hold
key again.
Note:
• While in keylock on mode, you can still use
the radio to receive transmissions, use CALL,
VOL or , PTT and MON.
• To turn the radio off and on, exit keylock on
mode.
Automatic Power Save Feature
Your radio has a unique circuit designed to
dramatically extend the life of the batteries. If there
is
no transmission nor an incoming call within 3
seconds,
your radio switches to the Power Save
mode. The radio is still able to receive
transmissions in this mode.
LCD Backlight
The LCD Backlight automatically turns ON when
any key (except the PTT button) is pressed. The
LCD illuminates for 10 seconds before turning OFF.
Roger Beep
Roger Beep is a BEEP that is sent to notify the end
of transmission (both PTT and VOX transmission).
Roger Beep can be heard through the speaker
when both Roger Beep and Key Beep are set to
ON. When Roger Beep is set to ON and Key Beep
OFF, Roger Beep will not be heard from the
speaker but it will be transmitted to your party.
When Roger Beep is set to OFF, Roger Beep
neither be heard nor transmitted.
This equipment complies with the European
R&TTE directive.
To view the complete Declaration of Conformity,
please refer to the free download available
at our web site: www.avera.eu.
Normal
Normal
VOX Level
Call Tone 1-10
OFF, 1-5
Sub Code
Scan
OFF, 1-121
ON/OFF
To change Roger Beep setting:
Press and hold VOL ▲while turning the radio on
and off. If Roger Beep is ON, it will be turned off;
if it is OFF, it will be turned on.
Your radio comes with a NiMH battery pack,
but will also operate with regular AAA alkaline
batteries.
NEVER try to charge the radio when alkaline
batteries are installed.
NEVER put the radio in the charging cradle when
alkaline batteries are installed.
To install the batteries:
LOCK
USE OF ALKALINE BATTERIES
1) Make sure your radio is OFF.
2) Release the battery latch at the bottom of the
radio, and remove the cover.
3) Install the regular AAA alkaline batteries into the
battery compartment. Be certain to follow the
instructions written on the label on the battery
pack. Installing the battery pack incorrectly will
prevent the unit from operating.
4) Before placing the battery cover back on the
radio, check the rubber seal around the battery
compartment and the ribbon of the battery pack:
make sure that the seal is in good condition and
that there is no foreign matter under the seal.
5) Replace the battery compartment cover.
