1
Before you use this scanner, please read and observe the following.
EARPHONE WARNING!
Use only a genuine Uniden earphone. An incorrect earphone may be
hazardous to your hearing. Turn down volume before connecting the
earphone and then adjust volume to suit.
Precautions
Precautions
UBC340CRS OM.indd 1 7/5/08 4:28:01 PM

2
WARNING!
Uniden does not represent this unit to be waterproof. To reduce the risk
of fire or electrical shock, do not expose this unit to rain or moisture.
Trademarks used throughout this manual are the property of their
respective holders.
Important: If you use the supplied AC adapter to power the scanner but
have not installed batteries in the scanner, never turn the scanner off by
disconnecting the AC adapter or unplugging it from the AC outlet. This
might corrupt the scanner’s memory. Always use POWER to turn the
scanner off before disconnecting AC power.
PrecautionsPrecautions
UBC340CRS OM.indd 2 7/5/08 4:28:01 PM

3
UnpackingYourScanner.....................................5
Introduction................................................6
Features..................................................7
Controls ..................................................9
SettingUpTheScanner.....................................13
ConnectingPower .........................................13
ConnectinganAntenna.....................................14
UsingtheBacklight.........................................15
Country mode (Australia/New Zealand). . . . . ... . . . . . . . . . . . . . . . . .15
UsingtheAlarmClock......................................16
SettingtheCurrentTime ....................................16
SettingtheAlarmClock.....................................16
UsingSnooze.............................................17
Listening to AM/FM/TV Channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Directly Selecting a Channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Using AM/FM/TV Channel Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
UsingtheScannerMemories................................20
ProgrammingMemories.....................................20
Selecting a Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
ScanningMemoryBanks....................................22
Locking/UnlockingMemories.................................22
UsingPriorityScan.........................................22
Setting Channel Delay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Searching for Active Frequencies . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
UsingLimitSearch.........................................24
Programming an Upper/Lower Limit . . . . . . . . . . . . . . . . . . . . . . . . . .24
Searching the Selected Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
UsingServiceSearch.......................................24
Selecting a Service to Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Saving a Found Frequency into a Scan Memory. . . . . . . . . . . . . . . . . .25
SearchLockouts...........................................25
CareandMaintenance......................................26
GeneralUse..............................................26
Contents
Contents
UBC340CRS OM.indd 3 7/5/08 4:28:02 PM

4
Location.................................................26
Cleaning.................................................26
Repairs..................................................26
Birdies...................................................26
Resetting the Scanner (Clearing all Memories) . . . . . . . . . . . . . . . . . . .26
TechnicalSpecifications....................................27
One-YearLimitedWarranty..................................29
ContentsContents
UBC340CRS OM.indd 4 7/5/08 4:28:02 PM

5
Please unpack this box carefully and make sure you have:
Unpacking Your Scanner
Unpacking Your Scanner
Band
No.
Lower Limit
(MHz)
Upper Limit
(MHz) Modulation Step (kHz) Service
1 0.53000 1.70000 AM 10 AM Broadcast
2 25.00000 27.99500 AM 5 AM Band
3 28.00000 50.74500 FM 5 10-6 Meter Amateur
Band
4
51.75000
WFM 7000 TV Broadcast Ch. 0 - 2
(AUS Mode)
62.75000
69.75000
5 70.00000 87.98750 FM 12.5 VHF Low Band
6 88.00000 107.90000 WFM 100 FM Broadcast
7 108.00000 136.98750 AM 12.5 Aircraft Band
8 137.00000 147.99500 FM 5 2 Meter Amateur Band
9 148.00000 174.00000 FM 12.5 VHF High Band
10
180.75000
WFM 7000 TV Broadcast Ch. 6 - 10
(AUS Mode)
187.75000
194.75000
201.75000
214.75000
11 400.00000 512.00000 FM 6.25 Land Mobile Radio
UBC340CRS Scanner
Note: If any of these items are missing or damaged, contact your place of
purchase.
This Owner’s Manual Other Printed Material
AM Loop Antenna AC Adapter
Telescopic Antenna
UBC340CRS
Owner’s Manual
Australia Scanner
Frequencies CD
UBC340CRS OM.indd 5 7/5/08 4:28:05 PM

6
Your UBC340CRS scanner is a multi-featured conventional channel
scanner. You can easily enter and store frequencies for police, marine,
air, amateur, and other radio services into 100 channels distributed over
ten banks. Use your scanner to monitor:
Police
Marine band
AM CB
UHF CB
Railroad
Air band
AM/FM Broadcast Stations
TV Channels (Australia 0-2, 6-10 and NZ 1-9)
Your scanner can monitor the following bands.
•
•
•
•
•
•
•
•
Introduction
IntroductionUnpacking Your Scanner
Band
No.
Lower Limit
(MHz)
Upper Limit
(MHz) Modulation Step (kHz) Service
1 0.53000 1.70000 AM 10 AM Broadcast
2 25.00000 27.99500 AM 5 AM Band
3 28.00000 50.74500 FM 5 10-6 Meter Amateur
Band
4
51.75000
WFM 7000 TV Broadcast Ch. 0 - 2
(AUS Mode)
62.75000
69.75000
5 70.00000 87.98750 FM 12.5 VHF Low Band
6 88.00000 107.90000 WFM 100 FM Broadcast
7 108.00000 136.98750 AM 12.5 Aircraft Band
8 137.00000 147.99500 FM 5 2 Meter Amateur Band
9 148.00000 174.00000 FM 12.5 VHF High Band
10
180.75000
WFM 7000 TV Broadcast Ch. 6 - 10
(AUS Mode)
187.75000
194.75000
201.75000
214.75000
11 400.00000 512.00000 FM 6.25 Land Mobile Radio
UBC340CRS OM.indd 6 7/5/08 4:28:06 PM

7
Features
Channel Memory Scanning - Scans frequencies you have stored in any
of the channels or banks at a rate of up to 60 channels per second.
Memory Availability - Store and then scan any of up to 100 channels
distributed over 10 banks.
Direct Channel Access - Press 0-9and HOLD to directly access any
stored frequency.
Channel Lockout/Frequency Lockout - Skip over stored frequencies
(channels) using the Lockout feature to enable faster scanning. Lets you
designate up to 50 frequencies to skip during a search (limit or service) to
increase the scanning speed.
Alarm Clock with Snooze - provides standard radio broadcasts that you
can set as your alarm sound.
AM/FM and TV Broadcast - lets you store up to 30 preset broadcast
channels (10 AM and 20 FM/TV) for quick access. TV Broadcast allows
tuning to the audio of CH 0-2 and 6-10 in Australian Mode and CH1-9 in
New Zealand Mode.
Air Band - separate search setting for Air band, 118MHz to
136.9875MHz.
Priority Channel - Designate a specific frequency as a Priority Channel.
Then the radio scans and checks that channel every 2 seconds. Select
and designate up to 10 frequencies as Priority Channels (one per bank).
Duplicate Channel Alert - Lets you know that a selected frequency has
already been programmed into memory if you attempt to store it again.
Limit Frequency Searching - Lets you designate lower and upper
frequency range and search within that range for active frequencies.
You can then store frequencies in memory as channels for later recall.
Service Search - Lets you designate one of the five preprogrammed
service channels (Police, Marine, Railroad, AM-CB, UHF-CB) to search.
Scan and Search Speed
Scan Speed 60 channels per second maximum in SCAN MODE.
Search Speed 60 steps per second maximum in SEARCH MODE.
TURBO MODE For frequency steps 5kHz apart, searching occurs in
Turbo Mode which is 180 steps per second.
•
•
•
Introduction
UBC340CRS OM.indd 7 7/5/08 4:28:06 PM

8
Clock Display - the scanner, in standby mode, displays the time.
The clock also features an alarm that can sound up to 20 minutes or be
shut off manually. A convenient snooze button lets you silence the alarm
for an extra 5-minutes.
Delay - you can enable or disable the 2-second delay to resume
scanning when a transmission ends. Enabling this feature helps prevent
missing a response from one of the parties in the transmission.
LCD Backlight - you can enable or disable the LCD back lighted display.
Key Touch Tone - a tone sounds to confirm you have made a valid key
input while a different tone sounds to alert you to an invalid entry.
EEPROM Memory Backup - the scanner uses a non-volatile EEPROM
for memory backup.
Battery Alert - A battery icon alerts you to a no battery installed
condition, and a battery low voltage condition. An alert tone sounds when
the battery needs to be replaced. The backup provides backup for the
clock when power is off and will power scanning for a short time.
Auto Power Off - turns the scanner off when the battery power gets
too low.
IntroductionIntroduction
UBC340CRS OM.indd 8 7/5/08 4:28:07 PM

9
Introduction
Air
UBC340CRS
1234567891011
12
13
14
15
16
17
18
19
2120
Controls
Scanner
UBC340CRS OM.indd 9 7/5/08 4:28:08 PM

10
Introduction
1 VOLUME Control - lets you raise or lower the level of the sound.
2 SQUELCH Control - lets you set the signal level required to receive a
transmission. If you open the squelch all the way, you will hear hissing
between transmissions. This lets you hear weak signals, but prevents
scanning. As you close squelch, a stronger signal is required to stop scanning
and open audio. You normally set the control to a point just where hissing on
all channels stops between transmissions.
3 SCAN - press to begin scanning the channels or to resume scanning.
4 ALARM Select - Set to Off to disable alarm; Set to Radio to enable the radio
alarm; Set to Tone to enable the tone alarm.
5 SNOOZE/Backlight - Backlight: Tap to turn the LCD backlight on for 5
seconds. Press and hold to permanently turn on the backlight. Press and hold
again to turn off the backlight.
Snooze: Press while the alarm sounds to silence the alarm for 5 minutes.
6 TIME Set - Use to select your desired operation: Alarm Set; Clock Set;
Clock.
7 HOLD - press to temporarily stop scanning, limit searching, or AIR scanning
and remain on the channel. The scanner displays the channel on hold. Press
again to resume searching or scanning.
8 E/PGM - Press to enter the Program Mode. In Program Mode, enter the
desired frequency using the numeric keys. Then press E/PGM to store that
frequency into the memory.
In Limit Search Mode, after entering the frequency, press E/PGM to program
the upper and lower limit frequency.
9 0 to 9 - use the numeric keys in three basic operations:
• press a numeric key to enter a frequency.
• press a numeric key to change a channel using the Direct Channel Access
feature.
• press a numeric key while scanning to enable or disable the associated
scanning bank memory bands.
10 POWER - Press and hold more than 500ms to turn power on and off. The
time displays when power is off (standby mode).
11 ./CLR - this key has three functions:
• press to input a decimal point when you enter a frequency.
• press to cancel a numeric key input -0to 9
• press to clear an error display.
Introduction
UBC340CRS OM.indd 10 7/5/08 4:28:08 PM

11
Introduction
12 SEARCH/AM - In Scanner mode press to start a Limit Search or to resume
searching. In AM/FM mode, press to select the AM memory bank.
In Service mode, press to select the POLICE service.
13 L/O FM1 - In Scanner mode, press to lock or unlock a channel memory in
SCAN (HOLD) or PROGRAM mode.
In Search mode, press to set or clear a selected frequency previously locked
out in the LIMIT SEARCH or SERVICE SEARCH (Hold) mode. In AM/FM
mode, press to select the FM1 memory bank.
In Service mode, press to select the MARINE service.
14 DELAY/FM2 - In Scanner mode, press to turn the delay option on/off. In AM/
FM mode, press to select the FM2 memory bank.
In Service mode, press to select the RAIL ROAD service.
15 PRI/MEM - In Scanner mode, press to set a Priority channel for Scan Hold
mode and Program mode.
In Service mode, press to select AM CB service.
In Program mode, press to set the Priority channel setting. In SCAN and
SCAN HOLD, press to set Priority Scan on or off.
In AM/FM mode, press to select Memory Mode to allow quick channel recall
using the 0-9 keys.
16 SVC/DIR - In Scanner mode press to change to Service Search mode.
In AM/FM mode, press to change to Direct Entry mode to allow channel
frequency selection using the up / down arrows or 0-9 keys.
In Service mode, press to select the UHF CB service.
17 MODE Switch - Use to select the desired mode: AM/FM; Air; Scanner. (TIME
switch must be set to Clock)
18 t- Press and release to move down through channel numbers in the
following HOLD modes: SCAN, PROGRAM, SERVICE SEARCH, and AIR
or the step frequency in LIMIT SEARCH, and AM/FM mode. (refer to the
frequency and step table on page 6)
Press and hold for more than 1 second to have the changes run continuously.
19 s- Press and release to move up through channel numbers in the following
HOLD modes: SCAN, PROGRAM, SERVICE SEARCH, and AIR or the step
frequency in LIMIT SEARCH, and AM/FM mode. (refer to the frequency and
step table on page 6)
Press and hold for more than 1 second to have the changes run continuously.
20 HEADPHONE Jack - lets you use an headphone for private listening.
21 Antenna Connector - connect an external antenna using a BNC connector.
AM RADIO ANT connector - connect the supplied loop antenna and position it
for best AM Broadcast radio reception.
UBC340CRS OM.indd 11 7/5/08 4:28:09 PM

12
Introduction
11to 10 - Scan mode: indicates Channel memory Bank
AM/FM mode: indicates a radio station
2L/O - Indicates a Locked Out channel or to skip a frequency while searching
3SRCH - Indicates Limit Search mode, Service Search mode, and Direct
Entry mode
4DELAY - Indicates a 2 second set delay for a channel before scanning
resumes
5PGM - Indicates Program mode
6Battery - Flashes when the battery power is low.
Non-flashing: no battery installed
7ALARM - Indicates the alarm is enabled. Flashes when alarm sounds or
if Snooze is selected
8PRI - Indicates the designated Priority channel
9HOLD - Indicates a hold in Scan, Search, AIR, and Direct Entry mode
10 POLICE - Indicates a Police service search
11 MARINE - Indicates searching commercial and private watercraft
communications
12 AM/PM - Indicates AM/PM and appears in Clock mode
13 RAIL ROAD - Indicates searching Rail Road communications
14 AM-CB - Indicates searching AM CB band
15 UHF-CB - Indicates searching UHF CB band
Notes:
The backlight turns off automatically after 5 seconds from the last key
stroke (if not permanently turned on).
The scanner sounds special tones as follows:
• to confirm key entry.
• to indicate an error in key entry,
• to indicate low battery voltage.
Introduction
1
10 11 12 13 14 15
7 9
8
2 43 5 6
LCD
UBC340CRS OM.indd 12 7/5/08 4:28:10 PM

13
Setting Up The Scanner
Setting Up The Scanner
These guidelines will help you install and use your new scanner:
If your scanner receives interference or electrical noise, move the
scanner or its antenna away from the source. You might also try
changing the height or angle of the antennas.
Use an optional mono earphone or mono headset with proper
impedance for private listening.
Do not use the scanner in high-moisture environments such as in the
kitchen or bathroom.
Avoid placing the scanner in direct sunlight or near heating elements
or vents.
Connecting Power
Insert the supplied AC
Adapter’s barrel plug into the
power jack on the back of the
scanner. Then plug the Adapter
into a standard household outlet
that supplies 240V AC, 50Hz.
Do not plug the adapter into a
switch controlled outlet.
Open the battery compartment
and insert 3 AA batteries.
Be sure to note the polarity markings in
the battery compartment. You can use
either alkaline or rechargeable batteries,
but the scanner will not recharge
batteries in the compartment.
• Use only fresh alkaline AA batteries.
Rechargeable batteries can be used,
but battery life is shorter than with
alkaline batteries.
• Always remove old or weak batteries.
Batteries can leak chemicals that
destroy electronic circuits.
• Do not mix old and new batteries,
different types of batteries (standard,
alkaline, or rechargeable) or rechargeable batteries of different
capacities.
•
•
•
•
•
•
240
Model AAD-008S
UBC340CRS OM.indd 13 7/5/08 4:28:11 PM

14
Setting Up The Scanner
Note that the batteries are intended to provide backup power for the clock
and for scanning for a short time. When the backup batteries becomes too
low, appears. Promptly replace the batteries.
When you either install batteries or connect the AC Adapter to a standard
Australia/New Zealand wall outlet, the scanner powers on and goes to
STANDBY mode. The display shows the initial clock time of 12:00 AM.
The scanner remains in STANDBY mode.
Connecting an
Antenna
The scanner uses an
external loop antenna to
receive AM broadcast
stations and an external
telescopic antenna to
receive all other signals.
Connect the supplied rod
antenna by pushing the
antenna’s connector onto
the antenna jack on the back of the scanner and twisting it to the desired
angle. Connect the two wires from the loop antenna to the AM RADIO
ANT terminals on the back of the scanner.
* Carefully remove the tube inserted before using the AM
Antenna Jack. When the Jack is not in use, keep the
tube mounted.
You can also use an external antenna (not supplied) to help to bring
in weaker signals. Use RG58, 50-Ohm lead with a BNC connector to
connect the antenna to the scanner. Connect and mount the antenna
according to the instructions provided with the antenna.
Setting Up The Scanner
UBC340CRS OM.indd 14 7/5/08 4:28:13 PM

15
CAUTION: Be sure to follow all safety warnings provided with the
antenna. Failure to do so could expose you to risk of injury or death and
could severely damage the scanner.
Using the Backlight
To turn on the backlight for 5 seconds, tap SNOOZE/Backlight. To turn
on the backlight permanently, press and hold SNOOZE/Backlight for over
2 seconds. To turn off the backlight, press and hold SNOOZE/Backlight
again.
Country Mode (Australia/New Zealand)
The UBC340CRS is set to the Australian mode by default.
Australian mode: Australian service search frequencies and TV channel
frequencies.
New Zealand mode: New Zealand service search frequencies and TV
channel frequencies.
The country mode can be switched between Australia (AUS) and New
Zealand (nL) as follows:
1. Turn on the power while pressing down the [HOLD] key.
The display will momentarily show AUS for Australian mode or nL for
New Zealand mode.
The country mode is remembered for the next power on.
2. To change the country mode again, repeat step 1.
Setting Up The Scanner
UBC340CRS OM.indd 15 7/5/08 4:28:13 PM

16
Using the Alarm Clock
Using the Alarm Clock
Your scanner’s Clock displays whenever you turn off the radio functions.
It can also be used as a standard alarm clock.
Setting the Current Time
Follow the steps to set the current time:
1. Move the slide switch to Clock Set.
The hour digits flash.
2. Press sor tto change the hour by one
hour increments or press the number keys
to select the present hour. Then press
E/PGM to set the hour. The minutes digits
flash.
3. Press sor tto change the minute setting by one minute or press the
appropriate number keys to enter the minutes. The seconds reset to
00. Press E/PGM, AM/PM flashes.
4. Press sor tto select AM or PM. To make your selection, move the
slide switch to Clock. The scanner exits the clock setting mode.
Setting the Alarm Clock
Follow these steps to set the alarm time:
1. Move the slide switch to Alarm Set.
The hours digits flash.
2. Press sor tto change the hour by one
hour increments or press the number keys
to select the present hour. Then press
E/PGM to set the hour. The minutes digits
flash.
3. Press sor tto change the minute setting by one minute or press the
appropriate number keys to enter the minutes. Press E/PGM to set the
minutes. The AM/PM display icon flashes.
4. Press sor tto move from AM to PM and back. Press E/PGM to
make your selection. To lock in the alarm time, move the slide switch
to Clock.
CAUTION: Be sure to follow all safety warnings provided with the
antenna. Failure to do so could expose you to risk of injury or death and
could severely damage the scanner.
Using the Backlight
To turn on the backlight for 5 seconds, tap SNOOZE/Backlight. To turn
on the backlight permanently, press and hold SNOOZE/Backlight for over
2 seconds. To turn off the backlight, press and hold SNOOZE/Backlight
again.
Country Mode (Australia/New Zealand)
The UBC340CRS is set to the Australian mode by default.
Australian mode: Australian service search frequencies and TV channel
frequencies.
New Zealand mode: New Zealand service search frequencies and TV
channel frequencies.
The country mode can be switched between Australia (AUS) and New
Zealand (nL) as follows:
1. Turn on the power while pressing down the [HOLD] key.
The display will momentarily show AUS for Australian mode or nL for
New Zealand mode.
The country mode is remembered for the next power on.
2. To change the country mode again, repeat step 1.
Setting Up The Scanner
UBC340CRS OM.indd 16 7/5/08 4:28:15 PM

17
Using the Alarm Clock
To have the UBC340CRS alert you at the
selected time, slide Off/Radio/Tone to either
Radio or Tone. If you set the selector to
Radio, the alarm will sound with the selected
audio source (AM/FM, Scanner, or AIR). If
you set the selector to Tone, the scanner will
sound a tone at the set time. To silence the
alarm, slide Off/Radio/Tone to Off. If you
do not turn off the alarm, it will sound for 20
minutes, then reset to alert you again the
following day.
Using Snooze
When the alarm sounds, press the snooze
bar to silence the alarm for 5 minutes.
UBC340CRS OM.indd 17 7/5/08 4:28:16 PM

18
Listening to AM/FM/TV Channels
Listening to AM/FM/TV Channels
To listen to AM/FM/TV channels, slide the
mode selector to AM/FM. Then, press the
button at the top of the scanner to select
the desired source (AM for AM Broadcast,
FM1 or FM2 for FM or TV Broadcast).
Directly Selecting a Channel
Press SVC/DIR to select the direct entry
mode. Use the s/tbuttons to step through
the selected band. The scanner stops on
active channels. TV channels are scanned
after FM channels in FM mode.
You can also enter the channel frequency
using the keypad, enter the channel
frequency (for FM or AM) or the TV channel
number and press E/PGM.
Using the Alarm Clock
UBC340CRS OM.indd 18 7/5/08 4:28:17 PM

19
Using AM/FM/TV Channel Memory
Your scanner has 30 AM/FM memories
for quick channel recall (10 for AM, 20 for
FM/TV). To store a channel into memory,
first select the band (AM, FM1 or FM2).
Then, directly select the channel you want
to store (see above). While listening to the
channel, press and hold the number button
that corresponds to the memory you want
to save the channel into for 2 seconds. The
scanner switches to the Memory mode for the current band.
To quickly recall a channel, select the band, select the channel memory
mode by pressing PRI/MEM, then tap the number button that corresponds
to the memory where the channel is stored.
Listening to AM/FM/TV Channels
UBC340CRS OM.indd 19 7/5/08 4:28:18 PM
