ADJUSTING
INSTRUCTIONS
FOR
STYLE
60000
D
DESCRIPTION
OF
MACfflNE
60000
D
Flatbed,
single
needle,
chain
stitch
Type
101,
for
closing
small
filled
paper
bags
on
Style
21800 N,
with
two
paper
reinforcing
tapes,
one
guided
next
to
presser
foot
and
the
other
next
to
feed
dog,
seam
Type
SSa-1,
round
belt
drive,
trimming
mechanism
for
top
of
bag,
automatic
cutter
severing
tape
between
bags,
stitch
range
5
to
8
per
inch.
Needles
for
machine
Style
60000
D
are
Type
924
and
are
available
in
sizes
.049,
054,
067,
073
and
080.
The
size
ofthe needleshouldbe
determined
by the
size
of
the
thread.
The
thread
should
pass
through
the
needle
eye
freely.
The
following
instructions
apply
to
the
machine
as
it
sets
in
front
of
the
mechanic
on
a
repair
table
with
the
pulley
to
the
right,
and
the
needle
bar
in
a
vertical
position.
-3-
From the library of: Superior Sewing Machine & Supply LLC
HOOK
AND
HOOK
SHAFT
Insert
a
needle
of
the
size
required
as
far
up
in
the
needle
bar
as
it
will
go
with
the
scarf
or
spot
toward
the
pulley
end
of
the
machine.
Tighten
the
clamp
nut.
Wrench
No.
116
is
available
for
this
purpose.
Fig.
1
The
hook
should
be
placed
in
the
hook
shaft
so
that
the
set
screw (A,
Fig.
l)
in
the
shaft
bears
against
the
flat
(B) on
the
shank
of
the
hook
and
the
set
screw
should
be
firmly
tightened.
With
the
needle
bar
in
its
lowest
position^
the
hook
should
be
set
so
that
its
point
is
3/16
inch
from
the
center
of
the
needle
(Fig.
2).
Gauge
No.21225-3/16
can
be
used
advantageously
in
making
this
adjustment.
In
order
to
obtain
the
above
setting
when
the
hook
is
out
of
adjustment,
it
becomes
necessary
to
re-time
the
hook
shaft.
In
re-timing
the
hook
shaft,
the
two
screws
(C,D,
Fig.
1)
in
the
hook
shaft
coupling
should
be
loosened
so
the
hook
shaft
turns
freely.
The
shaft
should
then
be
turned
with
the
fingers
and
the
hook
located
properly,
maintaining
the
needle
bar
in
its
lowest
position.
Retighten
coupling
screws
securely.
-k-
Fig.
2
From the library of: Superior Sewing Machine & Supply LLC
T)ie
hook
should
also
be
set
later
ally
so
there
Is
approximately
.003
inch
to
.005
inch
clearance
between
the
spot
in
the
needle
and
the
point
of
the
hook
(Fig.
3).
This
is
done
by
loosen
ing
set
screw
(A,
Fig.
1)
and
moving
the
hook
to
the
left
or
to
the
right
as
may
be
required
and
retightening
the
screw.
NEEDLE
BAR
HEIGHT
With
the
needle
bar
moving
upward-
ly,
the
point
of
the
hook
should
be
even
with
the
back
of
the
needle
(Fig.
4)
when
the
bottom
of
the
point
is
1/64
inch
above
the
eye
of
the
needle.
Sy
loosening
clamp
screw
(E,
Fig.
14)
the
needle
bar
can
be
set
to
the
Fig.
3
correct
height.
As
a
final
check
see
that
the
needle
in
its
lowest
position,
does
not
strike
the
sides
of
the
hole
in
the
hook.
FEED
DOGS
The
front
feed
dog
(A,
Fig.
5)
should
be
set
so
that
at
its
highest
point
of
travel,
it
projects
the
full
depth
of
the
teeth
above
the
throat
plate.
Height
adjust
ing
screw (c)
for
the
front
feed dog
is
set
Fig*
4
in
the
feed
bar
so
that
the
screw
driver
slot
is
toward
the
bottom
of
the
machine
which
makes
for
easier
adjustment
when
machine
is
in
operating
position.
a
Fig.
5
-5-
.003
005
CLEARANCE
From the library of: Superior Sewing Machine & Supply LLC
The
rear
feed
dog
(B)
should
be
set
slightly
lower
than
the
front
feed
so
that
only
3/A
of
the
depth
of
a
tooth
extends
above
the
throat
plate
when
the
feed
dog
is
at
its
highest
point
of
travel.
This
is
done
to
prevent
the
possi
bility
of
the
rear
feed
dog
back
feeding.
LOWER
TAPE
CUTTER
KNIFE
Lower
tape
cutter
knife
(D^
Fig.
5)
should
be
set
in
the
holder
so
that
the
knife
edge
(E)
is
located
flush
with
the
top
of
the
throat
plate.
Adjusting
screw
(F)
is
used
to
raise
the
knife
to
its
proper
height
and
maintain
this
height
when
in
operation.
UPPER
TAPE
CUTTER
KNIFE
The
upper
tape
cutter
knife
(B,
Fig.
6)
must
be
set
after
the
tape
cutter
knife
bar
(A)
has
been
correctly
located.
The
knife
should
then
be
positioned
so
that
the
highest
point
of
its
cutting
edge
passes
the
cutting
edge
of
the
lower
knife
by
1/32
inch
when
the
knife
bar
is
in
its
lowest
position.
For
efficient
operation,
the
cutting
edges
of
the
upper
and
lower
knives
must
have
a
slight
shearing
angle
so
that
there
will
be
a
cutting
action
the
whole
l^gth
of
the
blades.
This
angle
is
set
in
the
upper
knife
mechanism
at
the
factory.
-6-
From the library of: Superior Sewing Machine & Supply LLC
The
two
cutting
edges
must
exert
a
pressure
against
one
another.
The
amount
of
press\ire
should
be
such
that
it
can
be
felt
in
the
upper
tape
cutter
knife
bar
when
the
knife
bar
is
pressed
down
with
the
finger.
The
pressure
is
ob
tained
by
adjusting
the
screw
(C^
Fig.
6)
in
the
upper
tape
cutter
knife
bar.
Turning
screw
to
the
right
adds
pressure
against
lower
knife,
turning
screw
to
the
left
acts
the
reverse.
AUTOMATIC
TAPE
CUTTING
MECHANISM
The
automatic
tape
cutting
mechanism
has
four
main
adjustments.
Adjustment
No. 1
(Fig.
7)
regulates
the
stop
position
of
actuating
lever
(A).
This
stop
is
properly
set
when
there
is
a
small
eunount
of
play,
from
1/32
to
1/16
inch,
between
points
(B) and (C) when
the
mechanism
is
at
rest.
Adjustment
No.
2
is
for
the
spring
that
maintains
a
downward
tension
on
the
actuating
shoe
(D).
The
tension
on
this
spring
is
corrected
loosening
the
two
set
screws (F)
and
turning
stud
(G)
clockwise
to
increase
tension
and
counterclockwise
to
reduce
tension.
The
tension
on
this
spring
should
be
only
sufficient
to
operate
the
mechanism
promptly
as
shoe
(D)
rides
off
the
bag.
Too
great
a
tension
Fig.
7
on
this
spring
will
cause
the
shoe
to
force
the
bag
down
into
the
throat
plate
slot
(E)
causing
the
front
end
of
the
bag
to
have
uneven
tape
ends.
Tighten
screws
(F)
securely
when
the
tension
has
been
properly
culjusted.
Adjustment
No. 3
limits
the
distance
shoe
(D)
drops
into
the
throat
plate
slot
(E)
and
controls
the
position
of
cutting
as
shoe
(D)
rides
on
to
the
bag.
This
depth
of
adjustment
is
proper
when
shoe
(D),
in
its
upward
travel,
is
about
1/32
inch
below
the
top
surface
of
throat
plate
as
the
points
(B)
and
(C)
pass.
From the library of: Superior Sewing Machine & Supply LLC
Adjustment
No. 4
locates
the
position
of
shoe
(D) on
the
end
of
the
actuating
lever
extension
(H)
and
controls
the
length
of
tape
on
the
ends
of
the
bag.
The
overall
length
of
the
tape
is
a
fixed
amount
and
is
only
divided
on
each
end
of
the
bag
by
the
location
of
shoe
(D).
This
automatic
tape
cutting
mechiuiism,
although
it
appears
complicated
and
to
have
numerous
adjustments^
is
relatively
simple
in
that
all
adjustments
are
fixed
and
there
is
no
reason
to
deviate
from
instructions.
Properly
adjusted,
it
will
give
a
positive
single
clip
at
each
end
of
the
sewn
bag
and
will
not
double
chop.
Several
details
of
the
tape
cutting
mechanism
were
not
discussed
in
the
instructions
for
the
four
main
adjustments
because
they
do
not
actually
enter
into
the
adjusting
of
the
unit.
It
is,
however,
necessary
that
the
mechanic
have
some
knowledge
of
these
because
they
are
important
to
the
func
tioning
of
the
unit
in
the
event
it
should
be
necessary
to
replace
any
parts.
The
actuating
lever
dog
(A,
Fig.
8)
is
held
on
to
the
actuating
lever
(B) by a
hinge
screw
(C).
The
amount
of
hinge
of
(A)
on (b)
is
limited
by two
stop
pins
(D). The
position
of
the
dog
(A)
is
controlled
by
the
stationary
spring
and
stationary
pin
(F).
The
function
of
this
Fig.
8
spring
is
to
allow
the
point
of
(A)
to
lag
as
it
contacts
the
point
of
the
trip
dog
(G)
until
the
actuating
dog
(A)
reaches
the
limit
of
hinge
controlled
by
pins
(D).
Spring
(£)
then
accelerates
the
point
of
(A)
in
the
direction
the
lever
is
moving
to
msike
the
points
of
(A)
and
trip
dog
(G)
pass
each
other
by
a
considerable
simount
and
prevent
the
possibility
of
a
double
chop.
After
the
upper
tape
cutter
knife
(B,
Fig.
6)
has
been
temporarily
assembled
in
the
upper
tape
cutter
bar
(A),
set
the
bar
height
by
manipulating
adjusting
screw
(C,
Fig.
9)
so
that
.015
to
.020
inch
dist2ince
remains
between
the
point
of
driving
pawl
(A,
Fig.
9)
and
the
point
of
ratchet
lever
(B)
-8-
From the library of: Superior Sewing Machine & Supply LLC
when
the
ratchet
lever
is
in
Its
lowest
operating
position.
Maintain
this
adjustment
by
locking
the
nut
(D)
on
adjusting
screw
(C).
A^ C
Fig.
9
sTO
ADJUST
HEIGHT
OF
THE
DRIVING
PAWL
ABOVE
RATCHET
LEVER
With
set
screw (A,
Fig.
10)
released
from
position,
adjust
the
point
of
pawl
(B)
above
the
point
of
ratchet
Q
Fig.
10
lever
(C)
to
1/32
inch
by
loosening
screw (D) and moving
adjusting
block
(E)
in
or
out
whichever
is
required.
This
-9-
From the library of: Superior Sewing Machine & Supply LLC
adjustment
Is
made when
the
pawl
lever
extension
(F)
is
rest
ing
against
dog
(G).
Retighten
screw
(D)
securely.
Maintain
this
position
by
setting
and
locking
screw
(A)
to
this
height,
but
do
not
exert
a
tension
on
spring
(H)
with
screw
(a)
.
The
trip
of
this
mechanism
is
accurately
set
when
the
point
of
the
pawl
lever
extension
(A,
Fig.
11)
passes
over
the
top
of
the
point
of
dog
(B)
momentarily
before
the
point
Fig.
11
/
of
the
actuating
lever
trip
dog (C)
passes
the
point
of
dog
(D)
at
position
(E) when
the
actuating
lever
is
moved
either
up
or
down
causing
the
points
at
(E)
to
pass.
This
adjust
ment
is
made by
loosening
clamp
screw
(G)
and
moving
the
dog
(B) up
or
down
whichever
is
required.
NOTE;
On
machines
having
the
dogs (B and D)
in
one
integral
unit
without
any
clamp screw (G),
this
adjustment
is
made by
loosening
the
screw (F) and moving
the
pawl
lever
extension
(A) up
or
down
as
required.
Fig.
12
From the library of: Superior Sewing Machine & Supply LLC
The
height
of
dog
(F,
Fig.
12)
is
properly
set
hy
ad
justing
screw
(C)
against
stop
pin
(D)
until
the
point
of
the
dog (F)
is
flush
with
the
top
of
the
lever
extension
(G).
This
adjustment
and
the
one
in
the
preceding
paragraph
may
seem
to
conflict.
However,
by
working
these
two
adjustments
together
the
desired
settings
will
be
obtained.
Spring
(a.
Fig.
12)
should
be
positioned
in
the
proper
notch
of
bracket
(B)
to
return
screw (C)
against
stop
pin
(D)
during
the
clipping
cycle
when
the
dog (£)
is
free
to
move.
Another
feature
not
mentioned
in
the
adjusting
instruc
tions
is
the
action
of
springs
(A and B,
Fig.
13).
Spring
(a)
engages
the
driving
pawl
(C)
into
ratchet
lever
(D) when
dog
(E)
is
tripped
by
the
movement
of
the
actuating
lever.
It
is
important
that
this
spring
be
strong
enough
to
overcome
the
tension
of
spring
(F)
that
holds
dog
(E)
in
position.
EXAMPLE:
If
dog
(e)
is
tripped
while
the
ratchet
lever
(D)
is
in
its
forward
position
as
indicated
by
dotted
line,
pawl (C)
will
by
action
of
spring
(A)
drop
to
rest
on
top
of
ratchet
lever
(D). Pawl (C)
will
not
drop
into
operating
position
until
(D)
has
returned
to
the
back
of
its
stroke.
It
is
then
necessary
for
spring
(A)
to
drop
pawl (C)
into
ratchet
lever
(D)
firmly
and
completely.
In
making
this
Fig.
13
motion,
the
pawl
lever
extension
(G)
forces
dog (E) downward
thereby
overcoming
the
action
of
spring
(F)
which
holds
dog
(E) up
into
position.
Spring
(B)
is
a
strong
spring
and
used
only
to
cushion
the
disengagement
of
pawl
(C)
from
ratchet
lever
(D) when
the
clipping
cycle
is
completed.
-11-
From the library of: Superior Sewing Machine & Supply LLC
EXAMPLE:
As
ratchet
lever
(D,
Fig.
13)
is
returning
to
its
lowest
position
and
the
knife
bar
is
coming,
up
from
the
clip,
pawl
lever
extension
(G)
contacts
dog
(eJ,
which
has
returned
to
rest
position
by
action
of
spring
(F).
Spring
(B)
is
then
compressed
until
the
knife
bar
comes
to
rest
against
its
stop
screw.
Pawl
(C)
is
then
disengaged
by
the
action
of
spring
(B)
overcoming
the
tension
of
spring
(A).
Fig.
U
-12-
From the library of: Superior Sewing Machine & Supply LLC
PRESSER
BAR
HAND
LIFTER
Assemble
the
presser
foot
to
the
presser
bar.
Turn
handwheel
so
the
feed
dog
Is
In
Its
lowest
position.
Set
presser
bar
connection
(A,
Fig.
I4)
so
there
is
3/32
inch
clearance
between
it
and
the
hand
lifter.
PRESSER
BAR
Set
the
lower
presser
spring
collar
(B,
Fig.
I4.) so
there
is
1/16
inch
clearance
between
the
top
of
the
presser
bar
connection
and
the
bottom
of
the
collar.
Only
enough
pressure
to
feed
the
material
uniformly
should
be
applied
to
the
presser
foot.
To
increase
the
pressure
turn
the
regulator
(C)
in
a
clockwise
direction.
Turning
the
regulator
in
the
opposite
direction
releases
the
pressure.
The
presser
bar
can
be
swung
in
any
position
desired
to
line
up
the
front
presser
foot
by
loosening
the
set
screw
in
the
presser
bar
connection
(A,
Fig.
I4.).
NEEDLE
BAR
EfELET
With
the
needle
bar
in
its
highest
position^
the
needle
bar
thread
eyelet
holder
(D,
Fig.
I4.)
should
have
1/32
inch
clearance
between
it
and
the
bottom
of
the
bushing.
To
set
the
eyelet
correctly^
turn
handwheel
until
needle
bar
is
in
its
Mghest
position,
loosen
eyelet
holder
cl£unp
screw
and
move
eyelet
and
eyelet
holder
to
their
correct
positions.
TAKE-UP
EYELET
When
the
needle
bar
thread
eyelet
(A,
Fig.
15)
is
at
the
bottom
of
its
stroke,
the
take-up
eyelet
(B)
should
be
positioned
so
that
a
thread
drawn
through
the
take-up
thread
holes
and
the
needle
bar
thread
eyelet
hole
will
form
a
horizontal
line.
Also,
the
needle
bar
thread
eyelet,
in
its
lowest
position,
shooild
be
located
in
the
middle
of
the
needle
thread
take-up
eyelet
equidistant
from
the
Fig.
15
two
take-up
eyelet
thread
holes.
BAG
TRIMMING
KNIFE
The
bag
trimming
knife
(A,
Fig.
16)
should
be
set
cen
trally
in
the
knife
slots
in
the
presser
foot
and
throat
plate.
It
should
also
be
set
so
that
when
at
its
highest
position,
the
point
of
the
knife
is
1/32
inch
below
the
sur
face
of
the
throat
plate.
In
order
to
set
the
knife
for
height
loosen
knife
driving
stud
clamp screw "B" which
allows
the
knife
and
knife
holder
to
be
moved
up
or
down
to
proper
position.
To
set
the
knife
laterally,
loosen screws
(C)
and
locate
knife
in
center
of
knife
slot.
-13-
From the library of: Superior Sewing Machine & Supply LLC
Fig.
16
INTERMITTENT
THREAD
NIPPER
The
thread
nipper
is
set
correctly
when a maximum
amount
of
tension
can
be
applied
to
the
spring
without
breaking
the
thread
and
yet
have
sufficient
opening
between
the
tension
discs
to
allow
free
passage
of
thread
as
the
tension
is
re
leased.
After
the
nipper
mechanism
has
been
adjusted^
the
tension
should
be
relieved
and
Just
enough
tension
applied
to
eliminate
occa
sional
large
loops
in
the
stitching,
and
to
prevent
the
hook
from
catch
ing
the
cast
off
loops
causing
broken
stitches
to
occur
in
the
sewing.
The
nipper
mechanism
is
ad-
Justed
by
raising
or
lowering
the
thread
nipper
sleeve
(A,
Fig.
17)
in
the
sleeve
holder
(B).
The
opening
between
the
discs,
can
be
increased
by
loosening
the
set
screw
(C)
and
tapping
the
top
of
the
tension
post
forcing
the
nipper
mechanism
deeper
into
the
sleeve
holder.
Inserting
a
screw
driver
between
the
tension
eyelet
and
the
sleeve
holder
and
forcing
the
nipper
mechanism
up
decreases
the
amount
of
opening
between
the
discs.
The
nipper
mechanism
is
set
correctly
for
a
12-4
twine
when
there
is
a
3/64
inch
space
between
the
discs
at
their
open
position.
The
sleeve
should
then
extend
3/64
inch
out
of
the
sleeve
holder.
-14-
From the library of: Superior Sewing Machine & Supply LLC
THREADING
Thread
the
machine
as
shown
in
the
threading
diagram
(Fig.
18)
noting
the
position
of
the
tension
eyelets.
The
needle
thread
tension
(the
one
nearest
the
cone
of
thread)
should
be
set
so
that
Just
enough
tension
is
applied
to
the
thread
to
pull
up
a
neat
stitch.
-15-
From the library of: Superior Sewing Machine & Supply LLC
TAPE
GUIDES
The
lower
tape
guide
must
be
set
so
that
the
delivery
end
fits
up
against
tape
opening
in
the
throat
plate.
The
tape
should
then
slide
from
the
guide
into
the
throat
plate
in
one
continuous
motion
until
it
contacts
the
presser
foot.
The
setting
of
the
upper
tape
guide
is
a
matter
of
placing
its
brackets
in
their
proper
places.
Refer
to
the
threading
diagram
(Fig.
18)
for
these
adjustments.
STITCH
LENGTH
To
set
the
length
of
stitch,
loosen
the
hexagonal
head
screw
(A,
Fig.
19)
that
holds
the
feed
drive
eccentric
connecting
rod
to
the
feed
rocker.
Wrench
No.
21388
AG
is
available
for
this
purpose.
Moving
the
sleeve
screw
nut
(B)
in
the
feed
rocker
slot
(C)
toward
the
cloth
plate
shortens
the
stitch,
the
reverse
lengthens
the
stitch.
Make
sure
that
hexagonal
head
screw
is
tight
after
setting
the
stitch
length.
Fig.
19
OILING
Before
starting
the
machine,
make
sure
that
all
oiling
points
as
indicated
on
(Fig.
20)
are
lubricated
with
a
straight
mineral
oil
similar
to
an
S.A.E.
10
W.
The
oiling
points
are
arranged
in
numerical
sequence
on
the
chart
for
the
operator's
convenience.
When
machine
is
operated
all
day
long
and
in
hard
ser
vice,
oil
twice
daily,
once
at
the
morning
start
and
again
at
the
noon
start.
If
there
is
a
large
quantity
of
dust
in
the
air,
more
frequent
oilinv-
will
be
beneficial.
From the library of: Superior Sewing Machine & Supply LLC
Fig.
20
-17-
From the library of: Superior Sewing Machine & Supply LLC
The
amount
of
grease
In
the
gear
housing
should
be
checked
semi-annually
to
keep
gears
well
lubricated.
If
more
Is
necessary^
refill
with
grease
similar
to
a
commercial
No.
3.
The
correct
application
of
good
quality
oil
and
grease
will
add
years
of
service
and
trouble
free
operation.
FEED
TIMING
The
feed
dog
and
needle
bar
motions
are
synchronized
so
that
when
the
handwheel
is
turned
in
the
operating
direction
and
the
needle
bar
is
moved downwardly
until
the
top
of
the
eye
of
the
needle
is
even
with
the
top
surface
of
the
throat
plate,
the
teeth
of
the
feed
dog
are
.015
inch
above
the
throat
plate
and
the
feed
is
descending.
This
adjustment
is
made
at
the
factory.
For
convenience
in
checking,
timing
marks
will
be
found
on
the
feed
drive
shaft
collar
and
its
adjoining
bushing
(F,
G,
Fig.
1).
If
the
machine
is
synchronized
as
described
above,
the
timing
marks
will
coincide
when
the
needle
bar
is
at
the
bottom
of
its
stroke.
CAUTION:
Do
not
change
timing
of
machine
unless
it
becomes
abso
lutely
necessary.
If
machine does
not
operate
correctly,
check
all
the
other
adjustments
on
the
machine.
In
all
probability,
it
will
be
found
that
some
other
adjustment
has
not
been
taken
care
of.
Fig.
21
Should
it
become
necessary
to
change
the
timing
the
following
procedure
must
be
observed.
-18-
From the library of: Superior Sewing Machine & Supply LLC
1.
2.
3.
4.
5.
6.
7.
Check
to
see
if
the
fillister
head
screw
in
the
feed
driving
shaft
collar
(A,
Fig.
21)
bears
against
the
flat
on
shaft
(E).
Remove
gear
housing
cover.
Check
position
of
feed
driving
gear
(B)
on
the
shaft.
When
the
handwheel
is
turned
in
the
operating
direc
tion
and
the
feed
driving
gear
is
rotating
in
the
direction
indicated
by
the
arrow
(Fig.
21),
the
first
screw
coming
into
view
is
the
time
screw
(C)
and
should
bear
against
the
flat
on
the
shaft.
The
flat
for
the
time
screw
is
in
line
with
the
flat
for
the
feed
driving
shaft
collar
set
screw.
Loosen
the
screws
in
the
feed
driving
gear
and
disen
gage
the
gear
from
the
intermediate
gear
(D) by
sliding
it
to
the
right.
Turn
handwheel
in
operating
direction
until
needle
bar
is
at
the
bottom
of
its
stroke.
Turn
the
feed
driving
shaft
(E)
with
the
fingers
un
til
the
timing
marks
on
the
collar
£ind
the
bushing
coincide.
Re-engage
driving
gear
temporarily
with
the
time
screw
up
as
high
as
possible
and
still
remain
access
ible
to
a
screw
driver
(Fig.
22).
Tighten
screw
only
enough
to
maintain
adjustments.
Fig.
22
8.
Turn
handwheel
in
operating
direction
until
fillister
head
screw
(A,
Fig.
21)
in
the
feed
driving
shaft
collar
is
in
line
with
the
timing
mark
on
the
bushing.
9*
Loosen
time
screw
in
driving
gear,
disengage
gear,
holding
handwheel
to
maintain
settings,
and
turn
driving
gear
so
that
the
time
screw
is
in
line
with
the
timing
mark
on
the
bushing.
Re-engage
gear
and
tighten
all
screws
securely.
10.
Check
timing
and
reset
hook
and
hook
shaft
as
pre
viously
described.
-19-
From the library of: Superior Sewing Machine & Supply LLC
r
^4
9.
o'I
WORLD'S FINEST
QUALITY
★
INDUSTRIAL
SEWING
MACHINES
"*'*#06
UNION
SPECIAL
maintains
sales
and
service
facilities throughout
the
world. These offices will
aid you in the selection of the right sewing
equipment for your particular operation.
Union
Special representatives
and
service men
are
fac
tory trained and are able to serve your needs
promptly and efficiently. Whatever your loca
tion, there is a
Union
Special Representative to
serve you. Check with himtoday.
ATLANTA,
GA.
BOSTON,
MASS.
CHICAGO,
ILL.
DALLAS,
TEXAS
LOS
ANGELES,
CAL.
NEW
YORK,
N.
Y.
PHILADELPHIA,
PA.
MONTREAL,
CANADA
TORONTO,
CANADA
BRUSSELS,
BELGIUM
LEICESTER,
ENGLAND
LONDON,
ENGLAND
PARIS,
FRANCE
STUHGART,
GERMANY
Representatives
and
distributors
in
all
important
industrial
cities
throughout
the
world.
MACHINE
COMPANY
400
N.
FRANKLIN
ST.,
CHICAGO,
ILL.
60610
From the library of: Superior Sewing Machine & Supply LLC
Table of contents
Other UnionSpecial Sewing Machine manuals
UnionSpecial
UnionSpecial 80800R Setup guide
UnionSpecial
UnionSpecial 61800 Series Instruction sheet
UnionSpecial
UnionSpecial 80800 User manual
UnionSpecial
UnionSpecial 57700 Series Instruction sheet
UnionSpecial
UnionSpecial 34700 F Parts list manual
UnionSpecial
UnionSpecial 81300B1HL User manual
UnionSpecial
UnionSpecial BC200 Setup guide
UnionSpecial
UnionSpecial 81500A Setup guide
UnionSpecial
UnionSpecial CLASS 2100 Instruction sheet
UnionSpecial
UnionSpecial SP100 Series User manual
UnionSpecial
UnionSpecial 39500FW Instruction sheet
UnionSpecial
UnionSpecial 39500 Series Instruction sheet
UnionSpecial
UnionSpecial 3100A Datasheet
UnionSpecial
UnionSpecial 31200AQ64Z6 Setup guide
UnionSpecial
UnionSpecial 307 Setup guide
UnionSpecial
UnionSpecial BC200 User manual
UnionSpecial
UnionSpecial PT0502-GR User manual
UnionSpecial
UnionSpecial 63900 Series Instruction sheet
UnionSpecial
UnionSpecial Advanced 56100 Series User manual
UnionSpecial
UnionSpecial CS100 series User manual
Popular Sewing Machine manuals by other brands
Merrow
Merrow 60AD Instructions for setting up and operating
Singer
Singer 620 Service manual
Pfaff Industrial
Pfaff Industrial 5626-840 Series Adjustment manual
typical
typical GC0303D Operation instructions
Brother
Brother BE-0901E PC Oiling Procedures
Baby Lock
Baby Lock Enterprise BNT10L Instruction and reference guide
