Unipulse TM200 User manual

Introduction
I
Introduction
I
Introduction
Thank you for purchasing the TM200 torque monitor.
TM200 is a dedicated USB interface for the UNIPULSE UTM Ⅱseries. This product can be used with
devices which utilize UTMⅡ.
Be sure to read this operation manual before use in order to take full advantage of the superb quality of the
TM200 and to use it properly and safely. Use this product with accurate understanding of the contents.
Keep this operation manual in a safe place to be used for further reference.
Safety precautions
Make sure that installation, maintenance, and inspection of the TM200 are performed by personnel with
electrical knowledge.
In this manual, precautions for safe use of the TM200 are described separately as and
in the following text. The precautions described in this text are important contents regarding
safety. Use this product with accurate understanding of the contents.
Be sure to read for safety.
Warning
Events that may cause death or severe injury to personnel in case of misuse.
Caution
Events that may cause injury to personnel or material damage in case of misuse.
Warning
Caution

Warning
II
Warning
II
Warning
●Prepare a safety circuit outside the TM200 so that the entire system functions safely
if the TM200 fails or malfunctions.
●Be sure to contact our sales representative before use if the TM200 will be used in
the following situations:
- In an environment not described in the operation manual;
- In a way that causes substantial effects on medical devices, transportation equipment,
entertainment devices, safety devices, etc.
●Do not disassemble, repair or alter the TM200. Fire or electric shock may occur.
●Do not install the product in the following environments:
- Locations with corrosive gases or combustible gases;
- Locations over which water, oil, or chemicals splash.
●Do not connect commercial power supply directly to the main unit.
(Be sure to use the dedicated AC adapter included.)
●Do not connect AC adapters other than the dedicated adapter included for the TM200 to
the power input connector.
●Be sure to check wiring and so on carefully before turning the power on.
●Use power supply voltage within the rated range.
●Do not damage the power cords. Fire or electric shock may occur.
●Electric shock may occur inside the main unit when the cover is opened.
Internal capacitors are charged even when power supply is cut off.
Contact us for inspection and repair of internal parts.
●In case of smoke, abnormal smell or abnormal noise, unplug the adapter from the outlet
and the USB cable from the PC immediately.
Events that may cause death or severe
injury to personnel in case of misuse.
Design warning
Installation warning
Wiring warning
Startup/maintenance warning

Caution
III
Caution
III
Caution
●Do not install the product in the following environments:
- Locations where temperature or humidity exceeds specifications;
- Locations subject to drastic temperature fluctuations or icing and condensing;
- Outdoors or locations above 2,000m;
- Locations exposed to direct sunlight;
- Locations subject to dust accumulation;
- Locations with poor ventilation;
- Locations with excessive salt and metal powder;
- Locations where the main unit is subject to direct vibration and shock.
●Perform adequate shielding if the product is used in the following locations:
- Near power lines;
- Locations subject to strong electric field and magnetic field;
- Locations subject to noise such as static electricity and relays.
●Install the product as far away as possible from equipment generating high frequency, high
voltage, large current, surge, etc. Perform wiring of cables separately from these power
lines. Do not perform parallel wiring and identical wiring.
●Do not use the product if it is damaged.
●Be sure to have a time interval of five seconds or longer between turning the power on and
off or between the USB cable plugging in and unplugging.
●Use only after warming up for 30 minutes or longer following the start of power supply.
●Protective performance of the TM200 may be lost if it is not used as specified.
●Cleaning
- During cleaning, unplug the adapter from the outlet and the USB cable from the PC.
- Do not wipe with a wet cloth, benzine, thinner, alcohol, etc. Doing so may cause
discoloration or deformation of the TM200. When dirty, clean the product with a cloth
soaked in diluted neutral detergent and squeezed and then wipe with a soft, dry cloth.
●Although the TM200 is considered to be sufficiently shock absorbing during delivery, reusing
the same packaging materials may damage the product when a shock is encountered. When
sending this product to us for repair and so on, pack it with sufficiently shock-absorbing materi-
als.
●Dispose of as industrial waste.
Events that may cause injury to personnel
or material damage in case of misuse.
Installation precautions
Startup/maintenance precautions
Transportation precautions
Disposal precautions

Product supporting RoHS Directive
IV
Product supporting RoHS Directive
IV
Product supporting RoHS Directive
The parts and accessories used in this product (including the operation manual, package box and so on)
support RoHS Directive, which regulates the use of toxic substances that may have adverse effects on the
environment and the human body.
RoHS Directive
RoHS stands for Restriction on Hazardous Substances. This is an EU regulation regarding toxic
substances. This directive prohibits the use of six specific substances in electrical/electronic equipment
sold in the EU region. The six substances include lead, mercury, cadmium, hexavalentchromium, PBB
(polybrominated biphenyl) and PBDE (polybrominated diphenyl ether).

Contents
V
Contents
V
Contents
1 Outline. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1-1. Main features of the TM200 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1-2. Package contents and accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1-3. Dedicated PC application and operation manual (this manual) . . . . . . . . . . . . . . . . . . 1
1-4. Connection with other devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1-5. Part names and functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1-6. Procedures for the first-time use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2 Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2-1. Connection procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Connection of power input connector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Connection of UTM Ⅱ. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Connection of the USB cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Connection to the outlet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3 Setting Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3-1. USB interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Communication specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3-2. PC preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
PC operating environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
USB driver installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
USB connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Check of virtual COM port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Installation of the dedicated PC application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Turn-on of power supply. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Startup of PC application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Specification of COM port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3-3. Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
File . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
COM port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3-4. Waveform tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Waveform tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Setting conditions for waveform acquisition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Digital zero . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Cursor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Waveform zoom-in . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Setting for smooth waveform display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3-5. Setting tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
System settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Initialization of the system settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Automatic deletion of waveform (CSV) files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3-6. Calibration tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Contents
VI
Contents
VI
Detail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Sensor type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Retrieve calibration settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Initialization of calibration settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Calibration settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Rotation speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3-7. Management tab. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Waveform (CSV) file comments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Setting protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Self check. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
3-8. Exiting procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
PC application exiting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Cable removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
4 Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
4-1. Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Equivalent input calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Actual load calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
4-2. Sensor type setting and calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Standard. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Custom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
4-3. Procedures of equivalent input calibration and actual load calibration (torque) . . . . . 30
Input procedure of rated capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
4-4. Display setting of rotation speed/power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
4-5. Unit conversion table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Unit conversion table of torque. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Unit conversion table of power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
5 Function Description Related to Indicated Values . . . . . . . . . . . . . . . . . . . . 37
5-1. Indicated values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
5-2. Digital zero . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
5-3. Moving average filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
5-4. Digital low-pass filter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
6 Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
6-1. Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
UTM Ⅱinterface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Display section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
USB interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
General performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
6-2. Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
6-3. TM200 block diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Contents
VII
Contents
VII
7 Appendices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
7-1. List of setting values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
7-2. Waveform data file format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
7-3. Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Contents
VIII
Contents
VIII
M E M O

1
1 Outline
1
Outline
Chapter
1
1-1. Main features of the TM200
●This is a simple torque monitor to check and fetch the data of the rotation torque meter in
the UTMⅡseries easily.
●In addition to torque, rotation speed and power can also be displayed on the PC.
●Up to 1000 files of waveform data from 0.1 to 1000 seconds can be fetched in CSV format
on the PC.
●While fetching the waveform data, a level trigger function is available, which prompts
fetching when a level change occurs in torque, rotation speed or power.
●Waveform data is displayed in graphs which are easy to check. Furthermore, the
maximum, minimum and average values can also be displayed.
1-2. Package contents and accessories
The following items are included in the package box.
Be sure to check the contents before use.
1-3. Dedicated PC application and
operation manual (this manual)
A USB driver and the dedicated PC application are required to use the TM200. Download and
install them from respective websites.
* Refer to P.6 "3-2.PC preparation" for details.
This manual can be downloaded from the UNIPULSE website or can be viewed in the help of the
dedicated PC application.
When the dedicated PC application is updated, this operation manual may also be updated.
Download the latest version of the operation manual or view the help of the dedicated PC
application.
To download the manual, user registration (free) is required.
* http://www.unipulse.com/en/products/TM200.html
1Outline
TM200 main unit・・・One unit TM200 setup guide・・・One copy
Cable for UTMⅡconnection (2m)・・・One piece
(with connector)
miniB-PC
USB cable (1.8ｍ)・・・One piece
Dedicated AC adapter
for the TM200 (1.8m)・・・One piece

2
1 Outline
2
Outline
Chapter
1
From ■Download at the bottom of this page, the operation manual and software can be downloaded.
1-4. Connection with other devices
1-5. Part names and functions
STATUS lamp (green)
UTMⅡoperation status is indicated.
This lamp lights off at stop and lights on shortly during operation to indicate the status.
Stop: Lights off
Detect torque: Lights on once
Detect rotation: Lights on twice
Detect torque and rotation: Lights on three times
Overload: Flashes
* The status with torque indicates a condition where input of approx. ±0.1V or more is detected;
the overload indicates a condition where input of approx. ±6V or more is detected.
Operation manual Dedicated PC application
㼁㼀㻹䊡㼟㼑㼞㼕㼟
STATUS lamp
POWER/ALM lamp
USB connector
Power input connector
UTMⅡconnection connector

3
1 Outline
3
Outline
Chapter
1
POWER/ALM lamp (red)
USB communication and power supply status from the AC adapter are indicated.
This lamp lights on during normal operation and lights off shortly when an error occurs to indicate
the status.
Normal: Lights on
When the PC application is not communicating:
Lights off once
When the AC adapter is not connected:
Lights off twice
Power input connector
The dedicated AC adapter included for the TM200 is connected.
Input power is AC100 to 240V (-15%, +10%), free power supply. Frequency is 50/60Hz.
* Refer to P.4 "Connection of power input connector" for connection.
UTMⅡconnection connector
UTMⅡis connected with the dedicated cable.
* Refer to P.4 "Connection of UTMⅡ" for connection.
USB connector
This part is connected to the PC with the USB cable included.
* Refer to P.5 "Connection of the USB cable" for connection.
1-6. Procedures for the first-time use
Set up the product following the procedures below.
1. Connect the AC adapter and UTMⅡ. Refer to P.4 "2-1.Connection procedure".
2. Install the USB driver and the dedicated PC application.
Refer to P.6 "3-2.PC preparation".
After installing this USB driver, connect the TM200 and PC with the USB cable.
Hereinafter, use the dedicated PC application to operate the TM200.
3. Set the sensor type. Refer to P.21 "3-6.Calibration tab" and perform calibration.
Once set, the torque and rotation speed can be checked in the waveform tab of the PC application.
Hereafter, set up the actual load calibration, filter and so on as required.

4
2 Connection
4
Connection
Chapter
2
The following precautions are related to connection.
The precautions described in this text are important contents regarding safety.
Connect this product with accurate understanding of the contents.
2-1. Connection procedure
Connection of power input connector
The dedicated AC adapter for the TM200 is connected to
the power input connector of the main unit.
Connection of UTMⅡ
The connection with UTMⅡcan be easily performed with the dedicated cable included. Both ends
of the connector have the same shape, and the cable is connected straight. Since the cable has no
directionality, either side of the connector may be connected to UTMⅡand TM200.
Connect UTMⅡwhile paying attention to the direction of the arrow on the connector.
Warning
●Do not connect commercial power supply directly to the main unit.
●Be sure to check the wiring and so on carefully before turning the power on.
●Be sure to use the dedicated AC adapter included for the TM200.
2Connection

5
2 Connection
5
Connection
Chapter
2
●Pin assignment
* The wire colors correspond with the color of cable included with UTMⅡ.
* Compatible connector: HR30-6P-6P (manufactured by HIROSE ELECTRIC CO., LTD.)
(Model without optional connector: CN90)
Connection of the USB cable
The USB cable included enables easy connection to the
PC.
Do not connect the USB cable if TM200 is being
connected with the PC for the first time. Refer to P.6
"3-2.PC preparation" for connection procedures.
Once the USB cable is connected, the TM200 turns on due
to power supply from the USB cable, and POWER/ALM
lamp (red) lights on or lights off once or twice.
Connection to the outlet
After connecting to UTMⅡ, the AC adapter is connected to the outlet.
Input power is AC100 to 240V (-15%, +10%), free power supply. Frequency is 50/60Hz.
Pin-out Pin number Wire color Signal name
1Red PWR＋(+24V)
2Black PWR－(0V)
3Green SIG IN (±5V DC)
4White SIG GND
5Yellow PULSE IN＋
6Brown PULSE IN－
Shield Braided wire * The shield is not connected
to the UTMⅡcase.

6
3 Setting Procedures
6
Setting Procedures
Chapter
3
3-1. USB interface
This USB interface allows the TM200 to be used in the dedicated PC application, such as retrieving
the torque, rotation speed and power of UTMⅡ, writing setting values into the TM200 and so on.
Communication specifications
Communication standard USB Ver.2.0 compliant, full speed (12Mbps)
Connector mini-B TYPE
3-2. PC preparation
Please make sure to install USB drive and PC application prior to connecting TM200 to the PC for
the first time.
PC operating environment
OS Windows7 CPU Core i3 2GHz or above
Display 800×600 pixel or above Memory 2GB or above
USB port One or more free ports Hard disk 15GB free space or more
USB driver Virtual COM Port (VCP) Drivers (developed by FTDI Limited)
USB driver installation
In order to connect the TM200 to the PC, USB driver must be installed.
Download and install the driver following the procedure below.
The contents of this manual may differ from the ones on the FTDI website when the website is
updated. Visit the following FTDI website for details.
Guide http://www.ftdichip.com/Support/Documents/InstallGuides.htm
Driver http://www.ftdichip.com/Drivers/VCP.htm
3Setting Procedures

7
3 Setting Procedures
7
Setting Procedures
Chapter
3
Installation procedures
1. Access the driver download page using your Internet browser.
In the lower part of this page, there is a table called "Currently Supported VCP Drivers".
From this table, select between OS (Windows) 32 bit or 64 bit and download the file.
2. In the downloaded zip file, there is a file with CDM name xxx.exe (xxx differs
depending on the file version downloaded). Execute this file to begin the driver
installation.
USB connection
Following the installation procedures, connect the USB cable included to the PC.
The USB connector of the TM200 is mini-B TYPE.

8
3 Setting Procedures
8
Setting Procedures
Chapter
3
Check of virtual COM port
After installing this USB driver, connect the
TM200 with the USB cable.
Next, check the virtual COM port number to
which the TM200 is connected from the
Device Manager of the PC.
Device Manager can be opened by double-
clicking
the Device Manager in "Control Panel" from
the Start menu.
Installation of the dedicated PC application
Download and install the dedicated PC application from the UNIPULSE website. To download the
application, user registration (free) is required.
* http://www.unipulse.com/en/products/TM200.html
Virtual COM port number
If the COM port number of the TM200 cannot be determined due to multiple USB
Serial Ports and so on, unplug the USB cable once and confirm that one COM
port is removed from the list of ports (COM and LPT). When the USB cable is
reconnected to the previous connector, the number of COM ports displayed in
the list increases. This number represents the COM port number of the TM200.
Key points
Operation manual Dedicated PC application
Download the compressed file to the PC from the download page
Extract the compressed file on the PC and start up the installer
Follow the procedure and complete the installation

9
3 Setting Procedures
9
Setting Procedures
Chapter
3
Turn-on of power supply
When connected to the PC with the USB cable, the power of the TM200 turns on.
Startup of PC application
Double-click the shortcut of the TM200 on the desktop or click
"UNIPULSE"→"TM200"→TM200 from the Start menu.
Specification of COM port
Select the virtual COM port checked in the
Device Manager of the PC on the start
screen, click the "OK" button, and the PC
application starts up.
Once the PC application starts up,
the POWER/ALM lamp of the TM200
lights on.
If the lamp lights off twice, check that power is supplied from the AC adapter, and if the lamp lights
off once, check that the virtual COM port of the TM200 has been properly selected in the PC
application.
* If the number of enabled COM ports is one, the PC application starts up without displaying this
selection screen.
Shortcut

10
3 Setting Procedures
10
Setting Procedures
Chapter
3
3-3. Menu
File
From the file menu, saving and opening the waveform data and printing the screen can be
performed.
Save(S)
The setting of waveform display scale is overwritten on the file of the waveform data currently
shown.
Save as(A)
The waveform data currently shown is saved with a new file name.
Thin out and save(T)
The acquired waveform data is thinned out and
saved as a new file.
The original waveform file is not modified.
When this menu is selected, the screen on the
right is displayed.
When x is specified in the range of 2 to 300 and
"OK" is clicked, a file name can be input.
Once the file name is input, the file whose
number of data is 1/x is created and saved.
e.g.) The number of data and data number of the file to be saved (n = 0, 1, 2, 3 ...)
Original file
300 samples/second first, second, third, ... nth
When x = 2,
150 samples/second first, third, fifth, ... 2n+1th
When x = 50,
6 samples/second first, 51st, 101st, ... 50n+1th
When x = 300,
1 sample/second first, 301st, 601st, ... 300n+1th
Waveforms of the file thinned out and saved cannot be displayed with the PC application.

11
3 Setting Procedures
11
Setting Procedures
Chapter
3
Open(R)
The saved waveform data is opened and its waveforms are displayed.
Print(P)
Screen hard copy is printed.
Exit(X)
This application software exits.
COM port
Use this port when changing to the virtual COM port number of other TM200 or re-connecting it.
Refer to P.9 "Specification of COM port" for details.
Help
Help and the PC application version information are displayed.
Help(H)
The operation manual (this manual) is displayed.
Setting for smooth waveform display(S)
Setting procedures are shown for displaying the waveforms smoothly that appear as in frame-by-
frame advance.
Refer to the attached "USB Serial Port Setting Guide" for details.
Version info.(A)
The PC application version information is displayed.
Version info
