Unique CLASSIC RETRO UGP-36CR W User manual

OWNER’S GUIDE
serial number:
CLASSIC RETRO BY UNIQUE
36”CONVECTION GAS RANGE
MODEL NUMBERS: UGP-36CR W, UGP-36CR B, UGP-36CR LG, UGP-36CR T
4002621 DEC22V1

CLASSIC RETRO BY UNIQUE 36” CONVECTION GAS RANGE
GAS RANGE - NG & LPG CONVERTIBLE
READ AND SAVE THESE INSTRUCTIONS
Have the dealer where you purchase your new range install it or have him recommend
a qualified installer. Installation must conform with local codes. In the absence of local
codes, the installation must conform with the National Fuel Gas Code, ANSI Z223.
1-Latest Edition in the U.S.A. or the CAN/CGA B149.1 or .2 Installation Codes in Canada.
Read and save these instructions
Installation & Owner’s Manual
This manual contains information for:
• Important Safeguards
• Installation
• Use and Care
Important
TO THE OWNER OF THE RANGE: Retain this owner’s manual for future reference.
TO THE INSTALLER: Leave this owner’s manual with the range.
Certain ranges come equipped with special features. Determine from a study of
your range which of the instructions given in this booklet pertain to your range.
This booklet gives valuable instructions covering the installation, adjustment and
use of your range.
How to Obtain Service and/or Parts
When your range does not operate in accordance with the instructions in the
manual, you should contact the dealer in your immediate vicinity for service.
Or, the purchaser may contact the service organization noted on the warranty.

Making sure the anti-tip bracket is installed:
• Slide range forward.
• Look for the anti-tip bracket securely attached to floor.
• Slide range back so rear range foot is under anti-tip bracket.
MANUFACTURED & CERTIFIED BY
Unique Appliances
2245 Wyecroft Road #5, Oakville, Ontario, Canada L6L 5L7
Phone: [phone] Toll Free: 1-877-427-2266 Email: [e-mail]
www.UniqueAppliances.com
WARNING: If the information in this manual is not followed exactly, a fire or
explosion may result causing property damage, personal injury or death.
Do not store or use gasoline or other flammable vapors and liquids in the vicinity
of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your building.
• Immediately call your gas supplier from a neighbor’s phone.
Follow the gas supplier’s instructions.
• If you cannot reach your gas supplier, call the fire department.
Installation and service must be performed by a qualified installer, service
agency or the gas supplier.
WARNING To reduce the risk of tipping the appliance by
abnormal usage or improper door loading, the appliance must be
secured by properly installing the Anti-Tip device packed with the
appliance. To check if the device is installed and engaged properly.
Carefully tip the range forward. The Anti-Tip device should engage
and prevent the range from tipping over.
If this range is removed for any reason, service or cleaning, etc., it
must be replaced as outlined in the installation instructions before
placing the range back in operation.
X2
Range Foot Anti-tip Bracket
RANGE
BACK PANEL

4
BEFORE USING YOUR GAS RANGE . . . . . . . . . . . . . . . . . . . . 5
WELCOME . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
IMPORTANT SAFEGUARDS . . . . . . . . . . . . . . . . . . . . . . . . 7
SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . 8
INSTALLATION AND OPERATION INSTRUCTIONS . . . . . . . . . . . 10
INSTALLATION INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . 13
HANDLE INSTALLATION INSTRUCTIONS . . . . . . . . . . . . . . . . 18
GAS CONNECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
GAS RANGE CONVERSION . . . . . . . . . . . . . . . . . . . . . . . 20
CONVERTING RANGE TO LIQUIFIED PERTOLEUM GAS . . . . . . . . 22
HOOD COMPOSITE INSTALL & USING RANGE FOR FIRST TIME . . . 28
COOKTOP OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . .29
OVEN OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
BROILER OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
CARE & MAINTENANCE. . . . . . . . . . . . . . . . . . . . . . . . . . .38
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
WIRING DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
PRODUCT REGISTRATION . . . . . . . . . . . . . . . . . . . . . . . . 49
RATING PLATE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
TABLE OF CONTENTS

5
BEFORE USING YOUR GAS RANGE
WARNING
HAVE THIS RANGE INSTALLED BY A QUALIFIED INSTALLER.
Improper installation, adjustment, alteration, services, or maintenance can cause injury
or property damage. Consult a qualified installer, service agency, or the gas supplier.
BEFORE USING YOUR GAS RANGE:
• Remove the exterior and interior packing.
• Remove the protective film on steel and aluminum parts.
• Check to be sure you have all of the parts listed below:
• 2 backsplash
• LP gas conversion packet (injectors for LP gas)
• 2 anti-tip brackets
• 2 oven racks (pre-installed)
• 7 caps and 6 burner rings (base)
• 7 knobs
• 3 cast iron grates
• 1 regulator (pre-installed)
• 8 screws for Retro backsplash
• 1 instruction/installation manual
• 1 allen key
• Clean the interior surface with lukewarm water using a soft cloth
• Have the installer show you the location of the range’s gas shut-o valve and how to
shut it o if necessary.
• Have your range installed and properly grounded by a qualified installer in
accordance with the installation instructions.
• Do not attempt to repair or replace any part of your range unless it is specifically
recommended in this manual.
• Be sure your range is correctly adjusted by a qualified service technician or installer
for the type of gas (natural or LP) that is being used.
• Do not remove permanently axed labels, warnings, or plates from the unit.
This may void the warranty.
• The installer should leave these instructions with the consumer who should retain for
local inspector’s use and for future reference.
• Please observe all local and national codes and ordinances.

6
WELCOME & CONGRATULATIONS
Congratulations on your purchase of a UNIQUE range! We are very proud of our
product – and are completely committed to providing you with the best service possible.
Your satisfaction is our #1 priority. Please read this manual very carefully. It contains
valuable information on how to properly maintain your new Unique propane range.
We know you will enjoy your new range and Thank You for choosing one of our
Unique Appliances! We hope you will consider us for future purchases.
PLEASE READ AND SAVE THESE INSTRUCTIONS
This manual provides specific operation instructions for your model. Use your range
only as instructed in this manual. These instructions are not meant to cover every
possible condition and situation that may occur. Common sense and caution must be
practiced when installing, operating and maintaining the appliance.
Record in the space provided below the Model No. and Serial No. of this appliance.
These numbers are found on the serial plate located at the bottom drawer.
Model No. ______________________
Serial No. ________________________
Purchase Date ________________________
Record these numbers for future use.
IM PO RTANT: Keep a copy of your bill of sale. The date on the bill establishes the
warranty period should service be required. If service is performed, it is in your best
interest to obtain and keep all receipts.
PLEASE DO THIS NOW!
Please visit our website at https://UniqueAppliances.com/product-registration/ to
register your product.

7
READ ALL IMPORTANT SAFEGUARDS AND
ALL INSTRUCTIONS BEFORE USING THE APPLIANCE.
If the information in this manual is not followed exactly, a fire or an explosion may
result causing property damage, personal injury or even death.
Do not store or use gasoline, liquid propane cylinder or other flammable vapors and
liquids in the viicinity of this appliance.
What to do if you smell gas?
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your residence.
• Immediately call your gas supplier from a neighbor’s phone.
• Follow the gas suppliers instructions.
• If you cannot reach your gas supplier, call the fire department.
For installation and service of your range product, it must be
performed by a licensed installer, an approved service agency
or your gas supplier.
The California Safe Drinking Water and Toxic Enforcement Act of 1986 (Proposition
65) requires the Governor of California to publish a list of substances known to the
State of California to cause cancer or reproductive harm. In addition, businesses must
warn customers of potential exposure to such substances.
Users of this appliance are hereby warned that the burning of gas can result in
low-level exposure to some of the listed substances, including formaldehyde, benzene,
soot and carbon monoxide. This is caused primarily from the incomplete combustion
of natural gas or LP fuel.
Properly adjusted burners will minimize incomplete combustion. Exposure to these
substances can also be minimized by properly venting the burners by opening a
window or using a ventilating hood or fan.
WARNING
WARNING

8
SAFETY INSTRUCTIONS
This is a safety alert symbol. It will alert you to potential personal or property
safety hazards. Obey all safety messages to avoid any property damage,
personal injury or death.
WARNING indicates a potentially hazardous situation which, if not avoided, could
result in serious injury or death.
CAUTION indicates a moderate hazardous situation which, if not avoided, could result
in minor or moderate injury.
CAUTION - when used without the safety alert symbol, indicates a potentially
hazardous situation which, if not avoided, could result in property damage.
IMPORTANT used for installation, operation and maintenance information that are not
related to safety.
If the information in this manual is not followed exactly, a fire or an explosion may
result causing property damage, personal injury or even death.
Do not store or use gasoline, liquid propane cylinder or other flammable vapors and
liquids in the vicinity of this appliance.
Save this manual for future references.
Definitions
WARNING
CAUTION
CAUTION
IMPORTANT

9
UNPACKING AND HANDLING
Extremely Heavy.
Proper equipment and adequate manpower when move the range to avoid personal
injury or damage to the unit or the floor. The unit is heavy and rests on adjustable steel
legs. Failure to follow this advice may result in damage or personal injury.
DO NOT lift range by the oven door handles !!
Do not store or use gasoline, liquid propane cylinder or other
flammable vapors and liquids in the vicinity of this appliance.
The installation and service of your range must be performed by a qualified installer, an
approved service agency or the gas supplier.
Gas appliances can cause minor exposure to four of these substances, namely benzene,
carbon monoxide, formaldehyde and soot, caused primarily by the incomplete
combustion of natural gas fuel. When operating your range on natural gas, the flames
from the burners should be blue in color. In addition, the flames should be stable, free
of yellow tipping, excessive noise and lifting. However, this yellow tipping should be
restricted to the primary flame kernels only. Properly adjusted burners, indicated by
a bluish rather than a yellow flame, will minimize incomplete combustion. Exposure
to those substances can be minimized by venting with an open window or use of a
ventilation fan or hood.
NOTICE: Never keep pet birds in the kitchen. birds have a very sensitive respiratory
system. Fumes released from cooking oil, fat, margarine or overheated non-stick
cookware may be harmful or fatal to birds.
ELECTRICAL GROUNDING INSTRUCTIONS
IMPORTANT
This indoor cooking appliance is equipped with a three-prong (grounding) plug for
your protection against shock hazard and should be plugged directly into a properly
grounded three-pronged receptacle. DO NOT cut or remove the grounding prong from
this plug.
SAFETY INSTRUCTIONS
WARNING
WARNING

10
INSTALLATION AND OPERATION INSTRUCTIONS
To ensure proper and safe operation, read all instructions before using the product.
Install or locate the product only in accordance with the provided Installation
Instructions.
• All servicing should be performed to a qualified technician.
• Do not attempt to adjust, repair, service or replace any part of your appliance
unless it is specifically recommended in this guide.
• Do not use the range for warming or heating the room.
• Do not leave children alone or unattended in the area where the range is in use.
Never allow them to sit or stand on any part of the range. Do not let children play
with the range.
• Have the technician show you the location of the gas shut o valve and how to
shut it o in an emergency situation.
• Always disconnect power to appliance before any type of servicing.
• Do not use abrasive or caustic cleaners or detergents on this appliance. They may
cause permanent damage to the surface.
• When cooking, set the burner controls so that the flame heats only the bottom of
the utensil and does not overlap at the sides of the utensil.
• Utensils (pots and pans) that conduct heat slowly, i.e. glass pots, should be used in
conjunction with burner flames at a low or medium setting.
• Turn o all controls and wait for appliance parts to cool down before touching
them. Do not touch the burner grates or surrounding areas until cool.
• Do not use water on grease fires.
• Clean appliance with caution.
• Always turn pot handles to the side or back of the range. Do not turn handles
towards the area where they can be easily burned. Handles should not extend over
the adjacent burners.
• Use the range only for cooking tasks as outlined in this manual. When using the
range, do not touch the grates, burner caps, burner bases, or any other parts in
proximity to the flame. These components may be hot enough to cause burns.
• Use dry pot holders. Moist or damp pot holders on hot surfaces may result in burns
from steam.
WARNING

11
INSTALLATION AND OPERATION INSTRUCTIONS
IMPORTANT
Keep appliance area clear and free from combustible materials, gasoline, and other
flammable vapors.
Gas Supply Requirements
Installation of this range must conform with local codes, or in the absence of local codes,
the National Fuel Gas Code, ANSI Z223.1 I NFPA 54. In Canada, installation must conform
to the current natural Gas Installation /code, CAN 1-1.1-M81 and with local codes where
applicable. This range has been design-certified according to ANSI Z21.1b-2012 latest
edition.
A statement of the maximum gas supply pressure in accordance with the inlet pressure
rating of the gas appliance pressure regulator supplied.
MINIMUM GAS SUPPLY PRESSURE TO APPLIANCE FOR LP GAS: 10 IN.W.C.
(Do not exceed 14 IN.W.C.)
MINIMUM GAS SUPPLY PRESSURE TO APPLIANCE FOR NG: 6 IN.W.C.
Do not obstruct the flow of combustion air into the range and ventilation air away from
the range.
Ventilation: it is recommended that the unit be operated with an oven head, vented
exhaust hood of sucient size and capacity.
Before installing the range, you must locate and secure the included anti-tip bracket to the
wall for your range.
The use of cabinets for storage above the appliance may result in a potential fire hazard.
Combustible items may ignite; metallic items may become hot and cause burns. If a
cabinet storage is to be provided, the risk can be reduced by installing a range hood that
projects horizontally a minimum of 5” (12.7cm) beyond the bottom of the cabinets.
The appliance shall not be used for space heating. This information is based on safety
considerations. All openings in the wall behind the appliance and in the floor under the
appliance shall be sealed.
CAUTION
WARNING
INPUT PRESSURE OUTPUT PRESSURE
NG 7inch 7inch
LPG 11inch 10inch

12
CARBON MONOXIDE WARNING
Carbon Monoxide is a possible danger when using any gas powered appliance.
All gas appliances MUST be installed by a licensed professional who is familiar with
the Carbon Monoxide levels appropriate for each appliance.
The American Gas Association publishes CO emissions for appliances and heating
equipment through the ANSI Std. Z21.1
The EPA reports that a maximum CO (Carbon Monoxide) level of 9 PPM over a 24
hour period is the residential interior ambient level standard.
(A properly ventilated home will have a normal CO level of less than 5 PPM.)
NON-VENTED GAS COOKING APPLIANCES:
Non-vented gas cooking appliances in a residential application are normally used
for a short period of time. The CO generated during the operation will disperse to
the air in the home and be purged to the outside through the normal air exchange.

13
INSTALLATION INSTRUCTIONS
Be sure appliance is properly installed and grounded by a qualified technician.
It is the responsibility of the technician to make certain that your range is properly
installed. Situations caused by improper installation are not covered under the
warranty. Any expenses incurred due to such situations will not be paid by the
manufacturer of the appliance.
If this range is removed for any reason, (eg. service
or cleaning), it must be replaced as outlined before
placing the range back in operation.
Levelling a Free-Standing Range
All free-standing ranges must be level to obtain proper
cooking results. The leveling legs should be screwed
into the corner brackets. Place pan or measuring cup
partially filled with water or a level on the oven rack.
Adjust the leveling legs until the range is level. The top
of the side panels should be level with the counter top.
WARNING A child or adult can tip the range
and be killed. Install the anti-tip device to the structure
and/or the range. Verify the anti-tip device has been
properly installed and engaged. Engage the range
to the anti-tip device by ensuring the anti-tip device
is re-engaged when the range is moved. Re-engage
the anti-tip device if the range is moved. Do not
operate the range without the anti-tip device in place
and engaged. See installation instructions for details.
Failure to do so can result in death or serious burns to
children or adults.
Making sure the anti-tip bracket is installed:
• Slide range forward.
• Look for the anti-tip bracket securely attached to floor.
• Slide range back so rear range foot is under anti-tip bracket.
X2
Range Foot Anti-tip Bracket

14
27.3”
44.25”
36”
41”
37”
Depth with Door Open
INSTALLATION INSTRUCTIONS
Dimensions and Clearances
The range may be installed flush to the rear wall. You may install a non-combustible
material on the rear wall above the range and up to the vent hood. It is not necessary to
install non-combustible materials behind the range below the counter top height.
The minimum distance from the side of the range above the counter top to combustible
sidewalls must be at least 10 inches.
36”
(For low profile
backsplash)
(For larger backsplash)

15
INSTALLATION INSTRUCTIONS
Minimum to
cabimets on
either side
of the range
Minimum
To wall on either side sealed
burner models
Maximum depth
for cabinets above
countertops
Front edge of
the range side
panel forward
from cabinet
To countertops
below cooktop
and at the range
back

16
INSTALLATION INSTRUCTIONS
Electric Power Supply Requirements
Your range must be electrically grounded in accordance with local codes or, in the
absence of local codes, in accordance with the National Electrical Code (ANSI/NFPA 70,
latest edition). In Canada, electrical grounding must be in accordance with the current
CSA C22. l Canadian Electrical Code Part 1 and/or local codes. A copy of this standard
may be obtained from: National Fire Protection Association, 1 Batterymarch Park,
Quincy, Massachusetts 02269-9101.
The power supply must be the correct polarity. Reverse polarity will result in continuous
sparking of the electrodes, even after flame ignition. If there is any doubt as to whether
the power supply has the correct polarity or grounded, have it checked by a qualified
electrician.
Use 120V, 60Hz, and properly grounded branch circuit protected by a 15-amp or
20-amp circuit breaker or time delay fuse.
Electrical Grounding Instructions: this indoor gas cooking appliance is equipped with
a three-prong (grounding) plug for your protection against shock hazard and should
be plugged directly into a properly grounded three-pronged receptacle.
Do Not cut or removes the grounding prong from the plug.
Caution Label all wires prior to disconnection when servicing controls. Wiring errors
can cause improper and dangerous operation. Verify proper operation after servicing.
Grounding
• The power cord is equipped with a three-prong (grounding) plug which mates with
a standard three-prong grounding wall receptacle to minimize the possibility of
electrical shock hazard from the range.
• All cord connected appliance shall include instructions relative to location of the
wall receptacle and a warning to the user to disconnect the electrical supply before
serving the appliance.
• Where a standard two-prong wall receptacle is encountered, it is the responsibility
and obligation of the customer to have it replaced with a properly grounded three
prong wall receptacle. Do not cut or remove the grounding prong from the power
cord.
WARNING

17
INSTALLATION INSTRUCTIONS
Backsplash Option 1
Backsplash Option 2
1. Align the backsplash to the rear
part of the cooktop as shown in the
diagram.
2. Secure the backsplash to the
cooktop from the back using the
8 Phillips head screws provided as
shown in the diagram.
HOW TO INSTALL THE BACKSPLASH
Shortest connection from
hard pipe stub location
to range hook-up
Area allows for flush installation
with through-the-floor connection
of pipe stub/shut-o valve
Area allows for flush installation
with through-the-wall connection
of pipe stub/shut-o valve and rear
wall 120V outlet.

18
HANDLE INSTALLATION INSTRUCTIONS
� ]
-


 1
____________  __________ _
-----------------------
. . . . . .
� ]
-


 1
____________  __________ _
-----------------------
. . . . . .
� ]
-


 1
____________  __________ _
--------
---------------
. . . . . .
Step 2: Insert the assembled handle
onto the range door.
Step 1: Use the allen key that is included
with your range to loosen the screws on
the bottom of the handles.
Step 3: Use the allen key that is included
with your range to tighten the screws on
the bottom of the handles.

19
Connect Range to Gas Supply
• Install a manual gas line shut-o valve in the gas line in an easily accessed location
outside the range in the gas piping external to the appliance for the purpose of
turning on or shutting o gas to the appliance.
• Install male 1/2” flare union adapter to 1/2” NPT internal thread elbow at inlet of
regulator. On models equipped with standard twin burners, install the male pipe
thread end of the 1/2” flare union adapter to the 1/2” NPT internal thread at inlet of
pressure regulator. Use a wrench on the regulator fitting to avoid damage.
• Install male 1/2” or 3/4” flare union adapter to the NPT internal thread of the
manual shut-o valve, taking care to secure the shut-o valve to keep it from
turning.
• For Natural Gas (NG) the gas supply input pressure for checking the regulator
setting is 7inches and the output pressure is 5inches. For Liquid Propane Gas
(LPG) the gas supply input pressure for checking the regulator setting is 11inches
and the output pressure is 10inches.
• Connect the flexible gas line connector to the regulator on the range.
Position range to permit connection at the shut-o valve.
• When all connections have been made, check that all range controls are in the “o”
position and turn on the main gas supply valve.
• Leak testing of the appliance shall be conducted according to the manufacture’s
instructions. Use some soap water (50% water and 50% soap) or a leak detector
at all joints and connections to check for leaks in the system. Do not use a flame to
check for gas leaks.
GAS CONNECTIONS

20
To convert application and/or adjust from NG to LPG
The range is set for use with Natural Gas (NG). The factory setting is indicated on
the serial plate. When set for Natural Gas operation, the pressure regulator will
regulate the gas to 4” water column pressure. When set for Liquid Propane Gas (LPG)
operation, the pressure regulator will regulate the pressure to 11” water column.
Natural Gas to Liquid Propane Gas Conversion
The conversion kit must be installed by qualified service agency.
WARNING: Please ensure before beginning converting the appliance that the gas
supply is shut o and the electrical connection is disconnected. Failure to do can
result in injury or property damage.
Determine the combination of top burners that are featured on your range.
Identify the parts you need from this kit to complete the L.P. conversion.
When burners are converted from natural to L.P. the BTU ratings are as follows:
GAS RANGE CONVERSION
“This conversion kit shall be installed by a qualified service agency in accordance
with the manufacturer’s instructions and all applicable codes and requirements of the
authority having jurisdiction. If the information in these instructions is not followed
exactly, a fire, explosion or production of carbon monoxide may result in property
damage, personal injury or loss of life. The qualified service agency is responsible for
the proper installation of this kit. The installation is not proper and complete until the
operation of the converted appliances is checked as specified in the manufacturer’s
instructions supplied with the kit.”
Rear Left Burner 9,000 BTU L.P. Gas [1.0mm]
Rear Mid Burner 9,000 BTU L.P. Gas [0.90mm]
Rear Right Burner 12,000 BTU L.P. Gas [1.0mm]
Front Left Burner 15,000 BTU L.P. Gas [1.16mm]
Front Mid Burner 6,000 BTU L.P. Gas [0.74mm]
Triple Crown Burner 20,000 BTU L.P. Gas [0.89*2+0.53mm]
Broil Burner 10,000 BTU L.P. Gas [0.94mm]
Oven Burner 22,000 BTU L.P. Gas [1.40mm]
