Unique UGP-20V PC1 S/S Installation instructions

UGP-20V PC1 S/S
UGP-20V PC1 W
UGP-20V PC1 B
20” (50.8 cm)
PRESTIGE GAS RANGE
(NG & LPG convertible)
INSTALLATION
AND OWNER’S MANUAL
SERIAL NUMBER:
MAR19V1
READ AND SAVE THESE INSTRUCTIONS
File Number:
4009900
SEP20V3

UNIQUE 20” PRESTIGE MODEL
GAS RANGE - NG & LPG CONVERTIBLE
READ AND SAVE THESE INSTRUCTIONS
Have the dealer where you purchase your new range install it or have him recommend
a qualied installer. Installation must conform with local codes. In the absence of local
codes, the installation must conform with the National Fuel Gas Code, ANSI Z223. 1-Lat-
est Edition in the U.S.A. or the CAN/CGA B149.1 or .2 Installation Codes in Canada.
Installation & Owner’s Manual
This manual contains information for:
Important Safeguards
Installation
Use and Care
Certain ranges come equipped with special features. Determine from a study of
your range which of the instructions given in this booklet pertain to your range.
This booklet gives valuable instructions covering the installation, adjustment
and use of your range.
How to Obtain Service and/or Parts
When your range does not operate in accordance with the instructions in the manual,
you should contact the dealer in your immediate vicinity for service. Or, the purchaser
may contact the service organization noted on the warranty.
Important
TO THE OWNER OF THE RANGE: Retain this owner’s manual for future reference.
TO THE INSTALLER: Leave this owner’s manual with the range.
Read and Save These Instructions

2245 Wyecroft Road #5
Oakville, Ontario, Canada L6L 5L7
Ph: 905-827-6154 Toll Free: 1-877-427-2266 Fax: [phone]
www.UniqueOffGrid.com
MANUFACTURED & CERTIFIED BY
Unique Gas Products Ltd
X2

4
05 Important safety instructions
14 Energy saving ideas
15 Installation instructions
16 How to install the backsplash
17 Gas connections
20 Wall clearances
22 Gas range conversion
27 Adjustingthetopburnerandovename
30 Operation of range
36 Alignments and adjustments
37 Cleaning the range
39 Care and maintenance
44 Troubleshooting
46 Wiring diagram
47 Contact us
47 Warranty
48 Parts diagram
49 Parts list
52 Appliance information
53 Notes
UNIQUE GAS RANGE
Table of Contents

5
BEFORE USING YOUR GAS RANGE
WARNING
HAVE THIS RANGE INSTALLED BY A QUALIFIED INSTALLER.
Improper installation, adjustment, alteration, services, or maintenance can cause injury or prop-
ertydamage.Consultaqualiedinstaller,serviceagency,orthegassupplier.
BEFORE USING YOUR GAS RANGE:
• Remove the exterior and interior packing.
•Removetheprotectivelmonsteelandaluminumparts.
• Check to be sure you have all of the parts listed below.
• 1 backsplash
• LP gas conversion packet (injectors for LP gas, 6pcs)
• 2 anti-tip brackets
• 2 pan supports
• 2 oven racks
• 4 caps and bases in the burner assembly
• 1 broiler grid
• 1 broiler tray
• 1 regulator (pre-installed)
• 5 screws for backsplash
• 1 instruction/installation manual
• Clean the interior surface with lukewarm water using a soft cloth
• Have the installer show you the location of the range’s gas shut-off valve and how to shut it
off if necessary.
•Haveyourrangeinstalledandproperlygroundedbyaqualiedinstallerinaccordancewith
the installation instructions.
•Donotattempttorepairorreplaceanypartofyourrangeunlessitisspecicallyrecommend-
ed in this manual.
•Besureyourrangeiscorrectlyadjustedbyaqualiedservicetechnicianorinstallerforthe
type of gas (natural or LP) that is being used.
•Donotremovepermanentlyafxedlabels,warnings,orplatesfromtheunit.Thismayvoid
the warranty.
• The installer should leave these instructions with the consumer who should retain for local
inspector’s use and for future reference.
• Please observe all local and national codes and ordinances.

6
Welcome & Congratulations
Congratulations on your purchase of a UNIQUE range! We are very proud of our product – and
are completely committed to providing you with the best service possible. Your satisfaction is
our #1 priority. Please read this manual very carefully. It contains valuable information on how to
properly maintain your new Unique gas range.
We know you will enjoy your new range and Thank You for choosing one of our Unique Gas
Products! We hope you will consider us for future purchases.
IMPORTANT PRECAUTIONS AND RECOMMENDATIONS
This appliance is designed and manufactured solely for the cooking of domestic (household)
food and is not suitable for any non-domestic application and therefore CANNOT be used in a
commercial environment.
The appliance guarantee will be void if the appliance is used within a non-domestic environment
i.e. a semi commercial, commercial or communal environment..
PLEASE READ AND SAVE THESE INSTRUCTIONS
Thismanualprovidesspecicoperationinstructionsforyourmodel.Useyourrangeonlyas
instructed in this manual. These instructions are not meant to cover every possible condition and
situation that may occur. Common sense and caution must be practiced when installing, operat-
ing and maintaining the appliance
Record in the space provided below the Model No. and Serial No. of this appliance.
These numbers are found on the serial plate located at the back of the range.
Model No. ________________________ Type Number _______________________
Serial No. ________________________ Purchase Date________________________
Record these numbers for future use.
IMPORTANT: Keep a copy of your bill of sale. The date on the bill establishes the warranty
period should service be required. If service is performed, it is in your best interest to obtain and
keep all receipts.
PLEASE DO THIS NOW!
The PRODUCT REGISTRATION CARD should be lled in completely, signed and
returned. This information will register your product and help us to serve you quickly in
the future if necessary.

7
READ ALL IMPORTANT SAFEGUARDS AND
ALL INSTRUCTIONS BEFORE USING THE APPLIANCE.
IF YOU SMELL GAS:
• Open windows
• Don’t touch electrical switches
•Extinguishanyopename
• Immediately call your gas supplier
FOR YOUR SAFETY:
•Keepapplianceareaclearandfreefromcombustiblematerialsgasolineandotherammable
vapors and liquids.
WARNINGS
Destroy the carton and plastic bags after the range is unpacked. Children should not use pack-
aging material for play. Cartons covered with rugs, bedspreads, or plastic sheets can become
airtight chambers. Remove all staples from the carton. Staples can cause severe cuts and
destroynishesiftheycomeincontactwithotherappliancesorfurniture.
Be safety conscious. The preparation of food in an oven requires temperatures that could
cause severe burns. Before using this new appliance, carefully read and follow all instructions.
The California Safe Drinking Water and Toxic Enforcement Act of 1986 (Proposition 65) requires
the Governor of California to publish a list of substances known to the State of California to
cause cancer or reproductive harm. In addition, businesses must warn customers of potential
exposure to such substances.
Users of this appliance are hereby warned that the burning of gas can result in low-level expo-
sure to some of the listed substances, including formaldehyde, benzene, soot and carbon mon-
oxide. This is caused primarily from the incomplete combustion of natural gas or LP fuel.
Properly adjusted burners will minimize incomplete combustion. Exposure to these substances
can also be minimized by properly venting the burners by opening a window or using a ventilat-
ing hood or fan.
WARNING

8
Notice: Never keep pet birds in the kitchen. Birds have a very sensitive respi-
ratory system. Fumes released from cooking oil, fat, margarine or overheat-
ed non-stick cookware may be harmful or fatal to birds.
PROPER INSTALLATION: Besureaqualiedtechnicianinaccordancewiththe
National Fuel Gas Code ANSI Z223.1/NFPA54 properly installs your appliance.
Install only per installation instructions provided in the literature package for this
range. Be sure leveling legs are in place at the bottom corners of the range. If nec-
essary, raise or lower the leveling legs at the base of the range by turning clock-
wise or counter clockwise to insure a level range.
Askyourdealertorecommendaqualiedtechnicianandanauthorizedrepairser-
vice. Have the technician familiarize you with the locations of the manual gas shut
off valve and gas meter in the event it is necessary to shut off gas supply to the
unit during an emergency.
The following situations may cause serious bodily harm, death or property
damage.
TO REDUCE THE RISK OF TIPPING OF THE RANGE, THE RANGE MUST
BE SECURED BY A PROPERLY INSTALLED ANTI-TIP BRACKET PROVIDED
WITH THE RANGE. TO CHECK IF THE DEVICE IS INSTALLED AND ENGAGED
PROPERLY, CAREFULLY TIP THE RANGE FORWARD. THE ANTI-TIP DEVICE
SHOULD ENGAGE AND PREVENT THE RANGE FROM TIPPING OVER. RE-
FER TO THE INSTALLATION INSTRUCTIONS PACKAGED WITH THE ANTI-TIP
BRACKET FOR PROPER ANTI-TIP BRACKET INSTALLATION.
• Never leave children alone or unattended in the area where an appliance is
in use. They should never be allowed to sit or stand on any part of the appliance.
Never leave the oven door open when the range is unattended.
• Do not store items of interest to children in the cabinets above a range or
on the backguard of a range. Children climbing on the range to reach the items
could be seriously injured.
Do not allow children to climb or play around the range. The weight of a child
on an open oven door may cause the range to tip, resulting in serious burns or
other injury.
IMPORTANT: Observeallgoverningcodesandordinances.Donotobstructowof
combustion and ventilation air.

9
USER SERVICING: Do not repair or replace any part of the appliance unless
specicallyrecommendedinthisowner’sguide.Onlyaqualiedtechnician
should do all other servicing. This will reduce the risk of personal injury and dam-
age to the range.
Storage in or on appliance: Flammable materials should not be stored in an
oven, near surface burners or in the broiler section. This includes paper, plastic
andclothitems,suchascookbooks,plasticwareandtowels,aswellasammable
liquids. Do not use the oven for storage. Do not store explosives, such as aerosol
cans, on or near the range.
Remove the oven door from any unused range if it is to be stored or discarded.
Stepping, leaning or sitting on the doors or broiler section of this range can
result in serious injuries and cause damage to the range.
The following situations could cause bodily injury or
property damage.
DO NOT TOUCH SURFACE BURNERS, AREAS NEAR THESE BURNERS,
OVEN BURNERS OR INTERIOR SURFACES OF THE OVEN. Both surface burn-
ersandovenburnersmaybehoteventhoughtheameisnotvisible.Areasnear
surface burners may become hot enough to cause burns. During and after use, do
nottouch,orletclothingorotherammablematerialstouchtheseareasuntilthey
havehadsufcienttimetocool.Amongtheseareasaretherange,surfacesfacing
the range, the oven vent openings and surfaces near these openings, oven door
and windows.
NEVER use this appliance as a space heater to heat or warm the room.
Doing so may result in carbon monoxide poisoning and overheating of the
oven.
Wear proper apparel. Loosettingorhanginggarmentsshouldneverbeworn
whileusingtheappliance.Donotletclothingorotherammablematerialscontact
surfaceburnersorinteriorsurfacesoftheovenuntiltheyhavehadsufcienttime
to cool.
Never modify or alter the construction of the range. Do not remove leveling
legs, panels, wire covers, anti-tip brackets or any other permanent part of the prod-
uct.
When heating fat or grease, watch it closely. Fatorgreasemaycatchreifal-
lowed to become too hot.

10
Do not use water or  our on grease  res. Smothertherewithapanlid,baking
soda or use a dry chemical or foam-type extinguisher.
Operation of the Surface Burners. Whentheburnersareoperatedfortherst
time, a small amount of smoke may be generated due to tape residue or manufac-
turing lubrication, this is not dangerous.Operatetheburnersforaboutvemin-
utes to rid the burners of this material before cooking.
Use only dry potholders. Wet or damp potholders on hot surfaces could result in
burns from steam. Do not let the potholder touch hot heating areas. Do not use a
towel or other bulky cloth instead of a potholder.
Use proper  ame size. Adjustamesizesoitdoesnotextendbeyondtheedge
of the cookware. The use of undersized cookware will expose a portion of the
burnerameandmayresultinsevereburnsordirectcontactandignitionofcloth-
ing.Also,properrelationshipofcookwaretoburnerwillimproveefciency.
NEVER cover any slots, holes or passages in the oven bottom or cover
an entire rack with materials such as aluminum foil. Doing so blocks air
owthroughtheovenandmaycausecarbonmonoxidepoisoning.Aluminumfoil
liningsmayalsotrapheat,causingarehazard.Refertothecleaningsectionof
this manual for more information on the use of aluminum foil.
Placement of oven racks: Always place an oven rack in the desired location
while the oven is cool. If a rack must be moved when the oven is hot, use pothold-
ers and grasp the rack with both hands to reposition. Do not let potholders contact
hot oven walls. Remove all cookware from the rack before moving.
Do not heat unopened food containers. Build-up of pressure may cause the
container to burst and result in injury.
Keep the oven vent duct unobstructed. The oven vent is located along the bot-
tom of the back guard. Touching the surfaces in the vent area when the oven is
being operated may cause severe burns. Also, do not place plastic or heat-sensi-
tive items on or near the oven vents. These items could melt or ignite. The range
requiresfreshairforproperburnercombustion.Donotblocktheowofairaround
the base or beneath the lower front panel of the range.
Use care when opening oven door: Stand to the side of the oven when open-
ing the oven door. Slowly open the door to allow hot air or steam to escape
before removing or replacing food.
Know which knob controls each burner. Place a pan of food on the burner be-
fore turning it on, and turn the burner off before removing the pan. Always turn to
thefullpositionwhenignitingtopburners.Thenadjusttheamesizesoitdoesnot
extend beyond the edge of the cookware.

11
Cookware handles should be turned inward and not extend over adjacent
surface burners. Toreducetheriskofburns,ignitionofammablematerials,and
spillage due to unintentional contact with the cookware, the handle of a cookware
should be positioned so that it is turned inward, and does not extend over adjacent
surface burners.
Never leave the surface burners unattended. Boilovers may cause smoking,
greasyspill-oversmaycatchreorapanwhichhasboileddrymaymelt.
Do not place hands between the spring tension hinge and the oven door
frame when you are removing the oven door. Youcouldpinchyourngers.
Do not use the broiler pan without its insert. The broiler pan and its insert allow
dripping fat or grease to drain and be kept away from the high heat of the broiler.
Do not cover the insert with foil. Exposed fat or grease could ignite.
Allow parts to cool to room temperature before touching or removing them
from the range. Whenasurfaceburnerisrstturnedoff,theburnerandgrateare
hot enough to cause burns.
Clean the range regularly to keep all parts free of fat or grease, which could
catch re. Pay particular attention to the area underneath each surface burner.
Exhaustfanventilatinghoodsandgreaseltersshouldbeclean.Donotallowfat
orgreasetoaccumulate.Greasydepositsinthefancouldcatchre.Refertothe
hood manufacturer’s instructions for cleaning.
Do not use a “cyclonic” range hood with this product. Some range hoods cir-
culate air by blowing downward toward the range top then drawing the air back up
into the hood. This creates a “cyclonic” air wash that is designed for electric ranges
only. A “cyclonic” hood may cause the burners of a gas range to operate improp-
erly.
Glazed cookware: Only certain types of glass, glass/ceramic, ceramic, earthen-
ware, or other glazed cookware are suitable for rangetop service without breaking,
due to the sudden change in temperature. Check the manufacturer’s recommenda-
tions for rangetop use.
Do not place plastic salt and pepper shakers, spoon holders or plastic wrap-
pings on top of the range. These items could melt or ignite. Potholders, towels or
woodenspoonscouldcatchreifplacedtooclosetotheame.
Do not use a wok equipped with a metal ring that extends beyond the burner.
Because this ring traps heat, the burner and grate could be damaged. Also, the
burner may not work properly, creating a carbon monoxide level above current
health standards.
Do not clean the oven door gasket. The door gasket is essential for a good seal.
Care should be taken not to rub, damage or move the gasket.

12
Flexible Connectors: If the gas range/oven is connected to a gas supply with a
metalexibleconnector,movetherange/ovenwithCAUTIONforserviceorcleaning.
Flexible connectors are not intended for repeated bending. Do not allow
cleaners to make contact with  exible connectors.
The connector and its  ttings are designed for use only on the original in-
stallation and are not to be reused for another appliance or at another loca-
tion. Connectors must comply with ANSI Z21.24.
It’s good practice for each household to have an appropriate  re extinguish-
er for use in the event of a house  re.
NOTE: The instructions appearing in this owner’s guide are not meant to cover
every possible condition and situation that may occur. Common sense and caution
must be practiced when operating and maintaining any appliance.
On sealed burner models never attempt to operate the surface burners with-
outthecooktop,burnercapsandignitionwiresrmlyinplace.Thereisariskofre
and/or explosion which could result in personal injury or property loss.
ELECTRICAL GROUNDING INSTRUCTIONS
FOR PERSONAL SAFETY, THIS APPLIANCE MUST BE PROPERLY GROUNDED.
This appliance is equipped with a three-prong grounding plug for your protection
against shock hazard and should be plugged directly into a properly grounded
socket. Do not cut or remove the grounding prong from the plug.
• The gas range must be installed with all electrical connections in accordance with
state and local codes. A standard electrical supply (115 V AC only, 60 Hz), prop-
erly grounded in accordance with the National Electrical Code and local codes
and ordinances is required.
Do not under any circumstances cut or remove the third (ground) prong from the
power plug. Electrical installation should comply with national and local codes.
REPLACEMENT PARTS
Only authorized replacement parts may be used in performing service on the
range. Replacement parts are available from factory authorized parts distributors.
Contact the nearest Unique parts distributor in your area.

13
CARBON MONOXIDE WARNING:
Carbon Monoxide is a possible danger when using any gas powered appli-
ance.
All gas appliances MUST be installed by a licensed professional who is famil-
iar with the Carbon Monoxide levels appropriate for each appliance.
The American Gas Association publishes CO emissions for appliances and
heating equipment through the ANSI Std. Z21.1
The EPA reports that a maximum CO (Carbon Monoxide) level of 9 PPM over
a 24 hour period is the residential interior ambient level standard.
( A properly ventilated home will have a normal CO level of less than 5 PPM.)
NON-VENTED GAS COOKING APPLIANCES:
Non-vented gas cooking appliances in a residential application are normally
used for a short period of time. The CO generated during the operation will
disperse to the air in the home and be purged to the outside through the nor-
mal air exchange.

14
Surface Cooking
Use lids when surface cooking. A lid traps steam and uses it to speed up the cook-
ing process. If you have a pressure cooker or vegetable steamer, use it. You’ll
waste fewer vitamins, save time and cut energy costs.
Usemedium-weight,atbottomedpansthatmatchtheamesize.Choosepans
made of metals that conduct heat well.
When cooking on a surface burner, use as little water as possible to reduce cook-
ing time.
Oven Cooking
Preheat the oven only when a recipe tells you. Put roasts and casseroles into a
cold oven; then turn on the oven.
Opening the oven door often to check on foods wastes energy.
Use the oven to prepare complete meals. For instance, start a roast, add vegeta-
bles when the meat is half-cooked, and then warm rolls or dessert after the main
dishes are cooked.
Thaw frozen foods before cooking. Thawed food requires less cooking energy than
frozen food.
Make it a habit to turn the oven off before removing the cooked food.
ENERGY-SAVING IDEAS

15
Be sure appliance is properly installed and grounded by a quali ed technician.
It is the responsibility of the technician to make certain that your range is properly
installed. Situations caused by improper installation are not covered under the war-
ranty. Any expenses incurred due to such situations will not be paid by the manu-
facturer of the appliance.
A child or adult can tip the range and be killed. In-
stall the anti-tip device to the structure and/or the
range. Verify the anti-tip device has been properly
installed and engaged. Engage the range to the
anti-tip device by ensuring the anti-tip device is re-
engaged when the range is moved. Re-engage the
anti-tip device if the range is moved. Do not oper-
ate the range without the anti-tip device in place and
engaged. See installation instructions for details.
Failure to do so can result in death or serious burns
to children or adults.
If this range is removed for any reason, (eg. service
or cleaning), it must be replaced as outlined before
placing the range back in operation.
Levelling a Free-Standing Range
All free-standing ranges must be level to obtain
proper cooking results. The leveling legs should be
screwed into the corner brackets. Place pan or mea-
suringcuppartiallylledwithwateroralevelonthe
oven rack. Adjust the leveling legs until the range is
level. The top of the side panels should be level with
the counter top.
Making sure the anti-tip brackets are installed:
• Slide range forward.
• Look for the anti-tip bracket securely attached to
oor.
• Slide range back so rear range foot is under anti-
tip bracket.
INSTALLATION INSTRUCTIONS

16
1. Align the backsplash to the rear part of
the cooktop as shown in the diagram.
2. Secure the backsplash to the cooktop
from the back using the 2 Philips head
screws provided as shown in the diagram.
3. Secure the backsplash from the bottom
using the Philips head screws provided as
shown in the diagram.
HOW TO INSTALL THE BACKSPLASH

17
NOTICE TO MASSACHUSETTS APPLIANCE DEALERS:
Be sure this document is included in all gas range appliances sold to consumers in
the State of Massachusetts.
NOTICE: Massachusetts law requires the following:
•Appliancesmustbeinstalledbyalicensedplumberorgastter.
•Appliancesmustbeconnectedwithathree(3)foot(36”maximumlength)exible
gas connector and
• A “T” handle type manual gas valve in the gas supply line to the appliance.
Have the dealer where you purchase your new range install it or have him rec-
ommendaqualiedinstaller.Installationmustconformwithlocalcodes.Inthe
absence of local codes, the installation must conform with the National Fuel Gas
Code, ANSI Z223.1-Latest Edition in the U.S.A. or the CAN/CGA B149.1 or .2 In-
stallation Codes in Canada.
The range should be connected to the supply line with 1/2-inch black iron pipe or
acertiedexibletyperangeconnector.Topreventgasleaks,putanapproved
sealingcompound,whichisresistanttoliqueedpetroleumgases,onallthreaded
connections.
Important: Do not apply pressure directly to the range manifold pipe when tighten-
ing supply connections. The manifold pipe should be held securely at the pressure
regulator to prevent twisting. Hold the pressure regulator with a wrench during the
tightening of the connection, or the manifold pipe may be twisted and split, and
cause a dangerous leak.
The installation of ranges designed for manufactured (mobile) home installation
must conform with the Manufactured Construction and Safety, Title 24 CFR, Part
3280, [formerly the Federal standard for Mobile Home Construction and Safety,
Title 24, HUD (Part 280)] in the U.S.A. or C.S.A. Standard CAN/CGA Z240.4.2 in
Canada or, when such standards are not applicable with local codes.
The installation of ranges designed for recreational vehicle installation must con-
form to state or other codes and in the absence of such codes with the standard
for recreational vehicles ANSI A119.2.2–1982 in the U.S.A. or CAN/CGA Z240.4.2
in Canada. The installation of appliances designed for recreational park trailers
must conform to recreational park trailers, ANSI A119.5.
Note: Checkallpipingconnectionsintheunitforleaks.Neveruseanopename
to check for gas leaks. Use a soap solution with a recommended ratio of 75%
water and 25% dish washing soap. It’s possible for connections made at the fac-
tory to leak, due to vibration encountered in transportation. Make certain you have
checked them all, and repair any connections that leak.
GAS CONNECTIONS (All Units)

18
The appliance and its individual shut-off valve must be disconnected from the gas
supply piping system during any pressure testing of that system at test pressures
in excess of 1/2psig.
The appliance must be isolated from the gas supply piping system by closing its
individual manual shut-off valve during any pressure testing of the gas supply
piping system at test pressures equal to or less than 1/2psig.
• Gas line shut-off valve
• To reduce the possibility of gas leaks, apply
Teontapeorathreadcompoundapproved
for use with LP or Natural gases to all threaded
connections.
•Useaexibleapplianceconnectortoconnect
your gas supply to the appliance. A 3 foot length
is recommended for ease of installation but
other lengths are acceptable. Never use an old
connector when installing a new range.
• Check for leaks using a leak detector or soapy
water with a recommended ratio of 75% water,
25% dish washing soap.
Installation
It is the responsibility of the installer to make
certain that the range is properly adjusted at the
time of installation. Situations caused by improp-
er adjustments or improper installation are not
covered under the warranty. Any expenses incurred due to such situations will not
be paid by the manufacturer of the appliance.
Connecting gas to range
This range is designed to operate at a pressure of 5” of water column on natural
gas (NG) or 10” of water column on propane gas (LPG).
Make sure you are supplying your range with the type of gas for which it is de-
signed. This range comes equipped from the factory equipped for use with
NG (natural gas). This range is convertible for use on propane (LPG) also (pro-
paneoricesincludedinthepackaging).
GAS CONNECTIONS (continued)

19
WhenusingthisonLPGgas,conversionmustbemadebyaqualiedLPGinstall-
er before attempting to operate the range on that gas.
For correct operation, the pressure of natural gas supplied to the regulator should
be between 4” and 5” of water column. For LP gas, the pressure supplied must be
between 10” and 12” of water column.
When checking for correct operation of the regulator, the inlet pressure must be at
least 1” more than the operating -manifold- pressure as given above. The pressure
regulator located at the back of the range manifold must remain in the supply line
regardless of whether natural or LP gas is being used.
Regulator is only good for psi (14” w.c.) so test pressure must not exceed 1/2” psi.
Shut off the main gas supply valve before removing the old range and leave it off
until the new hook-up has been completed.
Because hard piping restricts movement of the range, the use of a CSA/ETL cer-
tiedexiblemetalapplianceconnectorisrecommendedunlesslocalcodesre-
quire a hardpiped connection. Never reuse an old connector when installing a new
range. If the hard piping method is used, you must carefully align the pipe; the
range cannot be moved after the connection is made.
To prevent gas leaks, use pipe joint compound resistant to LP or NG gases (de-
pending on set up) on all male -external- pipe threads.
1. In an easily accessible location, install a service manual gas shut off valve. Be
sure everyone operating the range knows where and how to shut off the gas
supply to the range.
2. When all connections have been made, be sure all range controls are in the off
position and turn on the main gas supply valve. Check for gas leaks by using a
soap and water solution. If a gas leak is present, shut off gas immediately, tight-
en all connections, and retest for leaks.
3.Anyopeninginthewallbehindtheapplianceandintheoorundertheappli-
ance must be sealed.
After installation:
1. Check ignition of cooktop burners.
2. Check ignition of oven burner.
3. Check ignition of broiler burner.
4.Checkforgasleaksatallgasconnections(usingagasdetector,neveraame)
GAS CONNECTIONS (All Units)

20
All units must be installed in accordance to minimum rear and side wall clearance
and clearances extended vertically above cooking top which are stated on the se-
rial plate located at the back of the range.
ANY OPENINGS IN THE WALL BEHIND THE UNIT AND IN THE FLOOR UNDER
THE UNIT MUST BE SEALED.
Note. Due to potential hazards it is recommended that storage cabinets NOT be
installed above the cooking surface.
IN THE EVENT OVERHEAD CABINETS ARE INSTALLED, THE MAXIMUM
DEPTH OF CABINETS INSTALLED ABOVE COOKING TOPS SHOULD BE 13”.
WALL CLEARANCES
