Unitech Ms842 User manual

Wired & Wireless 2D Imager Scanner

- MS842/MS842P -

User’s Manual

Version 1.4

Preface

About This Manual

This manual explains how to install, operate and maintain the MS842-series 2D scanners.

No part of this publication may be reproduced or used in any form, or by any electrical or

mechanical means, such as photocopying, recording, or information storage and retrieval

systems, without permission in writing from the manufacturer. The material in this manual is

subject to change without notice.

Unitech global website address: http://www.ute.com

Regulatory Compliance Statements

FCC Warning Statement

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference with radio communications. However, there is

no guarantee that interference will not occur in a particular installation. If this equipment does

cause harmful interference with radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

ΩReorient or relocate the receiving antenna.

ΩIncrease the separation between the equipment and receiver.

ΩConnect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

ΩConsult the dealer or an experienced radio/TV technician for help.

1. This equipment complies with FCC RF radiation exposure limits set forth for an

uncontrolled environment. To maintain compliance with FCC RF exposure requirements,

avoid direct contact to the transmitting antenna during transmitting.

2. Any changes or modifications (including the antennas) made to this device that are not

expressly approved by the manufacturer may void the user’s authority to operate the

equipment.

FCC Label Statement

This device complies with part 15 of the FCC rules. Operation is subject to the following two

conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, including interference that may cause

undesired operation.

Canadian Compliance Statement

This Class B Digital apparatus meets all requirements of the Canadian Interference-Causing

Equipment Regulations.

Cet appareil numerique de la classe B respecte les exigences du Reglement sur le material

broilleur du Canada.

European Conformity Statement

Declaration of Conformity with regards to the R&TTE 1999/5/EC and EMC 89/336/ EEC

directives.

RoHS Statement

This device conforms to RoHS (Reduction Of

Hazardous Substances) European Union

regulations that set maximum concentration limits

on hazardous materials used in electrical and

electronic equipment.

Taiwan NCC Warning Statement

ٌຏຝሽ᜔ݝ܅פ෷ሽᘿ୴ࢤሽᖲጥ෻ᙄ (930322)

௅ᖕٌຏຝ܅פ෷ጥ෻ᙄ๵ࡳΚ

รԼԲයʳ ᆖীڤᎁᢞٽ௑հ܅פ෷୴᙮ሽᖲΔᆖ๺ױΔֆ׹Ε೸ᇆࢨࠌش݁լ൓ᖐ۞᧢ޓ

᙮෷ΕףՕפ෷ࢨ᧢ޓ଺๻ૠհ௽ࢤ֗פ౨Ζ

รԼ؄යʳ ܅פ෷୴᙮ሽᖲհࠌشլ൓ᐙ᥼ଆ౰ڜ٤֗եឫٽຏΙᆖ࿇෼ڶեឫ෼ွழΔᚨ

مܛೖشΔࠀޏ࿳۟ྤեឫழֱ൓ᤉᥛࠌشΖছႈٽຏΔࠉሽ๵ࡳ܂ᄐհ

ྤᒵሽຏΖ

܅פ෷୴᙮ሽᖲႊݴ࠹ٽຏࢨՠᄐΕઝᖂ֗᠔᛭شሽᘿ୴ࢤሽᖲ๻ໂհեឫΖ

྇֟ሽ጖ᐙ᥼Δᓮݔᔞࠌش

Warranty

The following items covered under the Unitech Limited Warranty are free from defects during

normal use:

z MS842 series – 2-year limited warranty.

Warranty becomes void if equipment is modified, improperly installed or used, damaged by

accident or neglect, or if any parts are improperly installed or replaced by the user.

Use only the adapter supplied. Using the wrong adapter may damage the unit and will void the

warranty.
