UNITED USF-632 User manual

Read carefully these instructions and store them for future reference
3-IN-1 FAN
Model nr.: USF-632
Instructions Manual

Safety Warnings
When using electrical appliances, basic precautions should always be followed to reduce the risk of fire,
electric shock and injury to persons, including the followings:
1. To prevent fire or shock hazard, DO NOT expose this appliance to rain or moisture.
2. Dangerous high voltages are present inside this enclosure. To avoid electric shock, DO NOT open
the cabinet, refer servicing to qualified personnel only.
3. This appliance is intended for household use only and not for commercial, industrial or outdoor
use. Other use not recommended may cause fire, electric shock or injury.
4. Ensure the fan is not placed near drapes,curtains, or any objects that may be drawn into the fan.
5. To protect against fire, electrical shock and injury to persons, do not immerse the unit, plug or
cord in water or spray it with liquids.
6. The apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such
as vases, shall be placed on the product.
7. No naked flames sources, such as candles, should be placed on the product.
8. Ventilation should not be impeded by covering the ventilation openings. Slots and opening are
provided for ventilation to ensure reliable operation of the product and to protect it from
overheating.
9. Care required with the use of this apparatus in tropical climates. Do not use the appliance to
temperatures over 40 °C.
10. Place the fan on a stable level and dry surface when operating to avoid overturning.
11. Only connect to a suitably AC 220-240V~50Hz mains socket.
12. Do not operate the fan in the presence of explosive and/ or flammable fumes. Do not place the
fan or any parts near an open flame, cooking or other heating appliance.
13. Do not operate the fan with a damaged cord or plug, after a malfunction or if it is dropped or
damaged in any manner.
14. Do not operate the fan without the fan grilles properly in place.
15. Do not place the fan close to an open window. Rain splashing on the fan could cause an electric
shock hazard.
16. Do not let the power cord hang over the edge of a table or counter or let it touch any hot surfaces.
17. Do not insert or allow foreign objects to enter the grille openings as this may cause damage to the
appliance.
18. Do not use the fan if grille becomes damaged or loose.
19. This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety.
20. Children should be supervised to ensure that they do not play with the appliance.
21. Switch the fan OFF and unplug it from the outlet when it is not in use, when moving fan from one
location to another and before cleaning.
22. To disconnect, grip the plug and pull it from the wall outlet. Never pull by the cord.
23. Do not attempt to repair, disassemble or modify the appliance. There are no user-serviceable parts
inside. Refer all servicing to qualified service personnel.

READ AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
FEATURES OF THIS PRODUCT
Stand fan Using:
1. Front Grille
2. Blade Cap
3. Blade
4. Plastic Mounting Nut
5. Rear Grille
6. Motor Shaft
7. Motor Housing
8. Oscillating Knob
9. Connector
10. Switch Box
11. Set Screw
12. Cable
13. Inner Tube
14. Height Adjustment Collar
15. Outer Tube
16. Cross base
Table fan Using:
1. Front Grille
2. Blade Cap
3. Blade
4. Plastic Mounting Nut
5. Rear Grille
6. Motor Shaft
7. Bushing
8. Motor Housing
9. Oscillating Knob
10. Connector
11. Set Screw
12. Switch Box
13. Switch
14. Table base
15. Screw
Wall fan Using:
1. Screw
2. Wall mount adapter

PRODUCT ASSEMBLY
ASSEMBLE OF BLADE AND GRILLE
Unscrew the plastic mounting nut from the front of the motor housing by rotating it anticlockwise.
Position the rear grille against the front of the motor housing with the handle uppermost, ensuing that
the locating pegs on the motor housing are engaged correctly in the holes of the rear grille.
Tighten the Rear Grille Mounting Nut clockwise. DO NOT OVERTIGHTEN IT.
Push the fan blade onto the motor shaft, locating the slot at the back of the blade on the drive pin
that passes through the motor shaft.
Tighten the blade cap by turning it anticlockwise.
Position the front grille against the rear grille so that the holes in the rims that accept the small nut
and bolt are in line. Insert the bolt through the holes and screw on the nut. Do not fully tighten at the
stage.
Push the grille retaining clips into position ensuring that they engage correctly on the rim of the grille.
Fully tighten the small nut and bolt that passes through the rim of the grille.
ASSEMBLE OF BASE(For stand fan using)
Firstly, loosen and remove the four screws from the bars. Then cross bar A and bar B so that they
interlock.
Be sure to align the four holes in the bars with those on the flange of the Outer Tube. Secure the
flange to the bars with the four screws.
Loosen and remove the Height Adjustment Collar from the top of the Inner Tube. Slide the Base
Decorative Cap down over the assembly.
Replace the Height Adjustment Collar on top of the Inner Tube. Pull the Inner Tube out from the
Outer Tube to adjust the tube to the desired height and tighten the collar.
If necessary, slightly loosen the Set Screw by turning it anticlockwise. Slide the Switch Box down over
the Inner Tube and tighten the Set Screw. Make sure the Set Screw is tightly secured.
ASSEMBLE OF TABLE BASE(For table fan using)
Align the Fan Assembly over the Table Base and push together until secure.
Turn the Table Fan over and secure the 2 pieces together using the Table Base Screws.
ASSEMBLE OF wall mount(For wall fan using)
Before installing the Wall Mount Adapter, ensure the fan location is close enough to a wall adapter that
the fan can be plugged in.
Caution: due to the weight of this product, it is required it be mounted into a wall stud. Failure to do so,
could cause the product to fall and/or damage the wall location it is mounted in.
Place the Wall Mount Adapter against the wall and stud where you want to mount the fan.
level the Wall Mount Adapter for Asthetics.
Mark the hole locations on the wall with a pencil.
Using a 1/8 drill bit, drill the 2 holes for mounting.
line the holes on the Wall Mount Adapter to the Wall holes and insert the 2 Wall Mount Screws and
tighten Securely.
Remove the phillips head screw from the base of the Fan Assembly and insert the screw.
Insert the Wall Mount Adapter shaft into the Fan assembly.
Tighten the Thumb screw in the back of the Fan Assembly to secure fan.
OPERATION CONTROL
Before using the fan, make sure that it is on a flat and stable surface. Damage may occur if the fan is
placed on an incline.
Insertthe plug directly into a standard AC socket-outlet. Be sure that the plug fits tightly into the
socket-outlet.
Select the desired speed by pressing buttons 1 and up to 3. Select the 0 button to switch off
Oscillation: Press and depress the relative oscillation knob on the housing of the motor to enable
or disable this function

Care and Cleaning
Always disconnect from main socket before cleaning.
Avoid contact with moving fan parts.
Use only a soft and damp cloth to clean the fan.
DO NOT immerse the fan in water and never allow water to drip into the motor housing.
Never spray the appliance with liquids or submerge the appliance in water or any other liquids.
DO NOT use gasoline, paint thinner or other chemicals to clean the fan.
Ensure that the fan is switched off from the main socket before removing.
Clean the fan blade and grilles with a soft and damp cloth.
Store the fan in its original box or cover the fan to protect it from dust in a dry place if it is not being
used for a long period of time.
Technical Specifications
Power Supply: AC 220-240V ~ 50Hz
Power Consumption: 50W
NOTE: As a result of continual improvements, the design and specifications of the product within
may differ slightly to the unit illustrated on the packaging.
NOTICE ABOUT RECYCLING
Your product is designed and manufactured with high quality materials and components which can be recycled and
reused.
This symbol means that electrical and electronic equipment, at their end-of-life,
should be disposed of separately from your household waste. Please dispose of this equipment at your local
community waste collection/ recycling centre.
In the European Union there are separate collection systems for used electrical and electronic
products.
Please help us to conserve the environment we live in!
DECLARATION OF CONFORMITY
This product complies with the requirements of Directives:
EMC Directive: 2004/108/EC
Low Voltage Directive: 2006/95/EEC
The above directives declare that this model is in compliance
with following norms:
EN 55014-1: 2006 / A2: 2011
EN 55014-2: 1997/ A2: 2008
EN 61000-3-2: 2006/ A2: 2009
EN 61000-3-3: 2008
EN 60335-2-80: 2003+A1: 2004+A2: 2009
EN 60335-1: 2002+A1: 2004+A2: 2006+A11: 2004+A12: 2006+A13: 2008+A14: 2010
EN 62233: 2008
