Univex 7512 User manual

7512
7512
April 2005
Printed in USA
SLICER
UNIVEX CORPORATION ■3 Old Rockingham Road ■Salem, NH 03079-2140
Tel [phone] ■Fax [phone] ■E-mail [e-mail]
TOLL-FREE ORDERING FAX [phone]
www.univexcorp.com
Our main ingredient is value
SINCE 1948
™
The most popular workhorse in Food
and Deli slicing is the 12" Slicer.
Again, Univex with its model #7512
Slicer offers the maximum weight and
horsepower. . . the keys to precision
slice production. A redesigned
slice control mechanism
now allows slices up to
1 3/16” thick. As with all
Univex Slicers the 7512
comes equipped with a
German hollow ground
cutting blade and built-in
sharpener.
WARRANTY
The Model 7512 Duro Slicer carries a one-year, on-site parts and labor warranty against any flaws in materials and workmanship. This period begins with the date of purchase and,
provided the unit is used properly in accordance with our instructions, is in full effect for one year from that date. Any work to be performed under this warranty must be performed
between the hours of 8:00 a.m. and 5:00 p.m. local time, Monday through Friday. Univex will not pay overtime charges for work performed other than during normal business hours.
Damages incurred in transit or from installation error, accident, alteration or misuse are not covered. Transit damages should be reported to the carrier immediately. Univex shall not
be liable for any consequential, compensatory, incidental, or special damages. Contact Univex Service Department for any warranty claims.
HEAVIEST DUTY – EXTRA-WIDE 1 3/16" CUT

ELECTRICAL: 115/60/1* - 3.9 Amps
*Consult Price List or factory for special voltages
MOTOR: 1/3 HP Capacitor start, capacitor run,1625 RPM
SPEED: Blade Speed = 475 rpm .
CARRIAGE: Manual Operation
FINISH: Polished Anodized Aluminum
PRODUCT CUT:
STANDARD EQUIPMENT: 12" (305mm) German hollow ground hardened steel, high carbon chrome plated blade.
Built-in sharpener. Pilot Light indicating Knife and Motor (ON). Heavy duty multi-position
meat holder.
OPTIONAL ACCESSORIES: Vegetable Chute
BODY DIMENSIONS: 23" (584mm) high, 28 1/2" (724mm) wide, 24" (610mm) long
NET WEIGHT: 80lbs. (36kg)
SHIPPING WEIGHT: 92lbs. (42kg)
BOX DIMENSIONS: 23" (584mm) high, 28 1/2" (724mm) wide, 24" (610mm) long
NEW EXTRA WIDE 1 3/16" CUT
7512
SPECIFICATIONS
7512
April 2005
Printed in USA
UNIVEX CORPORATION ■3 Old Rockingham Road ■Salem, NH 03079-2140
Tel [phone] ■Fax [phone] ■E-mail [e-mail]
TOLL-FREE ORDERING FAX [phone]
www.univexcorp.com
SINCE 1948
*21"
533 mm
*20 1/2"
521 mm
*19"
483 mm
Max. Width per stroke 8" 203mm
Max. Length per stroke 9" 229mm
Max. Thickness per stroke 1 3/8" 30 mm
SLICER
™
