CEILING FAN HEATER
REPLACEMENT COMPONENT LIST INCLUDED
User’s GUide
UNIWATT is a line of products manufactured by STELPRO. For more information please contact customer service.
This unit complies
with CSA standards
UL
US
C
LISTED
INSUGH0315
2
WARNING
Before installing and operating this product, the user and/or installer must read, understand and follow these instructions and keep
them handy for future reference. If these instructions are not followed, the warranty will be considered null and void and the manufac-
turer deems no further responsibility for this product.
, according to the
effective in your region.
The following instructions must be adhered to in order to avoid personal injuries or property damages, serious injuries and potentially
fatal electric shocks.
Protect the heating unit with the appropriate circuit breaker or fuse, in accordance with the nameplate.
Make sure the line voltage (volt) is consistent with that indicated on the unit’s nameplate.
This unit must be .
Switch off the power at the circuit breaker/fuse before installing, repairing and cleaning the unit.
Make sure the unit is appropriate for the intended use (if needed, refer to the product catalog or a representative).
It corresponds to -
capacity to heat a room. If needed, refer to a specialist (industrial and commercial buildings) who will be able to calculate these heat losses and optimize the
required capacity or consult the “Online heating calculation” section of the Stelpro Design Web site (residential buildings). To heat a large room and to increase
your comfort, it is recommended to install several units instead of one. For example, 2 X 1000 W rather than 1 X 2000 W.
indicated in the installation section
This unit must not come into contact with a water source and must be protected from splashes. Do not use it if any part has been immersed.
When mounting the unit, make sure that the anchorage used can support the total weight of the unit with the mounting brackets.
When cutting or drilling into a ceiling, do not damage electrical wiring and other hidden utilities.
Because this unit is hot when in use, it may pose risks even in normal operation. Therefore, be careful and responsible when using it. To avoid burns, do not
let bare skin touch hot surfaces. The unit must cool down for few minutes since it will stay warm for some time after shut down.
more heat-sensitive than others, so make sure those near the unit can withstand heat.
products. Store it in a dry place when not using it.
Some areas are dustier than others. Thus, it is the user’s responsibility to evaluate if the unit based on the amount of dirt accumulated on
in accordance with these instructions.
The thermal protection activation indicates that the unit has been subjected to abnormal operating conditions. If the thermal protection remains activated or
damaged. (Refer to the limited warranty)
instances, the instruction manual may not entirely match all the functions of the actual product. Therefore, the actual product and packaging, as well as the name
and illustration, may differ from the manual.
IMPORTANT INSTRUCTIONS
SAVE THESE INSTRUCTIONS
INSUGH0315
3
INSTALLATION
Also, keep at least 12 inches away from any vertical surfaces or walls (see Fig.1).
1. Remove the external cover of the unit and set aside (4 screws, Fig. 2).
2. Remove the mounting bracket (1 screw and hook, Fig. 2)
3. Screw the mounting bracket to the ceiling and make sure the ceiling structure is strong enough to support the unit. Make sure the mounting
bracket is installed in such a way that the unit will sit straight and level. (Fig. 2)
5. Make sure a wall mounted thermostat is installed to control the heater.
8. Make the electrical connections using the supplied wirenuts. Connect the ground wire. Make sure all connections are secure and tight (Fig. 3).
WARNING - To avoid a short circuit, keep the stripped ground section wire inside the back wiring cover.
9. Replace the back wiring cover. Swing the other half of the internal assembly into position and screw the assembly to the bracket with the
screw(s) previously removed in step 2. (Fig. 4)
10. Optional; To prevent any possible vibration, use two (2) No. 8 screws with anchors (not supplied) (Fig 4.5)
11. Replace the external cover and screw it into place with the four screws removed in step 1.
12. Test the unit to make sure it is running properly.
240/208
WATTS 4000/3000
AMPERAGE 16
ORANGE
WEIGHT 10 lb / 4.5 kg
SIDE
5 1/2"
140mm
FRONT
13 3/4"
349.7mm
KO 7/8''
BACK
11 3/4"
298.5mm
INSUGH0315
4
INSTALLATION
FIGURE 1
FIGURE3
FIGURE 2
FIGURE 4
FIGURE 4.5 FIGURE 5
12 in. MIN.
(305 mm)
12 in. MIN.
(305 MM)
MOUNTING BRACKET
INTERNAL ASSEMBLY
SUSPENSION SLOT
HOOK
COVER
INSIDE THE BACK
KEEP BARE WIRE
KO.
7/8 COVER
BACK WIRING
L2
RED
L1
GREEN
BLACK
WIRING COVER
-WARNING-
-WARNING-
USE THIS KO FOR FINISHED CEILING
ANTIVIBRATION
OPTION HOLE.
USE (2) NO.8 SCREWS
WITH ANCHOR
(NOT SUPPLIED)
WIRING DIAGRAM
JUNCTION BOX COVER
INSUGH0315
5
MAINTENANCE, TROUBLESHOOTING
AND REPLACEMENT COMPONENTS
1 PROT-005
2 MO-016 MOTOR 208/240V 50/60HZ 0.4A (W/RING)
3
N.B. If you do not solve the problem after checking these points, cut off the power supply at the main electrical panel and contact our customer service (see the
“” section to obtain the phone numbers).
em
The unit does not work
Defective thermostat or wrong thermostat setting
Open circuit breaker or fuse
The thermal protection has been activated
Faulty connections
The unit runs continuously Defective thermostat or wrong thermostat setting
Heat losses higher than the unit capacity
The enclosure is extremely hot
Defective thermal protection
Defective motor
Blocked air vents
The desired room temperature cannot be reached
One or more elements are defective
Defective thermostat or wrong thermostat setting
Voltage lower than that written on the nameplate
Heat losses higher than the unit capacity
Room overheating Defective thermostat or wrong thermostat setting
The unit cycles under control of the thermal protection Blocked air vents
The breaker trips when the heater is turned on Faulty connections
Voltage higher than that written on the nameplate
In order for the warranty to be valid, the unit must be cleaned regularly.
Cut off power supply at circuit breaker/fuse before cleaning this heater. Use a soft rag for dusting. When cleaning, use only a damp rag and non-
a vacuum brush to remove dust and other foreign objects from the grilles. Note that cigarette smoke could yellow the discharge grille and that the
best way to prevent it is to clean the unit on a regular basis.
There is electrical current linked to the unit even if the thermostat is set to off. This means that there is a risk of electric shock as long as
the unit is energized.
1
2
3
INSUGH0315
6
STELPRO DESIGN INC. | Saint-Bruno-de-Montarville | Québec | J3V 6L7
This limited warranty is offered by Stelpro Design Inc. (“Stelpro”) and applies to the following products made by Stelpro: UNIWATT UGH model.
, Stelpro warrants its products and their components against
defects in workmanship and/or materials for the following periods from the date of purchase: . This warranty applies only to the original
purchaser; it is non-transferable and cannot be extended.
If at any time during the warranty period the unit becomes defective, you must cut off the power supply at the main electrical panel and contact 1) your
installer or distributor, 2) your service center or 3) Stelpro’s customer service department. In all cases, you must have a and
provide the . Stelpro reserves the right to examine or to ask one of its representatives to examine
the product itself or any part of it before honoring the warranty. Stelpro reserves the right to replace the entire unit, refund its purchase price or repair a
defective part. Please note that repairs made within the warranty period must be authorized in advance in writing by Stelpro and carried out by persons
authorized by Stelpro.
Before returning a product to Stelpro, you must have a Stelpro authorization number (RMA). To obtain it, call the customer service department at:
(electricians and distributors - French), (electricians and distributors - English), or (consumers).
The authorization number must be clearly written on the parcel or it will be refused.
This warranty is exclusive and in lieu of all other representations and warranties (except of title), expressed or implied, and Stelpro expressly disclaims
Stelpro’s liability with respect to products is limited as provided above. Stelpro shall not be subject to any other obligations or liabilities whatsoever,
whether based on contract, tort or other theories of law, with respect to goods or services furnished by it, or any undertakings, acts or omissions relating
thereto. Without limiting the generality of the foregoing, Stelpro expressly disclaims any liability for property or personal injury damages, penalties, special
all consequential, incidental and contingent damages whatsoever.
This warranty does not cover any damages or failures resulting from: 1) a faulty installation or improper storage; 2) an abusive or abnormal use, lack of
maintenance, improper maintenance (other than that prescribed by Stelpro) or a use other than that for which the unit was designed; 3) a natural disaster
damages, etc. This warranty does not cover any accidental or intentional losses or damages nor does it cover damages caused by negligence of the user
or owner of the product. Moreover, it does not cover the cost of disconnection, transport, and installation.
The warranty is limited to the repair or the replacement of the unit or the refund of its purchase price, . Any parts replaced
or repaired within the warranty period with the written authorization of Stelpro will be warranted for the remainder of the original warranty period. This
warranty will be considered null and void and Stelpro will have the right to refuse any claims if without the written
discoloration caused by excessive heat, chemical cleaning products and abrasive agents. It does not cover any damage that occurred during the shipping.
Some states and provinces do not allow the exclusion or limitation of incidental or consequential damages and some of them do not allow limitations on
have other rights which vary from state to state or from province to province.
