UNMAK 10 P 300 User manual

Panel Radiator Installation
and User Manual
This manual cover below types of panel radiator:
PANEL RADIATOR
Type 10 P: 300, 400, 500, 550, 600, 900
Type 11 PK: 300, 400, 500, 550, 600, 900
Type 21 PKP: 300, 400, 500, 550, 600, 900
Type 22 PKKP: 300, 400, 500, 550, 600, 900
Type 33 PKKPKP: 300, 400, 500, 550, 600, 900
ÜNLÜSOY
Yapı Malzemeleri Sanayi ve Ticaret Ltd. Şti.
Pancar Organize Sanayi Bölgesi, 10. Cadde, No:2, Torbalı – İZMİR
Tel: [phone], Faks: 0232 469 2412 www.unmak.com

Panel Radiator Installation and User Manual Ü n m a k |1
ÜNMAK After Sales Services
CONTENTS
Introduction
3
Handling and Storage
3
Recommended Installations
4
Technical Specificiations
6
Installation Scheme
9
Radiator Commissioning
10
Maintenance&Cleaning
10
Bleeding of Radiator
11
Information About Usage Error
12
Warranty
13
Rev: 121017

Panel Radiator Installation and User Manual Ü n m a k |2
INTRODUCTION
Thank you very much for choosing to ÜNMAK panel radiator product
group. Please read the user manual carefully before installing and
operating the product. Please keep this manual until the end of
service life of product. Do not touch or tamper with any part of the
product other than allowed section. Installation, maintenance and
service of the radiator should be done by authorized technical staff.
This manual and legislation should be considered for installation of the radiator,
selection of proper place and pipe work installation. Radiator should only use for
home heating system. Other purpose should considered as out of warranty.
Manual should be read carefully and must kept with warranty certificate
until the end of service life of the product.
HANDLING AND STORAGE
ÜNMAK panel radiators are dispatched with shrink nylon on the cardboard
protection.
Radiators are heavy products, so care should be taken when moving to installation
places. Necessary tools must be taken during lift and handling of the product.
Hard and sharp objects must not be used to avoid any paint damages when
product removed from the packaging.

Panel Radiator Installation and User Manual Ü n m a k |3
RECOMMENDED INSTALLATIONS
Fine air circulation should be taken
into account when choosing the right
installation place of panel radiator.
Front part of room window is cold
place and has fine air circulation.
For this reason, bottom of window
is right place at mounting.
•High panel radiators, such as 900 mm in height with high radiation ratio should be
used in high ceiling structures, stairwells and vertical connection spaces in duplex
structures. In such places, the heat emitted by the radiator is collected in the upper
parts and the lower floors remain relatively cold. However, this difference is largely
covered when the heat dissipation rate with the radiation in the radiators placed in
the lower floors is high. Radiation ratio is high at thin radiators and at the flat
surface. In this regard, panel radiators with less depth and high height are the most
advantageous types.
•In general, radiators are mounted to bottom of window. Especially in well insulated
structures, PK type should be preferred instead of PKKP types because of high heat
power and depth since heat loss is less.
•The height of the radiators to be placed in the niche
should be at least 15 cm less than the height of the
bulwark. Radiator should be lift from the floor
approximately 7 cm. Thus, such a space between the
radiator top and the parapet is at least 8 cm.
•The places where the most heat loss are glass and outer walls. Heat loss is not
prevented no matter how good double glazing and thermal insulation application.
Therefore, radiators are evaluated as a project when mounted under the glass.
Installation of the panel radiator should be done by a qualified plumber.
•Installation place should be clean and smooth.

Panel Radiator Installation and User Manual Ü n m a k |4
•Product should not be dropped. It should be carried
by two person due to heavy weight of the product.
•Please do not close top of the radiator, it may
obstacle heat transfer. More energy will be consumed
due to the reduced heat transfer. Loss of efficiency
will increase up to 20% in upper closed radiators. Heat
transfer will decrease when items such as cabinets,
seats, etc. are placed too close to radiators..
•The water in radiator should not be drain. Draining
the radiators at the end of the season requires filling
new water. This cause to increase of oxidation. If it is
necessary to fill the radiator with water, first the
water should be filled in the hose and then the air
inside the radiator must be drained.
•It is necessary to avoid the contact of children, pets
and living things or objects while radiator is working.
•The water in the radiators should not be drained even
if the system will not be used for a long time. Radiator
valves should be closed and water should remain from
radiator when the water in the system needs to be
drained. Otherwise, corrosive substances occurring
inside the radiator will worse affect the radiator. This
may damage the installation.
•It should not be used in open areas where there is a danger of freezing. Freezing of
water in the installation can damage both the radiator and the installation.
Antifreeze must be added to the installation water when the installation and radiator
are required to remain in an environment less than 0°C.
•Maximum operating heat of radiator is 120°C. It should not use at temperatures
higher than it.

Panel Radiator Installation and User Manual
Ü n m a k |5
TECHNICAL SPECIFICATIONS
Height
Junction
Length
Water Capacity
Weight
Type
Axis
Width
min-max
(mm)
(Lt)
(kg/m)
(mm)
(mm)
300
245
1,7
6,5
400
345
2,1
7,1
10
500
445
2,6
9,6
P
550
500
2,9
10,6
600
545
3,1
11,4
900
845
49
4,4
17,8
300
245
1,7
9,1
400
345
2,1
11,1
11
500
445
2,6
14,1
PK
550
500
2,9
15,1
600
545
3,1
16,9
900
845
4,4
25,5
300
245
3,4
14,4
400
345
400
4,3
21,1
21
500
445
5,1
25,9
70
-
PKP
550
500
5,6
27,9
3000
600
545
6,1
29,5
900
845
8,2
40,8
300
245
3,4
17,0
400
345
4,3
21,5
22
500
445
104
5,1
27,2
PKKP
550
500
5,6
29,2
600
545
6,1
31,9
900
845
8,2
48,5
300
245
5,1
25,1
400
345
6,2
31,9
33
500
445
160
7,6
40,3
PKKPKP
550
500
8,4
43,3
600
545
8,9
48,5
900
845
13,1
71,6

Panel Radiator Installation and User Manual Ü n m a k |6
Panel radiators divide into five according to types.
P letter indicates panel, K letter indicates
convector. Heat transfer increase depends on
increase of panel and convectors numbers.
HEAT OUTPUT at 80 oC WATER TEMPERATURE
ROOM TEMPERATURE
Height
Type
12 oC
15 oC
18 oC
20 oC
22 oC
24 oC
26 oC
(mm)
W
W
W
W
W
W
W
300
755
713
668
641
611
583
557
400
971
916
859
825
785
749
718
10
500
1227
1158
1086
1042
993
948
907
P
550
1349
1273
1194
1146
1092
1042
986
600
1418
1339
1255
1205
1147
1094
1047
900
1511
1426
1336
1284
1222
1166
1115
300
1004
948
889
853
813
776
742
400
1189
1178
1104
1059
1007
964
922
11
500
1453
1371
1286
1235
1176
1122
1073
PK
550
1598
1508
1414
1358
1293
1234
1180
600
1685
1592
1493
1433
1364
1304
1247
900
2355
2224
2085
2002
1906
1820
1741
300
1439
1359
1274
1233
1164
1112
1064
400
1807
1706
1599
1535
1463
1396
1335
21
500
2052
1936
1817
1743
1660
1585
1517
PKP
550
2257
2129
1998
1917
1826
1743
1668
600
2454
2317
2172
2085
1985
1895
1813
900
3467
3275
3069
2947
2806
2680
2562
22
300
1851
1749
1639
1573
1499
1430
1368
PKKP
400
2129
2011
1884
1810
1724
1644
1574

Panel Radiator Instruction and Installation
Manuels
Ü n m a k |7
2464
2327
2181
2095
1995
1904
1820
500
22
550
2710
2559
2399
2304
2194
2094
2002
PKKP
600
3117
2944
2760
2649
2524
2407
2304
900
4279
4041
3789
3637
3463
3308
3162
300
2510
2371
2222
2134
2032
1939
1855
400
3156
2981
2795
2683
2556
2439
2333
33
500
3800
3589
3363
3230
3075
3937
2807
PKKPKP
550
4180
3947
3732
3553
3382
4330
3087
600
4246
4010
3760
3610
3438
3282
3139
900
5945
5615
5264
5053
4811
4593
4394
INSTALLATION SCHEME
The most preferred method of panel
radiators mounting is the upper inlet -
lower outlet from the diagonal corner.
Second mounting method is upper
inlet and lower outlet at same
direction. It can be done left or right
side.

Panel Radiator Installation and User Manual Ü n m a k |8
It is not preferred method but in case of
necessity, it can be mounted from right
bottom side inlet or left bottom side
outlet or vice versa. This method is not
recommended due to the decrease in
radiator efficiency unless necessary.
RADIATOR COMMISSIONING
Pipework of the radiator must be connected with a hose from the lowest inlet level
of the system. Air bleeding should be done from highest outlet level. For this purpose
purger flange should be open. It is not necessary to determine this process for use at
open expanding system. The tap should be opened and the hose should be filled with
water, then the water should be connected to the point to be pressed. Air pressure
of system should be set to 1-1,5 bar by observing from manometer when filled from
the lowest elevation level. Necessary attention should be taken to avoid air in the
system.
MAINTENANCE&CLEANING
Regular controls:
Product should be check against for leaks. Please contact installation
company when leakage is observed. 
Radiators must only clean by smooth glass cleaning microfiber cloth without
using chemicals.

Periodical controls:
The convector part of the panel radiator can be cleaned by removing the
side covers and top grill. Dust can be poured by using hair dryer without
removing top grill.

Panel Radiator Installation and User Manual Ü n m a k |9
Radiator surfaces should be checked from bottom to top whether there is a
cold zone or not. Cold zone indicates air inside the radiator.
Annual controls:
Convector part cleaning can be done by Professional Cleaning Company.
BLEEDING OF RADIATOR
Air bleeding is taken from the places
shown in figure. Precautions should
be taken for dirty water to be
removed with a deep cup.System
should work and pressure set to 2
bar. Slowly turn the screw to
counterclock wise by air bleed plug or
srewdriwer. If air is stuck in the
system, it will exist during this
process.
Air has been evacuated when the water starts properly flow. Then system pressure
should be check and set to 1-1,5 bar.
It is sufficient to check the radiators while the system is operating in order to
understand whether there is air in the system. If there is air inside the radiator,
bottom part of the radiator will be colder than top of the radiator. You may also see
the thermal camera screen of observed air and non-observed air inside the radiator
in figures.

Panel Radiator Installation and User Manual
Ü n m a k |10
INFORMATION ABOUT USAGE ERRORS
PROBLEM
REASON
SOLUTION

Air may stuck in the

Please take the stuck
Cold part observed at
radiator
radiator
air with refering to “air
bleeding” section.

Mounting fault

Refer to installation
Leakage observed at
bottom part of radiator


company

Insufficient level of

Increase the level of
The radiator at the last
circulation pump
circulation pump
point of the installation

Air may stuck in the

Please take the stuck
does not heat up.
radiator
air with refering to “air
bleeding” section.

Panel Radiator Installation and User Manual Ü n m a k |11
WARRANTY
WARRANTY
10 YEARS
After Sales Services Competence Certificates
Chapter: TS 12676, Document No: 37278
This warranty document was made in accordance with the Law No. 6502 and the Regulation on
the Principles of Guarantee Certificate issued based on this Law. The use of this warranty
document is subject to the permission General Directorate of Consumer Protection and
Competition of the Ministry of Industry and Trade.

Panel Radiator Installation and User Manual
Ü n m a k |12
PRODUCER
Title :
Ünlüsoy Yapı Malzemeleri Sanayi ve
Ticaret Limited Şirketi
Adress:
Pancar Organize Sanayi Bölgesi, 10.
Cadde No:2, Torbalı - İZMİR
Tel –Fax:
444 3532 –0232 469 2412
Authorized person signature&stamp:
SELLER
Title :
Adress:
Invoice Date and Number:
Authorized person signature&stamp:
PRODUCT DETAILS
Description:
PANEL RADIATOR
Brand/Model:
ÜNMAK/Extra
Type:

Panel Radiator Installation and User Manual Ü n m a k |13
TERMS of GUARANTEE
1. Radiators whose initial operation is not performed by Ünmak Authorized Services are not
covered by the warranty.
2. The warranty period is ten (10) years. It commences from the date of delivery of the goods to
the consumer when warnings and conditions specified in the user manual are followed. The
maximum repair time is 20 days.
3. Our company will not be responsible for any damages and malfunctions due to the improper
usage of this product without concerning the user manual.
4. Malfunctions caused by inadequate, incorrect cleaning and improper maintenance are not
covered by the warranty.
5. The service life recommended by the Ministry for this product is fifteen (15) years.
6. Invoice issued for the purchased goods do not replace the warranty document. Nevertheless,
the invoice issued as a result of repair and replacement of the parts at the service stations
replaces the warranty document.
7. In case of failure, the time spent in repair is added to the warranty period.
8. The maximum repair time is 20 days. This period starts from the date of notification to the
service station of the error related to the product; the seller, dealer, agent and representative
can also acceptable when service station is not available. Consumer failure notification is
possible to make by phone, fax, e-mail, registered letter or similar method. Neverthless, in the
event of dispute, consumer responsible for obligation of the proof.
9. If the malfunction cannot be resolved within 20 working days, our company offer another
goods with the same specification to the use of the consumer until the repair of the goods is
completed.
10. This warranty certificate only valid for panel radiator. It is not covers other parts such as
pipeline, valves, fittings, etc.
11. The warranty is not valid when the destruction (erasure, scratch) of the seller and
manufacturer part or any part on the certificate observed.
12. The radiator is not covered by the warranty, which does not comply with the user manual of
the device or any application specified in the user manual.
13. Errors arising from user and radiator placement, errors due to natural disasters, freezing due
to climatic conditions are out of warranty.
14. Errors caused by the incorrect selected radiator capacity are not covered by the warranty.
15. Errors arising from transportation after the radiator is delivered to the customer are out of
warranty.
16. Damage that may occur on painted surfaces is not covered by the warranty.
17. Cases where the warranty certificate can not be shown are considered outside the scope of the warranty.
18. If the maintenance specified in the user's manual is not done by consumer, the errors that
occur are out of the scope of the radiator warranty.
19. Radiators are out of warranty when the commissioning or initial service has not been
performed by Ünmak Authorized Services.
ÜNLÜSOY YAPI MALZEMELERİ SANAYİ ve TİCARET LTD. ŞTİ
Pancar Organize Sanayi Bölgesi, 10. Cadde, No:2, Torbalı – İZMİR
Tel: [phone], Faks: 0232 469 2412
www.unmak.com
