UrbMob Fld16 Technical manual
Meet your Ebike
1 Handlebar sleeve
2 Display
3 Power-off brake handle(Left)
4 Handlebar
5 Power-off brake handle(right)
6 Handlebar sleeve
7 Vertical stand tube
8 Fixed buckle
9 Pole with folding system
10 Limiting stopper parts
11 Frame
12 Front light PCB
13 LED front light cup
14 Front light lens
15 Front light cover
16 Fender screw
17 Fork
18 Front fender
19 Front wheel
20 Front disc pad
21 Chain
22 Chain wheel
23 Sprocket crank
24 Pedal
25 Cover plate of
controller box
26 Power line
27 Controller
28 Motor
29 Rear disc gear
30 Rear Fender
31 Holder for fender
32 Flywheel
33 Rear light lens
34 PCB board rear light
35 Seat pole quick
dismantling
36 Inner support sleeve
37 Battery
38 Clamp of seat
cushion
39 Seat cushion
Paremeter
Product name: E-bike
Motor : 250W brushless geared DC motor
Break: 160mm disc break
Model name: UrbMob Fld16 Rated output power: 250W Rim: 16 inch Al-Alloy 13G36H
Size: 1320*580*980mm Motor efficiency: ≥80% Tire: Kenda 16*2.125
Folded size: 710*360*630mm Rated RPM: 300r/min Chain wheel: Pro wheel 52T
Wheel base: 930mm Rated voltage: 36V Fly wheel: 14T
Net weight: 14kg Max torque: 40N.m Rear hub: Sigma Alu-Alloy
Range: 25-40km Overcurrent protection: 12±1A Chain: KMC
Standard load: 100KG Low-voltage protection：30±1V Handlebar: EVA
Top speed: <25km/u Kwh：≤1.2Kw.h Display: Kunteng LCD
Charge time: 4-7Hs Ride system: 5 classes PAS + cruise Controller: Kunteng sine wave FOC
Battery type: Lithium-ion Tire diameter: 16inch Break lever: Alu-Alloy E-bike lever
Battery capacity: LG 36V 6.4Ah Frame: 16 inch 6061Alu-Alloy foldable Saddle: KNUS
Noise : ≤62db(A)
Front fork: 16 inch 6061 Alu-Alloy
Pedal: Foldable pedal
Fold your E-bike
1. Grab the seat post
(important). Loose the
clamp.
2. Push the seat post till
theground slowly tight
the seat post clamp.
5.Release the lock clamp,
fold the head tube.
6.Fold the pedal by pushingit
level.
3. Loose the handle
barclamp.
4. Turn the handlebar
clockwisetill vertical, tight
the clamp.
7. Release the safety cap.
8. Null the lock bar, fold
themain tube.
Operate your E-bike
I Display
Operate your E-bike
1
ASSIST
Gear
11
TM
Single ride time
2
battery status
12
TTM
Accumulated time
3
Brake sign
13
AVS
Average speed of a single ride
4
Front light open sign
14
MXS
Single maximum riding speed
5
ODO
Accumulated mileage
15
MPH
Real time riding speed (British
system)
6
DST
Single ride mileage
16
non zero start sign
7
VOL
Battery real time voltage
17
Km/H
Real time riding speed (Metric)
8
CRUISE
CRUISE sign
18
Mil
Mileage (British)
9
PAS
Power assist sign
19
Km
Mileage (Metric)
10
THROTTLE
THROTTLE handlebar
open
Operate your E-bike
II Display Function
1. Power on and power off
Long button , power on; Press the long key again to power off. When the bike stops and does not operate
the display for 10 consecutive minutes, the display will automatically shut down and power off. (Shutdown time can be set)
2. Key operation
After power on, short button , gear increase, long press to turn on front light (need controller support); Short
press to switch the display of ODO, DST and Vol. Short key to reduce gear.
3. Automatic prompt interface (fault code display)
Fault code definition
E-01 motor fault
E-02 THROTTLE handlebar failure
E-03 controller failure
Operate your E-bike
E-05 controller under voltage
E-06 communication failure, the display cannot receive the controller signal
E-07 communication failure, controller cannot receive display signal
When there is a fault in the electrical system, the fault code flashes. After the fault is eliminated, the display will
automatically exit the fault code interface.
4. Internal parameter setting
After power on, long press and key to enter the internal parameter setting
P01: backlight brightness adjustment, 1 darkest, 3 brightest;
P02: mileage unit, 0: km; 1：MILE；
Operate your E-bike
P03: voltage class: 24 V, 36 V, 48 V
P04: sleep time: 0 is not sleep, other numbers are sleep time 1-60 minutes;
P05: power gear: 3, 5, 9, 0;
P06: wheel diameter: unit, inch; Accuracy: 0.1;
P07: speed measuring magnetic steel number: 1-100 optional;
P08: speed limit, range 0-50km / h, 50 means no speed limit (this parameter is based on KM)
P09: Zero / non-zero start setting, 0: zero start; 1: Non zero start;
P10: drive mode setting, 0: power start; 1: Electric drive; 2. Assist and electric drive coexist;
P11: resistance sensitivity setting, range 1-24;
P12: power start strength setting, range 0-5;
P13: power magnetic steel plate type setting, 5, 8 and 12 magnetic steel quantity types;
Operate your E-bike
P14: controller current limit setting, range 1-20a;
P15: it has not been opened for the time being;
P16: long key to clear ODO for 5 seconds and total time TTM clear;
P17: cruise function setting, 0: no cruise; 1: Cruise;
Charge your Ebike
Accessory list
Charging port is right
beneath the saddle
covered by a rubber
dust-free cover, uncover
it, plug the charger into
the port; cover the port
again when charge
If you want to charge
your battery separately,
roll out the power port,
release the seat post
clamp, pull out the seat
post battery, then
repeat the steps above.
1 front mud
fender
2 rear mud
fender
3 reflectors
4 ring
5 lamp
Please mount accessories according to your
needs.
Attention
Battery & Charge
1.
Red indicator on the charger means charging, when it turns green ,please stop
charging your battery;
2.
Do not expose to temperature -20℃＜ or ＞35℃，Fully charge the battery and
store separately if not use for over 30 days. Fully charge it every 60days, or the
battery may self-discharge and be damaged. This damage is not covered by the
Limited Warranty;
3.
Never expose your battery to damp environment or soak into water, never short
circuit the battery terminals, This damage is not covered by the Limited Warranty;
4.
Charge with the original charger only;
5.Do not disassemble/punch battery pack. Do not place it in fire or drop from
high, Avoid contacting with contacts;
6.Turn off E-bike’s power before charge it. Plug the charge port first then the
AC plug;
7.Do not cover any items on the charger during charging;
8.Pull out charge port before the AC plug;’
9.Please keep battery outreach from children.
10. The capacity of Li-battery will decrease when -10℃<;
11. Recycle or dispose of in accordance with local regulations.
Ride & Maintain
1.Must with your helmet on and follow the local laws
andregulations；
2.Read this instruction carefully before riding a E-bike；
3.Start your ride with the 3rd PAS class；
4.Keep the lamp on at night；
5.Fully check break system ,tire pressure ,and battery
remainbefore riding；
6.Do not ride with 1 or more persons, do not jump；
7.Do not intense riding；
8.Do not ride into water (pools) over 3cm；
9.Replace & check the quick-wear parts(like break pad)in time
10. Juveniles Pregnant Intoxicated are not allowed to ride bike
11. Keep your E-bike away from damp, high temperature or
corrosive environment；
12. Keep your E-bike away from sun-scorched and rain-
drenched；
13. Check screws chain and other parts regularly, this is part of
your own daily maintenance.
