UrbMob M10 Installation and operation manual

Table of Content UrbMob Pro E-scooter
1. The Device & Accessories P.01
2. Functions P.02
3. Display Functions P.02
4. APP P.03
5. E-scooter assemble P.04
6. Charging the E-scooter P.05
7. Adjusting the Disc brake P.05
8. Adjusting the handle bar P.06
9. Pump Air tyre P.06
10. Model Specifications P.07
11. Warrantee P.08
1.The UrbMob+ Device & Accessories
Accessories:
4 x Screws Hex Wrench Charging Adapter

2.Functions
3.Display functions
1. Speed display; showing normal running speed
while riding.
2. Mode display; the GREEN light will be on
when the power is on. At the time it is LOW
speed
mode and the max speed is 15km/hr. Double
press the switch to change it to HIGH speed
mode: RED light is on and max. speed is 25km/hr
3. Battery indicator; there are 4 lights to indicate
the amount of electricity. With battery
consumption, the power light status will change
from the right to the left the order of light on, flashing and extinction.
When 4 lights are on the electricity is between 100% & 86%
When 3 lights are on the electricity is between 85% & 71%
When 2 lights are on the electricity is between 71% & 57%
When all lights extinct the electricity is used-up and the E-scooter will stop
4. Power Switch; When your UrbMob+ E-scooter is power-on long press the switch to open the
E-scooter. Long press the switch to turn-of your UrbMob+ E-scooter. After turning your E-
scooter on, short press the switch to turn on / off your lights

4.APP
App Download:
Use APP for Speed unit switching between Mph or
km/hr, zero-start and kick-start modes, constant speed
cruise mode can be set through APP.
Download App from this QR Code, APP name E-scooter.
Follow instructions in APP to pair by Bluetooth your
Smartphone & UrbMob E-scooter

5.UrbMob+ E-scooter assemble
Step 1. Fix the steering rod and
Step 2. Set handle bars vertical; open the parking bridge
Step 3. Using Hex wrench to tighten the bar
Step 4. Testing the power finish packing switch
power after the handle assembling with screws

6.Charging scooter
Open the cover Battery cover (under the Deck) & connect the charger cable, after
connecting the Charger Cable to the e-Scooter you can plug the power into the Wall-unit
7.Adjusting the brake disc
If a brake is very tight using M5 Hex wrench and scroll counter clockwise screws of
brake disc tensioner pulley, slightly shorten a length of a tail brake cable, then
tighten a tensioner pulley. If you think that brake is very free loosen a tension
pulley pull a brake cable to slightly increase a length of its tail. Tighten a tension
pulley.

8.Adjusting the handle bar
Staggering of steering rack: using a M5 hex wrench tighten two screws near the
folding mechanism.
9.Pump Air tyre
If a wheel of Electric Scooter is deflated, connect a connecting pipe to a wheel
nipple to pump it. First remove the a cap of pin then tighten a fitting and then you
start to pump a wheel.

10.Model specification

11.Warranty
Warranty service is carried out in accordance with the law on consumer rights
and the Law on the quality of products. The UrbMob warranty service includes 2
years of full Warranty when used within the guidelines
Recommendation: use the packaging for safe transport of the device. We
recommend keeping the original packaging within 15 days after receipt of goods.
Keeping the packaging after this period will safe carry your E-scooter for repair
purposes.
Non - warranty regulations
Authorized maintenance, misuse, collision, negligence, abuse, intake,
accident. Improper use of non-product accessories, or tear up the
modified label, anti-counterfeit mark;
The warranty period has expired;
Damage, caused by force majeure;
Failures, which do not correspond to the List of fault of UrbMob
service center;
A failure of the device or its components from the Fault list, which
arose in connection with the human factor, and which interfere with
normal operation.
Failures, that have arisen in connection with the human factors
(including, but not limited to, excessive wetting device, puncture,
drop, scratch and damage an outer casing, which have arisen as a
result of normal use of goods)
If this product is used for commercial purposes, all warranty
conditions are not maintained.
List of faults
name of Fault:
Incorrect motor operation
Problems with operation of the controller
Problems with charger
Problems with battery
In use, occurrence of cracks, deformation and similar defects
