usha MAXIQUICK MQ500M13 User manual

Instruction Manual
[email protected]om
USHA INTERNATIONAL LTD.
To explore our range of
product and recipe log
on to www.ushacook.com COOK
Looks Smart
Works Smartly
Mixer Grinder
MA I QUICK
TM
Plot No. 15, Institutional Area, Sector 32, Gurugram - 122 001 (Haryana)
Tel : [phone], Fax : [phone], E-mail: [email protected] , Website: www.usha.com
Regd. Oce : Surya Kiran Building, 19 Kasturba Gandhi Marg, New Delhi 110 001, (India) Tel : [phone] Fax : [phone]
ISO 9001 : 2015 Certied Company

Dear Customer,
Congratulations!
You are now the proud owner of USHA Mixer Grinder.
Innovatively designed, using only the highest quality material and components, your
USHA Mixer Grinder is designed for years of trouble free performance.
Please read this Instruction Manual carefully before using and keep it cautiously after
reading for future reference.
Best Wishes
CONTENTS
Important Precautions
Safety and Important Instructions 3
Know your Mixer Grinder
Identication of Parts 4-5
Operating Instructions
Using the Product 6
Operation 6
Overload Protection 7
Miscellaneous
Technical Specications 8
Recommended Usage Capacity - Jars 9
Troubleshooting 9
Care and Cleaning 10
Warranty Card 10
1 2

IDENTIFICATION OF PARTS
SAFETY PRECAUTIONS
SAFETY AND IMPORTANT INSTRUCTIONS
We recommend that you read the following instructions carefully, before using the appliance.
1. Check if the voltage indicated on the base of the appliance, corresponds to the local
electrical mains voltage before you connect the appliance.
2. Do not use the appliance when the mains cord, the plug or other components are damaged.
3. Always unplug the appliance after use.
4. Never immerse the motor unit in water or any other liquid. Do not rinse it either.
5. Always unplug the appliance before reaching in to the jar with your ngers or an object e.g.
spatula.
6. The appliance is not to be used by children or persons with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge unless they have been given
supervision or instruction as per applicable safety requirements by a person responsible for
their safety.
7. Children should be supervised not to play with the appliance.
8. Always ensure that speed selector knob is at 'OFF' position before mixing.
9. Blades should be tted properly before running the mixer grinder.
10. Do not operate the mixer without the dome or lid in place or with an empty jar.
11. Do not open the lid or dome when the mixer is running. Do not add solid ingredients when
mixer is running.
12. Do not grind hot ingredients in your Mixer Grinder
13. Do not overload the grinder
14. Handle the blades carefully. Wash them under running water and do not rub by hand.
15. In dry grinding, the jar may get heated up due to friction. This is nothing to do with motor.
Your jar will cool down with time. lf motor is getting hot you can feel hot air coming out of
the side vent or bottom. Switch OFF motor and restart after 10 minutes.
16. Do not use mixer on wet surface.
17. Do not run mixer for more than 5 minutes continuously. Give a gap of 2 minutes if you need
to use for more time.
18. Keep mixer away from hot gas burner electric hot plate or similar appliances.
19. lt is normal for the Mixer Grinder to get a little discoloured especially when used with item
like turmeric, to avoid this make sure that item like turmeric do not come in contact with the
Mixer Grinder body
20. This appliance is strictly for household use.
21. Do not drop the main unit or Jars.
22. Never use accessories or parts which are not recommended or made by other manufacturers
23. Do not use the jars as storage containers.
24. Do not leave unit unattended while in operation.
25. Caution : Always hold the Jar lid gently with your hand while the mixer is in operation.
Basic Unit
Stainless Steel Jar
Speed Switch
with pulse
Jar Socket
Suction Feet
Note: In view of USHA policy of continual development, specications may change without notice.
Images are used for representation only.
3 4

IDENTIFICATION OF PARTS OPERATING INSTRUCTIONS
BASIC UNIT
IDENTIFICATION OF PARTS
Basic Unit
1. A mixer grinder with 3 Jars :
Wet Jar, Dry Jar, Chutney Jar.
2. Basic unit: Containing the
motor, speed switch, mains
cord, overload protector
switch.
3. Speed selector knob: for
dierent speed adjustment.
4. Anti slip rubber feet.
5. Wet grinding jar: suitable for
liquidizing.
6. Dry grinding jar: suitable for
dry grinding.
7. Chutney grinding jar:
suitable for small quantity
grinding such as chutney,
pepper, dry masala, coee
beans.
8. Spatula: used as a spanner
for assembly/disassembly of
blade.
USING THE PRODUCT
1. How to t the blades - Hold the coupler on the underside of the jar and with the spanner,
tighten by rotating in anti-clockwise direction till the blade is securely locked. Follow the
same procedure for the other jars.
2. How to t jar to basic unit - Carefully insert the jar on top of the basic unit. Ensure that lock of
the jar ts the slot of the basic unit. Rotate the jar clockwise until it locks. ln case of the Wet &
Dry jar, use the handle to lock.
OPERATION
1. Before the rst use or starting after long time. Thoroughly clean parts that come in contact
with food.
2. Preparation for use : Cool the hot ingredients before putting in jar.
• Cut large ingredients into small pieces of approx. 2 cm before processing
• Please rotate the motor shaft by hand through the motor coupler. The motor shaft should
be free to rotate. Check speed selector is in OFF position. Connect mains plug to wall socket
after xing jar with main unit. Switch on main supply & turn selector knob to required
position and speed. After operation, turn selector knob OFF and check. Repeat till desired
results are obtained.
1
2
Note : The product illustrated/ photographed in this manual may vary from the actual product
3
4
8
5
67
P
U
L
S
E
P
U
L
S
E
5 6

Model Name / Model No. MAXIQUICK / MQ500M13
500 W
Power consumption No load 21 000 (+ - 1 000) rpm approx. on 3rd speed
Full Load 12 000 rpm approx. on 3rd speed
Voltage and frequency 230 V AC / 50 Hz - 60 Hz (working range)
Insulation F class overall insulation
Rating 30 Minutes rating (5 Minutes ON, 2 Minutes OFF)
Material of body ABS
Material of jars Stainless steel
Blade assembly Stainless steel
Speed control 3 speed with pulse
Power cord 3 Pin plug & 3 core exible PVC cord
Country of origin India
• For blending / liquidizing / pureeing use 'pulse' on speed knob. This will activate the
whipping till you release the button.
• Hold down the jar lid gently while your Mixer Grinder is in operation.
• After switching OFF the Mixer Grinder, wait till the blade stops rotating completely and only
then remove lid or put spatula in the jar.
• Before removing the jar, ensure that power supply is disconnected.
• Avoid using your hand for lling or cleaning out jars. lt is safe and more hygienic to use the
spatula.
• Avoid storing food in jar.
• Never place plastic or cloth under the mixer grinder it may block the ventilation holes.
OVERLOAD PROTECTION
Mixer is tted with an over load protector mechanism to avoid motor burning due to overloading.
ln case of excess loading of ingredients in the jar or very thick paste or low voltage conditions,
your USHA mixer grinder automatically switches o due to overloading and the Overload Switch
Lever at the bottom will come out. lf this happens, switch o your mixer grinder and then remove
the excess ingredients / add sucient water in case of thick paste and wait for 2-3 minutes. Press
the Lever and start mixer again.
TECHNICAL SPECIFICATIONSOPERATING INSTRUCTIONS
JAR RATED CAPACITY AND DIMENSION
Wet Jar 1.5 L
Dry Jar 1 L
Chutney Jar 400 mL
Dimension of base unit with wet jar 445 mm
Net Weight of the Product 3.0 kg
Note: The ambient working temperature range is from 10° C to 43° C
7 8

TECHNICAL SPECIFICATIONS
TROUBLESHOOTING
TROUBLE REASON CHECK POINTS
Mixer does not No power supply Check main supply
run Overloading of Remove some material and add in small quantities
material
Overload trip Press the overload trip button at the bottom
of mixie
Other than above Call USHA care 18001033111
mentioned
Motor cooling is Motor housing Use a dry brush to clean air-vents
not sucient air-vents blocked
Increase in mixing/ Overloading of Remove some material and add in small
blending time Material quantities
Unit overheating External heat source Check and remove if any heat source nearby
Uneven platform Place the blender on level surface
that block air-vents
Overloading of Material Remove some material and add in small quantities
Damaged Cord Physical damage It is advised that the cord be replaced by an USHA
authorised service technician
Care and Cleaning
To keep your USHA Mixer Grinder sparkling clean, just follow these steps.
1. First remove the mains plug from the electrical socket.
2. Clean the main unit using a damp/wet cloth, but do not use any abrasive cleaning materials.
3. Run the jar with water for a minute after each use to clean the residue.
4. Remove the jars after each use and wash the jars in soapy water.
5. Then rinse with clean water
6. Dry the parts thoroughly with a clean, soft cloth.
7. Always keep / store the jar up side down.
8. We recommend that you clean your USHA Mixer Grinder immediately after use for easier
removal of residue.
9. Do not immerse the base unit in water or any other liquid.
WARRANTY CARD
This appliance is warranted for 2 years for the product and 5 years for the motor against all
manufacturing defects from the date of sale. In the event of any complaint, please contact
USHA Care at: Toll Free No. 1800 1033 111.
The warranty is valid only when:
1. The appliance has been installed, used and maintained in accordance with the instruction
manual.
2. The warranty card and cash memo duly signed by the authorized dealer are presented with
the complaint.
3. The appliance has not been opened or tampered with, by any unauthorized person.
This warranty does not apply for:
1. Damages due to chipping, peeling, plating and denting.
2. Breakage or damage to components made out of Bakelite, Urea, ABS, SAN and such plastic
materials, rubber parts and cord.
3. Normal wear and tear of parts.
4. Damage resulting from accidents, mishandling or negligence on part of the customer.
Liability for consequential loss or damage is neither accepted nor implied.
S. No:___________________________ DATE:______________________________
CASH MEMO:__________________________
DEALER’S NAME AND ADDRESS:______________________________________________________
OWNER’S NAME & ADDRESS:_________________________________________________________
RECOMMENDED USAGE CAPACITY - JARS
Jar Type Actual Recommended Jar Capacity
Capacity Dry Grinding Wet Grinding Blending
150 g of
Wet Jar 1.5 L NA Urad Dal + 350 mL 500 mL
water
150 g 100 g
Multiprupose 1 L Turmeric/ of Urad Dal + 300 mL
Jar Spice Grinding 225 mL water
Chutney / 400 mL
50 g Turmeric/ 100 g of NA
Small Jar Spice Grinding Coconut/Onion
9 10
