INSTRUCTION MANUAL
MIXER GRINDER
Model: MG 3563, 3576, 3775

Introduction
Dear Customer,
Congratulations!
Thank you for buying USHA mixer grinder, the powerful Mixer Grinder to
make your cooking much more easier now. Your USHA Mixer Grinder is
perfect for frequent Mixing, Blending and Tough Grinding.
USHAMixer Grinder has been carefully manufactured, tested and packaged.
Please read the instructions in this manual carefully, before use.
Bon Appetite !

1. A mixer grinder with 3 steel jars: wet, dry and chutney, and 1 blender jar with
fruit filter (Only for MG 3775).
2. Basic unit: Containing the motor, speed switch, mains cord, overload protector and switch.
3. Guide for jar lock: to aid in locking of jar on basic unit.
4. Speed selector knob: for different speed adjustment.
5. Anti slip rubber feet.
6. Overload protection switch.
7. Wet grinding jar: Suitable for liquidizing and blending.
8. Dry grinding jar: for dry grinding.
9. Chutney grinding jar: for small quantity
grinding such as chutney, pepper, dry masala,
coffee beans.
10. Blender jar with fruit filter : for juicing and
blending (Only for MG 3775).
11. Grind & Store Jar with Lid.
12. Dry and chutney grinding blade: Detachable.
13. Wet grinding blade: Detachable.
14. Blender jar blade (Only for MG 3775).
Motor
Rating
Power Consumption
Voltage & Frequency
Insulation
Material of body
Material of Jars
Blade Assembly
Speed Control
Power Cable
Country of Origin
750 Watt motor for MG 3576 & MG 3775
600 Watt motor for MG 3563
No load 21000 (+/-1000)rpm approx. on 3rd Speed
On Load 11500 rpm approx. on 3rd Speed
30 mintues rating
5 mintutes ON & 2 minutes OFF ( 6 cycle )
750 Watt motor for MG 3576 & MG 3775
600 Watt for MG 3563
230V AC, 50 Hz
F class overall insulation
ABS
Stainless Steel & Polycarbonate (blender Jar)
Stainless Steel
3 speed with whip
3 Pin Plug & 3 core flexible PVC cord
India
Technical Specification
13
14
GENERAL DESCRIPTION
1211

Wet Jar
Dry Jar
Chutney Jar
Dimension
Net Wt. of product
with jar
Jar Rated Capacity & Dimension
Note: The Ambient working temperature range is from 10°C to 43°C
SAFETY AND IMPORTANT INSTRUCTIONS
We recommend that you read the following instructions carefully, before using
the appliance.
1. Check if the voltage indicated on the base of the appliance, corresponds
to the local electrical mains voltage before you connect the appliance.
2. Do not use the appliance when the main cord, the plug or other
components are damaged.
3. Always unplug the appliance after use.
4. Never immerse the motor unit in water or any other liquid. Do not rinse it
either.
5. Always unplug the appliance before reaching in to the jar with your
fingers or an object e.g. spatula.
6. The appliance is not to be used by children or persons with reduced
physical, sensory or mental capabilities, or lack of experience and
knowledge unless they have been given supervision or instruction as per
applicable safety requirements by a person responsible for their safety.
7. Children should be supervised not to play with the appliance.
8. Always ensure that speed selector knob is at 'OFF' position before fixing
accessories.
9. Blades should be fitted properly before running the mixer grinder.
10. Do not operate the mixer without the dome or lid in place or with an
empty jar.
11. Do not open the lid or dome when the mixer is running. Do not add solid
ingredients when mixer is running.
12. Do not grind hot ingredients in your mixer grinder.
13. Do not overload the grinder.
14. Handle the blades carefully. Wash them under running water and do not
rub by hand.
Note: Images are only for reference, Actual product may vary.
Actual Capacity
1.5 L
1.0 L
0.5 L
Dia -225mm X Height 227mm (Only machine)
MG 3775 - 4.2 kg
MG 3576 - 4.2 kg
MG 3563 - 4.2 kg

15. In dry grinding, the jar may get heated up due to friction- The is nothing to do with motor.
Your jar will cool down with time. If motor is getting hot you can feel hot air coming out of
the side vent or bottom. Switch OFF motor and restart after 10 minutes.
16. Do not use mixer on wet surface.
17. Do not run mixer for more than 5 minutes continuously. Give a gap of 2
minutes of you need to use for more time.
18. Keep mixer away from hot gas burner electric hot plate or similar
appliances.
19. It is normal for the mixer grinder to get a little discolored especially when
used with item like turmeric, to avoid this make sure that item like
turmeric do not come in contact with the mixer grinder body.
20. The appliance is strictly for household use.
21. Do not drop the main unit or jars.
• Never use accessories or parts which are not recommended or made by other
manufactures.
• Do not use the jars as storage containers.
24. Do not leave unit unattended while in operation.
CORD PLACEMENT
INSTRUCTIONS
For replacement of the cord: make sure the appliance is unplugged, open the bottom, replace
the cord and close the bottom. It is advised that the cord is replaced by an authorized service
person.
USING THE PRODUCT
1. How to fit the blades - Hold the coupler on the underside of the jar and
with the spanner; tighten by rotating in anti-clockwise direction till the
blade is securely locked. Repeat procedure for the other jars.
2. How to fit jar to basic unit - carefully insert the jar on top of the basic
unit. Ensure that lock of the jar fits the slot of the basic unit. Rotate the
jar clockwise until it locks. In case of the wet jar, use the handle to lock.
OPERATION
1. Before the first use or starting after long time. Thoroughly clean parts that come in
contact with food.
2. Preparation for use.
• Cool the hot ingredients before putting in jar.
• Cut large ingredients into small pieces of approx. 2cm
before processing.

• Please rotate the motor shaft by hand through the motor coupler. The
Motor shaft should be free to rotate. Check speed selector is in OFF
Position. Connect mains plug to wall socket after fixing jar. Switch on
main Supply & turn selector knob to required position and speed. After
operation, turn selector knob OFF and check. Repeat till desired results
are obtained.
• For blending / liquidizing / pureeing use 'whip 'on speed knob. This will
activate the whipping till you release the button.
• Hold down the Jar lid gently while your Mixer Grinder is in operation.
• After switching OFF the Mixer Grinder, wait till the blade stops rotating
completely and only then remove lid or put in the spatula.
• Before removing the jar, ensure that power supply is disconnected.
• Avoid using your hand for filling or cleaning out jars. It is safe and more hygienic to use
the spatula.
• Avoid storing food in Jar.
• Never place plastic or cloth under the mixer grinder it may block the ventilation holes.
HOW TO USE BLENDER / MIXER JAR
(Only for MG 3775).
Hold blender / mixer jar and check if the blade assembly moves
freely and rotates.
Put ingredients into blender / mixer jar and lock jar cover. Place
jar on basic unit and turn the lower socket clockwise to lock with
the body lock. Plug in and choose appropriate speed for mixing.
It is advisable to start the mixer at the lower speed (position 1)
and step on to higher speeds (position 2, 3).
For whipping frothy lassi and milk shakes use the 'pulse' switch after blending is done. After
using, switch off and remove blender / mixer jar. Remove ingredients.
USES
1. Whipping lassi, frothy cold coffee, fluffy omelette, fresh cream, butter churning and
mayonnaise.
2. For making chutneys.
3. Juicing in Blender jar with Fruit filter. Recommended for juicing for grapes,
watermelon, muskmelon, sweet lime, oranges, anar, lichi, tomatoes.
4. Liquidising for fruit juice, soups, milk shakes with fresh fruits etc.
SPECIAL INSTRUCTIONS FOR USING FRUIT FILTER.
1. Place the fruit filter inside the blender jar such that its four clots fit into the four ribs
inside the blending jar.
2. Press it down so that it is fixed properly.
3. Fruits should be cut into small pieces before putting inside the fruit filter for extracting
juice.
4. Close the jar lid.
5. Initially use low speed and then
speed can be increased.
6. After juicing is done, pour the
contents into a glass.

HOW TO USE GRIND AND STORE JAR
The Grind and Store jar has been designed to help you prepare and store freshly ground
ingredients with minimum mess.
The Grind and store jar can be used to prepare and store chutneys, spices , etc..
You may use the chutney jar with the chutney jar lid or with the Store jar as lid over chutney jar
as per your convenience for complete action in one go.
1. Put the Ingredients to be ground into the Store Jar.
2. Push fit the Chutney Jar on top on Store Jar till it is properly locked.
3. Invert the assembly and place it on top of the mixer till its properly locked .
4. Grind on Speed 1 only.
• Never grind for more than 1 minute continuously. If you need to grind for more than 1
minute, please stop the mixer or 1 minute and then grind again.
• Continuous grinding for more than a minute will generate excessive heat which might
cause the store jar to warp out of shape.
5. After Grinding, remove the complete assembly from the mixer by holding the mixer base
and twisting the assembly anticlockwise and lifting off the mixer top.
6. Allow the contents to cool for some time.
7. Now invert the assembly till all the contents get transferred from the Chutney jar into the
Store jar.
8. Hold the Store jar firmly and gently pull the chutney jar assembly once all the contents are
transferred.
9. Now place the Store jar lid firmly on top of the Store jar to seal it and store the ready
ingredients happily.
Note:
Never leave the chutney jar base alone on the mixer
Never operate unless the store jar is properly locked on the base.

OVERLOAD PROTECTION
Mixer is fitted with an over load protector off mechanism to avoid motor burning due to
overloading.
In case of excess loading of ingredients in the jar or very thick paste or low voltage conditions,
your USHA mixer grinder automatically switches off due to overloading and the red knob at
the bottom will come out. If this happens, switch off your mixer grinder and then remove the
excess ingredients / add sufficient water in case of thick paste and wait for 2-3 minutes. Press
red knob and start mixer again.
CLEANING AND MAINTENANCE
To keep your USHA Mixer Grinder sparkling clean, just follow these steps.
1. First remove the mains plug from the electrical socket.
2. Clean the main unit using a damp/wet cloth, but do not use any abrasive cleaning
materials.
3. Run the jar with water for a minute after each use to clean the residue.
4. Remove the jars after each use and wash the Jars in soapy water.
5. Then rinse with clean water
6. Dry the parts thoroughly with a clean, soft cloth.
7. Always keep/store the jar up side down.
8. We recommend you clean your USHA Mixer Grinder immediately after use for easier
removal of residue.
9. Do not immerse the base unit in water or any other liquid.
HOW TO CLEAN BLENDER / MIXER JAR
1. Empty the contents of the jar.
2. Place the jar assembly on the basic unit.
3. Fill about 500 ml of lukewarm water and add little mild detergent
(do not use abrasive cleaning powders since these will scratch the
jar) and put on cover and stopper. Switch on the motor and run it at
the lowest speed 1 for about 30 seconds.
4. Pour out the contents. Rinse with plain water. After cleaning keep
the jar up-side down while not in use.
5. Wipe the lower socket, rubber gaskets and the cutter assembly
using a wet cloth, then wipe with a dry cloth.
6. Finally, after disconnecting the unit from the mains, clean the body
with a damp cloth & polish with a dry cloth.

TROUBLESHOOTING CHART
Trouble Reason Check
Mixie does not run
Increase in Mixing/
blending time
Unit overheating
No power supply
Overloading of Material
Overload trip
Other than above
mentioned
Motor cooling is not
sufficient
Overloading of Material
external heat source
uneven platform that
blocks airvents
Overloading of Material
Check main supply
Remove some material and add in
small quantities
Press the Overload trip button at the
bottom of Mixie
Call USHA care 18001033111
Motor housing airvents blocked and
use a dry brush to clean air vents
Remove some material and add in
small quantities
check and remove if any heat source
nearby
place the blender on level surface
Remove some material and add in
small quantities

NOTES

WARRANTY CARD
This appliance is warranted for two year for the machine and five years for the motor against
all manufacturing defects from the date of sale. In the event of any complaint contact the
nearest company service Centre or call our toll free number 1800 1033 111.
THIS WARRANTY IS VALID ONLY WHEN
1. The appliance has not been opened or tampered with, by any unauthorized person.
2. The warranty card or cash memo duly signed by the authorized dealer is presented with
the complaint.
3. The appliance has been installed, used and maintained in accordance with the
instruction manual.
THIS WARRANTY DOES NOT APPLY FOR
1. Damages due to chipping, peeling, plating and denting.
2. Breakage or damage to components made out of Bakelite, urea, abs, san, and such
plastic, materials, rubber parts and cord.
3. Normal wear and tear of the parts of the appliance.
4. Damage resulting from accidents, mishandling or negligence on part of the customer.
Liability for consequential loss or damage is neither accepted nor implied
S.NO:
CASH MEMO: DATE:
DEALER'S NAME AND ADDRESS:
OWNER'S NAME
