UT MyMovie MV3800 User manual

- 1 -
MV3800 MyMovie HD Media Recorder
User’s Guide

- 2 -
Table of Contents
Chapter 1
1.1.0 : Introduction............................................................................................................ 5
1.2.0 : Features Highlight ................................................................................................... 5
1.3.0 : Specifications.......................................................................................................... 5
1.3.1 : I/O Interfaces Supported.............................................................................. 5
1.3.2 : File System Supported.................................................................................. 6
1.3.3 : Content Formats Supported........................................................................... 6
1.3.4 : Video Codecs Supported............................................................................... 6
1.3.5 : Audio Codecs Supported............................................................................... 6
1.3.6 : Subtitle Formats Supported........................................................................... 6
1.3.7 : Network Feature .......................................................................................... 6
1.3.8 : Description for details................................................................................... 7
1.3.9 : Video Recording Mode.................................................................................. 7
1.4.0 : Contents of box....................................................................................................... 8
1.5.0 : Functionality........................................................................................................... 8
1.5.1 : A/V Output.................................................................................................. 8
1.5.2 : Multimedia Playback..................................................................................... 8
1.5.3 : DVB-T TV.................................................................................................... 8
1.5.4 : Video Recording........................................................................................... 8
1.5.5 : Network Feature.......................................................................................... 8
1.5.6 : File Copy..................................................................................................... 8
1.5.7 : USB 2.0 Support .......................................................................................... 9
1.6.0 : Packaging List......................................................................................................... 9
1.7.0 : Cautions................................................................................................................. 9
1.7.1 : Usage Cautions............................................................................................ 9
1.7.2 : Power......................................................................................................... 9
1.7.3 : Radio Interference........................................................................................ 9
1.7.4 : Repair........................................................................................................10
1.7.5 : Disposing of the Player................................................................................10
1.7.6 : Hard Disk Cautions......................................................................................10
1.7.7 : Others .......................................................................................................10
1.8.0 Connection ..............................................................................................................11
1.8.1 : Connecting the power supply .......................................................................11
1.8.2 : Connecting to a PC......................................................................................11
1.8.3 : Connecting a USB Device.............................................................................11
1.8.4 : Connecting a Memory Card ..........................................................................12
1.8.5 : Connecting to a TV .....................................................................................12
1.8.6 : Connecting to an Digital Amplifier.................................................................14
1.8.7 : Connecting to a LAN....................................................................................14
1.8.8 : Connecting to a WLAN.................................................................................15
1.9.0 : Power ON/OFF.......................................................................................................15
1.9.1 : Power ON ..................................................................................................15
1.9.2 : Power OFF .................................................................................................15
1.10.0 : Menu Language....................................................................................................15

- 3 -
Chapter 2
2.1.0 : About the Player.....................................................................................................16
2.1.1 : Remote Control...........................................................................................16
2.1.2 : Front Panel.................................................................................................19
2.1.3 : Rear Panel .................................................................................................19
Chapter 3
3.1.0 : Setup menu...........................................................................................................20
3.2.0 : Changing TV Settings..............................................................................................21
3.3.0 : Changing Audio Settings..........................................................................................23
3.3.1 : Night Mode ................................................................................................23
3.3.2 : Digital Output.............................................................................................23
3.4.0 : Changing Video Setting...........................................................................................24
3.4.1 : Aspect Ratio...............................................................................................24
3.4.2 : Brightness..................................................................................................24
3.4.3 : Contrast.....................................................................................................24
3.4.4 : TV System..................................................................................................24
3.5.0 : Changing Record Settings........................................................................................25
3.6.0 : Changing Network Settings......................................................................................27
3.6.1 : Wired LAN Setup.........................................................................................27
3.6.2 : Wireless Setup............................................................................................27
3.6.3 : Test Connection..........................................................................................29
3.6.4 : Peer to Peer (Ad Hoc)..................................................................................29
3.7.0 : Changing System Settings........................................................................................30
3.7.1 : Menu Language ..........................................................................................30
3.7.2 : Text Encoding.............................................................................................30
3.7.3 : Login Control..............................................................................................30
3.7.4 : System Info................................................................................................30
3.7.5 : System Update............................................................................................31
3.7.6 : HDD Format ...............................................................................................32
3.7.7 : System Info................................................................................................33
3.7.8 : Restore Default...........................................................................................33
3.8.0 : Miscellaneous.........................................................................................................34
3.8.1 : Slide Show Timing.......................................................................................34
3.8.2 : Transition Effect..........................................................................................34
3.8.3 : Background Music.......................................................................................34
3.8.4 : Screen Saver..............................................................................................34
3.8.5 : Movie Preview ............................................................................................34
3.8.6 : Resume Playback........................................................................................34
Chapter 4
4.1.0 : Browser Menu........................................................................................................35
4.1.1 : Browsing All ...............................................................................................36
4.1.2 : Browsing Music...........................................................................................36
4.1.3 : Browsing Photos.........................................................................................37
4.1.4 : Browsing Movies.........................................................................................37
4.1.5 : A/V Streaming via Network ..........................................................................38
4.1.6 : Browsing through Workgroup.......................................................................39
4.1.7 : Browsing trhough ‘My_Shortcuts’..................................................................39

- 4 -
4.2.0 : A/V Streaming via UPnP-Server................................................................................40
4.2.1 : Installing UPnP Media Server on your PC .......................................................40
4.2.2 : Sharing Media on your PC............................................................................41
4.2.3 : Streaming Media on your Player ...................................................................42
4.3.0 : Renaming / Deleting Files........................................................................................43
4.4.0 : Managing the Playlist..............................................................................................43
4.4.1 : Adding files to the Playlist............................................................................43
4.4.2 : Browsing the Playlist ...................................................................................44
Chapter 5
5.1.0 : File Copy Menu ......................................................................................................45
5.1.1 : Station.......................................................................................................46
5.1.2 : Genre........................................................................................................46
5.1.3 : Favorite .....................................................................................................46
Chapter 6
6.1.0 : Selecting Time REC.................................................................................................47
6.1.1 : Watching TV...............................................................................................47
6.1.2 : Watching DVB-T TV Programs.......................................................................47
6.1.3 : Program List Menu......................................................................................47
6.1.4 : Info Bar.....................................................................................................48
6.1.5 : Electronic Programming Guide......................................................................49
6.1.6 : Teletext Menu.............................................................................................49
6.1.7 : Subtitle List Menu .......................................................................................49
Chapter 7
7.1.0 : Timer Record Menu.................................................................................................50
7.1.1 : Creating a New Schedule .............................................................................50
7.1.2 : Editing Schedules........................................................................................51
7.1.3 : Deleting Schedules......................................................................................51
7.1.4 : Viewing Schedule Status ..............................................................................52
7.1.5 : Viewing Recording History............................................................................53
7.1.6 : The REC List...............................................................................................54
Chapter 8
8.1.0 : Web Server & BitTorrent..........................................................................................55
8.1.1 : Web Server (unicgi) ....................................................................................55
8.2.0 : Account Management .............................................................................................56
8.3.0 : Visit Neighbor (samba)............................................................................................56
8.4.0 : BitTorrent Download (btpd) .....................................................................................57
8.4.1 : Add new torrent..........................................................................................57
8.4.2 : Managing the downloads .............................................................................58
8.4.3 : Settings .....................................................................................................58
Chapter 9
9.1.0 : Upgrading the firmware ..........................................................................................60
Frequently Asked Questions...........................................................................................................61
Copyrights and Trademarks ...........................................................................................................65
Limited Warranty Statement ..........................................................................................................66
FTP Software Management............................................................................................................67

- 5 -
Chapter: 1
1.1.0 : Introduction
Thank you very much for purchasing the MV3800 HD Media Recorder product. We hope you will enjoy using
it as a great home entertainment partner.
The MV3800 HD Media Players & Recorders are designed to enhance the consumer experience with
breathtaking movie quality of High-Definition (HD) video and crystal sound clarity of DTS and Digital Dolby
digital audio. Featuring full support of major media formats, MV3800, offers users a simple way to play their
HD 1080p digital content on any TV.
Instead of keeping shelves full of music CDs, DVDs and Blue Ray Discs movies, more and more people prefer
to build large personal collections of digital content on their desktop or laptop computers. The drawback is
they must use the computer to play these files. Their movie watching or music listening experience is
confined to small screen and small speakers of their computer system. With MV3800, users can simply play
the digital content directly from the pre-assembled internal HDD up to 2TB or from USB external storage
device in the comfort of their living room or bedroom. They are free from struggling with burning media files
onto DVDs or connecting the computer to the TV.
MV3800 also has recording feature of TV shows from the Cable or Satellite, or family videos from a
Camcorder. It provides an ideal setup archiving old VCR tapes and DVDs to digital media files. MV3800 even
supports time-shift and scheduled recording functionalities - making Live TV playback a snap
1.2.0 : Features Highlight
High definition 1080p movie
Crystal clear high definition audio
More video format supported
Build-in HDD
Media Streaming with UPNP
Record, store and playback
USB 2.0 Host ports
Internet Radio
Download Station
NAS
Multi language support
1.3.0 : Specifications
1.3.1 : I/O INTERFACES SUPORTED:
3.5’’ SATA HDD
USB 2.0 HOST port x 2 (compatible to USB 1.1)
Memory Card slot (supports SD/MMC/MS Pro)
USB 2.0 DEVICE port (connecting to PC)

- 6 -
Composite (CVBS) A/V jack
Component Y/Pb/Pr jack
HDMI V1.3 interface
S/PDIF coaxial & optical jack
DC-IN 12V
1.3.2 : FILE SYSTEM SURPORTED:
FAT/FAT32/NTFS/EXT3
1.3.3 : CONTENT FORMATS SUPPORTED:
AVI/MKV/TS/TP/TRP/M2TS/MPG/MP4/MOV/M4V/VOB/ISO/IFO/DAT/WMV/ASF/RM/
RMVB/FLV, resolution up to 720p/1080i/1080p
MP3/OGG/WMA/WAV/AAC/FLAC
HD JPEG/BMP/GIF/TIF/PNG
1.3.4 : VIDEO CODECS SURPORTED:
MPEG-1
HD MPEG-2
HD MPEG-4 SP/ASP/AVC (H.264)
WMV9 (VC-1)
RealNetworks (RM/RMVB) 8/9/10, up to 720p
1.3.5 : AUDIO CODECS SURPORTED:
MP2/3, OGG Vorbis, WMA (DRM, and Advanced Profile not supported), PCM, LPCM, MS-ADPCM,
LC-AAC, HE-AAC, COOK, RA-Lossless
1.3.6 : SUBTITLE FORMATS SURPORTED:
SRT, SMI, SSA, ASS, IDX/SUB, SUB
1.3.7 : NETWORK FEATURE
10/100Mbps Auto-Negotiation Ethernet
802.11b/g/n WLAN, up to 300Mbps (supported by optional WLAN USB Adapter)
Record Format (AV in)
Video/DVB-T Rec.
Recorded Format: MPG
DVB-T Record format : TS
Resolution:720x576@25fps(PAL),720x480@30fps(NTSC)
In AV in model :5 adjustable quality level: HQ/SP/LP/EP/SLP
Support TV system: NTSC/PAL/SECAM
Audio Rec.
MP3(.mp3)
2 Channel: 16KHz,32Kbps24KHz,64Kbps32JHz,96Kbps
Hardware

- 7 -
Video Input
CVBS
Video Output interface
HDMI, CVBS, Y/Pb/Pr(up to 720p/1080i)
Audio Output interface
Analog Stereo (L/R), S/PDIF, COAXIAL
USB 2.0 plug
1. USB Device*1
2. USB Host*2
Ethernet
Wired: 10M/100M
Wireless: WI-FI(Optional)
DVB-T tunner
1. support digital MPEG4 ,H.264 DVB-T signal.
2. support 6MHZ, 7MHZ, 8MHZ channel DVB-T signal.
3. support Electronic Program Guide function (EPG)
4. Support TV progrem TTX function.
Card Reader
SD/MMC/MS
Storage format
Build-in 3.5”SATA HDD hard disk, 20G-1.5T.
FAT32 AND NTFS ,EXT3 partial
Support external SD/MMC/MS card
Support USB Storage
Voltage
power adapter:
input:100～240V AC 50/60HZ, output:12V/3A
Dimension
190(H)*173(D)*65mm(W)
Language
English, Traditional Chinese, Japanese, Spanish, French, German, Italian, Korean,
Dutch, Russian, Simple Chinese...
1.3.8 : Description for details:
AVI
NTSC
PAL
G/Hour
HQ
4.945Mbps,720*480,30fbs
4.945Mbps,720*576,25fbs
2G
SP
3.428Mbps,720*480,30fbs
3.428Mbps,720*576,25fbs
1.5G
LP
2.528Mbps,720*480,30fbs
2.528Mbps,720*576,25fbs
1G
EP
1.691Mbps,352*240,30fbs
1.691Mbps,352*288,25fbs
0.7G
SLP
1.268Mbps,352*240,30fbs
1.268Mbps,352*288,25fbs
0.5G
1.3.9 : VIDEO RECORDING MODE
Mode DVD 80 GB HDD 120 GB HDD160 GBHDD
HQ 1hr 16hrs 24hrs 33hrs
SP 2hrs 32hrs 48hrs 66hrs
LP 3hrs 48hrs 72hrs 99hrs
EP 4hrs 64hrs 96hrs 132hrs
SLP 6hrs 96hrs 144hrs 198hrs
Note: The specifications and design of this product are subject to change without notice.

- 8 -
1.4.0 Contents of box
MV3800 HD Media Recorder
Remote Control with Batteriese
Quick Installation Guide
Component AV Cables
Composite AV Cables
Power Adapter
HDMI Cable (optional)
Wireless N dongle (optional)
Note:
The actual contents in the package might be different from the packing list in this manual.
1.5.0 Functionality
This MV3800 HD Media Recorder has the following functionality.
1.5.1 : A/V Output
HDMI V1.3 for high-definition video and digital audio
Composite & component video and stereo audio for analog audio-visual connection
S/PDIF coaxial & optical interface for high-fidelity digital audio
Adjustable video output resolution (NTSC, PAL, 480p, 576p, 720p, 1080i, 1080p)
1.5.2 : Multimedia Playback
Supports major audio, video and image file formats (1080p HD video decoding)
Movie format: AVI/MKV/TS/TP/TRP/M2TS/MPG/MP4/M4V/MOV/VOB/ISO/IFO/DAT/
WMV/ASF/RM/RMVB/FLV
Music format: MP3/OGG/WMA/WAV/AAC/FLAC
Photo format: HD JPEG/BMP/GIF/TIF/PNG
Photo slide show with background music
1.5.3 : DVB-T TV
supports Digital Video Broadcasting Terrestrial (DVB-T) TV reception
supports Electronic Program Guide (EPG), Teletext and subtitle.
1.5.4 : Video Recording
supports one button recording and scheduled recording, can easily record programs from
DVB-T TV, DVD player, DV, etc., and save as MPEG-2 (.mpg, or .ts) format;
supports time shifting function
1.5.5 : Network Feature
A/V streaming/transmission via Ethernet (10M/100M) & Wi-Fi (802.11b/g/n, optional)
File sharing via Samba server
A/V streaming via UPnP Media Server
BitTorrent download (controlled and managed via web server)
Digital Radio (SHOUTcast) 3 / 63
1.5.6 : File Copy
Supports copying & moving files among Card, USB, HDD, and Network

- 9 -
1.5.7 : USB 2.0 Support
USB DEVICE port (for computer connection)
USB HOST port x 2 (for USB storage devices)
Note: All the information contained in this manual was correct at the time of publication. However, as our
engineers are always updating and improving the product, your device‟s software may have a slightly
different appearance or modified functionality than presented in this manual.
1.6.0 Packing List
Part
Quantity
MV3800 recorder
1
A/V cable
2
USB cable
1
Remote Control
1
Remote Control Battery
2
AC/DC wall-mounted adaptor
1
US plug - UK plug convertor
1
User Manual
1
Y/Pb/Pr cable
1
DVB-T antenna
1
HDMI cable
1
1.7.0 Cautions
This player‟s design and manufacture has your safety in mind. In order to safely and effectively use this
player, please read the following before usage.
1.7.1 : Usage Cautions
User should not modify this player. If commercial hard disk is being used, the environmental temperature
should be within +5℃~ +35℃.
1.7.2 : Power
The player’s power voltage: DC 12V. When using this player, please connect the supplied AC adapter or AC
adapter cable to the player’s power jack. When placing the adapter cable, make sure it cannot get damaged
or be subject to pressure. To reduce the risk of electric shock, unplug the adapter first before cleaning it.
Never connect the adapter to the player in a humid or dusty area. Do not replace the adapter or cable’s wire
or connector.
1.7.3 : Radio Interference
If not properly shielded, almost all electronic devices will get radio interference. Under some conditions,
your player might get interference. The design of this player has followed the FCC/CE standard, and has
followed the following rules:
(1) This player may not cause harmful interference;
(2) This player could accept some interference received including interference that may cause
undesired operation.

- 10 -
1.7.4 : Repair
If the player has a problem, you should take it to an appointed repair center and let the specialists do the
repair, never repair the player yourself, you might damage the player or endanger yourself or your data.
1.7.5 : Disposing of the Player
When you dispose of the player, be sure to dispose it appropriately. Some countries may regulate disposal of
electrical device, please consult with your local authority.
1.7.6 : Hard Disk Cautions
The player uses an internal hard disk for data storage, in normal case, format or repair is not required.
You should carefully read the < Frequently Asked Questions > chapter, and check our website for latest
information before formatting the hard disk.
Physical impact may create bad sector in the hard disk, you can use CHKDSK to fix the problem.
All data stored in the player may be lost due to physical impact, electrical shock, power lost, HDD
format etc. Please backup your data.
It is suggested to do defragment after a long period of usage.
Regularly backup the data in the hard disk so that it can be recovered in the event of data
corruption or loss. Our company takes no responsibility for loss of data stored on the hard disk.
1.7.7 : Others
When using this player, please do not let the player come into contact with water or other liquid, if water is
accidentally spilled on the player, please use a dry cloth to absorb the spillage.
Electronic products are vulnerable, when using please avoid shaking or hitting the player, and do not press
the buttons too hard.
Do not let the player come into contact with water or other liquid.
Do not disassemble the player, repair the player or change the design of the player, any damage
done will not be included in the repair policy.
Do not press the buttons of the player too hard.
Avoid hitting the player with hard object, avoid shaking the player, and stay away from magnetic
fields.
During electrostatic discharge and the strong electromagnetic field, the product will malfunction,
then unplug the power cable and the product will return to normal performance next time it is
powered on.

- 11 -
1.8.0 : Connection
1.8.1 : Connecting the Power Supply
(1) Follow the picture and connect the AC adaptor to the player’s DC IN jack;
(2) Follow the picture and plug in the AC adaptor to the power outlet.
1.8.2 : Connecting to a PC
(1) Make sure the player is powered on;
(2) Plug in the squarish connector of the USB cable to this player’s USB DEVICE port;
(3) Plug in the rectangular connector of the USB cable to computer.
In this way, you can manage content on the built-in HDD of the player on your local PC.
1.8.3 : Connecting a USB Device
(1) Make sure the player is powered on;
(2) Plug in the USB stick or USB HDD etc. to the USB HOST port of this player.
In this way, you can browse contents on the USB device.

- 12 -
1.8.4 : Connecting a Memory Card
Memory card can be used by inserting to the card slot
(1) Follow the picture to insert the memory card to the card slot properly;
(2) Insert the card by following the arrow pointer in the picture.
In this way, you can browse contents on the memory card.
1.8.5 : Connecting to a TV
A/V OUT
(1) Follow the picture and plug in the 3 color connector to the player’s A/V OUT jack;
(2) Follow the picture and plug in the 3 color connector to the TV’s A/V IN jack.
In this way, you can enjoy the content in the player on TV or other display devices.

- 13 -
Y/Pb/Pr Component OUT
(1) Follow the picture and plug in the 3 color connector to the player’s Y/Pb/Pr jack;
(2) Follow the picture and plug in the 3 color connector to the TV’s Y/Pb/Pr jack.
Audio Connection while using Y/Pb/Pr Video out:
First method: use the audio output from the A/V OUT jack;
Second method: use the audio output from the S/PDIF Coaxial or Optical jack.
In this way, you can also enjoy videos, music, and photos in the player on TV.
HDMI OUT
(1) Follow the picture and plug one connector on your HDMI cable to the player’s HDMI jack;
(2) Follow the picture and plug the other connector on your HDMI cable to the TV’s HDMI jack. Note: The
HDMI cable is an optional accessory sold separately.
In this way, you can have the highest quality video and audio via a single cable.

- 14 -
1.8.6 : Connecting to an Digital Amplifier
(1) Follow the picture and plug in the RCA connector on your coaxial cable to the player’s S/PDIF Coaxial
jack. Or if you use optical fiber, please plug in the Toslink connector on your optical fiber to the player’s
S/PDIF Optical jack;
(2) Follow the picture and plug in the other connector on your coaxial cable or optical fiber to the digital
audio device (digital amplifier or decoder).
Note: Optical fiber and coaxial cable are not supplied.
In this way, you can enjoy powerful Dolby Digital, DTS, or MPEG sound. (Please refer to ‘3.2 Changing
Audio Settings’ for configuration)
1.8.7 : Connecting to a LAN
To connect to a LAN (Local Area Network) you require a cat5, cat5e or cat6 network cable (not supplied).
(1) Connect one of the crystal plugs on the cable to the player’s RJ45 LAN socket;
(2) Connect the other crystal plug on the cable to a RJ45 LAN port on your router, switch, or hub devices.

- 15 -
1.8.8 : Connecting to a WLAN
(1) Make sure the player is powered on;
(2) Plug the Wireless LAN USB Adapter (i.e. Wi-Fi USB Dongle) to the USB HOST port of the player.
Note: The Wi-Fi Dongle is an optional accessory sold separately. (Please refer to ‘Changing Network
Settings’ for more details about wireless setup)
1.9.0 : Power On / Off
1.9.1 : Power On
After connecting the DC IN jack and press the power button on the front panel, the player will soon enter the
home screen, and the power indicator will turn blue.
1.9.2 : Power Off
Press the power button on the front panel, the player will soon enter standby mode, and the power indicator
will turn red. Then unplug the power cord to cut off the power supply.
1.10.0 : Menu Language
The system language of this player can be set to English or other languages. Change the language you wish
in the setup menu, the selected language will take effect immediately.

- 16 -
Chapter: 2
2.1.0 : About the Player
2.1.1 : Remote Control
All procedures in this manual can be carried out using the remote control buttons.
See the following for details on each button and its function:
Remark: EPG, TELETEXT, SOURCE button only available in DTV model
1.POWER
2.EPG
3. CONFIRM
4. TELETEXT
5. SELECT
6. TITLE
7. OPTION
8. EJECT
9. MENU
10. Numeric buttons
11. ZOOM
12. GOTO
13.DISPLAY
14. GUIDE
15. Navigational buttons
16.OK
17. REC
18. RETURN
19. VOL-
20. VOL+
21. FR
22. FF
23. STOP
24. PLAY
25. PREV
26. NEXT
27. SLOW
28. PAUSE/STEP
29.SOURCE
30. SUBTITLE
31.TIME SHIFT
32. REPEAT
33. SETUP
34.MUTE
35. TV SYSTEM
36.AUDIO
No.
Button
Function
1
POWER
Press to POWER on or off the AVHDD recorder.
2
EPG
Press to enter the Electronic Program Guide which displays an on-screen list of
programs for the coming week when watching Digital Terrestrial TV.

- 17 -
3
CONFIRM
Press to confirm and add the selects to the playlist.
4
TELETEXT
Press to open Teletext OSD if it is available in the broadcasted stream of Digital
Terrestrial TV.
5
SELECT
Press to select files in browser and file copy menu.
6
TITLE
Press to show HDD or DVD Title List.
7
OPTION
Press to select option bar.
8
EJECT
Press to eject a DVD from the DVD-ROM drive.
9
MENU
Press in the browser menu to rename and delete files.
Press in My_Shortcuts in NET of the browser menu to add
shortcuts for network access.
10
Numeric buttons
Press to enter numeric input when changing settings.
11
ZOOM
Press to zoom in/out when playing back photos or Video programs.
Photo zoom levels:2X,4X,8X,16X;
12
GOTO
Press to jump to a specific point on a title. Specify the point using Title,
Chapter and Time.
13
DISPLAY
Press to display current status.
Press during playback and an onscreen display appears, showing track number and
time elapsed/remaining.
Press during recording and an onscreen display appears, showing the recording quality
setting and time elapsed.
14
GUIDE
Press to view the Guide menu.
15
Navigational
buttons
Press the arrow buttons to select menu options
16
OK
Press the ENTER button to confirm.
17
REC
Press to begin recording or to resume when recording has been paused.
Press repeatedly to set OTR length (30 mins / 60 mins / 90 mins / 120 mins / 180 mins
/240 mins/Off).
18
RETURN
Press to return to the previous screen while navigating menus.
19
VOL-
Press to decrease the volume.
20
VOL+
Press to increase the volume.
21
FR
Press to fast rewind the current playback. Press repeatedly to select speeds.
22
FF
Press to fast forward the current playback. Press repeatedly to select speeds.
23
STOP
Press to stop playback.

- 18 -
24
PLAY
Press to begin playback.
25
PREV
Press to go the prev. on a HDD or USB file when playing music.
Press to page up the file list at Browser.
When play photo ,the button is enable; play Movie and Mp3 file, the button is disable.
26
NEXT
Press to go the next on a HDD or USB file when playing music.
Press to page down the file list at Browser.
When play photo ,the button is enable; play Movie and Mp3 file, the button is disable.
27
SLOW
Press to play back in slow motion. Press the PLAY button to resume regular
playback.
28
PAUSE/STEP
Press to pause the current playback. Press again to step to the next frame.
Press the PLAY button to resume playback.
29
SOURCE
Select the signal source from Video, DTV and Analog TV
30
SUBTITLE
Press to set subtitle options.
31
TIME SHIFT
Press to activate the timeshift function, which allows you to pause live TV and resume
the program from the point you left it. While paused, the program is recorded to the
HDD, as long as space is available.
Press to activate TIME SHIFT function and wait for the
PLAY arrow to appear on the screen.
Press and the program is paused.
Press to resume viewing the program.
Timeshift mode remains active until you press the button.
32
REPEAT
Press to set repeat option: One, All, (and Shuffle).
33
SETUP
Press to enter the setup menu.
34
MUTE
Press to mute audio output, and press again to resume.
35
TV SYSTEM
Press to switch between NTSC, PAL, 480P, 576P, 720P, 1080I, and 1080P.
36
AUDIO
Press to select an audio track.

- 19 -
2.1.2 : Front Panel
1. REC LED
2. DATA LED
3. Power LED
4. IR indicator
5. SD/MMC/MS/MS PRO SLOT
6.POWER ON/OFF
7.UP
8.DOWN
9.LEFT
10.RIGHT
11.OK
2.1.3 : Rear Panel
1. FAN
2. A/V in jack
3. A/V OUT jack
4. COAXIAL jack
5. POWER SW
6. RJ45 LAN socket
7. ANT. OUT (Only available in DTV model)
8. ANT. IN (Only available in DTV model)
9. Ypbpr jack
10. S/PDIF OPTICAL jack
11. HDMI Jack
12. USB HOST*2
13. USB DEVICE port (mini5p-Type)
14. DC IN jack

- 20 -
Chapter: 3
3.1.0 : Setup Menu
The Setup menu allows you to personalize and configure the preferences for your player.
To select a Setup option:
Select the Setup icon on the home screen, or press the SETUP button on the remote control.
Use the LEFT/RIGHT navigational buttons to select an option, and then press ENTER.
There are five Setup options, including TV,Audio, Video,REC, Network,System, and MISC. Use the
UP/DOWN navigational buttons to select a menu. Press ENTER to confirm. Press RETURN to cancel and
display the previous menu screen.
