Introduction
Congratulations on operating a Reach vehicle with a quality Utilimaster®body. Utilimaster is dedicated
to serving our customers' needs through the excellence of our products, services, and information.
Please read and follow the instructions in this document for safe and optimal operation and maintenance
of this vehicle.
This manual contains drawings and photos to aid in servicing the vehicle, and it may include
maintenance information on some items installed but not manufactured by Utilimaster Corporation.
Items such as chassis and drive train components or certain interior furnishings may be covered by
separate manufacturer-supplied information. Information provided here is intended to assist Utilimaster
customers and is in no way meant to replace or supersede instructions provided by other suppliers for
their products.
This Service Manual provides basic servicing information for Reach vehicle bodies built by Utilimaster
Corporation. See the Reach–Body Operator’s Guide for expanded descriptions on the features and
options unique to the Reach. For information on chassis and drive train operations, see the Isuzu’s NPR
Stripped Chassis Owner’s and Driver’s Manual. For additional technical documentation on parts and
wiring, see the references in the More Information and Publications section.
Utilimaster Corporation attempts to provide accurate, complete, and useful information. All information
contained in this manual is based on the latest product information available at the time of publication.
However, because of the Utilimaster policy of continual product improvement, Utilimaster reserves the
right to amend the information in this document at any time without prior notice.
Reach Customer Service
HOTLINE [phone]
Monday–Friday 8 a.m. to 5 p.m. Eastern Standard Time Zone
Email: [e-mail]
NOTE: The information in this document is generic. Images and procedures may differ from
those for vehicles you are servicing. Because Utilimaster manufactures customized vehicle
bodies, this document cannot list and illustrate every possible option for every vehicle. The
most common body options are described here. Use this information as a guideline.
