UTARGETTM MANUAL
UTARGETTM AUTO
Before use, please take the time to read this datasheet and make sure
you understood the advices and cautions of use.
•Do not watch directly the beam of light or through any optical instrument.
•Avoid any contact with the LEDs or its lens.
•Code IP40: protected against solid corpses larger than 1 mm and non-protected against water intrusion.
•Use the product in an environment where the working temperature is between +15°C and +35°C and there is
little humid air (<80%): if those conditions are not respected the product can be damaged.
•Do not use the product in an environment where smokes and oil vapors are present.
•Never try to repair by yourself any potential damages on the product.
•Make sure to use the right power supply before connecting the product.
•Do not reverse the electrical polarity –check your connections and the conventions before turning on the
product.
•Make sure you have the correct connector to link the product to the power supply.
Any incorrect use cancels the warranty.
User security

UTARGETTM
UTARGETTM
Version 2.3
Update: March 22
10 Avenue de Norvège
Parc des Erables –Bât. A3
91140 VILLEBON-SUR-YVETTE
FRANCE
Tel: [phone]
Fax: [phone]
Email: [e-mail]
Page 2 / 18
Table of contents
..........................................................................................................................................................................................1
..........................................................................................................................................................................................3
..........................................................................................................................................................................................4
..........................................................................................................................................................................................5
..........................................................................................................................................................................................7
..........................................................................................................................................................................................8
........................................................................................................................................................................................10
........................................................................................................................................................................................12
........................................................................................................................................................................................13
........................................................................................................................................................................................14
........................................................................................................................................................................................15
........................................................................................................................................................................................15
........................................................................................................................................................................................16
User security
Technical Overview
Product reference
Optical characteristics
Mechanical dimensions
How to use: UTARGET MANUAL
How to use: UTARGET AUTO
Signals (UTARGETTM AUTO only)
Accessories
Eyes & Skin Safety
Legal obligations
Possible health damages
Protective equipment

UTARGETTM
UTARGETTM
Version 2.3
Update: March 22
10 Avenue de Norvège
Parc des Erables –Bât. A3
91140 VILLEBON-SUR-YVETTE
FRANCE
Tel: [phone]
Fax: [phone]
Email: [e-mail]
Page 3 / 18
The UTARGETTM exists in 2 versions:
- The UTARGETTM MANUAL is held like a pen and controlled by hand. It is connected to a main socket.
- The UTARGETTM AUTO is integrated into an automatic process and controlled by a PLC or a footswitch.
UTARGETTM MANUAL
UTARGETTM AUTO
Electronics
Power supply
24V DC
Illumination mode
10 Levels between 0%
to 100% of light
intensity
Continuous with a
DIM process [0-24V]
Connector
Jack Connector
Lemo 0b –4 pins
Power consumption
~ 4W
Optics
Wavelength
365 or 385 or 395 or 405 nanometers
Irradiance
Up to 2000 mW/cm²
Mechanics
Diameter
36 mm (head) and 22 mm (body)
Length
150 mm
Material
Device body: Aluminum alloy
Weight
130 g
Thermal
Cooling system
Passive
Environment
Working temperature
+15°C to +35°C
Working Humidity
< 80% for temp < 35°C
IP Code
IP40
Technical Overview

UTARGETTM
UTARGETTM
Version 2.3
Update: March 22
10 Avenue de Norvège
Parc des Erables –Bât. A3
91140 VILLEBON-SUR-YVETTE
FRANCE
Tel: [phone]
Fax: [phone]
Email: [e-mail]
Page 4 / 18
*XXX corresponds to the wavelength of the product
KIT-UTARGET-XXX
*XXX corresponds to the wavelength of the product
Product reference
UTARGET -XXX*
UTARGET -XXX*- AUTO
UTARGETTM Manual:
UTARGETTM AUTO:

UTARGETTM
UTARGETTM
Version 2.3
Update: March 22
10 Avenue de Norvège
Parc des Erables –Bât. A3
91140 VILLEBON-SUR-YVETTE
FRANCE
Tel: [phone]
Fax: [phone]
Email: [e-mail]
Page 5 / 18
Spectra
Size of the exposed area
Thanks to its optical system, you will be able to change the size of the spot emitted by the UTARGETTM. In the
following graph, the area exposed is the area where the irradiance is higher than 50% of the maximum irradiance.
Pic
Wavelength
Full width at
half maximum
UTARGET 365
368 nm
14 nm
UTARGET 385
388 nm
10 nm
UTARGET 395
397 nm
14 nm
UTARGET 405
404 nm
18 nm
Optical characteristics
Collimated position
Focused position
0
0,2
0,4
0,6
0,8
1
350 370 390 410 430 450
Normalized intensity
Wavelength (nm)
Spectra of UTARGETTM
UTARGET 365 UTARGET 385
UTARGET 395 UTARGET 405
For other wavelengths (UVC / UVB / UVA / VISIBLE / IR), feel free to ask us!

UTARGETTM
UTARGETTM
Version 2.3
Update: March 22
10 Avenue de Norvège
Parc des Erables –Bât. A3
91140 VILLEBON-SUR-YVETTE
FRANCE
Tel: [phone]
Fax: [phone]
Email: [e-mail]
Page 6 / 18
Photometry

UTARGETTM
UTARGETTM
Version 2.3
Update: March 22
10 Avenue de Norvège
Parc des Erables –Bât. A3
91140 VILLEBON-SUR-YVETTE
FRANCE
Tel: [phone]
Fax: [phone]
Email: [e-mail]
Page 7 / 18
Mechanical dimensions
Collimated position
Focused position
Dimensions are the same for the UTARGET and the UTARGET AUTO

UTARGETTM
UTARGETTM
Version 2.3
Update: March 22
10 Avenue de Norvège
Parc des Erables –Bât. A3
91140 VILLEBON-SUR-YVETTE
FRANCE
Tel: [phone]
Fax: [phone]
Email: [e-mail]
Page 8 / 18
Before following the steps below, make sure you have considered the security part regarding UV emission. Then you
can follow these steps and make a quick and safety start.
Steps
Illustrations
Connect the electrical plug into the socket.
Plug the jack connector into the UTARGET™ and
Check your electrical connection thanks to the red
light on the UTARGETTM body which has to turn on.
Press the power button to turn the UTARGETTM ON.
The green light on the UTARGETTM body should
turn on.
The UTARGETTM (at 100%) is ready to be used. Use
the buttons –(less) and + (more) to control the
light intensity from 20% to 100%.
0%
10%
20%
30%
40%
50%
60%
70%
80%
90%
100%
0 1 2 3 4 5 6 7 8 9
Light intensity
Number of clicks
How to use: UTARGET MANUAL
-
+

UTARGETTM
UTARGETTM
Version 2.3
Update: March 22
10 Avenue de Norvège
Parc des Erables –Bât. A3
91140 VILLEBON-SUR-YVETTE
FRANCE
Tel: [phone]
Fax: [phone]
Email: [e-mail]
Page 9 / 18
Information about the two status LEDs
Green LED
Red LED
Situation
OFF
OFF
The UTARGETTM is not plugged
OFF
ON
The UTARGETTM is plugged to an electrical source but does not
emit UV
ON
OFF
The UTARGETTM is plugged to an electrical source and emits UV
ON
ON
The UTARGETTM is ON and it is at 100% of its power
BLINK
OFF
Change of the light intensity after pushing the button (+) or (-)
OFF
BLINK
Preventing the UTARGETTM from overheating
Power (ON/OFF) button
Plus (+) button
Minus (-)
button
Red LED
Green LED
Optical system

UTARGETTM
UTARGETTM
Version 2.3
Update: March 22
10 Avenue de Norvège
Parc des Erables –Bât. A3
91140 VILLEBON-SUR-YVETTE
FRANCE
Tel: [phone]
Fax: [phone]
Email: [e-mail]
Page 10 / 18
Plug M12 –4pins
Footswitch
ON button
STOP button
Light intensity
controller
With the UPOWERTM
The UTARGETTM AUTO can be provided with its power supply UPOWERTM.
Steps
Illustrations
Connect the cable M12 –4 pins between the
UTARGET and the UPOWER. The connector for the
UTARGETTM AUTO side is a LEMO connector.
Plug the UPOWERTM to a 230V outlet.
The UTARGETTM AUTO is ready to be used.
To turn the UTARGET on, you can either use the
buttons ON on the UPOWER, or use a foot pedal
(more details in “ACCESSORIES”) or connect the
UPOWER to your PLC.
How to choose the light intensity
Use the light intensity controller buttons on the
UPOWER to control the light intensity from 20% to
99%.
How to use: UTARGET AUTO
