V.Brøndum RONDA Mini-Vac User manual
USER MANUAL
(Last edited: 24.02.2022)
RONDAMini-Vac
Portable Class H Vacuum Cleaner with collection bag
V. BRØNDUM A/S
A0.80.1044
IMPORTANT!
Only use for dry dust.
Read this manual before you start using the vacuum cleaner.
USER MANUAL
V. BRØNDUM A/S RONDA
Mini-Vac 2
USER MANUAL
V. BRØNDUM A/S RONDA
Mini-Vac 3
Table of Content
General Description.................................................................................................................5
Safety.......................................................................................................................................5
Technical Data.........................................................................................................................7
Standard Accessories..............................................................................................................8
Guidelines Regarding the Disposal of the Machine.................................................................8
Applications .............................................................................................................................9
ASBESTOS AND HEALTH-HAZARDOUS DUST ................................................................................9
Assembling............................................................................................................................10
Thermal Overload..................................................................................................................10
Replacement of the Collection Bag........................................................................................11
Replacement of the Pre-filter.................................................................................................11
HEPA-filter.............................................................................................................................12
Cleaning and Maintenance....................................................................................................12
Trouble Shooting ...................................................................................................................13
Declaration of Conformity ......................................................................................................14
Service and Repair................................................................................................................14
USER MANUAL
V. BRØNDUM A/S RONDA
Mini-Vac 4
USER MANUAL
V. BRØNDUM A/S RONDA
Mini-Vac 5
RONDAMini-Vac
Class H Vacuum Cleaner for Health-Hazardous Dust
General Description
Congratulations on your new RONDAMini-Vac vacuum cleaner from V. BRØNDUM A/S.
RONDAMini-Vac is a small, portable vacuum cleaner developed for collection of health-hazardous class H dust.
For collection of all dust types. The vacuum cleaner is designed for use in environments where the material
collected is of such a dangerous nature that any contact must be minimized.
The RONDAMini-Vac vacuum cleaner consists of a suction unit with HEPA filter and pre-filter as well as a
container with a collection bag. When the bag is full, an indicator light comes on to indicate that the bag needs to
be replaced before work can continue. The bag is easily accessible and easy to change with minimal dust
exposure.
RONDAMini-Vac is intended for commercial and industrial use.
Read this manual before you operate the machine.
Keep the manual readily accessible to all users.
Portable low-weight vacuum cleaner with a carry strap
Made of strong polypropylene
Protection class IPX4 (IEC 60 529)
Complies with the requirements of EN 60 335-2-69 Appendix
AA, for collection of hazardous dust in dust class "H"
With collection bag
Warning light at low airflow, when the bag needs to be
replaced.
USER MANUAL
V. BRØNDUM A/S RONDA
Mini-Vac 6
Safety
The user manual is to ensure a secure operation of the vacuum cleaner, and to
secure that the user is in no way uncertain as to the use. The manual must be stored
near the vacuum cleaner.
Does any uncertainty arise as to the use of the vacuum cleaner or the material
collected, the work should be stopped until all questions have been cleared.
Pictures and drawings are for illustrative purpose and will make the understanding of
the manual easier. The pictures shown may therefore be different from the actual
product.
May only be used for dry dust. The vacuum cleaner is NOT suitable for collecting
liquid or damp material.
Under no circumstances should the vacuum cleaner be used in areas where
potentially explosive dust types or vapors may be present.
The vacuum cleaner must not be used or stored outdoors in a wet environment.
Filters and collection bag must be installed during use.
IMPORTANT! The vacuum cleaner must not be started with covers
removed.
IMPORTANT! The suction unit / inlet / outlet must not be covered when the
machine is in use.
Please read the RONDA Safety Instructions which were delivered with the machine
together with this user manual.
Does the safe use or maintenance of the appliance raise any questions; do not
hesitate to contact either your dealer or V. BRØNDUM A/S.
USER MANUAL
V. BRØNDUM A/S RONDA
Mini-Vac 7
Make sure that the voltage
and fuse of the power supply
correspond with the
information of the data plate
of the machine and the
information of this manual.
Technical Data
RONDAMini-Vac vacuum cleaner is connected to 230 V power supply.
Below table shows the technical data of RONDAMini-Vac vacuum cleaner.
EU
Voltage
Suction motor (max./nom.)
Power outlet, max.
Vacuum
Air volume, max.
Air volume max, measured
Filter area, multi tube filter
Filter area, HEPA
Collection capacity (bag / container)
Height (without coupling)
Length
Width
Weight without accessories
Length of supply cable
Noise
Machine pressure level: uncertainty KpA=3dB
(Measured only as machine)
Max. Sound Power Level LWA= uncertainty KWA=3dB
(Measured with hose, pipes and floor accessory)
Vibration
230
1100/1050
-
2600
25,5
54,5
193
47 / 170
-
0,3
3
320
390
210
7,4
8
<78
<85
≤ 2,5
Volt
Watt
Watt
mmH2O
kPa
l/sec
m3/h
l/sek / m³/h
m2
m²
l
mm
mm
mm
kg
m
dB(A)
dB
m/s2
USER MANUAL
V. BRØNDUM A/S RONDA
Mini-Vac 8
Standard Accessories
RONDAMini-Vac vacuum cleaner is delivered with a small set of accessories including hose and two nozzles.
You can reorder the accessories using the following product numbers:
1. 32 mm accessories set ...............................................................82.33.3291
2. Plastic hose Ø 32mm 2,75 m with air adjustment..........................84.54.3231
3. Crevice nozzle...............................................................................82.34.3200
4. Round brush..................................................................................80.34.3201
Guidelines Regarding the Disposal of the Machine
1
2
3
4
The product you have purchased is subject to Directive 2002/96/EC of the European
Parliament and the Council of the European Union on waste electrical and electronic
equipment (WEEE) and should not be disposed of as unsorted municipal waste. Please
utilize your local WEEE collection facilities in the disposition of this product and otherwise
observe all applicable national requirements.
USER MANUAL
V. BRØNDUM A/S RONDA
Mini-Vac 9
Applications
RONDAMini-Vac is a vacuum cleaner in accordance with DS/EN 60335-2-2 and CEI/IEC 60335-2-69 Annex AA
class H and may only be used as such.
RONDAMini-Vac may be used for collection of dust hazardous to health according to CEI/IEC 60335-2-69
Annex AA dust class H.
RONDAMini-Vac may not be used for collection of fluids or moist dust.
RONDAMini-Vac may not be used for collection of flammable, explosive, poisonous or extremely health-
hazardous types of dust, liquid or gas.
RONDAMini-Vac may only be used in dry environments and may not be used or stored outdoors or indoors
under wet conditions.
The capacity of a vacuum cleaner to suck vacuum depends on the air. Theoretically, the suction capacity will fall
when the vacuum cleaner is used at altitudes. The suction capacity of the vacuum cleaner will be constant from 0
to approx. 800 m above sea level. From 800 to 2000 m the suction capacity will theoretically fall to approx. 75%. It
is not recommended to use the vacuum cleaner at more than 2000 m above sea level, as the cooling and the
suction capacity will be considerably reduced.
Asbestos and Health-Hazardous Dust
Always check up on the local/national regulations where the work is performed.
Always investigate how the disposal is to be packed / wrapped up. It might be different from place to place.
Usually the following is mentioned:
Close-fitting packing, drum/vat with cover
Plastic bag min. 100 μm.
Collection of dust hazardous to health must always take place in collection bag. The collection bag must be
removed from the machine and disposed of in accordance with the local regulations.
Always mark the materials and waste according to the national regulations.
If the machine has been used inside a closed asbestos area, the machine must be disassembled and cleaned
before leaving this area to be used in a clean environment.
If the machine was used for cleaning after taking samples, the collection bag must be replaced. The collection
bag is removed and disposed of as dangerous waste according to applicable regulations. The machine is wiped
off using wet wipes which are then disposed of together with disposable suit and other PPE.
The machine must be emptied, cleaned and packed before transport. Mark the packing according to the national
regulations.
USER MANUAL
V. BRØNDUM A/S RONDA
Mini-Vac 10
Assembling
Check that the packing is intact and has no sign of damage from handling and transport.
Unpack RONDAMini-Vac vacuum cleaner and check that all the parts ordered are there.
Remove the blanking plug and insert the hose in the container coupling of the RONDAMini-Vac vacuum
cleaner. Always make sure that the blanking plug is removed before turning on the vacuum cleaner.
Make sure that the collection bag and the filters of the machine are intact and undamaged (see the
section: Replacement of the Collection Bag).
Before the cable is connected to a power supply, check that cable and plugs are undamaged. If the cable
or plug is damaged, the parts must be replaced by a professional. Only use original cable.
In case the plug does not fit the mains socket, the plug must be replaced. Color codes of the wires:
oGreen/yellow wire is connected to terminal marked with E or earth-symbol
oBlue wire is connected to terminal marked with N (neutral)
oBrown wire is connected to terminal marked with L (phase)
ATTENTION! The cut-off plug must be destroyed to avoid accidents –it can be dangerous if a cut-off plug
is inserted into an active socket.
Connect the machine to 230 V mains with a reliable grounding.
RONDAMini-Vac vacuum cleaner is turned on an off at the switch located on the suction unit.
Thermal overload
The motor is equipped with a thermal overload control which switches off the machine if the hose is blocked or
if the vacuum cleaner is switched on with the blanking plug fitted, or if the collection bag is full and needs to be
replaced.
When the motor has cooled down sufficiently, the control function is reset automatically. The cause of
overheating must always be investigated and resolved.
USER MANUAL
V. BRØNDUM A/S RONDA
Mini-Vac 11
Replacement of the Collection Bag
When the suction power starts to drop, and it is time to change the collection bag, the warning light of the vacuum
cleaner will come on.
1. Stop vacuuming, turn off the vacuum cleaner, and seal the container by fitting
on the blanking plug.
2. Open the four clips that hold the collection container onto the vacuum cleaner
(pull back the catch to release the clip to open).
2.
3. Lift off the lid.
4. Close the bag by means of the cardboard flap and take out the bag (dispose of
the bag according to local rules).
5. Check the pre-filter; if it is covered with dust or worn,
it must be cleaned or replaced (see the section:
Replacement of the Pre-Filter)
6. Insert the new collection bag –make sure to get the
corners underneath the flange.
7. Put the lid back in place and secure it with the four clips.
8. Fit the hose onto the vacuum cleaner and start vacuuming.
Replacement of the Pre-Filter
The pre-filter must be replaced if it shows signs of wear and tear or if it is covered with a thick layer of dust.
NEVER clean the filter by means of compressed air.
The filter can be vacuumed and/or hand washed at 40°C in a mild detergent solution (do not machine wash).
USER MANUAL
V. BRØNDUM A/S RONDA
Mini-Vac 12
IMPORTANT!
The machine must not be
connected to the power supply
during service and cleaning
HEPA-Filter
The HEPA-filter is placed underneath the motor housing.
The HEPA-filter must be replaced by a professional service technician.
Cleaning and Maintenance
The collection bag must always be replaced after use. If the machine is
left with dust in the collection bag, there is a risk of self-ignition.
Read the section regarding safety precautions before cleaning and
maintaining the vacuum cleaner.
The easiest way to clean the vacuum cleaner is following:
Wipe the exterior of the machine with a dry or damp cloth.
Maintaining the vacuum cleaner
The vacuum cleaner is made of maintenance-free parts and therefore needs no daily maintenance, apart from
external cleaning and check that the cords and plugs are undamaged.
The easiest way to clean the vacuum cleaner is with a damp cloth. Do not aim jets of water directly at the vacuum
cleaner.
To avoid downtime and to make sure that the safety of the vacuum cleaner is intact, it is recommended that an
authorized service technician inspect the electrical parts and replaces the HEPA-filter annually.
USER MANUAL
V. BRØNDUM A/S RONDA
Mini-Vac 13
Check / Maintenance of the Machine
Description
Before/after use
Month / Year
Hours
Check / replacement of motor
700
Safety check of the machine
Yearly
Emptying and cleaning
After use (as required)
Check of filters and machine in general
Before use
Check of cord and plugs
Before use
Check of alarm (lamp)
Before use
Reordering Collection Bag and Pre-Filter incl. HEPA Filter:
Pre-filter RONDA Mini-Vac .................................................................84.67.1014
Collection bag N/W fleece* .................................................................84.64.0027
* When vacuuming fine dust the bag cannot be filled 100 %
Trouble Shooting
If the machine does not vacuum satisfactorily:
Hose, pipe or nozzle may be blocked, or the blanking plug is fitted.
Stop the machine and remove the blocking or the blanking plug.
The collection bag may be full.
Stop the machine and replace the bag. See the relevant section.
A leak may have occurred when replacing the collection bag.
Start the machine and block the hose. Normally you will be able to hear a possible leak. Make sure that the
lid is securely fastened onto the machine.
The HEPA-filter may be blocked.
The HEPA-filter MUST be replaced by a professional service technician.
Thermal overload activated:
The machine is not getting enough cooling air and is automatically cut off
Let the motor cool and resolve the cause of the overload (see above).
Any repairs and service on the vacuum cleaner must be carried out by V. BRØNDUM A/S, an authorized dealer
or a similarly qualified person to avoid dangers.
USER MANUAL
V. BRØNDUM A/S RONDA
Mini-Vac 14
DECLARATION OF CONFORMITY
V. BRØNDUM A/S
Sadolinsvej 14
DK –8600 Silkeborg
hereby declares that the following product:
Electrically operated industrial vacuum cleaner,
classified for dust class “H” .
Model:
RONDAMini-Vac
has been designed and produced in conformity with the basic requirements and other relevant conditions of the
following directives:
Machine Directive (Directive 2006/42/EU)
EMC-Directive (Directive 2014/30/EU)
ROHS-Directive (Directive 2011/65/EU - COMMISSION DELEGATED DIRECTIVE (EU) 2015/863 31 March
2015)
The compliance has been achieved by use of the following standards:
EN 60335-1
EN 60 335-2-2
EN 60 335-2-69
Silkeborg, November 2021
Kennet Vallø
Product Manager
V. BRØNDUM A/S
USER MANUAL
V. BRØNDUM A/S RONDA
Mini-Vac 15
Service and Repair
Service and repair are provided free of charge within the guarantee period (invoice must be presented) provided
that:
The defect has been caused by a construction defect or defective materials. (Normal wear and tear,
misuse or insufficient maintenance is not covered by the guarantee).
No repair attempts have been made by others than V. BRØNDUM A/S, or service centres approved by
V. BRØNDUM A/S to carry out guarantee repairs.
Service free of charge includes replacement of defect parts and the cost for related working hours.
The machine is handed in via the V. BRØNDUM A/S dealers or is sent directly, carriage paid, to:
V. BRØNDUM A/S
Sadolinsvej 14
DK-8600 Silkeborg
Tlf. (+45) 8682 4366
Fax (+45) 8680 3363
Subject to changes.
Table of contents
Other V.Brøndum Vacuum Cleaner manuals
