V-tech VM312 User manual

Quick start guide
VM312
VM312-2
VM302
Go to www.vtechphones.com
to register your product for
enhanced warranty support
and latest VTech product news.
Specifications are subject to change without notice.
© 2014 VTech Communications, Inc.
All rights reserved. 12/14. VM312-X_QSG_V1.0
Document order number: 96-010233-010-100
What’s in the box
1 set for VM302/VM312
2 sets for VM312-2
1 set for VM312/VM312-2
Sound activation
When the infrared LEDs are on, the
image is in black and white. This is
normal due to external light sources.
Depending on the surroundings
and other interfering factors, like
lightings, objects, colors and
backgrounds, the display resolution
may vary. Adjust the baby unit’s angle,
or place the baby unit at a higher
level to prevent glare and blurry
display.
TIP
The baby unit has infrared LEDs that
allow you to see your baby at night
or in a dark room. When the baby
unit detects low light levels, the
infrared LEDs turn on automatically.
NOTE
Night vision

Mount the baby monitor
Use a pencil to mark two holes in
parallel. Make sure they are the
same distance apart as the wall
mount at the bottom of the baby
unit.
Drill two holes in the wall (7/32” drill
bit). If you drill the holes into a stud,
insert the screws into the holes.
Tighten the screws until only 1/4 inch
of the screws are exposed.
Align the holes on the wall mount
with the screws on the wall.
Slide the wall mount down until it
locks into place.
Pan or tilt to adjust the baby unit
angle.
Check for reception strength and
camera angle before drilling the
holes.
NOTE
Install the battery, connect, and power on Place the baby monitor
At least 1 meter
(3 feet)
At least 1 meter (3 feet)
THIS SIDE UP
3
1
1
1
3
1
1
2
2
2
2
2
