V-tech VM343-2 User manual

Go to www.vtechphones.com
to register your product for
enhanced warranty support
and latest VTech product news.
VM343-2
Quick start guide
What’s in the box
Install the battery
123
123
Dim mode
With dim mode preset to on, your parent unit display will dim after 10 minutes of inactivity to conserve energy.
10 min inactivity
Press any buttons
Connect and power on - Baby unit Connect and power on - Parent unit
CAUTION
The default volume of your parent unit
is level 4. If you experience high-pitched
screeching noise from your baby monitor
while positioning:
Make sure your baby units and parent unit
are more than 1 meter (3 feet) apart, OR
Turn down the volume of your parent unit.
•
-
-
6U]KXOTMUT
6U]KXOTMUT
2s
THIS SIDE UP
Once you power on your baby monitor, your parent unit displays image from baby unit , and the LI NK LED
light turns on.
The ON/OFF LED light of baby unit turns on. As baby unit is not being viewed, its ON/OFF LED light flashes.
Status check
63ē
Press VIEW to switch between the image of baby units and .
Press VIEW
Change different views - View Change different views - Patrol
Press PATROL to alternately view the image from baby units and every 10 seconds.
10s
Change different views - Split
Press SPLIT to view the images from all baby units at once.
VM343-2 baby monitor system
Baby’s room Living room
More than 1 meter
(3 feet)
>1m (3ft)
63ē
63ē
>1m (3ft)
<1m (3ft)

Specifications are subject to change without notice.
© 2016 for VTech Communications, Inc. All rights reserved.
03/16. VM343-2_QSG_V5.Document order number : 96-011156-010-100
Basic operation - Parent unit
Adjust speaker volume
Press + / VOL / -to adjust your parent unit speaker
volume. It determines the volume of sound
transmitted from your baby units.
Pan, tilt, zoom
Press and hold , , or to move the camera.
Talk to your baby unit
Press and hold TALK and speak to your parent unit.
Your voice is transmitted to the baby unit.
Turn off the screen
Press and hold LCD ON/OFF to switch off the screen.
You can still hear sound from the selected baby unit.
Use the menu
Press MENU/SELECT to enter the menu, choose
a menu item, or save a setting.
While in the menu:
Press or to scroll up or down.
Press to select an item, or save a setting.
Press BACK to return to the main menu or
idle screen.
•
•
•
Turn off the parent unit
Press and hold to power off your parent unit.
Basic operation - Baby unit
63ē
ē
63ē
63ē
AlertTone
LowBattery Tone
NoLink Alert
Soundalert in split-view
Long press
Adjust speaker volume
Press + / VOL / -to adjust your baby unit speaker
volume. It determines the talkback volume
transmitted from your parent unit.
Turn off the baby unit
Slide the ON/OFF switch to OFF to power off
your baby unit.
6U]KXOTMULL
6U]KXOTMULL
2s
LCDis turning off...
2s
Overview - Parent unit
Stand Power jack
Speaker
On/off
TALK
Zoom
Antenna
Microphone
Light indicators
Arrow keys
MENU / SELECT
+ / VOL / -
VIEW / LCD ON/OFF
PATROL
SPLIT
63ē
63℉
> More than 1
meter (3 feet)
63℉
Overview - Baby unit
Insert the screws into the
holes and tighten the screws
until only 1/4 inch of the
screws are exposed.
If you drill the holes into a stud,
go to step 3.
-OR-
If you drill the holes into an object
other than a stud, insert the wall
anchors into the holes. Tap gently
on the ends with a hammer until
the wall anchors are flush with
the wall.
Mount the baby monitor (optional)
OR
Place the wall mount bracket on a
wall and then use a pencil to mark
the top and the bottom holes as
shown. Remove the wall mount
bracket and drill two holes in the
wall (7/32 inch drill bit).
NOTES
Check for reception strength and
camera angle before drilling the holes.
•
Align the wall mount bracket and
screws with the holes in the wall
as shown. Tighten the screw in the
middle hole first, so that the wall
mount bracket position is fixed.You
can tighten the other screw in the
top hole.
Place the baby unit on the wall
mount bracket.Tighten the screw
into the threaded socket at the
bottom to secure the baby unit.
Place the baby unit on the wall mount
bracket.Tighten the screw into the threaded
socket at the bottom to secure the baby
unit. Align the holes on the wall mount
bracket with the screws on the wall, and
slide the wall mount bracket down until it
locks into place.
Camera
Light sensor
Infrared LEDs
Mircrophone
- / VOL / +
ON/OFF slide
ON/OFF light
Temperature
sensor
Speaker
Antenna
Power jack
Press to zoom in or out.
Sound activation
Automatically turns on the parent unit screen when the baby
unit being viewed detects a sound after the screen is turned
off. When no sound is detected within 50 seconds, the
screen is automatically turned off to save power.
Sound-activated Screen
On
O
Night vision
The baby unit has infrared LEDs that allow you to
see your baby at night or in a dark room. When the
baby unit detects low light levels, the infrared LEDs
turn on automatically.The images from this baby
unit is in black and white, and appears on screen.
