V-tech DM1111-2 User manual

Note
• This baby monitor is intended as an aid. It is not a substitute for proper adult supervision, and should not be
used as such.
Test your baby monitor
You may test the baby monitor before initial use, and at regular times thereafter.
Caution
• For hearing protection, make sure the parent
unit is more than 6.5 feet (2 meters) away from
the baby unit. If you hear any high-pitched
noise, move the parent unit further until the
noise stops. You can also press on the parent
unit to lower or mute the noise.
1. Make sure your baby unit and parent unit are on.
2. Speak towards the microphone of the baby unit.
You will hear the sound at the parent unit, and see
the visual sound indicators light up.
Note
• When the POWER/LINK LED light flashes, move the parent unit closer to the baby unit (observe the
minimum distance of 6.5 feet / 2 meters). You can also check if the baby monitor is connected to a live
power socket and switched on.
Tip
• Increase the speaker volume of the parent unit if you cannot hear the sounds transmitted from the baby units.
Positioning the baby monitor
Caution
• Keep the baby unit out of the reach of your baby. Never place
or mount the baby unit inside the baby’s crib or playpen.
Note
• To avoid interference from other electronic devices, place your
baby monitor far away from devices such as wireless routers,
microwaves, cell phones and computers.
1. Place the baby units more than 3 feet (1 meter) away
from your baby.
2. Place the parent unit more than 6.5 feet (2 meters)
away from the baby unit to avoid screeching noise.
Caution
• The default volume of your parent unit is Level 3, and the
maximum volume is level 5. If you experience high-pitched
screeching noise
from your baby monitor while positioning:
- Make sure your baby units and parent unit are more than
6.5 feet (2 meter) apart, OR
- Turn down the volume of your parent unit.
Operating range
The operating range of the baby monitor is up to 1,500 feet (450 meters) outdoors or 160 feet
(50 meters) indoors. The actual operating range may vary depending on the environmental
conditions and other interferences such as walls, doors and other obstructions.
Frequency control Crystal controlled PLL synthesizer
Transmit frequency Baby unit: 1921.536 - 1928.448 MHz
Parent unit: 1921.536 - 1928.448 MHz
Channels 5
Nominal effective
range
Maximum power allowed by FCC and IC. Actual operating range may
vary according to environmental conditions at the time of use.
Power requirements Baby unit adapter: Input: 100-120V AC 60Hz;
Output: 6V DC @ 400mA
Parent unit adapter: Input: 100-120V AC 60Hz;
Output: 6V DC @ 400mA
Parent unit battery: 2.4V NiMH battery
Technical specifications
Specifications are subject to change without notice.
© 2020 VTech Technologies Canada Ltd.
All rights reserved. 09/20. DM1111-X_CA_CIB_V2
DM1111
DM1111-2
Enhanced Range
Digital Audio Monitor
What’s in the box
Strangulation
Hazard
Keepthiscordout of reach of children.
Thecordneedstobe at leastthree feet
awayfromthechildat all times.Do not
usewithan extensioncord.Do not
removethistag.
Éloignezcecordondes enfants. Le
cordondoitse trouveràaumoinstrois
piedsd’unenfantet ce, en tout temps.
N’utilisezpasderallonge.Neretirezpas
cetteétiquette.
Mantengaestecablefuera de la alcance
delosniños.Estecable debe estar por
lomenostres pies fuera de la alcance
delniñoentodo momento. No lo use
conunaextensióninalámbrica. Noquite
estaetiqueta.
Risque
d’étranglement
Riesgode
estrangulación
Strangulation
Hazard
Keepthiscordout of reach of children.
Thecordneedstobe at leastthree feet
awayfromthechildat all times.Do not
usewithan extensioncord.Do not
removethistag.
Éloignezcecordondes enfants. Le
cordondoitsetrouveràaumoins trois
piedsd’unenfantet ce, en tout temps.
N’utilisezpasderallonge.Neretirezpas
cetteétiquette.
Mantengaestecablefuera de la alcance
delosniños.Estecable debe estar por
lomenostres pies fuera de la alcance
delniñoentodo momento. No lo use
conunaextensióninalámbrica. Noquite
estaetiqueta.
Risque
d’étranglement
Riesgode
estrangulación
1 set for DM1111
2 sets for DM1111-2
1
Connect the baby monitor
2Before use
>6.5ft (2m)
Power on or off the baby unit
• Press and hold until the POWER light
turns on.
• Press and hold until the POWER light
turns off.
Power on or off the parent unit
• Press and hold until the POWER / LINK
light turns on.
• Press and hold until the POWER / LINK
light turns off.
Adjust parent unit speaker volume
The speaker volume is preset to Level 3 on the parent unit. You can adjust to your preferred sound level.
• Press to decrease the volume, and to increase the volume.
Note
• If you continue to press or when the volume reaches the minimum or maximum setting, the parent
unit will beep twice.
To mute the speaker volume
• Press repeatedly until the volume reaches the minimum.
Notes
• When the parent unit is in mute, the visual sound indicator will still indicate the sound detected from the
baby unit.
• To unmute, press repeatedly until it reaches your desired volume.
Turn on or off the audio reminder
With audio reminder feature preset to on, the parent
unit plays an audio reminder when it is connected to
a baby unit. It reminds you to place the baby unit at
least 3 feet (1 meter) away from your baby, and keep
the cords out of the reach of children.
• Press and hold for 8 seconds when the parent
unit is not in use. The visual sound indicators
flashes for 3 times. The audio reminder is disabled.
• Press and hold for 8 seconds when the parent
unit is not in use. The visual sound indicators flashes for 3 times. The audio reminder is enabled.
Notes
• You can press or to adjust or mute the volume when the parent unit is playing the reminder.
• If the speaker volume of the parent unit is turned off, it will resume to the default volume level when the
parent unit plays the reminder.
3
Using the baby monitor
Important safety instructions
The applied nameplate is located at the bottom of the
baby unit’s base.
When using your equipment, basic safety precautions
should always be followed to reduce the risk of fire,
electric shock and injury, including the following:
1. Follow all warnings and instructions marked on the
product.
2. Adult setup is required.
3. CAUTION: Do not install the baby unit at a height
above 2 meters.
4. This product is not a substitute for adult supervision of the
infant. Supervising the infant is the parent’s or caregiver’s
responsibility. This product could cease operating, and
therefore you should not assume it will continue working
properly for any given period of time. Further, this is not
a medical device and should not be used as such. This
product is intended to assist you in supervising your baby.
5. Do not use this product near water. For example, do
not use it next to a bath tub, wash bowl, kitchen sink,
laundry tub or swimming pool, or in a wet basement
or shower.
6. CAUTION: Use only the battery provided. There may be a
risk of explosion if a wrong type of battery is used for the
parent unit. The battery cannot be subjected to high or low
extreme temperature and low air pressure at high altitude
during use, storage or transportation. Disposal of battery
into fire or a hot oven, or mechanically crushing or cutting or
the battery can result in an explosion. Leaving the battery in
an extremely high temperature surrounding environment
can result in an explosion or the leakage of flammable liquid
of gas. Battery subjected to extremely low air pressure may
result in an explosion or the leakage of flammable liquid or
gas. Dispose of used battery according to the information in
The RBRC®seal.
7. Use only the adapters included with this product.
Incorrect adapter polarity or voltage can seriously
damage the product.
Power adapter information:
Output: 6V DC 400mA
VTECH TELECOMMUNICATIONS LTD.
Model: VT05UUS06040
Rechargeable battery information:
2xAAA 2.4V 400mAh
YIYANG CORUN BATTERY CO LTD.
Model: NI-MHAAA400×2-FF
8. The power adapters are intended to be correctly
oriented in a vertical or floor mount position. The
prongs are not designed to hold the plug in place if it
is plugged into a ceiling, under-the-table or cabinet
outlet.
9. For pluggable equipment, the socket-outlet shall
be installed near the equipment and shall be easily
accessible.
10. Unplug this product from the wall outlet before cleaning.
Do not use liquid or aerosol cleaners. Use a damp cloth
for cleaning.
11. Unplug the power cords before replacing battery.
12. Do not cut off the power adapters to replace them with
other plugs, as this causes a hazardous situation.
13. Do not allow anything to rest on the power cords. Do
not install this product where the cords may be walked
on or crimped.
14. This product should be operated only from the type
of power source indicated on the marking label. If you
are not sure of the type of power supply in your home,
consult your dealer or local power company.
15. Do not overload wall outlets or use an extension cord.
16. Do not place this product on an unstable table, shelf,
stand or other unstable surfaces.
17. This product should not be placed in any area where
proper ventilation is not provided. Slots and openings
in the back or bottom of this product are provided for
ventilation. To protect them from overheating, these
openings must not be blocked by placing the product
on a soft surface such as a bed, sofa or rug. This
product should never be placed near or over a radiator
or heat register.
18. Never push objects of any kind into this product
through the slots because they may touch dangerous
voltage points or create a short circuit. Never spill liquid
of any kind on the product.
19. To reduce the risk of electric shock, do not
disassemble this product, but take it to an authorized
service facility. Opening or removing parts of the
product other than specified access doors may
expose you to dangerous voltages or other risks.
Incorrect reassembling can cause electric shock
when the product is subsequently used.
20. You should test the sound reception every time you
turn on the units or move one of the components.
21. Periodically examine all components for damage.
22. There is a very low risk of privacy loss when using
certain electronic devices, such as baby monitors,
cordless telephones, etc. To protect your privacy,
make sure the product has never been used before
purchase, reset the baby monitor periodically by
powering off and then powering on the units, and
power off the baby monitor if you will not use it for
some time.
23. Children should be supervised to ensure that they do
not play with the product.
24. The product is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person
responsible for their safety.
SAVE THESE INSTRUCTIONS
Cautions
1. Use and store the product at a temperature between
32oF and 104oF.
2. Do not expose the product to extreme cold, heat
or direct sunlight. Do not put the product close to a
heating source.
3. Batteries should not be exposed to excessive heat such
as bright sunshine or fire.
4. Make sure the baby unit(s) and the
adapter cord(s) are always out of reach
of the baby, at least 3 feet away from
the baby or crib, to avoid a possible
strangulation hazard.
5. Never place the baby unit(s) inside the baby’s crib or
playpen. Never cover the baby unit(s) or parent unit
with anything such as a towel or a blanket.
6. Other electronic products may cause interference
with your baby monitor. Try installing your baby
monitor as far away from these electronic devices
as possible: wireless routers, radios, cellular
telephones, intercoms, room monitors, televisions,
personal computers, kitchen appliances and
cordless telephones.
Precautions for users of implanted cardiac pacemakers
Cardiac pacemakers (applies only to digital cordless
devices):
Wireless Technology Research, LLC (WTR), an independent
research entity, led a multidisciplinary evaluation of the
interference between portable wireless devices and
implanted cardiac pacemakers. Supported by the U.S. Food
and Drug Administration, WTR recommends to physicians
that:
Pacemaker patients
• Should keep wireless devices at least six inches from the
pacemaker.
• Should NOT place wireless devices directly over the
pacemaker, such as in a breast pocket, when it is turned
ON.
WTR’s evaluation did not identify any risk to bystanders
with pacemakers from other persons using wireless devices.
Electromagnetic fields (EMF)
This VTech product complies with all standards regarding
electromagnetic fields (EMF). If handled properly and
according to the instructions in this user’s manual, the
product is safe to be used based on scientific evidence
available today.
Install the parent unit battery
The parent unit runs on rechargeable battery or AC power. To continuously monitor your
baby, make sure you use both battery and AC power at the same time. With the battery
alone, the parent unit can cordlessly run for a short time only.
NOTESNOTE
• Use only the battery supplied with this product.
• If the parent unit will not be used for a long time, disconnect and remove the battery to prevent possible
leakage.
Replace the battery
To replace the battery, press down on the battery compartment cover and pull it out, then
follow the steps above to install the battery.
Connect the baby monitor
NOTESNOTE
• Use only the power adapters supplied with this product.
• Make sure the baby monitor is not connected to a switch controlled
electric outlet.
• Connect the power adapters in a vertical or floor mount position
only. The adapters’ prongs are not designed to hold the weight of
baby monitor, so do not connect them to any ceiling, under-the-
table, or cabinet outlets. Otherwise, the adapters may not properly
connect to the outlets.
• Make sure the parent unit, the baby unit and the power adapter
cords are out of reach of children.
• Make sure the POWER light is on after the power plug is fully inserted
into the power jack of the baby unit.
• With audio reminder feature preset to on, the parent unit plays an
audio reminder when it is connected to a baby unit.
Charge the parent unit battery
When you have connected and turned on the baby unit
and all the parent units, they will enter pairing mode
automatically. It takes around 10 minutes for the pairing
process to complete. When the parent unit and baby unit
are successfully paired, both their power LEDs are on
steadily. The baby monitor is ready to use.
NOTESNOTE
• Before using the baby monitor for the first time, charge the parent unit battery for 12 hours.
• It takes longer to charge the battery when the parent unit is turned on. To shorten the charging time, turn
the parent unit off while charging.
• The standby time varies depending on the sensitivity level you set, your actual use and the age of the battery.
• The parent unit beeps twice every 10 minutes and the light flashes in red when the battery is low.
Charge the parent unit battery without interruption for at least 30 minutes.
• To keep the battery charged, connect it to AC power when not in use.
Strangulation
Hazard
Keepthis cordout of reach of children.
Thecordneeds to be at leastthreefeet
awayfromthe child at all times.Do not
usewithan extension cord.Do not
removethis tag.
Éloignezcecordondesenfants. Le
cordondoitsetrouverà au moins trois
piedsd’unenfant etce,entout temps.
N’utilisezpasderallonge.Neretirez pas
cetteétiquette.
Mantengaestecable fuerade laalcance
delos niños. Estecabledebe estarpor
lomenostrespiesfuera de la alcance
delniño en todo momento.No louse
conuna extensión inalámbrica. No quite
estaetiqueta.
Risque
d’étranglement
Riesgode
estrangulación
Strangulation
Hazard
Keepthis cordout of reach of children.
Thecordneeds to be at leastthree feet
awayfromthe child atall times.Do not
usewithan extension cord.Do not
removethistag.
Éloignezcecordondesenfants.Le
cordondoitsetrouverà au moins trois
piedsd’unenfant etce,entouttemps.
N’utilisezpasderallonge.Neretirezpas
cetteétiquette.
Mantengaestecablefueradelaalcance
delos niños. Estecabledebe estarpor
lomenostrespiesfuera de la alcance
delniño en todo momento.No louse
conuna extensióninalámbrica. No quite
estaetiqueta.
Risque
d’étranglement
Riesgode
estrangulación
1> 3 ft
(1 m)
2
< 6.5 ft (2m)
> 6.5 ft (2m)
123
Go to www.vtechcanada.com
for the latest VTech product news.
User’s manual
(Canada version)
For more support information
S
m
Congratulations
on purchasing your new VTech product. Before using this product, please read Important
safety instructions.
This manual has all the feature operations and troubleshooting necessary to install and
operate your new VTech product. Please review this manual thoroughly to ensure proper
installation and operation of this innovative and feature-rich VTech product.
For support, shopping, and everything new at VTech, visit our website at
www.vtechcanada.com.

Baby monitor lights and tones
Parent unit lights
POWER / LINK POWER / LINK light
• Lights off when the parent unit is off.
• Lights on in green when the parent unit is on and linked to the baby unit.
• Flashes in green when there is no link between the baby unit and parent
unit, or when the parent unit is out of range from the baby unit.
Visual sound indicator
The visual sound indicator has two functions. One is to show the sound level
detected by the baby unit. The other one is to show the volume level during
speaker volume setting.
Sound level detected by the baby unit
• One to three green lights indicate a moderate sound level detected by
the baby unit.
• Additional red lights indicate a higher sound level detected by the baby
unit (e.g. baby crying loudly).
Speaker volume level
• One to three green lights indicate Level 1 to Level 3 of the speaker
volume setting.
• Additional red lights indicate Level 4 to Level 5 of the speaker volume
setting.
Flashes in red when the battery is low.
Parent unit alert tones
Low battery tone • Beeps twice every 10 minutes when the battery is low.
Out of range tone • Beeps three times every 30 seconds when there is no link between the
baby unit and parent unit, or when the parent unit is out of range from
the baby unit.
To keep this product working well and looking good, follow these guidelines:
• Avoid putting it near heating appliances and devices that generate electrical noise (for example, motors or
fluorescent lamps).
• DO NOT expose it to direct sunlight or moisture.
• Avoid dropping the product or treating it roughly.
• Clean with a soft cloth.
• DO NOT immerse the parent unit and the baby unit in water and do not clean them under the tap.
• DO NOT use cleaning spray or liquid cleaners.
• Make sure the baby unit and parent unit are dry before you connect them to the mains again.
When you are not going to use the baby monitor for some time, store the parent unit, the baby unit and the adapters
in a cool and dry place.
Below are the questions most frequently asked about the baby monitor. If you cannot find the answer to your question,
visit our website at www.vtechcanada.com, or contact 1 [phone] for customer service.
Why doesn’t the POWER
light on the baby unit turn
on when I switch on the
units?
Perhaps the baby unit is not connected to the power supply.
Connect the baby unit to power supply. The baby unit turns on.
Why doesn’t the POWER
/ LINK light on the parent
unit turn on when I switch
on the units?
Perhaps the battery of the parent unit is depleted and the parent unit is not connected to
power supply. Connect the parent unit to power supply and charge the parent unit battery.
The parent unit turns on and establishes connection with the baby unit.
Why does the baby
monitor not respond
normally?
Try the following (in the order listed) for common cure:
1. Make sure that both baby unit and parent unit are on. Disconnect the power from the
baby unit and the parent unit.
2. Remove the battery from the parent unit.
3. Connect the baby unit to the power supply again. The baby unit turns on.
4. Connect the parent unit to the power supply again. The parent unit turns on.
5. Wait for the parent unit to synchronize with the baby unit. Allow up to one minute for this
to take place.
6. Press or to adjust the speaker volume on the parent unit.
Why does the baby
monitor produce a high-
pitched noise?
The units may be too close to each other. Make sure the parent unit and the baby unit at
least 6.5 feet / 2 meters away from each other.
Why don’t I hear a sound/
Why can’t I hear my baby
cry?
Make sure that both baby unit and parent unit are on. If you see the visual sound indicators
light up, but there is no sound, then you may have muted the volume or set it to a lower
level. Adjust the volume to a higher level.
If the visual sound indicators do not light up, and you cannot hear any sound, it is because
the baby sound is too low for the baby unit to detect. This is normal. Place the baby unit at
least 6.5 feet / 2 meters away from your baby.
Why does the parent unit
beep?
The parent unit beeps three times every 30 seconds when the baby unit is out of range. Move
the parent unit closer to the baby unit (but not less than 6.5 feet / 2 meters).
The parent unit beeps twice every 10 minutes and the light flashes in red when the
battery is low. Connect the parent unit to the power supply and charge the battery for at
least 30 minutes.
Why does the parent unit
light flash?
The parent unit beeps twice every 10 minutes and the light flashes in red when the
battery is low. Connect the parent unit to the power supply and charge the battery for at
least 30 minutes.
Why can’t I establish a
connection? Why is the
connection lost every now
and then? Why are there
sound interruptions?
The baby unit may be out of range. Move the parent unit closer to the baby unit (but not less
than 6.5 feet / 2 meters).
Other electronic products may cause interference with your baby monitor. Try installing your
baby monitor as far away from these electronic devices as possible.
Frequently asked questions
General product care
Storage
What does this limited warranty cover?
The manufacturer of this VTech Product warrants to the
holder of a valid proof of purchase (“Consumer” or “you”)
that the Product and all accessories provided in the sales
package (“Product”) are free from defects in material
and workmanship, pursuant to the following terms and
conditions, when installed and used normally and in
accordance with the Product operating instructions. This
limited warranty extends only to the Consumer for Products
purchased and used in the United States of America and
Canada.
What will VTech do if the Product is not free from defects
in materials and workmanship during the limited warranty
period (“Materially Defective Product”)?
During the limited warranty period, VTech’s authorized service
representative will repair or replace at VTech’s option, without
charge, a Materially Defective Product. If we repair the
Product, we may use new or refurbished replacement parts.
If we choose to replace the Product, we may replace it with
a new or refurbished Product of the same or similar design.
We will retain defective parts, modules, or equipment.
Repair or replacement of the Product, at VTech’s option,
is your exclusive remedy. VTech will return the repaired
or replacement Products to you in working condition.
You should expect the repair or replacement to take
approximately 30 days.
How long is the limited warranty period?
The limited warranty period for the Product extends for
ONE (1) YEAR from the date of purchase. If VTech repairs or
replaces a Materially Defective Product under the terms of
this limited warranty, this limited warranty also applies to the
repaired or replacement Product for a period of either (a)
90 days from the date the repaired or replacement Product
is shipped to you or (b) the time remaining on the original
one-year warranty; whichever is longer.
What is not covered by this limited warranty?
This limited warranty does not cover:
1. Product that has been subjected to misuse, accident,
shipping or other physical damage, improper installation,
abnormal operation or handling, neglect, inundation, fire,
water or other liquid intrusion; or
2. Product that has been damaged due to repair, alteration
or modification by anyone other than an authorized
service representative of VTech; or
3. Product to the extent that the problem experienced is
caused by signal conditions, network reliability, or cable or
antenna systems; or
4. Product to the extent that the problem is caused by use
with non-VTech accessories; or
5. Product whose warranty/quality stickers, product serial
number plates or electronic serial numbers have been
removed, altered or rendered illegible; or
6. Product purchased, used, serviced, or shipped for repair
from outside the United States of America or Canada, or
used for commercial or institutional purposes (including
but not limited to Products used for rental purposes); or
7. Product returned without a valid proof of purchase (see
item 2 on the following part); or
8. Charges for installation or set up, adjustment of customer
controls, and installation or repair of systems outside the
unit.
How do you get warranty service?
To obtain warranty service in Canada, please visit our
website at www.vtechcanada.com or call 1 [phone].
NOTE: Before calling for service, please review the user’s
manual - a check of the Product’s controls and features may
save you a service call.
Except as provided by applicable law, you assume the risk
of loss or damage during transit and transportation and are
responsible for delivery or handling charges incurred in the
transport of the Product(s) to the service location. VTech
will return repaired or replaced Product under this limited
warranty. Transportation, delivery or handling charges are
prepaid. VTech assumes no risk for damage or loss of the
Product in transit. If the Product failure is not covered by
this limited warranty, or proof of purchase does not meet
the terms of this limited warranty, VTech will notify you and
will request that you authorize the cost of repair prior to any
further repair activity. You must pay for the cost of repair and
return shipping costs for the repair of Products that are not
covered by this limited warranty.
What must you return with the Product to get warranty
service?
1. Return the entire original package and contents including
the Product to the VTech service location along with a
description of the malfunction or difficulty; and
2. Include a “valid proof of purchase” (sales receipt)
identifying the Product purchased (Product model) and
the date of purchase or receipt; and
3. Provide your name, complete and correct mailing
address, and telephone number.
Other limitations
This warranty is the complete and exclusive agreement
between you and VTech. It supersedes all other written or
oral communications related to this Product. VTech provides
no other warranties for this Product. The warranty exclusively
describes all of VTech’s responsibilities regarding the
Product. There are no other express warranties. No one is
authorized to make modifications to this limited warranty and
you should not rely on any such modification. State/Provincial
Law Rights: This warranty gives you specific legal rights, and
you may also have other rights, which vary from state to state
or province to province.
Limitations: Implied warranties, including those of fitness
for a particular purpose and merchantability (an unwritten
warranty that the Product is fit for ordinary use) are limited
to one year from the date of purchase. Some states/
provinces do not allow limitations on how long an implied
warranty lasts, so the above limitation may not apply to you.
In no event shall VTech be liable for any indirect, special,
incidental, consequential, or similar damages (including,
but not limited to lost profits or revenue, inability to use
the Product or other associated equipment, the cost of
substitute equipment, and claims by third parties) resulting
from the use of this Product. Some states/provinces
do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitation or exclusion
may not apply to you.
Please retain your original sales receipt as proof of
purchase.
FCC Part 15
This equipment has been tested and found to comply with the requirements for a Class B digital device under Part 15 of the
Federal Communications Commission (FCC) rules. These requirements are intended to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
WARNING: Changes or modifications to this equipment not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
To ensure safety of users, the FCC has established criteria for the amount of radio frequency energy that can be safely absorbed
by a user or bystander according to the intended usage of the product. This product has been tested and found to comply with
the FCC criteria. Caution: This Transmitter must be installed to provide a separation distance of at least 20cm from all persons.
The transmitter and antenna of the parent unit shall be held at least 1 in (2.5 cm) from your face.
This Class B digital apparatus complies with Canadian requirement:
CAN ICES-3 (B)/NMB-3(B)
Industry Canada
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic
Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference that may cause undesired operation of the device.
The term ‘’IC:‘’ before the certification/registration number only signifies that the Industry Canada technical specifications
were met.
This product meets the applicable Innovation, Science and Economic Development Canada technical specifications.
FCC RF radiation exposure statement
Caution: This Transmitter must be installed to provide a separation distance of at least 20cm from all persons. Use of other
accessories may not ensure compliance with FCC RF exposure guidelines. This transmitter must not be co-located or operating
in conjunction with any other antenna or transmitter. This equipment complies also with Industry Canada RSS-102 with respect to
Canada’s Health Code 6 for Exposure of Humans to RF Fields.
Limited warranty
FCC and IC regulations
Operating range
This product operates with the maximum power allowed by the Federal Communications Commission (FCC). Even so,
the baby unit and the parent unit can communicate over only a certain distance - which can vary with the locations of the
baby unit, the parent unit, the weather, and the layout of your home. When the parent unit is out of range, it will beep
three times every 30 seconds and enter searching mode. To improve reception, move closer to the baby unit (but not
less than 6.5 feet / 2 meters).
The RBRC® seal
Baby unit overview
1(On/off)
Press and hold to turn on or off the baby unit.
2Microphone
3POWER light
4Power jack
Parent unit overview
1 Speaker
2(On/off)
Press and hold to turn on or off the
parent unit.
3(Volume up)
Press to increase the speaker volume.
4POWER / LINK light
5Power jack
6Visual sound indicator
Indicate the sound level detected by
the baby unit or show the volume level
during speaker volume setting.
7(Volume down)
• Press to decrease the speaker volume.
• Press repeatedly until the volume
reaches the minimum to mute the
parent unit.
8(Battery indicator light)
9Belt clip
10 Battery compartment cover
1
3
4
5
6
7
8
2
9
10
Baby unit light
POWER POWER light
• Lights off when the baby unit is off.
• Lights on in green when the baby unit is on.
The RBRC®seal on the Ni-MH battery indicates that VTech Communications, Inc. is voluntarily
participating in an industry program to collect and recycle these batteries at the end of their useful lives,
when taken out of service within the United States and Canada.
The RBRC®program provides a convenient alternative to placing used Ni-MH batteries into the trash or
municipal waste, which may be illegal in your area.
VTech’s participation in RBRC®makes it easy for you to drop off the spent battery at local retailers
participating in the RBRC®program or at authorized VTech product service centers. Please call
1 (800) 8 BATTERY®for information on Ni-MH battery recycling and disposal bans/restrictions in your area. VTech’s
involvement in this program is part of its commitment to protecting our environment and conserving natural resources.
RBRC® seal and 1-800-8-BATTERY® are registered trademarks of Call2recycle, Inc.
