V-ZUG Adora SLQ WP User manual

Operating instructions
Adora SLQ WP
Washing machine

2
© V-ZUG Ltd, CH-6302 Zug, 2016

3
Contents
1Appliance description 7
1.1 Appliance construction ...................................... 7
1.2 Indicator lights and button state ...................... 7
1.3 Operating and display elements...................... 8
2Programme overview 9
2.1 Whites and coloureds programmes................ 9
2.2 Standard and extra programmes..................... 9
2.3 Fabric types .......................................................10
2.4 Additional functions.......................................... 11
2.5 EcoManagement...............................................13
3Operating the appliance 14
3.1 Preparations.......................................................14
3.2 Loading the washing ........................................ 14
3.3 Adding washing detergent.............................. 15
3.4 Detergent dosage ............................................. 16
3.5 Dyeing textiles ...................................................16
3.6 Selecting programme.......................................16
3.7 Selecting additional functions.........................18
3.8 EcoHybrid........................................................... 18
3.9 Delayed start......................................................19
3.10 OptiTime .............................................................20
3.11 Separate rinsing / Separate spinning...........20
3.12 Bio wash / Soap wash.....................................21
3.13 Correcting entry.................................................21
3.14 Aborting a programme ....................................21
3.15 With childproof lock activated ........................22
3.16 Opening the appliance door during
washing...............................................................23
3.17 End of programme ...........................................23
3.18 EcoManagement statistics ..............................25
4Favourites 26
4.1 Defining favourites ............................................26
4.2 Changing favourites ..........................................26
4.3 Deleting favourites.............................................27
4.4 Starting favourites..............................................27
5User settings 28
6Care and maintenance 32
6.1 Cleaning the detergent dispenser drawer (as
required)..............................................................32
6.2 Cleaning the water inlet filter...........................32
6.3 Emergency draining ..........................................33
6.4 Cleaning the foreign body trap .......................34
6.5 Opening the appliance door in the event
of a power failure...............................................35
7Trouble-shooting 36
7.1 Error messages..................................................36
7.2 Other possible problems .................................39
7.3 Unsatisfactory wash results.............................40
8Spare parts 42
9Technical data 43
9.1 Noise values .......................................................43
9.2 Note for testing institutes .................................43
9.3 Consumption values .........................................44
9.4 VAS Vibration Absorbing System...................45
9.5 Water and energy economy ............................45
10 Washing tips 45
10.1 Energy and water economy.............................45
10.2 Avoiding damage ..............................................46
11 Disposal 47
Quick instructions 48

Safety precautions
Read the operating instructions before
using the appliance for the first time.
General safety precautions
▪This appliance can be used
by children aged8 and above
and by persons with reduced
physical, sensory or mental
capabilities, or lack of experi-
ence and/or knowledge,
provided they are supervised
or have been instructed on
the safe use of the appliance
and have understood the haz-
ards involved. Children must
not play with the appliance.
Cleaning and user mainten-
ance shall not be undertaken
by children without supervi-
sion.
▪If an appliance is not
equipped with a mains cable
and a plug or other means for
disconnecting from the mains
with a contact opening on
each pole complying with the
conditions of overvoltage cat-
egory III for full isolation, an
isolating device must be in-
corporated into the perman-
ently installed electrical install-
ation in accordance with the
installation regulations.
▪If the mains cable of this ap-
pliance is damaged, it must
be replaced by the manufac-
turer or its Customer Services
or a similarly qualified person
in order to avoid hazard.
Appliance-specific safety
precautions
▪Children under 3 years of age
must be kept away from the
appliance unless they are
constantly supervised.
▪The appliance has a max-
imum dry load capacity of
8 kg.
Instructions for use
▪If connected to the water mains by de-
tachable hoses, the new hose set sup-
plied with the appliance must be used. Do
not reuse old hose sets.
▪Ensure ready access to the power socket
being used.
▪Any repairs, modifications or manipula-
tions to the appliance, especially any elec-
trically live parts, may only be carried out
by the manufacturer, its customer service
department or similarly qualified persons.
Repairs if carried out incorrectly may
cause serious injury, damage to the appli-
ance and fittings, as well as affect the
4

Safety precautions
5
functioning of the appliance. If the appli-
ance is not working properly or in case a
repair is needed, follow the instructions
given in the «Service and repairs» section.
Please contact our Customer Services if
necessary.
▪Before closing the appliance door and
starting a programme, ensure that there
are no foreign objects or pets in the drum.
▪Strictly use original spare parts only.
▪If the appliance is not functioning properly,
disconnect it from the power supply im-
mediately.
▪Packaging material, e.g. plastic film and
polystyrene, can be dangerous for chil-
dren. Danger of suffocation! Keep pack-
aging material away from children.
▪To protect your washing, follow the fabric
care symbols and the hints and advice in
the «Washing tips» section.
▪Textiles that have been cleaned, treated
or soaked with flammable chemicals, de-
tergents or solvents such as benzene, al-
cohol, stain remover, oil, paint, wax, etc.
are not to be washed in the appliance.
Fire or explosion hazard! Wash materials
containing such substances first by hand
with water or allow the solvent to evapor-
ate completely.
▪Ensure the washing drum has stopped
moving before reaching inside. Do not
touch the washing drum while it is still in
motion – risk of serious injury!
▪Disconnect the appliance from the mains
before carrying out maintenance work.
Correct use
The appliance is only suitable for washing
home textiles with water and regular washing
machine detergent. It is designed for use in
the home and for the above-mentioned pur-
pose only. No liability is assumed for any
damage caused by improper or incorrect
use.
How to avoid damaging the
appliance
▪Close the appliance door carefully.
▪Before closing the appliance door and
starting a programme, ensure that there
are no foreign objects or pets in the wash-
ing drum, detergent dispenser drawer or
around the foreign body trap. Foreign ob-
jects such as coins, nails, paper clips, etc.
can damage parts of the appliance as
well as the washing.
▪During longer periods of absence, turn off
the water tap before switching off the
power by pulling out the mains plug.
Never pull the mains plug out by the
cable. Please note: The built-in overflow
protection is rendered inactive when the
power is switched off.
▪When cleaning the appliance make sure
no water gets inside it. Use a moderately
damp cloth. Do not spray the outside or
the inside of the appliance with water. If
water gets inside the appliance, it will
cause damage.
▪Textiles with metal reinforcements are not
to be washed in the appliance Risk of
damage.
▪Trainers, diving suits, rucksacks, carpets,
etc. are not to be washed in the appli-
ance.

Safety precautions
6
Using for the first time
The appliance must be installed and
connected to the electricity supply by a
qualified fitter/electrician in accordance
with the separate installation instruc-
tions.
Transport lock
Remove the transport lock (hexagon
head screws at the back of the appli-
ance) in order to avoid damage to the
appliance (see installation instructions).
Running the first wash cycle without any
washing
▸ Add a little washing detergent to compart-
ment II.
▸ Run an empty coloureds 60°C cycle to
remove any residues from the manufactur-
ing process.
Serial number
The serial number (SN) is located on the
identification plate:
▸ Note down the SN on the back page of
these operating instructions.
The SN can also be retrieved as follows:
▸Hold the button depressed until the
following display appears:
Settings
SN 12006 000123
Note on the operating instructions
For more information on your appliance and
for answers to frequently asked questions,
visit http://www.vzug.com.
Symbols used
Denotes important safety precautions.
Failure to observe said precautions can res-
ult in injury or in damage to the appliance or
fittings!
Validity
The product family (model number) corres-
ponds to the first alphanumerics on the iden-
tification plate. These operating instructions
apply to:
Model Adora SLQ WP
Type WAASLQWPZ
Product family 11014
Variations depending on the model are noted
in the text.
Modifications
Text, diagrams and data correspond to the
technical standard of the appliance at the
time these operating instructions went to
press. The right to make technical modifica-
tions for the purpose of the further develop-
ment of the appliances is reserved.
Colour operating instructions can be down-
loaded from the internet from www.vzug.com.

1 Appliance description
1.1 Appliance construction
6
7
8
9
10
12
13
14
11
1
2
3
4
5
Detergent dispenser
drawer (2)
Drain tray (5)
1Pivoting operating panel 8Fabric conditioner, compartment
2Detergent dispenser drawer 9Liquid detergent flap / drain tray opener
3Appliance door 10 Siphon for fabric conditioner
4Circulation nozzle 11 Emergency door release tool
5Drain tray 12 Foreign body trap
6Pre-wash detergent, compartment I 13 Identification plate / serial number (SN)
7Main wash detergent, compartment II 14 Emergency door release
1.2 Indicator lights and button state
Indicator lights Button state
Illuminated: relevant function
active
Blue background: relevant
function active
Off: relevant function not
selectable
Black button: relevant function not
selectable
Flashing: relevant function
selectable
Black background: relevant
function selectable
7

1 Appliance description
1.3 Operating and display elements
1
4
5
6 78
9
10
2
Coloureds
Select temperature
3
cold
1Door opener 7Whites and co-
1 h 00
End 16 : 13
60°C Coloureds
800
1 h 00
End 16 : 13
60°C Coloureds
800
11
2TouchDisplay loureds programmes
3Fabric types 8Standard and
4Start/Pause extra programmes
5Fast forward/ 9Eco (see
End of programme additional functions)
6Favourites 10 EcoManagement
11 Additional functions
Whites and co- Standard and Additional functions
loureds programmes extra programmes Eco (9)
Whites 95°C Standard 60°C Sprint
Coloureds 70°C Steam anti-crease Easy care
Coloureds 60°C Proofing Pre-wash
Coloureds 50°C Appliance hygiene Steam anti-crease
Coloureds 40°C Spinning Spin speed
Coloureds 30°C Degree of soiling,
Coloureds 20°C Anti-mite
cold
Coloureds 10°C AquaPlus
Delayed start incl.
OptiTime
8

2 Programme overview
2 Programme overview
To select the right programme, please follow the fabric care symbols on the laundry labels,
e.g.
40
. woollens and textiles with the fabric care label may only be washed using the
additional function «Hand wash».
2.1 Whites and coloureds programmes
Buttons Programmes Fabric care
symbols
Load
capacity
Whites 95°C: For white cottons/linens e.g. bed and
table linen, towels, white or colour-fast underwear.
95
1–8 kg
Coloureds 70°C: Energy-saving programme for
white cottons.
95
1–8 kg
Coloureds 60°C: For coloured cottons e.g. bright
blouses, overalls, shirts, bed linen.
60
,
95
1–8 kg
Coloureds 50°C: Energy-saving programme for col-
oured cottons.
60
,
95
1–8 kg
Coloureds 40°C: For coloured cottons and mixed
washing e.g. coloured sweatshirts, t-shirts.
40
,
60
,
95
1–8 kg
Coloureds 30°C: For coloured cottons and mixed
washing e.g. t-shirts.
30
,
40
,
60
,
95
1–8 kg
Coloureds 20°C: Energy-saving programme for
lightly soiled textiles.
30
,
40
,
60
,
95
1–8 kg
cold
Coloureds 10°C: Refresh programme without heat,
suitable for washing new clothes for the first time.
30
,
40
,
60
,
95
1–8 kg
2.2 Standard and extra programmes
Buttons Programmes Fabric care
symbols
Load
capacity
+Standard 60°C: The standard programme
is used for normally soiled load.
60
1–8 kg
+Steam anti-crease: Dry washing is partially
uncreased and made damp, ready to iron.
40
,
60
,
95
1–1.5 kg
+Proofing: For starching or proofing laundry, add the agent
to the fabric conditioner compartment.
1–3 kg
+Appliance hygiene: Steam cleaning without laundry. 0 kg
+Spin: Wet washing is spun. No wash cycle is carried out. 1–8 kg
9

2 Programme overview
2.3 Fabric types
Buttons Programmes Load
capacity
+Coloureds: Standard programme 1–8 kg
Shirts: Optimized for minimizing creasing, contains steam
anti-crease.
max.7items
Woollens: Gentle treatment for woollens and other delic-
ate textiles. Only for woollens with a felt-free finish and la-
belled as «machine washable».
1–2.5 kg
Hand wash: Very gentle treatment for textiles labelled with
the fabric care symbol.
1–2 kg
+Down: Optimized for the particular wetting characteristics
of down fabrics. Short spin at the beginning of the pro-
gramme to get rid of any air in down textiles.
max. 1 kg
Outdoor garments: For waterproof and breathable cloth-
ing. Higher water level during washing and spinning.
1–3 kg
Silks: For delicate silk articles. Spin speed is reduced to
minimize creasing.
1–1.5 kg
Underwear: For very delicate textiles labelled with the
fabric care symbol e.g. underwear.
1–3 kg
+Baby garments: Very thorough rinsing for the protection
of sensitive baby skin. If 95°C is selected as the temper-
ature, a pre-wash is included.
1–5 kg
Denim: Optimized for colour run from denim. 1–4 kg
WetClean: For all fabrics labelled as washable. Most
gentle treatment possible through applying a gentle rock-
ing motion and a fine spray of water.
1–1.5 kg
Net curtains: Reduced washing action for very gentle
treatment. Higher water level during washing and spin-
ning. The washing remains lying in the water after the final
rinse (stop after rinsing).
1–2 kg
+ 1x Draining with spinning
+ 2x Draining without spinning
+Black garments: Optimized rinsing through a higher water
level and extended rinsing time for dark textiles.
1–4 kg
Black hand wash: Optimized rinsing through a higher wa-
ter level and extended rinsing time for dark textiles la-
belled with the fabric care symbol.
1–2 kg
10

2 Programme overview
2.4 Additional functions
Buttons Additional functions Load
capacity
EcoHybrid: The appliance is equipped with two heating systems:
▪Heat pump heater (approximately 1kW heat output) with very low energy con-
sumption. Suitable for heating up to 50°C.
▪Conventional auxiliary heater (approximately 2.8kW heat output) with normal en-
ergy consumption.
Optimal energy efficiency: Initially heated only using the heat pump heater.
The conventional heater comes on at around 40–50°C. The set temperat-
ure is also reduced. The extended washing time, however, ensures the
washing performance is maintained. The energy consumed to heat the wa-
ter is around 50–70% lower than with conventional washing machines
without a heat pump.
Very good energy efficiency: Initially heated only using the heat pump
heater. The conventional heater comes on at around 40–50°C. It takes
longer to reach the desired wash temperature. The energy consumed to
heat the water is around 40–50% lower than with conventional washing
machines without a heat pump.
Good energy efficiency: Heating using both heating systems simultan-
eously. This provides a high heat energy output. The energy consumed to
heat the water is around 10–20% lower than with conventional washing
machines without a heat pump.
Sprint: Short programme for lightly soiled washing. 2 instead of 3
rinsing cycles. The programme time is for the EcoHybrid setting
:
2.5 kg
+ : 26mins. + : 28mins.
+ : 27mins. + : 39mins.
Note: Add a small quantity of washing detergent. A large washing
load or too much washing detergent can significantly extend the
programme time. Use liquid detergent only.
Easy care: For washing requiring very gentle treatment. Increased
water level, reduced washing action and lower spin speed.
3.5kg
Pre-wash: Suitable for heavily soiled washing. Programme duration extended about
15minutes.
Steam anti-crease: Reduces creasing significantly. Loosening-up
period: 60minutes. The washing is warm and should be hung up
immediately to dry or be tumble dried. The spin speed is limited to
1000 rpm.
max. 2 kg
11

2 Programme overview
Spin speed: The spin speed can be changed. Delicates can be spun at a lower spin
speed. However, this increases the drying time (greater energy consumption for
tumble drying).
Buttons Additional functions
Degree of soiling: Adjustment to the degree of soiling of the washing.
Light soiling: For lightly soiled washing.
Normal soiling: Extended wash time.
Heavy soiling: Extended wash time, higher water level, an additional rins-
ing cycle.
Soaking: The duration can be set between 0.5 and 6 hours.
Anti-mite: The main wash is extended and intensified. The mites are killed
and the allergens are rinsed out thoroughly.
AquaPlus: There are 5 different settings for rinsing intensity.
Standard: Normal water level.
more water: Increased water level during the main wash and rinsing.
+ 1 rinse: An additional rinsing cycle.
more water + 1 rinse: Increased water level during the main wash and rins-
ing, an additional rinsing cycle.
Skin protection: Increased water level during rinsing, two additional rinsing
cycles. Suitable for sensitive skin.
Delayed start: For using cheap-rate electricity (setting range of up to 24hours). The
programme starts automatically when the set time is reached.
OptiTime: If a programme end time has been selected, OptiTime calculates the
most energy-efficient programme that can be carried out in the time remaining to
programme end. OptiTime reduces the washing temperature, while the washing per-
formance is maintained. The more time is available for washing, the more the wash-
ing temperature can be reduced. If higher wash temperatures with a germ-killing ef-
fect are needed, a corresponding programme without the OptiTime function must
be selected.
Separate rinsing / Separate spinning: The programme starts at the desired parts of
the programme and the programme sequence is shortened (see page 20).
Bio wash (alkaline detergent + bleach) /
Soap wash (water softener + soap detergent): The programme sequence is adapted
for the use of multi-component detergents (see page 21).
Start/Pause: Touch the button to start or interrupt programmes. Touch the button
again to resume the programme after being interrupted.
12

2 Programme overview
2.5 EcoManagement
Only active if «EcoManagement» is turned on in the user settings.
EcoManagement provides information on the energy and water consumption of
the appliance and supports the sustainable use of energy. The following con-
sumption information can only be retrieved when no programme is running:
▪Energy and water consumption of the last programme
▪Total energy and water consumption
▪Average energy and water consumption of the last 25 programmes
The energy and water consumption of a programme is displayed during pro-
gramme selection. At the end of a programme, the energy and water consump-
tion of the last programme run is displayed.
The values can vary according to programme, load, additional functions and user
settings.
13

3 Operating the appliance
3 Operating the appliance
3.1 Preparations
▸ Check the foreign body trap is inserted correctly.
▸ Insert the mains plug into a suitable mains socket.
▸ Turn on water tap.
▸ Press the button to open the appliance door.
3.2 Loading the washing
▸ Load up to a maximum of 8kg dry washing.
full: Normally soiled whites and coloureds
max. ¾: Heavily soiled whites and coloureds
max. ½: Easy care cottons, white and coloured
synthetics as well as mixed fabrics
max. ¼: Delicates, woollens, silks, polyacrylics
and net curtains
Note: For wet loads, only half-fill the washing drum. The washing drum should not be loaded
with any one single, heavy item.
▸ Close the appliance door firmly.
If no programme selection is made within
5minutes, all the displays go out. Touch any-
where on the TouchDisplay at any time to display
the start screen again.
cold
Coloureds
Select temperature
14

3 Operating the appliance
3.3 Adding washing detergent
Liquid detergent Powder detergent
▸ Pull the detergent dis-
penser drawer out as far
as it will go.
▸ Pull the detergent dis-
penser drawer out as far
as it will go.
a
1
▸ Pull flap a upwards and out
and insert into
position 1.
2a
▸ Pull flap a upwards and out
and insert into
position 2.
Note: Liquid detergent
▪Do not fill past the upper mark.
▪Only use for main wash with programmes without a pre-wash.
▪Only use for temperatures of up to 60°C.
▪If washing with a delayed start, add to a dosing aid (e.g. ball) and place it directly in the
washing drum so that no detergent gets onto the washing during the delayed start time.
Compartments
Conventional washing
III
Pre-wash detergent Compartment I
Main wash detergent Compartment II
Fabric conditioner Compartment
Bio wash
Alkaline detergent Compartment II
Bleach Compartment I
Fabric conditioner Compartment
Soap wash
Water softener Compartment I
Soap detergent Compartment II
Fabric conditioner Compartment
Note: Do not fill fabric conditioner past the upper mark.
15

3 Operating the appliance
3.4 Detergent dosage
Adding too much washing detergent can cause excess foaming, The con-
sequences: poor wash results, damage to the appliance in the worst case.
The correct dosage depends on the degree of soiling, the wash load, the water hardness and
the product used. Follow the manufacturer’s dosing instructions.
Water hardness
Soft 0°fH to 15°fH The local water authorities can provide
information on the level of water hard-
ness in your area.
Medium 15°fH to 25°fH
Hard over 25°fH
After adding the washing detergent
▸ Push the detergent dispenser drawer back in.
▸ Select a programme.
3.5 Dyeing textiles
Textiles can be dyed in the appliance using suitable dyeing agents. Follow the manufacturer’s
safety instructions and warnings.
Note: Each wash programme starts with brief draining. Add liquid dye components after this.
3.6 Selecting programme
Main wash programmes
When a programme is selected, all the necessary settings for it are assigned automatically.
Additional functions can be selected or deselected by using further buttons in other views.
▸ Close the appliance door.
cold
Coloureds
Select temperature
The start screen appears.
16

3 Operating the appliance
60
▸ Touch the button for the de-
sired programme.
1200
1 h 00
End 16 : 13
60°C Coloureds
The programme selected, the
expected duration, the expec-
ted programme end time and
the selectable additional func-
tions are displayed. The indic-
ator light for the selectable
button flashes.
▸ Touch the button.
The programme selected
starts.
Fabric programmes
▸ Touch the button.
Fabric selection
Coloureds
Hand washWoollens
Shirts
The adjacent TouchDisplay ap-
pears.
▸ Touch the button repeatedly
until the desired fabric type ap-
pears in the TouchDisplay.
Shirts
▸ Touch the button for the de-
sired fabric type.
60
▸ Touch the button for the de-
sired temperature.
▸ Touch the button.
The programme selected starts.
Standard and extra programmes
▸ Close the appliance door.
Steam anti-crease
60° Standard
Appliance hygieneSpin
Proofing
Extra
▸ Touch the button.
The adjacent TouchDisplay ap-
pears.
▸ Touch the button for the de-
sired standard or extra pro-
gramme.
▸ Touch the button.
The programme selected starts.
17

3 Operating the appliance
3.7 Selecting additional functions
60
▸ Touch the button for the de-
sired programme.
1200
1 h 00
End 16 : 13
60°C Coloureds
The programme selected ap-
pears. All selectable additional
functions are displayed. The in-
dicator light for the selectable
button flashes.
▸ For desired additional functions, touch the corresponding buttons.
The new programme duration and programme end time are displayed
▸ Touch the button.
The programme selected starts.
3.8 EcoHybrid
▸ Touch the button while the in-
dicator light is flashing. The ad-
jacent TouchDisplay appears.
EcoHybrid
Optimal
energy efficiency
Very good
energy efficiency
Good
energy efficiency
e
e
e
e
n
n
n
n
e
e
e
e
r
r
r
r
g
g
g
g
g
g
g
g
g
y
y
y
y
y
y
y
y
y
e
e
e
e
ffi
ffi
ffi
ffi
c
c
c
c
i
i
i
i
e
e
e
e
n
n
n
n
c
c
c
c
y
y
y
y
y
y
y
y
y
▸ Touch the button for the de-
sired EcoHybrid setting.
The new programme duration
and time are displayed.
▸ Touch the button.
The programme selected starts.
18

3 Operating the appliance
3.9 Delayed start
Selecting programme end time
The option «Programme end, OptiTime off» must be enabled in the user settings under «Pro-
gramming delayed start / OptiTime» (see page 30).
60
▸ Touch the button for the de-
sired programme.
▸ Touch the button.
81 4 5
Progr. end time
The adjacent TouchDisplay ap-
pears.
81
▸ Enter the time the desired pro-
gramme should end.
▸ Touch the button.
The programme end time is
saved.
▸ Touch the button again if any
changes have to be made.
▸ Touch the button.
The delayed start time starts. The desired programme starts automatically
when the set time is reached.
Selecting programme start time
The option «Programme start» must be enabled in the user settings under «Programming
delayed start». (see page 30)
▸ Carry out steps analogous to those described in «Selecting programme end time».
19

3 Operating the appliance
3.10 OptiTime
The option «Programme end, OptiTime on» must be enabled in the user settings under «Pro-
gramming delayed start / OptiTime» (see page 30).
60
▸ Touch the button for the de-
sired programme.
▸ Touch the button.
81 4 5
Progr. end time
The adjacent TouchDisplay ap-
pears.
81
▸ Enter the time the desired pro-
gramme should end.
▸ Touch the button.
The programme end time is
saved.
▸ Touch the button again if any
changes have to be made.
▸ Touch the button.
The delayed start time starts with the additional function «OptiTime». The de-
sired programme starts automatically when the set time is reached.
3.11 Separate rinsing / Separate spinning
60
▸ Press the button for the desired programme.
▸ Press the button 1x.
Programme starts from «Rinsing» and «Spinning».
▸ Press the button 2x.
Programme starts from «Final rinse / Conditioning» and «Final spin».
▸ Press the button 3x.
Programme starts from «Separate spinning».
20
