V3 SOUND Sonority XXL User manual

Sonority XXL
Manual

HPF High Pass Filter
BPF Band Pass Filter
LPF Low Pass Filter
Notch Notch Filter
(1) DRUM MAP - Exclusive mode - one note give sound
velo. Velocity split
Slide Velocity zone 116-127 Slide up version
Silence no Sound
PROGRAM LIST SOLO SOUNDSLEGEND
1
BANK 22 and higher
If you call up a sound in MSB Bank higher then 22
you get no sound.
SAFETY INSTRUCTIONS
• Read the user manual before using the device
• Do not allow any liquid to come in contact
with the device
• Do not place anything on top of the device
• Do not handle the power supply with wet hands
• Turn off all connected devices before you
connect any new devices
Do not use or store the device where it is
exposed to:
• dampness or wetness
• extreme temperature changes
(i.e. do not store in a vehicle in winter)
• strong vibrations or jolts
HANDLING
• Use only the original cables and power supply
• Remove the cable only by pulling on the plug,
not on the cable
• Do not expose the power adapter to any
mechanical stress
CUSTOMER SERVICE
Do not carry out any repairs at home, as this may
result in permanent damage to the electronics.
Any guarantee claims are no longer valid in this
case.
ACCESSORIES
Manual and power
POWER REQUIREMENT
9VDC / 1.0A
HUMIDITY
max. 80%, non-condensing
OPERATING TEMPERATURE
10 to 40 degrees Celsius

!


All the audio recordings V3SOUND uses on
the sound boards are protected by copyright.
V3SOUND alone has been given the right by all
musicians involved to use this material. Any du-
plication, editing or any other copy of individual
sounds by or given to a third party in any form
(audio sampling CD, data storage device with
individual sounds, download of any file, etc.) is
strictly forbidden.
Copyright © 2019 V3SOUND - Austria
• Master Volume
• Master Reverb
• 4 GB flash memory
• 16 MIDI channels
• 4 audio out (2 stereo)
• Polyphony 256 voice
• Port available for 1 sustain foot pedal
• Dimensions: 12cm (L) x 12cm (W) x 6cm (H)
• Weight: 0.2 kg
• USB Host
The CE certification is available at
http://www.v3sound.com/support/
V3SOUND GMBH
Kirchplatz 7 - 6114 Kolsass - Austria - Europe
This product conforms to the
FCC 47 CFR PART 15
SUBPART B
Safety precautions Copyright
Specification
MIDI-THRU MIDI-IN
POWER ON/OFF USB-HOST
MAIN REVERB
LED - POWER ON
LED - MIDI
MAIN VOLUME
User interface and ports
TIP SILENCE
e program SILENCE can be found on all soundbanks on Program Change 127.
e program allows you to „turn o“ a MIDI channel while playing.
If you want to mute a MIDI channel via a MIDI controller, etc., it is not that easy while playing.
Just choose the Program Change 127 and the channel becomes mute, and can be played back at any time by
sending a Program Change with a sound.

2
To avoid possible damage to the loud speakers or
other connected electronic devices, always con-
nect all cables before turning on the amplifier. Turn
on the SONORITY XXL first before turning on any
active loud speakers or amplifiers.
Make sure the POWER switch on the back
of the device is in the OFF position
(LED light is not on).
Plug the power adapter that came with the
device into the DC port on the back of the unit.
Plug the other end of the power adapter
into a power outlet. Make sure that the
adapter is compatible with the power supply.
Connect the audio outputs to an amplifier,
active loudspeakers or headphones.
Connect the MIDI or USB cable
to the V3 unit.








Before you turn the device on or off, make sure that
all connected audio devices that amplify the audio
signal (mixer, amplifier, active loud speakers) have
their volumes turned down.
Press the POWER ON/OFF switch on the
back of the device.
Turn up the V3 unit MAIN VOLUME
knob to adjust the volume.
Adjust the volume on your mixer or
active loudspeaker.
The V3 unit can be connected to any USB Audio
Class 1 compatible keyboard.
The SONORITY XXL can supply your USB key-
board with a maximum of 500mA.
If your keyboard requires more than 500mA,
you will need an external power supply.
Just plug in your USB keyboard here.
The polarity of the sustain foot pedal is set up
automatically when you turn on the V3 unit.
The pedal only works on MIDI channel 1.
Connect the foot pedal before turning on the
device.
To use the AUX OUT for any MIDI channel, you
must manually change the 4 internal switches
and send a MIDI message on the specied
MIDI channel.
The connection changes from 2 mono jacks to
2 stereo jacks.
One stereo jack gives you the MAIN stereo;
the other one the AUX stereo.
The SONORITY XXL sound board is a 16-chan-
nel, multi-timbral MIDI tone generator.
Change sounds by sending a program change
through MIDI.
Sustain pedal grabbing and the half pedal
function are only active on MIDI channel 1.
HO = Hammer off noise
PD = Pedal noise
V= Number of necessary voices (OSC) per note.
STEREO L + R standard = BABAA (grafic)
STEREO + AUX = BBABB
ABOUT POLYPHONY
e unit oers 256 mono voices. Many sounds of the
Sonority XXL use 6 voices per note.
If you hit 10 notes at the same time, 60 voices are used.
If you hold down the sustain pedal, the 60 voices are
sustained and still in use. If you play again, 60 more
voices are needed.
So, do not forget to release the sustain pedal!
If you exceed the Polyphony, a clicking sound is audible.
Connect To turn on Foot pedal
Aux out - 2nd stereo out
Select sounds
Connect – USB keys
TIP
Turn the volume on the V3 unit as loud as possible,
and then adjust the volume of the sound on your mixer.

PROGRAM LIST SOLO SOUNDS PROGRAM LIST SOLO SOUNDSgENERAL MIDI BANK 0 gENERAL MIDI BANK 0
1 Grand Piano
2 Bright Piano
3 Electric Grand Piano
4 Honky Tonk
5 E-Piano Tines
6 E-Piano FM
7 Harpsichord
8 Clavinet
9 Celesta
10 Glockenspiel
11 Music Box
12 Vibraphon
13 Marimba
14 Xylophon
15 Tubular Bell
16 Dulcimer
17 Drawbar Organ
18 Percussive Organ
19 Rock Organ
20 Church Organ
21 Reed Organ
22 Accordion
23 Harmonica
24 Accordion Tango
25 Nylon Guitar
26 Acoustic Steel
27 Jazz Guitar
28 Guitar clean
29 Guitar mute clean
30 Overdrive Guitar
31 Distortion Guitar
32 Guitar harmonics
65 Sopran Sax
66 Alto Sax
67 Tenor Sax
68 Bariton Sax
69 Oboe
70 English Horn
71 Bassoon
72 Clarinet
73 Piccolo
74 Flute
75 Recorder
76 Pan Flute
77 Blown Bottle
78 Shakuhachi
79 Whistle
80 Ocarina
81 Square Lead
82 Saw Lead
83 Calliope
84 Chiffer Lead
85 Charang
86 Solo Vox
87 5th Saw wave
88 Bass & Lead
89 New Age
90 Warm Pad
91 Polysynth
92 Choir pad
93 Bowed
94 Metallic
95 Halo pad
96 Sweep
97 Rain
98 Soundtrack 5th
99 Crystal
100 Atmosphere
101 Brightness
102 Goblins
103 Echoes
104 Sci-fi Star
105 Sitar
106 Banjo
107 Shamisen
108 Koto
109 Kalimba
110 Bag pipe
111 Fiddle
112 Shanai
113 Tinkle Bell
114 Agogo
115 Steel Drums
116 Woodblock
117 Taiko Drum
118 Melodic Tom
119 Synth Drum
120 Reverse Cymbal
121 Guitar Noise
122 Breath Noise
123 Seashore
124 Bird
125 Telephon
126 Helicopter
127 Applaus
128 Gunshot
33 Upright Jazz Bass
34 E-Bass fingered
35 E-Bass picked
36 Fretless Bass
37 Slap Bass 1
38 Slap Bass 2
39 Synth Bass 1
40 Synth Bass 2
41 Violin
42 Viola
43 Cello
44 Contrabass
45 Tremolo Strings
46 Pizzicato Strings
47 Harp
48 Timpani
49 String Ensemble 1
50 String Ensemble 2
51 Synth Strings 1
52 Synth Strings 2
53 Choir Aahs
54 Voice Dohs
55 Synth Voice
56 Orchestra Hit
57 Trumpet
58 Trombone
59 Tuba
60 Trp. Mute
61 Horn
62 Brass Section
63 Synth Brass 1
64 Synth Brass 2
3

Prg.
00 Grand Piano POLYPHONY
e unit oers 256 mono voices. Some sounds of the So-
nority XXL use 6 voices per note.
If you hit 10 notes at the same time, 60 voices are used.
So, do not forget to release the sustain pedal!
If you exceed the Polyphony, a clicking sound is audible.
01 Grand Piano & Pedal down Resonance
02 Rock Piano
03 Rock Piano & Pedal down Resonance
04 Classic Grand Piano
05 Classic Grand Piano & Pedal dw. Resonance
06 Honky Tonk
07 Grand Latin Octave
08 Upright Piano
09 Grand Piano Layered EP-FM
10 Grand Piano Layered E-Piano
11 Grand Piano Layered Pad
12 Grand Piano Layered Strings
127 Silence - no sound
Prg.
18 E-Piano DX Classic
19 E-Piano FM
20 E-Piano FM Layered Bell
21 E-Piano FM Filter
22 E-Piano FM Note-off
23 E-Piano FM Layered MKS
24 E-Piano FM Vibrato 1
25 E-Piano FM Vibrato 2
26 E-Piano FM Layered Bell
27 E-Piano FM Layered Bell & Pad
127 Silence - no sound
Prg.
0 Electric Grand
1 Electric Grand Vibrato 1
2 Electric Grand Vibrato 2
3 Electric Grand Layered Pad
4 E-Piano MK1 Classic
5 E-Piano MK1 Classic soft
6 E-Piano MK1 Classic Layered MKS
7 E-Piano MK1 Classic Vibrato 1
8 E-Piano MK1 Classic Layered Bell
9 E-Piano MK1 Classic Layered EP-FM
10 E-Piano MK1 Classic Layered Pad
11 E-Piano V3 Bella
12 E-Piano V3 Bella Note-off 1 Octave up
13 E-Piano V3 Bella Layered Cortales
14 E-Piano V3 Bella Layered Pad
15 E-Piano Wurl. A200
16 E-Piano Wurl. A200 Vibrato 1
17 E-Piano Wurl. A200 Vibrato 2
Bank MSB 1 Bank MSB 2
Bank MSB 2
Piano E-Piano
E-Piano
4
Prg.
0 Organ 776555678 slow slow Rotary
1 Organ 776555678 fast fast Rotary
2 Organ 800000568 slow slow Rotary
3 Organ 800000568 fast fast Rotary
4 Organ 008530000 slow slow Rotary
5 Organ 008530000 fast fast Rotary
6 Organ 800000000 slow slow Rotary
7 Organ 800000000 fast fast Rotary
8 Organ 807800000 slow slow Rotary
9 Organ 807800000 fast fast Rotary
10 Organ 804708000 slow slow Rotary
11 Organ 804708000 fast fast Rotary
12 Organ 800008000 slow slow Rotary
13 Organ 800008000 fast fast Rotary
14 Organ 800000008 slow slow Rotary
15 Organ 800000008 fast fast Rotary
16 Organ 687600000 slow slow Rotary
17 Organ 687600000 fast fast Rotary
18 Organ 888 perc slow
19 Rock Organ
20 Ham Full
21 Ham L100 Retro KW1
22 Ham L100 Retro KW2
Bank MSB 3
Organ

Prg.
23 German Organ DB slow
24 German Organ DB fast
25 German Organ FL slow
26 German Organ FL fast
27 Version UK
28 Theatre Organ Mighty Tower
29 Theatre Organ + Xylophone Reiteration
30 Theatre Organ + Glocken Reiteration
31 Theatre Organ Piston 2
32 Theatre O. Piston 2+ Xylo. Reiteration
33 Theatre O. Piston 2 + Glocken Reiteration
34 Theatre Organ Royal
35 Theatre O. Royal + Xylo. Reiteration
36 Theatre O. Royal + Glocken Reiteration
37 Theatre Organ Pedal Bass
38 Organ House
39 Combo Retro Vibrato 1
40 Combo Retro Vibrato 2
41 Classic Organ Tutti 1
42 Classic Organ Tutti 2
43 Classic Organ Pipe Flute
44 Classic Organ Pipe Combi
45 Classic Organ Pedal Flute 16
118 Theatre Organ Glocken Hit
119 Theatre Organ Glocken short
120 Theatre Organ Glocken Reiteration
121 Theatre Organ Xylophone Hit
122 Theatre Organ Xylo. Reiteration
123 Theatre Organ Xylo. Hit & Reiteration
124 T. O. Glocken Reiteration velocity dynamic
125 T. O. Xylo Reiteration velocity dynamic
126 Organ Click
127 Silence - no sound
Bank MSB 3
Organ
5
Prg. Attitudes of 16 51/3 8 4 22/3 2 13/5 11/3 1 Percussion
00 Jimmy Smith 8 8 8 Perc 3
01 Joey DeFrancesco 8 8 8 8 Perc 2
02 Charles Earland 8 8 8 8 Perc 3
03 Brian Auger 8 8 8 6 Perc 2
04 Garner-Set 8 8 8 8 8 Perc 3
05 Piano Set 8 Perc 2
06 Walter Wanderley 8 7 Perc 2
07 Whistle 8 8 Perc 2
08 Gospel Set 8 8 8 4 4 8 Perc 2
09 Blues Set 8 8 5 3 2 3 5 8 8 Perc 3
10 EasyListening 8 8 8 8 8 Perc 2
11 Jimmy Smith 8 8 Perc 3
12 Jimmy Smith 8 8 Perc 3
13 Joey Defrancesco 8 8 7 6 4 Perc 3
14 Ballad 2 8 2 Perc 2
15 Jesse Crawford 8 8 Perc 3
16 Joey Defrancesco 8 3 8 Perc 3
17 Booker T. Jones 8 8 8 6 3 Perc 3
18 Green Onions 8 8 8 8 Perc 3
19 Matthew Fisher 8 8 8 Perc 2
20 Jimmy McGriff Gospel 8 8 8 6 6 Perc 2
21 Chords 4 3 7 Perc 3
22 Chords 8 4 Perc 2
23 Walter Wanderley 8 8 6 Perc 3
24 Walter Wanderley 8 8 Perc 3
25 Lenny Dee 8 8 8 8 Perc 2
26 Lenny Dee 8 8 8 8 8 Perc 3
27 Lenny Dee 8 8 8 8 8 Perc 2
28 Ethel Smith 8 8 8 8 8 Perc 2
29 Ken Griffin 8 8 8 8 8 Perc 2
30 Jon Lord 8 8 8 Perc 2
31 Jimmy Smith 8 8 Perc 2
32 Jimmy Smith 8 8 Perc 2
33 Exclusive 8 8 Perc 2 & 3 Repetition
34 Exclusive 8 3 8 Perc 2 & 3 Repetition
Bank MSB 4
Organ - Drawbar Registrations

6
Prg. 16 51/3 8 4 22/3 2 13/5 11/3 1 Percussion
35 Standard 8 8 8 7 6 6 Perc 2
36 Standard 8 8 8 5 5 5 6 6 6 Perc 2
37 Standard 8 8 8 8 8 8 Perc 3
38 Standard 8 8 8 5 4 4 8 8 8 Perc 3
39 Standard 8 8 8 8 7 6 6 Perc 3
40 Experiment 8 8 8 6 Perc 1 exp.
41 Experiment 8 7 6 5 Perc 1 exp.
42 Experiment 8 8 8 8 5 Perc 13/5 exp.
43 Experiment 8 7 6 5 Perc 8 exp.
44 Standard 8 7 6 7 Perc 3
Bank MSB 4
Organ - Drawbar Registrations
Prg.
45 Bars 1st Three
46 Bars 1st Four
47 Bar 16
48 Bars 16 - 8
49 Bar 8
50 Bar 5 1/3
51 Vib A (HPF)
52 Vib B (HPF)
53 Full Organ (HPF)
54 Highest (HPF)
55 Middle Mixed (HPF)
56 Bars 1st Three
57 Bars 1st Four
58 Bar 16
59 Bar 16 & 8
60 Bar 8
61 Bar 5 1/3
62 Bar 4
63 Bar 2 2/3
64 Bar 2
65 Bar 1 3/5
66 Bar 1 1/3
67 Bar 1
Prg.
68 Percussion 2
69 Percussion 2 long
70 Percussion 3
71 Percussion 3 long
72 Organ Click
127 Silence - no sound
Bank MSB 4
Organ - Drawbars
Prg.
0 Music Box
1 Music Box octave delay
2 Music Box octave delay - soft Attack
3 Vibraphone
4 Vibraphone short Release
5 Vibraphone soft Attack
6 Vibraphone no Vibrato
7 Vibraphone no Vibrato shot Release
8 Vibraphone fast Tremolo
9 Celeste
10 Tinkle
11 Marimba
12 Marimba octave delay
13 Marimba & Xylophone
14 Xylophone
15 Xylophone octave delay
16 Tubular Bell
17 Tubular Bell 2
18 Timpani
19 Kalimba
20 Cortales
21 Steel drums
22 Alpin Bells Hit
23 Alpin Bells Roll
24 Alpin Bells Hit & Roll
25 Bells
127 Silence - no sound
Prg.
0 Harpsichord
1 Harpsichord & Octave
2 Clavinet 1
3 Clavinet 2
4 Zither
5 Dulcimer 3 strings
6 Dulcimer 3 strings+
7 Dulcimer 3 strings Tremolo
8 Dulcimer 3 strings bowed
9 Dulcimer 5 strings
10 Dulcimer 5 strings+
11 Dulcimer 5 strings Tremolo
12 Dulcimer 5 strings bowed
13 Harp
14 Harp long
127 Silence - no sound
Bank MSB 5 Bank MSB 6
Perc. Tuned Instr. String Instr.

Bank MSB 7 Bank MSB 7
Guitar Guitar
7
Prg.
00 Harmonica
01 Harmonica Slide velo. 116-127
02 Harmonica Vibrato
03 Accordina
04 Accordion Musette 888
05 Accordion Musette 888+16
06 Accordion Musette 4+888
07 Accordion Musette 4+888+16
08 Accordion Musette Vintage Italian
09 Accordion Vintage Musette VM 888
10 Accordion Vintage Musette VM 888+16
11 Accordion Vintage Musette VM 4+888
12 Accordion V. Musette VM 4+888+16
13 Accordion Musette 888 Benelux
14 Accordion Musette 888 Germany
15 Accordion Musette 888 Italy Retro
16 Accordion Musette 888 French
17 Accordion 88 French
18 Accordion 88+16
19 Accordion 4+88
20 Accordion 4+88+16
21 Tango 8+16
22 Tango 8+16 Repetition
23 Accordion Celeste 88 French
24 Accordion Celeste 88+16
25 Accordion Celeste 4+88+16
26 Accordion Celeste VE10 88 French
27 Accordion Celeste VE10 88+16
28 Accordion Super VI - Reed 8
29 Accordion Super VI - Reed 4+8
30 Accordion Super VI - Reed 88
31 Accordion Super VI - Reed 4+16
32 Accordion Super VI - Reed 4+88
33 Accordion Super VI - Reed 8+16
34 Accordion Super VI - Reed 4+8+16
35 Accordion Super VI - Reed 88+16
36 Accordion Super VI - Reed 4+88+16
Bank MSB 8
Accordion
Prg.
00 Guitar Nylon
01 Guitar Nylon soft
02 Guitar Nylon Octave
03 G. Nylon Slide velo. 116-127
04 Guitar Nylon Harmonics
05 Guitar Steel 1
06 Guitar Steel 1 soft
07 Guitar Steel 1 hard
08 Guitar Steel 1 double
09 Guitar Steel 1 mute
10 Guitar Steel 1 bowed
11 Guitar Steel 2
12 Guitar Steel 2 soft Attack
13 Guitar Steel 3
14 Guitar Steel 3 soft Attack
15 Banjo
16 Banjo Slide velo. 116-127
17 Mandoline Italian
18 Mandoline Ensemble Tremolo
19 Mandoline Ensemble
20 M. Ens. Split velo. 116-127 Split
Prg.
21 Git. Jazz 1
22 Git. Jazz 2
23 Git. Jazz & Octave
24 Pedal Steel Vibrato
25 Pedal Steel
26 Pedal Steel bowed
27 P. Steel Slide velo. 116-127
28 Guitar Jazz 3
29 Guitar Jazz 3 Chicken Picking
30 Guitar Jazz 4
31 Guitar Jazz 4 Chicken Picking
32 E-Guitar 1 US clean
33 E-Guitar 1 US mute
34 E-Guitar 2 BR clean HPF
35 E-Guitar 2 BR mute HPF
36 E-Guitar Overdrive
37 E-Guitar Distortion
38 Rhythm Guitar
39 Rhythm Guitar
123 Nylon Guitar Percussion
124 Guitar stroke
125 Guitar noise
126 Guitar ghost note
127 Silence - no sound
Prg.
37 Big Musette
38 Accordion 16
39 Accordion 8+16
40 Accordion 4+8+16
41 Accordion 4+16
42 Accordion 888
43 Accordion 888+
44 Accordion 888++
45 Accordion 888+++
46 Accordion 8
47 Accordion 8+16
48 Accordion 4+8+16
49 Accordion 4+8
50 Melodeon 8
51 Melodeon 88 flat
52 Melodeon 88 medium
53 Melodeon 88 wide
54 Melodeon 816
55 Melodeon Tradition Austria „Steirische“
56 Melodeon Tradition Norway „Cororna“
57 Melodeon Tradition Irish „Saturn“
58 Melodeon Tradition Swiss „Örgeli“
59 Melodeon Tradition Benelux „Serena“
117 Maultrommel
118 Elec. Accordion VOX4
119 Elec. Accordion VOX4
120 Accordion Bass & Chord
121 Melodeon Chord
122 Melodeon Bass
123 Melodeon Bass Helikon
124 Accordion Attack noise Curve 3
125 Accordion Attack noise Curve linear
126 Accordion Bellow noise
127 Silence - no sound

8
Prg.
00 Full Strings 1 Chamber Emotion velocity to Attack
01 Full Strings 1 Chamber short Release shot
02 Full Strings 1 Chamber medium Release medium
03 Full Strings 1 Chamber long Release long
04 Full Strings 1 Chamber slow Slow Attack
05 Full Strings 2 short Release shot
06 Full Strings 2 medium Release medium
07 Full Strings 2 long Release long
08 Full Strings 2 forte forte only
09 Full Strings 2 piano piano only
10 Full Strings 3 Emotion velocity to Attack time
11 Full Strings 3 FAD layered 4
12 Full Strings 3 slow slow
13 Full Strings 3 standard
14 Full Strings Tremolo
15 Full Strings Pizzicato
16 Disco Strings long
17 Disco Strings short
18 Disco Strings Glide down
19 Disco Strings Slide velo. 116-127 Slide
Bank MSB 9
Full Strings & Disco Strings
Prg.
20 Violin Ensemble velocity split with arco
21 Violin Ensemble velocity split
22 Violin Ensemble piano only
23 Violin Ensemble slow
24 Violin Ensemble piano only slow
25 Violin Ensemble detache
26 Violin Ensemble legato
27 Violin Ensemble sordino
28 Violin Ensemble tremolo
29 Violin Ensemble pizzicato
30 Viola Ensemble velocity split with arco
31 Viola Ensemble velocity split
32 Viola Ensemble piano only
33 Viola Ensemble slow
34 Viola Ensemble piano only slow
35 Viola Ensemble detache
36 Viola Ensemble legato
37 Viola Ensemble sordino
38 Viola Ensemble tremolo
39 Viola Ensemble pizzicato
40 Cello Ensemble velocity split with arco
41 Cello Ensemble velocity split
43 Cello Ensemble slow
45 Cello Ensemble detache
46 Cello Ensemble legato
48 Cello Ensemble tremolo
49 Cello Ensemble pizzicato
50 Contra Bass Ensemble velocity split with arco
51 Contra Bass Ensemble velocity split
53 Contra Bass Ensemble slow
55 Contra Bass Ensemble detache
56 Contra Bass Ensemble legato
58 Contra Bass Ensemble tremolo
59 Contra Bass Ensemble pizzicato
125 String Ensemble Detache only Dynamic curve 1
126 String Ensemble Detache only Dynamic curve 2
127 Silence - no sound
Bank MSB 9
String Ensembles Classic

Prg.
0 Geige
1 Geige soft Attack
2 Geige legato Attack - no arco
3 Geige legato up Attack
4 Geige legato down Attack
5 Geige Slide velo. 116-127 Slide
6 Celtic Fiddle
7 Celtic Fiddle more arco
8 Celtic Fiddle Slide velo. 116-127 Slide
9Classic Solo Violin velocity dynamic
10 Classic Solo Violin marcato
11 Classic Solo Violin slow
12 Classic Solo Violin detache
13 Classic Solo Violin legato
14 Classic Solo Violin tremolo
15 Classic Solo Violin pizzicato
16 Classic Solo Viola velocity dynamic
17 Classic Solo Viola marcato
18 Classic Solo Viola slow
19 Classic Solo Viola detache
20 Classic Solo Viola legato
21 Classic Solo Viola tremolo
22 Classic Solo Viola pizzicato
23 Classic Solo Cello velocity dynamic
24 Classic Solo Cello marcato
25 Classic Solo Cello slow
26 Classic Solo Cello detache
27 Classic Solo Cello legato
28 Classic Solo Cello tremolo
29 Classic Solo Cello pizzicato
30 Classic Solo Contra Bass velocity dynamic
31 Classic Solo Contra Bass marcato
32 Classic Solo Contra Bass slow
33 Classic Solo Contra Bass detache
34 Classic Solo Contra Bass legato
35 Classic Solo Contra Bass tremolo
36 Classic Solo Contra Bass pizzicato
127 Silence - no sound
Bank MSB 10
Solo Strings Bank MSB 11 Synth Strings
Prg.
0 Strings PWM
1 Strings PWM - up
2 Strings PWM - ENV
3 Strings PWM - notch
4 Strings MKS
5 Strings MKS II
6 Strings MKS LP24
7 Strings MKS Rise
8 Strings Retro Solino
9 Stringmaster Retro
10 Strings M12
11 Strings M12
12 Strings M12
13 Strings M12 Notch
14 Strings M12 Notch
15 Strings M12 Notch
16 Chroma Strings LPF
17 Chroma Strings Notch
18 Chroma Strings BPF
19 Chroma Strings HPF
20 Strings MKS fast
21 Strings MKS medium
22 Strings MKS slow
Prg.
23 Analog Strings mono fast
24 Analog Strings mono medium
25 Analog Strings mono slow
26 JP Strings mono fast
27 JP Strings mono medium
28 JP Strings mono slow
29 JP mono BPF
30 MKS Strings fast
31 MKS Strings medium
32 MKS Strings slow
33 OB Strings fast
34 OB Strings slow
35 OB Strings II mono LPF
36 OB Strings II mono BPF
37 OB Strings II mono HPF
127 Silence - no sound
9

10
Prg.
0 Trumpet 1 velo. split 48 - 96
1 Trumpet 1 velo. split 64
2 Trumpet 1 piano only
3 Trumpet 1 mezzo only
4 Trumpet 1 forte only
5 Trumpet 1 velocity zone 116-127 fall
6 Trumpet 1 velocity zone 116-127 goup
7 Trumpet 1 velocity zone 116-127 Slide
8 Trumpet 2 Ivan
9 Trumpet 2 Ivan 4 velocity split
10 Trumpet 2 Ivan 1/4 note
11 Trumpet 2 Ivan 1/4 note 4 velocity split
12 Trumpet 3 Vibrato 5 velocity split
13 Trumpet 3 Vibrato soft 3 velocity split - soft version
14 Trumpet 3 Vibrato hard 3 velocity split - hard only
15 Trumpet 3 Vibrato 2 Modell 2
16 Trumpet 3 Vibrato sfz sfz
17 Trumpet 3 Vibrato leagto leagto
18 Trumpet 3 High Lead - no Vibrato ff Lead only
19 Cornet
20 Cornet soft
21 Cornet hard
22 Cornet portamento Attack
23 Trumpet mute
24 Trumpet mute AV Repetition / Auto Variation
25 Flugelhorn
26 Trombone Vibrato
27 Trombone
28 Trombone damper
29 F-Horn
30 Tenorhorn
31 Tenorhorn Vibrato
Prg.
32 Alphorn
33 Baritone horn Vibrato
34 Baritone horn staccato
35 Tuba
36 Tuba soft
127 Silence no sound
Bank MSB 12 Bank MSB 12
Brass Solo Brass Solo
Prg.
0US Trumpet Section dynamic split
1 US Trumpet Section forte forte
2 US Trumpet Section mezzo mezzo
3 US Trumpet Section fast fall fast fall
4 US Trumpet Section medium fall medium fall
5 US Trumpet Section Split velo. 116-127 fall
6US Trombone Section dynamic split
7 US Trombone Section forte forte
8 US Trombone Section mezzo mezzo
9 US Trombone Section fast fall fast fall
10 US Trombone Section medium fall medium fall
11 US Trombone Section Split velo. 116-127 fall
12 US Trump. & Trombone Section dynamic split
13 US Trump. & Trombone Section forte forte
14 US Trump. & Trombone Section mz mezzo
15 Flugelhorn Duo
16 Tenorhorn Ensemble Vibrato
17 Alphorn Duett
18 Alphorn Trio
19 Alphorn Ensemble
127 Silence - no sound
Bank MSB 13
Brass Section

11
Prg.
00 Classic Trumpet Solo
01 Classic Trumpet Solo just piano
02 Classic Trumpet Solo staccato
03 Classic Trombone Solo
04 Classic Trombone Solo just piano
05 Classic Trombone Solo staccato
06 Classic Horn Solo
07 Classic Horn Solo just piano
08 Classic Horn Solo staccato
09 Classic Tuba Solo
10 Classic Tuba Solo just piano
11 Classic Tuba Solo staccato
12 Full Brass Classic Ensemble velocity split
13 Full Brass Classic Ensemble piano only
13 Classic Trumpet Ensemble velocity split
14 Classic Trumpet Ensemble piano only
15 Classic Trumpet Ensemble staccato
16 Classic Trombone Ensemble velocity split
17 Classic Trombone Ensemble piano only
18 Classic Trombone Ensemble staccato
19 Horn Ensemble velocity split
20 Horn Ensemble piano only
21 Horn Ensemble staccato
22 Tuba Ensemble
126 Horn Ensemble Riff up
127 Silence - no sound
Bank MSB 14
Classic Brass Bank MSB 47
Prg.
00 Soprano Sax dynamic split
01 Soprano Sax softer softer zones
02 Soprano Sax harder harder zones
03 Soprano Sax and noise breath noise
04 Soprano Sax Slide velo. 116-127 Slide
05 Soprano Sax II more Vibrato
06 Alto Sax dynamic split
07 Alto Sax softer softer zones
08 Alto Sax harder harder zones
09 Alto Sax breath breath noise
10 Alto Sax Slide velo. 116-127 Slide
11 Tenor Sax dynamic split
12 Tenor Sax softer softer zones
13 Tenor Sax harder harder zones
14 Tenor Sax breath breath noise
15 Tenor Sax Slide velo. 116-127 Slide
16 Max Jazz Tenor velo. split 116 Random Key & breath noise
17 Max Jazz Tenor velo. split 64 Random Key & breath noise
18 Max Jazz Tenor soft soft only Random Key & breath noise
19 Max Jazz Tenor velo. split 96
20 Max Jazz Tenor Vibrato less delay velo. split 96
21 Max Jazz Tenor soft soft only breath noise
22 Max Jazz Tenor Slide velo. 116-127 Slide Random Key & breath noise
23 Max Jazz Tenor Slide soft velo. 116-127 Slide Random Key & breath noise
24 Tenor Sax Funky
25 Tenor Sax Funky growl
26 Tenor Sax Funky Split velo. split 116
27 Baritone Sax
28 Sax Section 1
29 Sax Section 2
126 Sax Breath Noise only
127 Silence - no sound
Bank MSB 15
Saxophon

Prg.
0 Clarinet
1 Clarinet soft
2 Clarinet Slide velocity zone 116-127 Slide
3 Hugo Clarinet - no loop
4 Hugo Clarinet Slide velocity zone 116-127 Slide
5Clarinet Vito Tradition
6Clarinet Vito Tradition
7Clarinet Vito Tradition soft soft velocity 1-97
8Clarinet Vito Tradition staccato
9Clarinet Vito Tradition staccato
10 Piccolo
11 Flute
12 Flute EQ
13 Flute High Pass Filter
14 Low Whistle
15 Panflute
16 Shakuhachi
17 Celtic High Whistle
18 Celtic High Whistle Grace note AV Auto Grace note
19 C. High Wh. Slide velocity zone 116-127 Slide
20 Bottle
21 Bottle Q
22 Bottle LFO
23 Whistle
24 Okarina
25 Highland Pipers & Drone Ensemble split note 60 - c1
26 Ullian Piper & Drone
27 Ullian Piper & Drone Grace note AV Auto Grace note
28 Ullian Piper & Dr. Slide velocity zone 116-127 Slide
29 Ullian Drone & Chords
30 Border Pipe
31 Border Pipe AV Auto Grace note
32 Border Pipe Slide velocity zone 116-127 Slide
33 Border Pipe Drone
127 Silence no sound
Winds Bank MSB 16
Prg.
0 Classic Flute
1 Classic Flute just piano
2 Classic Flute staccato
3 Oboe
4 Oboe just piano
5 Oboe staccato
6 English horn
7 English horn just piano
8 English horn staccato
9 Classic Clarinet
10 Classic Clarinet just piano
11 Classic Clarinet staccato
12 Bassoon
13 Bassoon just piano
14 Bassoon staccato
15 Bass Clarinet
16 Contra Bassoon
17 Flute Ensemble
18 Clarinet Ensemble
127 Silence no sound
Classic Winds Bank MSB 17
12

Prg.
00 E-Bass 1
01 E-Bass 1 & Note-off
02 E-Bass 1 Slide velocity zone 116-127 Slide
03 E-Bass 2
04 E-Bass 2 & Note-off
05 E-Bass 3
06 E-Bass 3 Slide velocity zone 116-127 Slide
07 E-Bass 4
08 E-Bass 5 Picking 1
09 E-Bass 5 Picking 1 & Note-off
10 E-Bass 6 Picking 2
11 E-Bass 6 Picking 2 & Note-off
12 E-Bass 7
13 E-Bass 7 Repetition
14 E-Bass 7 & Note-off Repetition
15 E-Bass Fretless
16 E-Bass Slap 1
17 E-Bass Slap 1 & Note-off
18 E-Bass Slap 2
19 E-Bass Slap 2 & Note-off
20 Upright Jazz Bass Random
21 Upright Jazz Bass & Note-off Random
22 Upright Jazz Bass velocity split at 96 & 105
23 Upright Jazz Bass & Note-off velocity split at 96 & 105
24 Upright Jazz Bass velocity split 120
25 Upright Jazz Bass & Note-off velocity split 120
26 Upright Jazz Bass no finger Attack
27 Upright Bass finger Attack
28 Upright Bass more finger Attack
29 Upright Bass no finger Attack
30 Upright Bass DI
31 Upright Bass DI no finger Attack
32 Upright Bass DI long Release
33 Upright Bass DI long Release no finger Attack
34 Bowed Upright Bass
35 Bowed Upright Bass shorter Release
127 Silence no sound
Bank MSB 19
Bass
Bank MSB 47
Prg.
00 Classic Choir Aah
01 Classic Choir Aah Filter
02 Classic Choir Ooh
03 Classic Choir Ooh Filter
04 Choir Pop Ooh
05 Choir Pop Ooh Filter
06 Synth Voice
07 Classic Voice
08 Boys Aah
09 Boys Bap
10 Boys Daa
11 Boys Doo Bass
12 Boys Doo
13 Boys Falsetto Ooh
14 Boys Hmm
15 Boys Laa
16 Boys Mix Ooh
17 Boys Ooh
18 Girls Aah
19 Girls Doo
20 Girls Ooh
21 Voiceless
126 Voice Kit mapping like Drum Kit 58
127 Silence - no sound
Bank MSB 18
Choir

14
Prg.
0 Bells & Pad
1 Digital Pad
2OBX & Wavebell
3DX1 Toy
4Star Theme
5 Brightness
6 OB & Noise
7 Atmos
8 Brass Comp
9 Brass Rex
10 Polysynth Classic
11 Halo Pad
12 Caliope
13 Charang
14 Fairly Space
15 Echo Drop
16 VF Vox
17 Bass & Lead
18 Fantasia
19 Bowed Glass
20 Soft Pad
21 Ice Rain
22 Goblin
23 SoundTrack
24 Atmosguitar
25 Bottle soft
26 Polysynth Classic 5th
27 SquareLead
28 P5Brass
29 Saw
Prg.
30 SawEnv
31 C-Lead
32 SoloVox
33 MetalPad
34 JunoSweep
35 Vangbrass
36 Crystal
37 FM8
38 Mo55
39 DXBell
40 OBS1
41 OBSoft
42 Hook
43 FMPluk
44 FMBrazz
45 Ice
46 BoHook
47 VPhrase
48 VP1
49 Grace
50 Noise
51 Digirace
52 Shinner
53 Pad-A
54 Vibro
55 Digisi
56 Alex
57 VZBell
58 VZ1
59 Mizoo
Bank MSB 20
Synthesizer
Bank MSB 20
Synthesizer
Prg.
60 Bellko
61 Bellz
62 AnalogOB
63 M3Osc
64 M12Brass
65 M12Brass ENV
66 OBLead
67 OBArp
68 OBell
69 OBrass
70 Mach1
71 Brazza
72 Brasso
73 T8SuperBrass
74 T8SuperBrass ENV
75 Dells
76 Pulse
77 Pulso
78 PWD24
79 Xypho
80 Charpo
81 Jippo
82 JXArp
83 Bamarimba
84 JCO10
85 JXBell
86 StabBrass
87 Clouds
88 BellHit HP Filter
89 OBNoise
90 Noise down
91 Voxo (Notch filter 12)
92 APad Notch (Notch filter 12)
93 PWD (Notch filter 12)
94 MOSC (Notch filter 12)
Prg.
95 Square (Band pass filter 24)
96 OXB (Band pass filter 24)
97 Hook (Band pass filter 24)
98 Pulso (Band pass filter 24)
99 Jops (Band pass filter 12)
100 Filter (Band pass filter 24)
101 PolyS (Band pass filter 24)
102 OBLead (Band pass filter 24)
103 JXBell (Notch Filter 24)
104 Barimbo (Band pass filter 24)
105 Arpp (Band pass filter 24)
106 Bottle (High pass filter 12)
107 Jells (Band pass filter 24)
108 Poly (High pass filter 24)
109 Mogo (High pass filter 24)
110 HBells (High pass filter 24)
111 HBelly (High pass filter 6)
112 HBrass (High pass filter 24)
113 ClassicPoly (High pass filter 12)
114 Harppo (High pass filter 24)
115 Hipps (High pass filter 6)
Prg.
116 Classic Synth Bass
117 Classic Synth Bass Rezo
118 JBass 1
119 JBass 2
120 JBass 3
121 JBass soft
122 CS Classic Bass
123 MoBass
124 MoBass ENV
125 XBass 1
126 XBass 2
127 Silence
Bank MSB 20
Syn. Bass

15
Bank MSB 21
FX & Percussion
ACOUSTIC STANDARD
0Standard
1 Pop 1
2 Pop 2
3 Hit
4 Vintage
5 Rock
6Latin
7Tradition Buzzer Snare
ROOM & OVERHEAD
8Standard
9 Pop 1
10 Pop 2
11 Studio
12 Vintage
13 Rock
14 Hit 1
15 Hit 2
POWER KITS
16 Rock 1
17 Rock 2
18 Rock 3
19 Rock 4
ELECTRONIC & DANCE
24 Dance
25 Electric
26 808/909
27 808
28 606
29 Dance
30 Dance
31 House
ACOUSTIC JAZZ
32 Light
33 Medium
34 Radio King
DRUM KITS - ACOUSTIC BRUSH
40 Medium 1
41 Medium 2
DRUM KITS - ACOUSTIC BRUSH
48 Classic Percussion
49 Concert Band
DRUM KITS - Specials
56 Latin Percussion
58 Vocal Kit
Drum Kit (Channel 10)
2ND DRUM KIT
After power on the drum kits are only available on parts
with active DRUM MODE. e default MIDI chan-
nel for this is MIDI channel 10.
You can also set a second part to DRUM MODE with
a System Exclusive command.
Prg.
00 Orchestra Hit Major
01 Orchestra Hit Minor
62 Synth FX down
63 Synth FX up
64 Drum Kit Map Drum Kit 0
65 Percussion Kit Map Drum Kit 56
66 Classic Percussion Map Drum Kit 48
70-77 Acoustic Kick Drums Sounds from Drum Kit 0-7
78-85 Acoustic Kick Drum Sounds from Drum Kit 8-15
86-89 Acoustic Kick Drum Sounds from Drum Kit 16-19
90-93 Acoustic Kick Drum Sounds from Drum Kit 32-35
94 Classic Bass drum note Sounds from Classic PercussionKit 48
95 Concert Bass drum Sounds from Concert Band Kit 49
96-103 E-Bass Drum Sounds from E-Drum Kit 24-31
127 Silence - no sound
Prg. 70-103
When you use programs 70-103 in MIDI les, play
notes 24, 48 and 84. us, these bass drum sounds
sound correctly even when transposed.

Nr. Prg. 0 Standard Kit Prg. 1 Standard Kit Prg. 2 Standard Kit Prg. 3 Standard Kit Prg. 4 Standard Kit Prg. 5 Standard Kit Prg. 6 Standard Kit Prg. 7 Standard Kit
G 7 Dance Kick ~ ~ ~ ~ ~ ~ Snare QA Latin
8 Dance Kick ~ ~ ~ ~ ~ ~ Snare QA Latin
A 9 Dance Kick ~ ~ ~ ~ ~ ~ Snare QA Latin
10 Dance Kick ~ ~ ~ ~ ~ ~ Snare QA Latin
11 Dance Kick ~ ~ ~ ~ ~ ~ Snare QA Latin
C 12 Dance Kick ~ ~ ~ ~ ~ ~ Snare QA Latin
13 Surdo Mute ~ ~ ~ ~ ~ ~ ~
D 14 Surdo Open ~ ~ ~ ~ ~ ~ ~
15 Hi Q ~ ~ ~ ~ ~ ~ ~
E 16 Whipe Slap ~ ~ ~ ~ ~ ~ ~
F 17 Scratch ~ ~ ~ ~ ~ ~ ~
18 Scratch ~ ~ ~ ~ ~ ~ ~
G 19 Finger Snap ~ ~ ~ ~ ~ ~ ~
20 Click Noise ~ ~ ~ ~ ~ ~ ~
A 21 Metronom Click ~ ~ ~ ~ ~ ~ ~
22 Metronom Bell ~ ~ ~ ~ ~ ~ ~
23 Seq. Click ~ ~ ~ ~ ~ ~ ~
C 24 Seq. Click ~ ~ ~ ~ ~ ~ ~
25 Brush Tap ~~~~~~~
D 26 Brush Swirl ~ ~ ~ ~ ~ ~ ~
27 Brush Slap ~ ~ ~ ~ ~ ~ ~
E 28 Brush Tap Swirl ~~~~~~~
F 29 Snare Roll ~ ~ ~ ~ ~ ~ ~
30 Castagnet ~ ~ ~ ~ ~ ~ ~
G 31 Snare soft LS Cravio. Snare soft EZ GMS Piccolo Snare soft EZ Roge. Snare soft LS Bronze Snare soft QA 5.5 Radio King Snare soft LS SG Snare soft CR Snare soft QA Latin
32 Sticks ~ Sticks ~ ~ ~ ~ ~
A 33 Bass Drum LS Ludw. Bass Drum EZGMS 2 Bass Drum EZ GMS Bass Drum LS Studio Bass Drum QA MAS Bass Drum AD LL Bass Drum Modern 1 Bass Drum QA Latin
34 Snare Var. LS Cravio. Snare Var. EZ GMS Piccolo Snare Var. EZ Roge. Snare Var. LS Bronze Snare Var. QA 5.5 Radio King Snare Var. LS SG Snare Var. CR Snare Var. QA Latin
35 Bass Drum LS Ludw. Bass Drum EZ GMS 2 Bass Drum EZ GMS Bass Drum LS Studio Bass Drum QA MAS Bass Drum AD LL Bass Drum Modern 2 Bass Drum QA Latin
C 36 Bass Drum LS Ludw. Bass Drum EZ GMS 2 Bass Drum EZ GMS Bass Drum LS Studio Bass Drum QA MAS Bass Drum AD LL Bass Drum Modern 3 Bass Drum QA Latin
37 Sidestick LS Cravio. Sidestick EZB Piccolo Sidestick EZ Roge. Sidestick LS Bronze Sidestick QA 5.5 Radio King Sidestick LS SG Sidestick CR Sidestick QA Latin
D 38 Snare LS Cravio. Snare EZB Piccolo Snare EZ Roge Snare LS Bronze Snare QA 5.5 Radio King Snare LS SG Snare CR Snare QA Latin
39 Clap ~ ~ ~ ~ ~ ~ ~
E 40 Snare Rimshot LS Cravio. Snare Rimshot EZB Piccolo Snare Rimshot EZ Roge. Snare Rimshot LS Bronze Snare RS QA 5.5 Radio King Snare Rimshot LS SG Snare Rimshot CR Snare Rimshot QA Latin
F 41 Tom Low Low EZ GMS ~ ~ ~ ~ ~ ~ ~
42 HiHat closed (0) ~ ~ ~ ~ ~ ~ ~
G 43 Tom Low EZ GMS ~ ~ ~ ~ ~ ~ ~
44 HiHat Pedal (0) ~ ~ ~ ~ ~ ~ ~
A 45 Tom Medium L. EZ GMS ~ ~ ~ ~ ~ ~ ~
46 HiHat open (0) ~ ~ ~ ~ ~ ~ ~
47 Tom Medium EZ GMS ~ ~ ~ ~ ~ ~ ~
C 48 Tom High EZ GMS ~ ~ ~ ~ ~ ~ ~
49 Crash Cymbal 1 ~ ~ ~ ~ ~ ~ ~
D 50 Tom High High EZ GMS ~ ~ ~ ~ ~ ~ ~
51 Ride Cymbal 1 [Repetition] ~ ~ ~ ~ ~ ~ ~
E 52 China Cymbal ~ ~ ~ ~ ~ ~ ~
F 53 Ride Cup ~ ~ ~ ~ ~ ~ ~
54 Tambourin [Repetition] ~ ~ ~ ~ ~ ~ ~
G 55 Splash Cymbal ~ ~ ~ ~ ~ ~ ~
56 Cowbell ~ ~ ~ ~ ~ ~ ~
A 57 Crash Cymbal 2 ~ ~ ~ ~ ~ ~ ~
58 Vibraslap ~ ~ ~ ~ ~ ~ ~
59 Ride Cymbal 2 [Repetition] ~ ~ ~ ~ ~ ~ ~
C 60 Bongo high [Repetition] ~ ~ ~ ~ ~ ~ ~
61 Bongo low [Repetition] ~ ~ ~ ~ ~ ~ ~
D 62 Conga mute [Repetition] ~ ~ ~ ~ ~ ~ ~
63 Conga open [Repetition] ~ ~ ~ ~ ~ ~ ~
Nr. Prg. 0 - 7
E 64 Conga low [Repetition]
F 65 Timbale high [Repetition]
66 Timbale low [Repetition]
G 67 Agogo high [Repetition]
68 Agogo low [Repetition]
A 69 Cabasa [Repetition]
70 Maracas [Repetition]
71 Whistle
C 72 Whistle
73 Guiro short
D 74 Guiro long
75 Claves
E 76 Woodblock low
F 77 Woodblock hi
78 Cuica mute
G 79 Cuica open
80 Triangle mute (5)
A 81 Triangle open (5)
82 Shaker
83 Jingle Bell
C 84 Chimes
85 Tamburin Hit 1
D 86 Tamburin Hit 2
87 Tamburin Hit 3
E 88 Tamburin Hit 4
F 89 E-Snare
90 E-Snare
G 91 E-Snare
92 E-Snare
A 93 E-Snare
94 E-Snare
95 E-Snare
C 96 E-Snare
97 E-Snare
D 98 E-Snare
99 E-Snare
E 100 E-Snare
F 101 E-Snare
102 E-Snare
G 103 E-Snare
104 E-Claps
A 105 E-Claps
106 E-Claps
107 E-Claps
C 108 E-Claps
109 Claps Hit 1
D 110 Claps Hit 2
111 Claps Hit 3
E 112 Claps Hit 4
F 113 Stomp 1
114 Stomp 2
G 115 Stomp 3
116 Reverse Stomp
A 117 Reverse Snare
118 Reverse Clap
119 Reverse BD
C 120 HiHat Open 1/2
121 Cym. Crash NL
D 122 Cym. Ride NL
123 Cym. Cup NL
E 124 Cym. Splash NL
125 Reverse Cym.

Nr. Prg. 8 Overhead Kit Prg. 9 Overhead Kit Prg. 10 Overhead Kit Prg. 11 Overhead Kit Prg. 12 Overhead Kit Prg. 13 Overhead Kit Prg. 14 Overhead Kit Prg. 15 Overhead Kit
G 7 Dance Kick ~ ~ ~ ~ ~ ~ ~
8 Dance Kick ~ ~ ~ ~ ~ ~ ~
A 9 Dance Kick ~ ~ ~ ~ ~ ~ ~
10 Dance Kick ~ ~ ~ ~ ~ ~ ~
11 Dance Kick ~ ~ ~ ~ ~ ~ ~
C 12 Dance Kick ~ ~ ~ ~ ~ ~ ~
13 Surdo Mute ~ ~ ~ ~ ~ ~ ~
D 14 Surdo Open ~ ~ ~ ~ ~ ~ ~
15 Hi Q ~ ~ ~ ~ ~ ~ ~
E 16 Whipe Slap ~ ~ ~ ~ ~ ~ ~
F 17 Scratch ~ ~ ~ ~ ~ ~ ~
18 Scratch ~ ~ ~ ~ ~ ~ ~
G 19 Finger Snap ~ ~ ~ ~ ~ ~ ~
20 Click Noise ~ ~ ~ ~ ~ ~ ~
A 21 Metronom Click ~ ~ ~ ~ ~ ~ ~
22 Metronom Bell ~ ~ ~ ~ ~ ~ ~
23 Seq. Click ~ ~ ~ ~ ~ ~ ~
C 24 Seq. Click ~ ~ ~ ~ ~ ~ ~
25 Brush Tap ~~~~~~~
D 26 Brush Swirl ~ ~ ~ ~ ~ ~ ~
27 Brush Slap ~ ~ ~ ~ ~ ~ ~
E 28 Brush Tap Swirl ~~~~~~~
F 29 Snare Roll ~ ~ ~ ~ ~ ~ ~
30 Castagnet ~ ~ ~ ~ ~ ~ ~
G 31 Snare soft QA 12x15 WFL Snare soft QA 4x14SW Snare soft QA 4x15 Ludw. Snare soft QA 5x14 Leedy Snare soft QA 5x14 Ludwig Snare soft QA 6.5x14 Lud. Snare soft QA Black Beauty Snare soft QA 7x14 Radio K.
32 Sticks ~ ~ ~ ~ ~ ~ ~
A 33 Bass Drum EZ GMS Bass Drum EZ GMS 2 Bass Drum LS Ludw. Bass Drum AD LL Bass Drum QA Latin Bass Drum AD Tam. Bass Drum LS IC Bass Drum LS Studio
34 Snare Var. QA 12x15 WFL Snare Var. QA 4x14SW Snare Var. QA 4x15 Ludw. Snare Var. QA 5x14 Leedy Snare Var. QA 5x14 Ludw. Snare Var. QA 6.5x14 Lud. Snare Var. QA Black Beauty Snare Var. QA 7x14 Radio K.
35 Bass Drum EZ GMS Bass Drum EZ GMS 2 Bass Drum LS Ludw. Bass Drum AD LL Bass Drum QA Latin Bass Drum AD Tam. Bass Drum LS IC Bass Drum LS Studio
C 36 Bass Drum EZ GMS Bass Drum EZ GMS 2 Bass Drum LS Ludw. Bass Drum AD LL Bass Drum QA Latin Bass Drum AD Tam. Bass Drum LS IC Bass Drum LS Studio
37 Sidestick QA 12x15 WFL Sidestick QA 4x14SW Sidestick QA 4x15 Ludw. Sidestick QA 5x14 Leedy Sidestick QA 5x14 Ludw. Sidestick QA 6.5x14 Lud. Sidestick QA Black Beauty Sidestick QA 7x14 Radio K.
D 38 Snare QA 12x15 WFL Snare QA 4x14SW Snare QA 4x15 Ludw. Snare QA 5x14 Leedy Snare QA 5x14 Ludw. Snare QA 6.5x14 Lud. Snare QA Black Beauty Snare QA 7x14 Radio K.
39 Clap ~ ~ ~ ~ ~ ~ ~
E 40 Snare RS QA 12x15 WFL Snare Rimshot QA 4x14SW Snare RS QA 4x15 Ludw. Snare RS QA 5x14 Leedy Snare RS QA 5x14 Ludw. Snare RS QA 6.5x14 Lud. Snare RS QA Black Beauty Snare RS QA 7x14 Radio K.
F 41 Tom Low EZ GMS Overhead ~ ~ ~ ~ ~ ~ ~
42 HiHat closed (0) ~ ~ ~ ~ ~ ~ ~
G 43 Tom Low EZ GMS Overhead ~ ~ ~ ~ ~ ~ ~
44 HiHat Pedal (0) ~ ~ ~ ~ ~ ~ ~
A 45 Tom M. L. EZ GMS Overhead ~ ~ ~ ~ ~ ~ ~
46 HiHat open (0) ~ ~ ~ ~ ~ ~ ~
47 Tom M. EZ GMS Overhead ~ ~ ~ ~ ~ ~ ~
C 48 Tom High EZ GMS Overhead ~ ~ ~ ~ ~ ~ ~
49 Crash Cymbal 1 ~ ~ ~ ~ ~ ~ ~
D 50 Tom High High EZ GMS Ov. ~ ~ ~ ~ ~ ~ ~
51 Ride Cymbal 1 [Repetition] ~ ~ ~ ~ ~ ~ ~
E 52 China Cymbal ~ ~ ~ ~ ~ ~ ~
F 53 Ride Cup ~ ~ ~ ~ ~ ~ ~
54 Tambourin [Repetition] ~ ~ ~ ~ ~ ~ ~
G 55 Splash Cymbal ~ ~ ~ ~ ~ ~ ~
56 Cowbell ~ ~ ~ ~ ~ ~ ~
A 57 Crash Cymbal 2 ~ ~ ~ ~ ~ ~ ~
58 Vibraslap ~ ~ ~ ~ ~ ~ ~
59 Ride Cymbal 2 [Repetition] ~ ~ ~ ~ ~ ~ ~
C 60 Bongo high [Repetition] ~ ~ ~ ~ ~ ~ ~
61 Bongo low [Repetition] ~ ~ ~ ~ ~ ~ ~
D 62 Conga mute [Repetition] ~ ~ ~ ~ ~ ~ ~
63 Conga open [Repetition] ~ ~ ~ ~ ~ ~ ~
Nr. Prg. 8 - 15
E 64 Conga low [Repetition]
F 65 Timbale high [Repetition]
66 Timbale low [Repetition]
G 67 Agogo high [Repetition]
68 Agogo low [Repetition]
A 69 Cabasa [Repetition]
70 Maracas [Repetition]
71 Whistle
C 72 Whistle
73 Guiro short
D 74 Guiro long
75 Claves
E 76 Woodblock low
F 77 Woodblock hi
78 Cuica mute
G 79 Cuica open
80 Triangle mute (5)
A 81 Triangle open (5)
82 Shaker
83 Jingle Bell
C 84 Chimes
85 Tamburin Hit 1
D 86 Tamburin Hit 2
87 Tamburin Hit 3
E 88 Tamburin Hit 4
F 89 E-Snare
90 E-Snare
G 91 E-Snare
92 E-Snare
A 93 E-Snare
94 E-Snare
95 E-Snare
C 96 E-Snare
97 E-Snare
D 98 E-Snare
99 E-Snare
E 100 E-Snare
F 101 E-Snare
102 E-Snare
G 103 E-Snare
104 E-Claps
A 105 E-Claps
106 E-Claps
107 E-Claps
C 108 E-Claps
109 Claps Hit 1
D 110 Claps Hit 2
111 Claps Hit 3
E 112 Claps Hit 4
F 113 Stomp 1
114 Stomp 2
G 115 Stomp 3
116 Reverse Stomp
A 117 Reverse Snare
118 Reverse Clap
119 Reverse BD
C 120 HiHat Open 1/2
121 Cym. Crash NL
D 122 Cym. Ride NL
123 Cym. Cup NL
E 124 Cym. Splash NL
125 Reverse Cym.

Nr. Prg. 16 Power Kit Prg. 17 Power Kit Prg. 18 Power Kit Prg. 19 Power Kit
G 7 Dance Kick ~ ~ ~
8 Dance Kick ~ ~ ~
A 9 Dance Kick ~ ~ ~
10 Dance Kick ~ ~ ~
11 Dance Kick ~ ~ ~
C 12 Dance Kick ~ ~ ~
13 Surdo Mute ~ ~ ~
D 14 Surdo Open ~ ~ ~
15 Hi Q ~ ~ ~
E 16 Whipe Slap ~ ~ ~
F 17 Scratch ~ ~ ~
18 Scratch ~ ~ ~
G 19 Finger Snap ~ ~ ~
20 Click Noise ~ ~ ~
A 21 Metronom Click ~ ~ ~
22 Metronom Bell ~ ~ ~
23 Seq. Click ~ ~ ~
C 24 Seq. Click ~ ~ ~
25 Brush Tap ~~~
D 26 Brush Swirl ~ ~ ~
27 Brush Slap ~ ~ ~
E 28 Brush Tap Swirl ~~~
F 29 Snare Roll ~ ~ ~
30 Castagnet ~ ~ ~
G 31 Snare soft AD Sono Snare soft LS Ludw. Snare soft QA Gadd Power Snare soft QA Gadd Power
32 Sticks ~ ~ ~
A 33 Bass Drum AD Tama Bass Drum QA Gadd Bass Drum LS Ludwig Bass Drum AD LL
34 Snare Var. AD Sonor Snare Var. LS Ludw. Snare Var. QA Gadd Power Snare Var. QA Gadd Power
35 Bass Drum AD Tama Bass Drum QA Gadd Bass Drum LS Ludwig Bass Drum AD LL
C 36 Bass Drum AD Tama Bass Drum QA Gadd Bass Drum LS Ludwig Bass Drum AD LL
37 Sidestick AD Sono Sidestick LS Ludw. Sidestick QA Gadd Power Sidestick QA Gadd Power
D 38 Snare AD Sono Snare LS Ludw. Snare QA Gadd Power Snare QA Gadd Power
39 Clap ~ ~ ~
E 40 Snare Rimshot AD Sono Snare Rimshot LS Ludw. Snare RS QA Gadd Power Snare RS QA Gadd Power
F 41 Tom Low SG ~ ~ ~
42 HiHat closed (0) ~ ~ ~
G 43 Tom Low SG ~ ~ ~
44 HiHat Pedal (0) ~ ~ ~
A 45 Tom M. L. SG ~ ~ ~
46 HiHat open (0) ~ ~ ~
47 Tom M. SG ~ ~ ~
C 48 Tom High SG ~ ~ ~
49 Crash Cymbal 1 ~ ~ ~
D 50 Tom High High SG ~ ~ ~
51 Ride Cymbal 1 [Repetition] ~ ~ ~
E 52 China Cymbal ~ ~ ~
F 53 Ride Cup ~ ~ ~
54 Tambourin [Repetition] ~ ~ ~
G 55 Splash Cymbal ~ ~ ~
56 Cowbell Rock Cowbell Rock Cowbell Rock Cowbell Rock
A 57 Crash Cymbal 2 ~ ~ ~
58 Vibraslap ~ ~ ~
59 Ride Cymbal 2 [Repetition] ~ ~ ~
C 60 Bongo high [Repetition] ~ ~ ~
61 Bongo low [Repetition] ~ ~ ~
D 62 Conga mute [Repetition] ~ ~ ~
63 Conga open [Repetition] ~ ~ ~
Nr. Prg. 16 - 19
E 64 Conga low [Repetition]
F 65 Timbale high [Repetition]
66 Timbale low [Repetition]
G 67 Agogo high [Repetition]
68 Agogo low [Repetition]
A 69 Cabasa [Repetition]
70 Maracas [Repetition]
71 Whistle
C 72 Whistle
73 Guiro short
D 74 Guiro long
75 Claves
E 76 Woodblock low
F 77 Woodblock hi
78 Cuica mute
G 79 Cuica open
80 Triangle mute (5)
A 81 Triangle open (5)
82 Shaker
83 Jingle Bell
C 84 Chimes
85 Tamburin Hit 1
D 86 Tamburin Hit 2
87 Tamburin Hit 3
E 88 Tamburin Hit 4
F 89 E-Snare
90 E-Snare
G 91 E-Snare
92 E-Snare
A 93 E-Snare
94 E-Snare
95 E-Snare
C 96 E-Snare
97 E-Snare
D 98 E-Snare
99 E-Snare
E 100 E-Snare
F 101 E-Snare
102 E-Snare
G 103 E-Snare
104 E-Claps
A 105 E-Claps
106 E-Claps
107 E-Claps
C 108 E-Claps
109 Claps Hit 1
D 110 Claps Hit 2
111 Claps Hit 3
E 112 Claps Hit 4
F 113 Stomp 1
114 Stomp 2
G 115 Stomp 3
116 Reverse Stomp
A 117 Reverse Snare
118 Reverse Clap
119 Reverse BD
C 120 HiHat Open 1/2
121 Cym. Crash NL
D 122 Cym. Ride NL
123 Cym. Cup NL
E 124 Cym. Splash NL
125 Reverse Cym.

Nr. Prg. 24 Dance Kit Prg. 25 Electro Kit Prg. 26 808/909 Kit Prg. 27 909 Kit Prg. 28 Analog Kit Prg. 29 Dance Kit Prg. 30 Dance Kit Prg. 31 House Kit
G 7 E-Kick ~ ~ ~ ~ ~ ~ ~
8 E-Kick ~ ~ ~ ~ ~ ~ ~
A 9 E-Kick ~ ~ ~ ~ ~ ~ ~
10 E-Kick ~ ~ ~ ~ ~ ~ ~
11 E-Kick ~ ~ ~ ~ ~ ~ ~
C 12 E-Kick ~ ~ ~ ~ ~ ~ ~
13 E-Kick ~ ~ ~ ~ ~ ~ ~
D 14 E-Kick ~ ~ ~ ~ ~ ~ ~
15 Hi Q ~ ~ ~ ~ ~ ~ ~
E 16 Whipe Slap ~ ~ ~ ~ ~ ~ ~
F 17 Scratch ~ ~ ~ ~ ~ ~ ~
18 Scratch ~ ~ ~ ~ ~ ~ ~
G 19 Finger Snap ~ ~ ~ ~ ~ ~ ~
20 Click Noise ~ ~ ~ ~ ~ ~ ~
A 21 Metronom Click ~ ~ ~ ~ ~ ~ ~
22 Metronom Bell ~ ~ ~ ~ ~ ~ ~
23 Seq. Click ~ ~ ~ ~ ~ ~ ~
C 24 Seq. Click ~ ~ ~ ~ ~ ~ ~
25 E-Kick ~ ~ ~ ~ ~ ~ ~
D 26 E-Kick ~ ~ ~ ~ ~ ~ ~
27 E-Kick ~ ~ ~ ~ ~ ~ ~
E 28 E-Kick ~ ~ ~ ~ ~ ~ ~
F 29 E-Kick ~ ~ ~ ~ ~ ~ ~
30 E-Kick ~ ~ ~ ~ ~ ~ ~
G 31 Elec Snare ~ ~ ~ ~ ~ ~ ~
32 E-Kick ~ ~ ~ ~ ~ ~ ~
A 33 E-Kick ~ ~ ~ ~ ~ ~ ~
34 Elec Snare ~ ~ ~ ~ ~ ~ ~
35 Dance BD Elec BD 909 BD 909 BD 606 BD Dance BD Dance BD Dance BD
C 36 Dance BD Elec BD 808 BD 909 BD 80 BD Dance BD Dance BD Dance BD
37 Rim 808 Rim 808 808 Rim 909 Rim 606 Rim 909 Rim 909 Rim 909 Rim
D 38 Elec Snare 1 Elec Snare 808 Snare 909 Snare Snare 80 Dance Snare Dance Snare Dance Snare
39 Clap 808 Clap 808 Clap 808 Clap 808 Clap 80 Hit Clap Hit Clap Hit Clap
E 40 Elec Snare 2 Elec Snare 2 909 Snare 909 Snare Snare 85 Dance Snare Dance Snare Dance Snare
F 41 Elec Tom 909 Elec Tom 80 Lin. 808 Tom 909 Tom Tom 85 909 Tom 909 Tom 909 Tom
42 HH 909 HH elec 808 HHat cl. 909 HHat cl. HHat cl. 85 909 HHat cl. 909 HHat cl. 909 HHat cl.
G 43 Elec Tom 909 Elec Tom 80 Lin. 808 Tom 909 Tom Tom 85 909 Tom 909 Tom 909 Tom
44 HH 909 HH elec 808 HHat P. 909 HHat P. HHat cl. 85 909 HHat e. 909 HHat e. 909 HHat e.
A 45 Elec Tom 909 Elec Tom 80 Lin. 808 Tom 909 Tom Tom 85 909 Tom 909 Tom 909 Tom
46 HH 909 HH elec 808 HH. op. 909 HH. op. HHat cl. 85 909 HH. op. 909 HH. op. 909 HH. op.
47 Elec Tom 909 Elec Tom 80 Lin. 808 Tom 909 Tom Tom 85 909 Tom 909 Tom 909 Tom
C 48 Elec Tom 909 Elec Tom 80 Lin. 808 Tom 909 Tom Tom 85 909 Tom 909 Tom 909 Tom
49 E-Crash 909 Crash 909 808 Cym 909 Cym 808 Cym 808 Cym 808 Cym 808 Cym
D 50 Elec Tom 909 Elec Tom 80 Lin. 808 Tom 90 Tom Tom 85 90 Tom 90 Tom 90 Tom
51 E-Ride 909 ~ ~ ~ ~ ~ ~ ~
E 52 E-China ~ ~ ~ ~ ~ ~ ~
F 53 E-Cup 66 ~ ~ ~ ~ ~ ~ ~
54 E-Tamb. 77 ~ ~ ~ ~ ~ ~ ~
G 55 E-Splash Cymbal ~ ~ ~ ~ ~ ~ ~
56 E-Cowbell ~ ~ ~ ~ ~ ~ ~
A 57 E-Crash Cymbal 2 ~ ~ ~ ~ ~ ~ ~
58 E-Vibraslap ~ ~ ~ ~ ~ ~ ~
59 E-Ride Cymbal 2 ~ ~ ~ ~ ~ ~ ~
C 60 E-Bongo high ~ ~ ~ ~ ~ ~ ~
61 E-Bongo low ~ ~ ~ ~ ~ ~ ~
D 62 E-Conga mute ~ ~ ~ ~ ~ ~ ~
63 E-Conga open ~ ~ ~ ~ ~ ~ ~
Nr. Prg. 24 - 31
E 64 E-Conga low
F 65 E-Timbale high
66 E-Timbale low
G 67 E.Agogo high
68 E-Agogo low
A 69 E-Cabasa
70 E-Maracas
71 E-Whistle
C 72 E-Whistle
73 E-Guiro short
D 74 E-Guiro long
75 E-Claves
E 76 E-Woodblock low
F 77 E-Woodblock hi
78 E-Cuica mute
G 79 E-Cuica open
80 E-Triangle mute
A 81 E-Triangle open
82 E-Shaker
83 E-Jingle Bell
C 84 E-Chimes
85 Tamburin Hit 1
D 86 Tamburin Hit 2
87 Tamburin Hit 3
E 88 Tamburin Hit 4
F 89 E-Snare
90 E-Snare
G 91 E-Snare
92 E-Snare
A 93 E-Snare
94 E-Snare
95 E-Snare
C 96 E-Snare
97 E-Snare
D 98 E-Snare
99 E-Snare
E 100 E-Snare
F 101 E-Snare
102 E-Snare
G 103 E-Snare
104 E-Claps
A 105 E-Claps
106 E-Claps
107 E-Claps
C 108 E-Claps
109 E-Claps
D 110 E-Claps
111 E-Claps
E 112 E-Claps
F 113 E-Claps
114 E-Claps
G 115 E-Claps
116 E-Claps
A 117 E-Claps
118 E-Claps
119 E-Claps
C 120 E-Claps
121 Cym. Crash NL
D 122 Cym. Ride NL
123 Cym. Cup NL
E 124 Cym. Splash NL
125 Reverse Cym.
