V3 SOUND sonority User manual

TONE GENERATOR
sonority
midi implementation
sound lists
optional sound packs
100 accordions
100 organs
celtic instruments
V3SOUND.COM

The recordings used in this device are protected by copyright. V3SOUND alone has been given the
right by all musicians involved to use this material. Any duplication, editing or any other copy by or
given to a third party in any form (audio sampling CD, data storage device, download of any file, etc.)
is strictly forbidden.
Copyright © 2017 by V3SOUND GBMH - Austria www.v3sound.com
HPF High Pass Filter: Use the cutoff parameter to set the low frequency limit. When you do this,
the sound will naturally be brighter and thinner. A cutoff value over 64 usually needs to be
selected just so you notice the change.
120FX Find on note number 120 different effect.
They are placed in velocity zones each 24 steps.
120FX ² Find on note number 120 different effect.
They are placed in velocity zones each 10 steps.
(1) DRUM MAP - exclusive mode for percussion sounds - only one of these sounds can be
active.
velo. Velocity split
The sound board will just give sound, when you call up a sound with a bank and program number
from this sound list. Sending a bank message with another value - NO SOUND!
PROGRAM LIST SOLO SOUNDSPROGRAM LIST SOLO SOUNDSPROGRAM LIST SOLO SOUNDS
PROGRAM LIST SOLO SOUNDS
PROGRAM LIST SOLO SOUNDS
BANK CONCEPTSAFETY PRECAUTIONS COPYRIGHT
SPECIFICATIONS
LEGEND
PROGRAM LIST SOLO SOUNDS
COPYRIGHT
SAFETY INSTRUCTIONS
• Read the user manual before using the device
• Do not allow any liquid to come in contact
with the device
• Do not place anything on top of the device
• Do not handle the power supply with wet hands
• Turn off all connected devices before you
connect any new devices
Do not use or store the device where it is
exposed to:
• dampness or wetness
• extreme temperature changes
(i.e. do not store in a vehicle in winter)
• strong vibrations or jolts
HANDLING
• Use only the original cables and power supply
• Remove the cable only by pulling on the plug,
not on the cable
• Do not expose the power adapter to any
mechanical stress
CUSTOMER SERVICE
Do not carry out any repairs at home, as this may result
in permanent damage to the electronics. Any guarantee
claims are no longer valid in this case.
ACCESSORIES
Manual and power
POWER REQUIREMENT
9VDC / 1.0A
HUMIDITY
max. 80%, non-condensing
OPERATING TEMPERATURE
10 to 40 degrees Celsius

!


All the audio recordings V3SOUND uses on
the sound boards are protected by copyright.
V3SOUND alone has been given the right by all
musicians involved to use this material. Any duplica-
tion, editing or any other copy of individual sounds
by or given to a third party in any form (audio samp-
ling CD, data storage device with individual sounds,
download of any file, etc.) is strictly forbidden.
Copyright © 2017 V3SOUND - Austria
• Master Volume
• Master Reverb
• 4GB flash memory
• 16 MIDI channels
• 4 audio out (2 stereo)
• Polyphony 256 voice
• Ports available for 1 sustain foot pedal
• Dimensions: 12cm (L) x 12cm (W) x 6cm (H)
• Weight: 0,2kg
• USB Host
The CE certification is available at
http://www.v3sound.com/support/
V3SOUND GMBH
Kirchplatz 7 - 6114 Kolsass - Austria - Europe
This product conforms to the
FCC 47 CFR PART 15
SUBPART B

To avoid possible damage to the loud speakers
or other connected electronic devices, always
connect all cables before turn on the amplifier.
Turn on the V3 unit first before turning on any ac-
tive loud speakers or amplifiers.
Make sure the POWER switch on the
back of the device is in the OFF position
(LED light is not on).
Plug the power adapter that came with the
device into the DC port on the back of the
unit.
Plug the other end of the power adapter into a
power outlet. Make sure that the adapter is com-
patible with the power supply.
Connect the audio outputs to an amplifier,
active loudspeakers or headphones.
Connect the MIDI-cable or the USB cable.
Before you turn the device on or off, make sure that
all connected audio devices that amplify the audio
signal (mixer, amplifier, active loud-speakers) have
their volumes turned down.
Turn the power on by pressing the
POWER ON/OFF switch on the back of
the device.
Turn up the V3 unit
MAIN VOLUME potentiometer to
maximum.
Adjust the volume on your mixer or
active loudspeaker.
Turn the volume on the V3 unit as loud as possi-
ble, and adjust the volume of the sound on your
mixer.
The V3 unit can be connected to any USB Audio
Class 1 compatible Keyboard.
The V3 unit supports your USB keyboard with a
maximum 500mA power.
Please check the power consumption of your key-
board exceeds 500mA. Otherwise connect your
keyboard to an external power-supply.
Just plug in your USB keyboard here.
The polarity of the sustain footpedal is set up
automatically on power on.
The pedal works just work in MIDI-Channel 1.
To use the AUX OUT for any MIDI channel, it´s
necessary to change 4 internal switches and to
send a MIDI Message on the requered MIDI chan-
nel.
Also the connection is to change from 2 mono
Jack to 2 stereo jacks.
One stereo jack gives you the MAIN in stereo, on
the other one the AUX in stereo.
STEREO L + R = B A B B
STEREO + AUX = A B A A
MIDI-THRU MIDI-IN
POWER ON/OFF USB-HOST
MAIN REVERB
LED - POWER ON
LED - MIDI
MAIN VOLUME
PROGRAM LIST SOLO SOUNDSUSER INTERFACE PORTS CONNECT - USB KEYS
CONNECT - USB KEYS TO TURN ON FOOT PEDAL
AUX OUT - stereo
1

PROGRAM LIST SOLO SOUNDS PROGRAM LIST SOLO SOUNDSgENERAL MIDI MAIN BANK 0 gENERAL MIDI MAIN BANK 0
1 Grand Piano
2 Bright Piano
3 Electric Grand Piano
4 Honky Tonk
5 E-Piano Tines
6 E-Piano FM
7 Harpsichord
8 Clavinet
9 Celesta
10 Glockenspiel
11 Music Box
12 Vibraphon
13 Marimba
14 Xylophon
15 Tubular Bell
16 Dulcimer
17 Drawbar Organ
18 Percussive Organ
19 Rock Organ
20 Church Organ
21 Reed Organ
22 Accordion
23 Harmonica
24 Accordion Tango
25 Nylon Guitar
26 Acoustic Steel
27 Jazz Guitar
28 Guitar clean
29 Guitar mute clean
30 Overdrive Guitar
31 Distortion Guitar
32 Guitar harmonics
65 Sopran Sax
66 Alto Sax
67 Tenor Sax
68 Bariton Sax
69 Oboe
70 English Horn
71 Bassoon
72 Clarinet
73 Piccolo
74 Flute
75 Recorder
76 Pan Flute
77 Blown Bottle
78 Shakuhachi
79 Whistle
80 Ocarina
81 Square Lead
82 Saw Lead
83 Calliope
84 Chiffer Lead
85 Charang
86 Solo Vox
87 5th Saw wave
88 Bass & Lead
89 New Age
90 Warm Pad
91 Polysynth
92 Choir pad
93 Bowed
94 Metallic
95 Halo pad
96 Sweep
97 Rain
98 Soundtrack 5th
99 Crystal
100 Atmosphere
101 Brightness
102 Goblins
103 Echoes
104 Sci-fi Star
105 Sitar
106 Banjo
107 Shamisen
108 Koto
109 Kalimba
110 Bag pipe
111 Fiddle
112 Shanai
113 Tinkle Bell
114 Agogo
115 Steel Drums
116 Woodblock
117 Taiko Drum
118 Melodic Tom
119 Synth Drum
120 Reverse Cymbal
121 Guitar Noise
122 Breath Noise
123 Seashore
124 Bird
125 Telephon
126 Helicopter
127 Applaus
128 Gunshot
33 Upright Jazz Bass
34 E-Bass fingered
35 E-Bass picked
36 Fretless Bass
37 Slap Bass 1
38 Slap Bass 2
39 Synth Bass 1
40 Synth Bass 2
41 Violin
42 Viola
43 Cello
44 Contrabass
45 Tremolo Strings
46 Pizzicato Strings
47 Harp
48 Timpani
49 String Ensemble 1
50 String Ensemble 2
51 Synth Strings 1
52 Synth Strings 2
53 Choir Aahs
54 Voice Dohs
55 Synth Voice
56 Orchestra Hit
57 Trumpet
58 Trombone
59 Tuba
60 Trp. Mute
61 Horn
62 Brass Section
63 Synth Brass 1
64 Synth Brass 2
2
V3SOUND

MSB Prg.
55 1 Grand Piano
56 1 Classic Grand Piano
57 1 Rock Piano
58 1 Grand Stack 1 FM
59 1 Grand Piano Tinkle
60 1 Grand Piano and Pad
55 2 Bright Piano
56 2 Octave Piano
57 2 Bright Rock Piano
58 2 Grand Stack 2 EP
59 2 Grand Piano just Pad
60 2 Grand Piano Tremolo
55 3 Electric Grand Piano
56 3 Electric Grand Piano 2
57 3 Electric Grand Piano Trem.
58 3 Electric Grand Piano Stack
59 3 Electric Grand Piano Trem.
60 3 Electric Grand Piano hard Atk
55 4 Honky Tonk
56 4 E-Piano Wurly
57 4 E-Piano Wurly Trem. slow
58 4 E-Piano Wurly TInkle
59 4 E-Piano Wurly Trem. fast
60 4 E-Piano Wurly TInkle Trem.sl.
55 5 E-Piano Tines
56 5 E-Piano Tines Tinkle
57 5 E-Piano Tines Tremolo slow
58 5 E-Piano Tines Stack Bells
59 5 E-Piano Tines Tremolo fast
60 5 E-Piano Tines Tinkle Trem. sl.
55 6 E-Piano FM
56 6 E-Piano FM B
57 6 E-Piano FM filter
58 6 E-Piano FM detuned
59 6 E-Piano FM soft pad
60 6 E-Piano FM soft pad tremolo
MSB Prg.
55 7 Harpsichord
56 7 Harpsichord plus octave
57 7 Harpsichord octave delay
58 7 Har. Oct. delay long release
55 8 Clavinet
56 8 Clavinet filter
55 9 Celesta
56 9 Celesta Tinkle
57 9 Celesta Tinkle filter
58 9 Celesta just Attack
59 9 Celesta Tinkle and Pad
60 9 Celesta Tinkle octave delay
55 10 Glockenspiel
55 11 Music Box
56 11 Music Box oct. delay
57 11 Music Box oct. delay soft Atk.
55 12 Vibraphon
56 12 Vibraphon short release
57 12 Vibraphon soft Attack
58 12 Vibraphon no Vib.
59 12 Vibraphon no Vib. shot Rel.
60 12 Vibraphon fast Tremolo
55 13 Marimba
56 13 Marimba octave delay
57 13 Marimba & Xylo.octave delay
58 13 Marimba & Xylophon
55 14 Xylophon
56 14 Xylophon octave delay
55 15 Tubular Bell
56 15 Tubular Bell 2
55 16 Dulcimer
56 16 Dulcimer bright
57 16 Dulcimer 3
58 16 Dulcimer 3 out of tune
59 16 Dulcimer Tremolo
60 16 Dulcimer Fade in
MSB Prg.
55 17 Drawbar Organ
56 17 Ham 776555678 slow
57 17 Ham 776555678 fast
58 17 Ham 800000568 slow
59 17 Ham 800000568 fast
60 17 Ham 807800000 slow
55 18 Percussive Organ
56 18 Entertainer Organ Germany 1
57 18 Entertainer Organ Germany 2
58 18 Vintage German Organ 1
59 18 Vintage German Organ 2
60 18 Ham 807800000 fast
55 19 Rock Organ
56 19 Organ FL 1
57 19 Organ FL 2
58 19 Ham 800000000 slow
59 19 Ham 800000000 fast
55 20 Church Organ
56 20 Church Organ 2
57 20 Church Organ Flutes
55 21 Reed Organ
56 21 Theatre Organ Mighty
57 21 Theatre Organ Piston
58 21 Theatre Organ Acc
55 22 Accordion
56 22 Accordion Alpin 888
57 22 Accordion French Musette
58 22 Accordion French Celeste
59 22 Steirische Harmonika
60 22 Vox 4 Hawaii soft pad
55 23 Harmonica
55 24 Accordion Tango
56 24 Accordion Reed 16 Jazz
57 24 Accordion Reed 8 SCVI
58 24 Melodeon 8
59 24 Bandoneon
60 24 Vox 4 Hawaii fast
MSB Prg.
55 25 Nylon Guitar (120FX)
56 25 Ny. Git. soft (120FX)
57 25 Ny. Git. hard layer (120FX)
58 25 Ny. Git. death note (120FX)
59 25 Ny. Git. oct. Arp (120FX)
55 26 Acoustic Steel (120FX)
56 26 Acoustic Steel soft layers
57 26 Acoustic Steel hard (120FX)
58 26 Ac. Steel Double (120FX)
59 26 Acoustic Steel fall (120FX)
55 27 Jazz Guitar (120FX)
56 27 Jazz Guitar - note off (120FX)
57 27 Jazz Guitar Mute (120FX)
58 27 Jazz Guitar Mute DN (120FX)
59 27 Jazz Guitar Octave
55 28 Guitar clean (120FX)
56 28 Guitar clean soft EQ (120FX)
57 28 Guitar clean - PAD (120FX)
58 28 Guitar clean - stop (120FX)
59 28 Acoustic Steel Mute (120FX)
55 29 Guitar mute clean (120FX)
56 29 Guitar mute HPF (120FX)
55 30 Overdrive Guitar (120FX)²
56 30 Overdrive Guitar 8th (120FX)²
57 30 Ov. Git. Death note (120FX)²
55 31 Distortion Guitar (120FX)²
56 31 Distortion Guitar 8th (120FX)²
57 31 Dis. Gt. Death note (120FX)²
55 32 Guitar harmonics
56 32 Nylon Guitar harmonics
PROGRAM LIST SOLO SOUNDS PROGRAM LIST SOLO SOUNDSVARIATION SOUNDS VARIATION SOUNDS
Sound bank 55 offers the same sounds as GM sound bank 0. But all sounds has more volume and
the sound use OSC overlapping. All sounds in this sound bank needs more polyphony as in Bank 0.
3
V3SOUND

4
MSB Prg.
55 49 String Ensemble 1 20314
56 49 String Ensemble 1 ENV fast
57 49 String Ensemble 1 detache
58 49 String Ensemble 1 Layer
55 50 String Ensemble 2 20301ADL
56 50 String Ensemble 2 slow
57 50 String Ensemble 2 fad m3
58 50 String ENV - Filter ENV
59 50 String Ensemble 2 fad p3
55 51 Synth Strings 1
56 51 Synth Strings 1 filter up
57 51 Synth Strings 1 filter lfo
58 51 Synth Strings 1 filter
55 52 Synth Strings 2 MKS
56 52 Synth Strings 2 MKS dark
57 52 Synth Strings 2 MKS filter
58 52 Synth Strings 2 MKS rel.down
55 53 Choir Aahs
57 53 String Ens. Retro Synth. 1
58 53 String Ens. Retro Synth. 2
55 54 Voice Oohs
56 54 Voice Ooh
57 54 Voice Ooh Double
55 55 Synth Voice
56 55 Synth Voice 2 Layer
57 55 Synth Voice 2 Layer EQ
55 56 Orchestra Hit Major
56 56 Orchestra Hit Minor
55 57 Trumpet
56 57 Trumpet soft layers
57 57 Trumpet hard layers
59 57 Trumpet legato down vel.116
60 57 Trumpet 2 Vibrato forte
55 58 Trombone
56 58 Trombone soft layers
57 58 Trombone hard layers
55 59 Tuba
58 59 Bariton Bass (note 84 up FX)
MSB Prg.
55 60 Trp. Mute
56 60 Trp Mute auto variation
55 61 Horn
55 62 Brass Section
56 62 Brass Section Sfz
57 62 Brass Section fall fast
58 62 Brass Section fall slow
55 63 Synth Brass 1
55 64 Synth Brass 2
55 65 Sopran Sax
56 65 Sopran Sax soft Layers
57 65 Sopran Sax hard Layers
58 65 Sopran Sax soft Layers noise
55 66 Alto Sax
56 66 Alto Sax soft Layers
57 66 Alto Sax hard Layers
58 66 Alto Sax soft Layers noise
55 67 Tenor Sax
56 67 Tenor Sax only soft Layers
57 67 Tenor Sax only hard Layers
58 67 Tenor Sax soft Layers & noise
59 67 Tenor Sax medium version
60 67 Tenor Sax 2 soft Jazz
55 68 Bariton Sax
55 69 Oboe
55 70 English Horn
55 71 Bassoon
55 72 Clarinet
56 72 Clarinet noise
55 73 Piccolo
55 74 Flute
56 74 Flute EQ
57 74 Flute EQ2
MSB Prg.
55 33 Upright Jazz Bass
56 33 Upright Jazz Bass more Atk.
57 33 Upright JB no finger Atk.
55 34 E-Bass fingered
56 34 E-Bass fingered EQ1
57 34 E-Bass fingered EQ2
58 34 E-Bass fingered HQ
55 35 E-Bass picked
56 35 E-Bass picked dark
55 36 Fretless Bass
55 37 Slap Bass 1 (120FX)
55 37 Slap Bass 1 (120FX)
56 38 Slap Bass 2 (120FX)
56 38 Slap Bass 2 (120FX)
55 39 Synth Bass 1
56 39 Synth Bass 1 Reso
57 39 Synth Bass 1 Reso
58 39 Synth Bass 1 filter
55 40 Synth Bass 2
56 40 Synth Bass 2 Reso
57 40 Synth Bass 2 Reso
58 40 Synth Bass 2 filter
55 41 Violin
55 42 Viola
55 43 Cello
55 44 Contrabass
55 45 Tremolo Strings
55 46 Pizzicato Strings
55 47 Harp
55 48 Timpani
MSB Prg.
55 75 Recorder
55 76 Pan Flute
55 77 Blown Bottle
56 77 Blown Bottle soft
57 77 Blown Bottle filter
58 77 Blown Bottle filter LFO
55 78 Shakuhachi
55 79 Whistle
55 80 Ocarina
55 81 Square Lead
56 81 Square Lead 1 Layer
57 81 Square Lead filter ENV
58 81 Square Lead soft Atk.
55 82 Saw Lead
56 82 Saw Lead ENV
57 82 Saw Lead HPF
58 82 Saw Lead dynamic filter
59 82 Saw Lead dynamic filter 24db
55 83 Calliope
56 83 Calliope no noise
55 84 Chiffer Lead
56 84 Chiffer Lead 2
57 84 Chiffer Lead Reso
58 84 Chiffer Lead Notch
59 84 Hook Lead
60 84 Reco Pluck
55 85 Charang
56 85 Charang Low Pass
57 85 Poly FM
55 86 Solo Vox
56 86 Solo Vox Filter
57 86 Solo Vox Filter pad
58 86 Solo Vox Filter Rise
55 87 5th Saw wave
56 87 Saw wave dynamic short
57 87 Saw wave 2
58 87 Saw wave soft
V3SOUND
PROGRAM LIST SOLO SOUNDSVARIATION SOUNDS VARIATION SOUNDS

5
MSB Prg.
55 88 Bass & Lead
56 88 Bass & Lead tuned
57 88 Bass & Lead perc.
58 88 Bass & Lead reso
55 89 New Age
56 89 New age 2
57 89 New age 816
58 89 New age DX1
59 89 New age double
55 90 Warm Pad
56 90 Warm Pad less bass
57 90 Pad Obx
58 90 Soft Pad Obx
59 90 Dark Pad Obx
60 90 Pad Obx Rise
55 91 Polysynth
56 91 Polysynth filter
57 91 Polysynth bright
58 91 Choir pad filter
59 91 Choir pad filter up
55 92 Choir pad
56 92 Choir pad 2
57 92 Choir pad 3
55 93 Bowed
56 93 More Metal Pad
55 94 Metallic
55 95 Halo pad
55 96 Sweep
56 96 Sweep fast
57 96 Sweep fast attack
55 97 Rain
55 98 Soundtrack 5th
56 98 Soundtrack
57 98 Soundtrack soft
58 98 Soundtrack fast
60 98 Soundtrack fast fad stereo
55 99 Crystal
56 99 Crystal HPF
57 99 Crystal note off
MSB Prg.
55 100 Atmosphere
56 100 Atmosphere 2
55 101 Brightness
56 101 Brightness 1OP
57 101 Brightness Notch
55 102 Goblins
55 103 Echoes
55 104 Sci-fi Star
55 105 Sitar
57 105 Rhy. Guitar Steel CX (120FX)²
58 105 Rhy.Guitar soft CX (120FX)²
55 106 Banjo
57 106 Rhythm Guitar Folk
58 106 Rhythm Guitar Folk less Bass
55 107 Shamisen
55 108 Koto
58 108 Mandoline Tremolo
55 109 Kalimba
55 110 Bag pipe
55 111 Fiddle
56 111 Fiddle less Attack
55 112 Shanai
55 113 Tinkle Bell
55 114 Agogo
55 115 Steel Drums
55 116 Woodblock
55 117 Taiko Drum
55 118 Melodic Tom
55 119 Synth Drum
55 120 Reverse Cymbal
59 120 Bell noise motion
55 121 Guitar Noise
55 122 Breath Noise
55 123 Seashore
55 124 Bird
55 125 Telephon
55 126 Helicopter
55 127 Applaus
55 128 Gunshot
MSB Prg.
61 25 Ny. Git. slide 116 (120FX)
61 26 Ac. Steel slide 116 (120FX)
61 34 E-Bass fing. slide 116
61 57 Trumpet slide 116
61 65 Sopran Sax slide 116
61 66 Alto Sax slide 116
61 67 Tenor Sax 1 slide 116
61 72 Clarinet slide 116
61 106 Banjo slide 116
61 111 Fiddle slide up 116
V3SOUND
PROGRAM LIST SOLO SOUNDSVARIATION SOUNDS SLIDE VARIATION SOUNDS
This sound use a special velocity mapping.
From the velocity value 116 to top you get a slide
up sound.

6
Violin Ensemble
31 Marcato
32 Slow Attack
33 Detache
34 Legato 1
35 Legato 2
36 Legato up bend - small
37 Legato up bend - medium
38 Legato down bend - small
39 Legato down bend - meium
40 Pizzicato
Viola Ensemble
41 Marcato
42 Slow Attack
43 Detache
44 Legato 1
45 Legato 2
46 Legato up bend - small
47 Legato up bend - medium
48 Legato down bend - small
49 Legato down bend - medium
50 Pizzicato
Cello Ensemble
51 Marcato
52 Slow Attack
53 Detache
54 Legato 1
55 Legato 2
56 Legato up bend - small
57 Legato up bend - medium
58 Legato down bend - small
59 Legato down bend - medium
60 Pizzicato
Contrabass Ensemble
61 Marcato
62 Slow Attack
63 Detache
64 Legato 1
65 Legato 2
66 Legato up bend - small
67 Legato up bend - medium
68 Legato down bend - small
69 Legato down bend - medium
70 Pizzicato
FULL Symphonic String Orchestra
01 Dynamic Marcato/Legato fast
02 Dynamic Marcato/Legato (no note-off)
03 Dynamic Marc./Leg. slow (no note-off)
04 Marcato/Legato (no note-off samples)
05 Marcato piano (no note-off samples)
FULL Chamber Ensemble
06 Dynamic Marcato/Legato fast
07 Dynamic Marcato/Legato (no note-off)
08 Dynamic Marc. Leg. slow (no note-off)
09 Marcato/Legato (no note-off samples)
10 Marcato piano (no note-off samples)
Group Ensembles
11 Violins Marcato/Legato fast
12 Violas Marcato/Legato fast
13 Celli Marcato/Legato fast
14 Contra.Bs. Marcato/Legato fast
Just Piano Samples
15 Violins just piano Layer
16 Violins just piano Layer slow
17 Violas just piano Layer
18 Violas just piano Layer slow
Ensemble Articulations
19 Pizzicato
20 Tremolo
22 Disco Violins short
23 Disco Violins Fall
Solo Violin
71 Marcato
72 Slow Attack
73 Detache
74 Legato 1
75 Legato 2
76 Legato up bend - small
77 Legato up bend - medium
78 Legato down bend - small
79 Legato down bend - medium
80 Pizzicato
Solo Viola
81 Marcato
82 Slow Attack
83 Detache
84 Legato 1
85 Legato 2
86 Legato up bend - small
87 Legato up bend - medium
88 Legato down bend - small
89 Legato down bend - medium
90 Pizzicato
Solo Cello
91 Marcato
92 Slow Attack
93 Detache
94 Legato 1
95 Legato 2
96 Legato up bend - small
97 Legato up bend - medium
98 Legato down bend - small
99 Legato down bend - medium
100 Pizzicato
Solo Contrabass
101 Marcato
102 Slow Attack
103 Detache
104 Legato 1
105 Legato 2
106 Legato up bend - small
107 Legato up bend - medium
108 Legato down bend - small
109 Legato down bend - medium
110 Pizzicato
Solo Tremolo
111 Violin Tremolo
112 Viola Tremolo
113 Cello Tremolo
114 Contrabass Tremolo
Solo Piano Layer only
115 Violin - Piano
116 Viola - Piano
Ensembles no note-off samples
117 Violin Ens. Marcato (no note-off)
118 Violin Ens. Legato (no note-off)
119 Viola Ens. Marcato (no note-off)
120 Viola Ens. Legato (no note-off)
121 Cello Ens. Marcato (no note-off)
122 Cello Ens. Legato (no note-off)
123 Contrabass Ens. Marcato (no note-off)
124 Contrabass Ens. Legato (no note-off)
PROGRAM LIST SOLO SOUNDS PROGRAM LIST SOLO SOUNDSCLASSIC ORCHESTRA BANK MSB 62 CLASSIC ORCHESTRA BANK MSB 62
V3SOUND

PROGRAM LIST SOLO SOUNDS PROGRAM LIST SOLO SOUNDSCLASSIC ORCHESTRA BANK MSB 63 CLASSIC ORCHESTRA BANK MSB 63
Trumpet Ensemble
01 Marcato (velo. spl. piano47/forte48)
02 Marcato Piano
03 Staccato
04 Sforzato
05 Legato
06 Legato up bend - small
07 Legato up bend - medium
08 Legato down bend - small
09 Legato down bend - medium
10 -
Trombone Ensemble
11 Marcato (velo. spl. piano47/forte48)
12 Marcato Piano
13 Staccato
14 Sforzato
15 Legato
16 Legato up bend - small
17 Legato up bend - medium
18 Legato down bend - small
19 Legato down bend - medium
20 -
Horn Ensemble * Note Riff up
21 Marcato (velo. spl. piano47/forte48)
22 Marcato Piano
23 Staccato
24 Sforzato
25 Legato
26 Legato up bend - small
27 Legato up bend - medium
28 Legato down bend - small
29 Legato down bend - medium
30 -
Tuben Ensemble
31 Marcato
Tenorhorn Ensemble
41 Tenorhorn Ensemble
Tenorhorn
101 Tenorhorn
Extras instument effects
121 Horn Riff up - Note 60-84
Bb Trumpet
61 Marcato (velo. spl. piano47/forte48)
62 Marcato Piano
63 Staccato
64 Sforzato
65 Legato
66 Legato up bend - small
67 Legato up bend - medium
68 Legato down bend - small
69 Legato down bend - medium
70 -
Trombone
71 Marcato (velo. spl. piano47/forte48)
72 Marcato Piano
73 Staccato
74 Sforzato
75 Legato
76 Legato up bend - small
77 Legato up bend - medium
78 Legato down bend - small
79 Legato down bend - medium
80 -
Horn
81 Marcato (velo. spl. piano47/forte48)
82 Marcato Piano
83 Staccato
84 Sforzato
85 Legato
86 Legato up bend - small
87 Legato up bend - medium
88 Legato down bend - small
89 Legato down bend - medium
90 -
Tuba
91 Marcato (velo. spl. piano47/forte48)
92 Marcato Piano
93 Staccato
94 Sforzato
95 Legato
96 Legato up bend - small
97 Legato up bend - medium
98 Legato down bend - small
99 Legato down bend - medium
100 -
7
V3SOUND

PROGRAM LIST SOLO SOUNDS PROGRAM LIST SOLO SOUNDSCLASSIC ORCHESTRA BANK MSB 64 CLASSIC ORCHESTRA BANK MSB 64
C-Flute
01 Marcato
02 Slow Attack
03 Staccato
04 Sforzato
05 Legato
06 Legato up bend - small
07 Legato up bend - medium
08 Legato down bend - small
09 Legato down bend - medium
10 -
Oboe
11 Marcato
12 Slow Attack
13 Staccato
14 Sforzato
15 Legato
16 Legato up bend - small
17 Legato up bend - medium
18 Legato down bend - small
19 Legato down bend - medium
20 -
English horn
21 Marcato
22 Slow Attack
23 Staccato
24 Sforzato
25 Legato
26 Legato up bend - small
27 Legato up bend - medium
28 Legato down bend - small
29 Legato down bend - medium
30 -
Bb Clarinet
31 Marcato
32 Slow Attack
33 Staccato
34 Sforzato
35 Legato
36 Legato up bend - small
37 Legato up bend - medium
38 Legato down bend - small
39 Legato down bend - medium
40 -
Extras
127 Percussion Map / Drumkit 62
With this program you can use the
orchestra percussion sounds
on any standard MIDI channel.
After power on it´s
MIDI Channel 1-9 and 11-16
128 Silence - no sound
101 Ensemble Flutes
102 Ensemble Clarinets
Bass Clarinet
41 Marcato
Bassoon
51 Marcato
52 Slow Attack
53 Staccato
54 Sforzato
55 Legato
56 Legato up bend - small
57 Legato up bend - medium
58 Legato down bend - small
59 Legato down bend - medium
60 -
Contra Bassoon
61 Marcato
8
V3SOUND

Nr. Kit 1 Kit 9 Kit 17 Kit 25 Kit 26 Kit 27 Kit 28 Kit 29 Kit 31 Kit 32 Kit 33 Kit 41 Kit 49 Kit 62
GM Electro 808/909 909 analog 2010 2011 Party Jazz Brush Orchestra Orchestra
G 7 Brush AY swirl 1 ~ ~ ~ ~ ~ Gran Casa
8 Brush AY swirl 2 ~ ~ ~ ~ ~ Gran Casa
A 9 Brush AY swirl 3 ~ ~ ~ ~ ~ Gran Casa
10 Brush MO open ~ ~ ~ ~ ~ Gran Casa
11 Brush MO ~ ~ ~ ~ ~ Gran Casa
C 12 Brush MO ~ ~ ~ ~ ~ Gran Casa
13 Brush MO o. ac ~ ~ ~ ~ ~ Gran Casa
D 14 Snare AY ~ ~ ~ ~ ~ Gran Casa
15 Snare AY ~ ~ ~ ~ ~ Gran Casa
E 16 Snare AY ~ ~ ~ ~ ~ Gran Casa
F 17 Rim AY Rim MO ~ Jz. Stick Rim ~ Rim MO Gran Casa
18 Snare AY Snare MO ~ Jazz Stick Std ~ Snare MO GC. forte
G 19 Snare AY Snare MO ~ Jz. Stick Rim ~ Rim MO GC. medium
20 Snare AY Snare MO ~ Jazz Stick Std ~ Snare MO GC. piano
A 21 Snare AY Snare MO ~
22 Sn. AY shallow Sn. MO sh ~ Jazz Stich sh ~ Snare MO
23 Snare Rim shot Sn. MO Rims ~ Jz. Stick Rim ~ Snare MO Gong
C 24 Snare Rim shall. Sn. MO RiSh ~ Jz. Stick Rsh. ~ Snare MO
25 Buzzer ~ ~ ~ ~ ~
D 26
27 High Q ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ Closed HH
E 28 Slap ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ Pedal Ped.
F 29 Scratch Push (7) ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ Open HH.
30 Scratch Pull (7) ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ Ride Cymbal
G31Sticks ~~~~~~~~~~~~
32 Square Click ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~
A 33 Metronom Click ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~
34 Metronom Bell ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~
35 Bass Drum 1 BD 3 BD 5 Elec BD 7 909 BD 9 909 BD 11 606 BD 13 Hit BD 15 Hit BD 17 Party BD 19 Jazz BD 21 Jazz BD 21 BD 23 Gran Casa
C 36 Bass Drum 2 BD 4 BD 6 Elec BD 8 808 BD 10 909 BD 12 80 BD 14 Hit BD 16 Hit BD 18 Party BD 20 Jazz BD 22 Jazz BD 22 BD Orch. Gran Casa
37 Rim ~ ~ Rim 808 808 Rim 909 Rim 606 Rim 909 Rim 909 Rim 909 Rim Jazz Rim Sidestick ~
D 38 Snare 1 AY Snare 2 MO Snare 3 SO Elec Snare 1 808 Snare 1 909 Snare 2 Snare 80 Hit Snare 1 Hit Snare 3 Party Snare 1 Jazz Snare 1 Brush mp Snare Orch. Concert Sn.
39 Clap ~ ~ Clap 808 Clap 808 Clap 808 Clap 80 Hit Clap Hit Clap Hit Clap ~ Brush mf Castanet Castanets
E 40 Snare 1 AY Snare 2 MO Snare 3 SO Elec Snare 2 909 Snare 1 909 Snare 1 Snare 85 Hit Snare 2 Hit Snare 4 Party Snare 2 Jazz Snare 2 Brush swirl Snare Orch. Concert Sn.
F41 Tom Low Low ~ ~ Elec Tom 80 808 Tom 909 Tom Tom 85 909 Tom 909 Tom 909 Tom ~Brush Tom Timpani Timpani
42 HiHat closed (0) ~ ~ HH elec 808 HHat cl. 909 HHat cl. HHat cl. 85 909 HHat cl. 909 HHat cl. 909 HHat cl. ~ ~ Timpani Timpani
G 43 Tom Low ~ ~ Elec Tom 80 808 Tom 909 Tom Tom 85 909 Tom 909 Tom 909 Tom ~Brush Tom Timpani Timpani
44 HiHat Pedal (0) ~ ~ HH elec 808 HHat P. 909 HHat P. HHat cl. 85 909 HHat P. 909 HHat P. 909 HHat e. ~ ~ Timpani Timpani
A 45 Tom Medium L. ~ ~ Elec Tom 80 808 Tom 909 Tom Tom 85 909 Tom 909 Tom 909 Tom ~Brush Tom Timpani Timpani
46 HiHat open (0) ~ ~ HH elec 808 HH. op. 909 HH. op. HHat cl. 85 909 HH. op. 909 HH. op. 909 HH. op. ~ ~ Timpani Timpani
47 Tom Medium ~ ~ Elec Tom 80 808 Tom 909 Tom Tom 85 909 Tom 909 Tom 909 Tom ~Brush Tom Timpani Timpani
C 48 Tom High ~ ~ Elec Tom 80 808 Tom 909 Tom Tom 85 909 Tom 909 Tom 909 Tom ~Brush Tom Timpani Timpani
49 Crash Cymbal 1 ~ ~ Crash 909 808 Cym 909 Cym 808 Cym 808 Cym 808 Cym 808 Cym ~ ~ Timpani Timpani
D 50 Tom High High ~ ~ Elec Tom 80 808 Tom 90 Tom Tom 85 90 Tom 90 Tom 90 Tom ~Brush Tom Timpani Timpani
51 Ride Cymbal 1 ~ ~ Ride 909 Ride 909 Ride 909 Ride 85 Ride 909 Ride 909 Ride 909 ~ ~ Timpani Timpani
E 52 China Cymbal ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ Timpani Timpani
F 53 Ride Cup ~ ~ Cup 66 Cup 66 Cup 66 Cup 66 Cup 66 Cup 66 Cup 66 ~ ~ Timpani Timpani
54 Tambourin ~ ~ Tamb. 66 Tamb. 66 Tamb. 77 Tamb. 66 Tamb. 77 Tamb. 77 Tamb. 77 ~ ~ ~ Tamburin
G 55 Splash Cymbal ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ Concert Cy.
56 Cowbell ~ ~ ~ 808 Cowbell 808 Cowbell 808 Cowbell 808 Cowbell 808 Cowbell 808 Cowbell Cowbell Jazz Cowbell Jazz ~ Concert Cy.
A 57 Crash Cymbal 2 ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ Concert Cy.
58 Vibraslap ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ Concert Cy.
59 Ride Cymbal 2 ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ Concert Cy.
C 60 Bongo high ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ Concert Cy.
61 Bongo low ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ Concert Cy.
D 62 Conga mute ~ ~ Conga elec. Conga elec. Conga elec. Conga elec. Conga elec. Conga elec. Conga elec. ~ ~ ~ Concert Cy.
63 Conga open ~ ~ Conga elec. Conga elec. Conga elec. Conga elec. Conga elec. Conga elec. Conga elec. ~ ~ ~ Concert Cy.
Drumkits are just available on DRUM
MODE parts. The MIDI-sysex message
„General MIDI reset“ set up
MIDI-Channel 10 as DRUM MODE part.
MIDI-Sysex can change any Part
DRUM MODE.
DRUM KITS
1 Drum - General MIDI HQ
2 Drum - General MIDI HQ Pop
9 Drum Hit Kit
17 Studio Kit
25 Drum Electro 80
26 Drum Computer 808/909
27 Drum 909
28 Drum Electro Vintage
29 Drum Dance Kit
31 Drum Dance Kit
32 Drum Dance Kit
33 Drum Jazz Stick Kit
41 Drum Brush Kit
49 Orchestra Kit
62 Orchestra Kit
V3SOUND

Nr. Kit 1 Kit 9 Kit 17 Kit 25 Kit 26 Kit 27 Kit 28 Kit 29 Kit 31 Kit 32 Kit 33 Kit 41 Kit 49 Kit 62
E 64 Conga low ~ ~ Conga elec. Conga elec. Conga elec. Conga elec. Conga elec. Conga elec. Conga elec. ~ ~ ~ Concert Cy.
F 65 Timbale high ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ Concert Cy.
66 Timbale low ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ C. Cy. Roll
G 67 Agogo high ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~
68 Agogo low ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~
A 69 Cabasa ~ ~ Cabasa elec. Cabasa elec. Cabasa elec. Cabasa elec. Cabasa elec. Cabasa elec. Cabasa elec. ~ ~ ~
70 Maracas ~ ~ Maracas el. Maracas el. Maracas el. Maracas el. Maracas el. Maracas el. Maracas el. ~ ~ ~
71 Whistle (2) ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~
C 72 Whistle (2) ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ Triangle op.
73 Guiro short (3) ~ ~ Guiro elec. Guiro elec. Guiro elec. Guiro elec. Guiro elec. Guiro elec. Guiro elec. ~ ~ ~ Triangle mu.
D 74 Guiro long (3) ~ ~ Guiro elec. Guiro elec. Guiro elec. Guiro elec. Guiro elec. Guiro elec. Guiro elec. ~ ~ ~ Triangle roll
75 Claves ~ ~ Claves elec. Claves elec. Claves elec. Claves elec. Claves elec. Claves elec. Claves elec. ~ ~ ~
E 76 Woodblock low ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~
F 77 Woodblock hi ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ Wind. dwn.
78 Cuica mute (4) ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ Wind. up
G 79 Cuica open (4) ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~
80 Triangle mute(5) ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~
A 81 Triangle open(5) ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~
82 Shaker ~ ~ Shaker elec. Shaker elec. Shaker elec. Shaker elec. Shaker elec. Shaker elec. Shaker elec. ~ ~ ~
83 Jingle Bell ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~
C 84 Bell Tree ~~~~~~~~~~~~
85 Castanet ~ ~ Zap Zap Zap Zap Zap Zap Zap ~ ~ ~
D 86 Surdo mute (6) ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~
87 Surdo open (6) ~ ~ ~ ~ ~
E 88 Applaus Applaus
F 89 C. Snare pp
90 Bass Dr. 1 mp BD 3 BD 5 BD 7 BD 7 ~ C. Snare p
G 91 Bass Dr. 1 mf ~ ~ ~ ~ ~ C. Snare mp
92 Bass Dr.1 f ~ ~ ~ ~ ~ C. Snare mf
A 93 Bass Dr. 1 ff ~ ~ ~ ~ ~ C. Snare f
94 Bass Dr .1 mp ~ ~ ~ ~ ~ C. Snare ff
95 Bass Dr. 1 mf BD 4 BD 6 BD 8 BD 8 ~ C. Snare pp
C 96 Bass Dr. 1 f ~ ~ ~ ~ ~ C. Snare p
97 Bass Dr. 1 ff ~ ~ ~ ~ ~ C. Snare mp
D 98 HiHat Pedal (7) ~ ~ ~ ~ ~ C. Snare mf
99 Hi Hat cl. Tip ~ ~ ~ ~ ~ C. Snare f
E 100 Hi Hat cl. Pearl ~ ~ ~ ~ ~ C. Snare ff
F 101 Hi Hat cl. Pearl ~ ~ ~ ~ ~ Snare Roll p
102 Hi H. cl. Shaft 1 ~ ~ ~ ~ ~ Snare Roll p
G 103 Hi H. cl. Shaft 2 ~ ~ ~ ~ ~ Snare Roll m
104 Hi Hat med. 1 ~ ~ ~ ~ ~ Snare Roll m
A 105 Hi Hat med. 2 ~ ~ ~ ~ ~ Snare Roll f
106 Hi Hat Open 1 ~ ~ ~ ~ ~ Snare Roll f
107 Hi Hat Open 2 ~ ~ ~ ~ ~ Snare Ro.dyn
C 108 Hi Hat Splash ~ ~ ~ ~ ~ Snare Ro.dyn
109 Hi Hat Open 3 ~ ~ ~ ~ ~ Snare Ro.dyn
D 110 Ride Pearl ~ ~ ~ ~ ~ Snare Ro.dyn
111 Ride Pearl retrig ~ ~ ~ ~ ~ Snare Ro.dyn
E 112 Ride Cup ~ ~ ~ ~ ~ Snare Ro.dyn
F 113 Ride Cup retrig. ~ ~ ~ ~ ~ Opera Gong
114 Ride Shaft (8) ~ ~ ~ ~ ~ Opera Gong
G 115 Ride Shaft retrig. ~ ~ ~ ~ ~ Opera Gong
116 Ride Chock (8) ~ ~ ~ ~ ~ Opera Gong
A 117 Cym Crash 1 (9) ~ ~ ~ ~ ~ Opera Gong
118 Cym Splash (9) ~ ~ ~ ~ ~ Opera Gong
119 Cym Crash 2 (9) ~ ~ ~ ~ ~ Opera Gong
C 120 Cym Chock (9) ~ ~ ~ ~ ~ Opera Gong
121 Brush 1. Cym. O. s (1) Opera Gong
D 122 Brush 2. Cym. O. s Opera Gong
123 Brush 3. Cy. O. m (1) Opera Gong
E 124 Brush Rm Cy. O. m Opera Gong
F 125 Brush metal Cy. . open(1) Opera Gong
126 Brush A Cy. O. op. (1) Opera Gong
G 127 Brush B Intro Tune
V3SOUND

11
84 - Portamento control 91 - Reverb send 93 - Chorus send 120 - All sound off 121 - Reset all controllers 123 - All note off 126 - Mono-mode 127 - Poly-mode
RPN 0000H BnH 65H 00H 64H 00H 06H vv Pitch bend sensitive in semitone (default=2)
RPN 0001H Fine tune in cent BnH 65H 00H 64H 01H 06H vv vv=00 -100 vv=40H 0 vv=7FH +100
RPN 0002H Coarse tune half tone BnH 65H 00H 64H 02H 06H vv vv=00 -64 vv=40H 0 vv=7FH +64
NRPN 18rrH BnH 63H 18H 62H rr 06H vv Pitch coarse of perc. rr in semitone (vv=40H->no modif)
NRPN 1ArrH BnH 63H 1AH 62H rr 06H vv Level of perc. sound rr (vv=00 to 7FH)
NRPN 1CrrH BnH 63H 1CH 62H rr 06H vv Pan of perc. sound rr (40H = middle)
NRPN 1DrrH BnH 63H 1DH 62H rr 06H vv Reverb send level of perc rr (vv=00 to 7FH)
AUX AUDIO OUT (Reverb return is fixed in Main out)
BnH 63H 38H 62H rr 06H vv rr = MIDI channel - CH1 = 00 CH2 = 01
vv = 0 MAIN 127=AUX Example :Set CH1 to AUX - send 3 MIDI controllers: cc99 value 56 + cc98 value 00 + cc06 value 127
Program Change : 0-127 * depends on sound board System Exclusive: SYSEX F0H 7EH 7FH 09H 01H F7H General MIDI Reset SYSEX F0H 7FH 7FH 04H 01H 00H II F7H Master volume (II=0 to 127, default 127) SYSEX DSP1 F0h,41h,00h,42h,12h,40h,7Fh,7Fh,xxh,00h,F7h
xxh=Effect 00h=HALL1 01h=HALL2 02h=ROOM1 03h=ROOM2 04h=ROOM3“ 05h=PLATE1 06h=PLATE2 07h=PLATE3 08h=CHORUS 09h=FLANGE 0Ah=DELAY1 0Bh=DELAY2 0Ch=CHORUS/ROOM1 0Dh=CHORUS/ROOM2 0Eh=VOCCANCEL 0Fh=ROTARY SPEAKER
SYSEX DSP2 F0h,41h,00h,42h,12h,40h,01h,38h,xxh,00h,F7h xxh=Effect
0h=CHORUS 1 02h=CHORUS 3 04h=FEEDBACK 06h=SHORT DELAY
01h=CHORUS 2 03h=CHORUS 4 05h=FLANGER 07h=FB DELAY
Recognized
Basic Default 1 - 16 Mode 3 poly mode Messages Note number * 12-109 * depends on sounds Velocity Note ON 9nH,v=1-127 o Note OFF 9nH,v=0 x Key aftertouch o Channel aftertouch o Pitch Bend 0-12 Bank Select 00 * value depends on sound board - see page 3-13 Controller 01 - Modulation
05 - Portamento time 06 - Data Entry 07 - Volume 10 - Panorama 11 - Expression 64 - Sustain 65 - Portamento 66 - Sostenuto 71 - Filter resonance 72 - ENVELOPE Release 73 - ENVELOPE Attack 74 - Filter cutoff 75 - ENVELOPE Decay 76 - Vibrato rate 77 - Vibrato depth 78 - Vibrato delay
V3SOUND - MIDI IMPLEMENTATION

celtic
sound pack
sound list
midi implementation
V3SOUND.COM

Prg. Accordions scottish tuned
1 HOH Gol. 888
2 HOH Gol. 888-16
3 HOH Gol. 4-888
4 HOH Gol. 4-888-16
5 HOH Domino 888
6 HOH Domino 888-16
7 HOH Domino 4-888
8 HOH Domino 4-888-16
9 HOH J. Shand 888
10 HOH J. Shand 888-16
11 HOH J. Shand 4-888
12 HOH J. Shand 4-888-16
Accordions irish tuned
13 BOR Irish 888
14 BOR Irish 888-16
15 BOR Irish 4-888
16 BOR Irish 4-888-16
17 PMA Irish 88
18 PMA Irish 88-16
19 PMA Irish 4-88
20 PMA Irish 48816
21 PMA Irish 8
22 PMA Irish 8-16
23 PMA Irish 4-8
24 PMA Irish 4-8-16
Accordions standard tuned
25 PMA V3 8+88 wide
26 PMA V3 8+88 wide dark
27 PMA V3 8+88+8 wide
28 PMA V3 8+88 small
29 HOH Harmon 4816
30 HOH Harmon 4816 (4+)
31 HOH Harmon 4816 (4++)
32 HOH Harmon 4816 (4+++)
33 BUG Reed 16
34 ALG Reed 4
Melodeons & Concertina
35 BRA Irish tuned Melodeon 88
36 WMA 8+8 tune small
37 WMA 8+8 tune medium
38 WMA 8+8 tune wide
39 WMA 8+ Acc. 8 tune small
40 WMA 8+ Acc. 8 tune med.
41 WMA 8+ Acc. 8 tune wide
42 Concertina
ALL BRAND/PRODUCT NAMES ARE
REGISTERED TRADEMARKS OF THEIR
RESPECTIVE HOLDERS
HOH Hohner
BOR Borsini
PMA Pietro Mario
BUG Bugari
ALG Alpengold
BRA Brandoni
WMA Weltmeister
Legend
round
robin
Articulation happen
automatically
Repetition Straight samples
changes automatically
Slices Rhythm patterns
find MIDI-files in our homepage
Prg.
117-120
Could be mixed with any reed
instrument
High Whistle (Repetition)
43 High Whistle
44 High Whistle - round robin grace notes
45 High Whistle - slide up velocity 116-127
46 High Whistle - just grace notes to use in MIDI-files
Low Whistle
47 Low Whistle
48 Low Whistle - slide up velocity 116-127
Pipes (Repetition)
49 Bag Pipe
50 Bag Pipe - round robin grace notes
51 Bag Pipe - slide up velocity 116-127
note no. 120 birls to use in MIDI-files
52 Bag Pipe - just grace notes to use in MIDI-files
53 Bad Pipe - drone
Ullian Pipe (Repetition)
54 Ullian Pipe
55 Ullian Pipe - round robin grace notes
56 Ullian Pipe - slide up velocity 116-127
note no. 120 birls to use in MIDI-files
57 Ullian Pipe - just grace notes to use in MIDI-files
58 Ullian Pipe - drone & chord
Pipe Group (Repetition)
59 Highland Pipes
60 Highland Pipes - round robin grace notes
61 Highland Pipes - drone
62 Highland Pipes - just grace notes to use in MIDI-files
Fiddle (Repetition)
63 Fiddle
64 Fiddle - less attack
65 Fiddle - slide up velocity 116-127
66 Fiddle - slide up slow velocity 116-127
Banjo (Repetition)
67 Banjo
68 Banjo - slide up velocity 116-127
Harp
69 Harp
70 Harp less release
Mandolin
71 Mandolin
Steel Guitar
72 Steel Guitar
Piano
73 Grand Piano - full dynamic
74 Grand Piano - very soft dynamic
75 Grand Piano - soft dynamic
76 Grand Piano - medium dynamic
77 Grand Piano - hard dynamic
78 Grand Piano - no velocity
Contrabass
79 Contrabass
80 Contrabass more release
81 CB more finger noise
82 CB more finger noise& release
83 CB no finger noise
84 CB no finger noise & release
empty
85-116 empty
Noise partial
117 Key off
118 Attack layer linear
119 Attack layer concave
120 Attack Layer concace offset 50
Drums
121 Drum sound
122 Drum sound
123 Drum sound
124 Drum sounds Pipeband
Bodhran slices (for MIDI-files)
125 Bodhran slices 1
126 Bodhran slices 2
127 Bodhran slices 3
Silence
128 Silence
CELTIC BANK MSB 71 CELTIC BANK MSB 71
V3SOUND

PRG. 121
C 12
Ride Repetition cc56~
23
C 24 Ride
Repetition
velocity 1-127
Bass Drum
cc56
cc57
~
35
C 36 Ride
Repetition
velocity 1-115
Crash
Repetition
velocity 116-127
Bass Drum
cc56
cc57
~
47
C 48
Bass Drum cc57~
59
C 60
HiHat Pedal cc56~
71
C 72 HiHat Pedal
Bass Drum
cc56
cc57
~
83
MAPPING BANK MSB 71
PRG. 122+123
1 Snare roll
2 Snare roll
3 Drum Stick
4 - 11 Concert bass drum & Cymbal
12 - 23 Bass & Ride
24 - 35 Kick & HiHat Pedal
C 36 BD
37 Rim cc56 & HiHat cc59
D 38 Snare cc56 & HiHat cc59
39 Clap cc 56 & HiHat cc59
E 40 Snare cc 56 & HiHat cc59
F 41 Tom Low Low
42 HiHat closed (2) SCOTLAND
G 43 Tom Low
44 HiHat Pedal (2) SCOTLAND
A 45 Tom Medium L.
46 HiHat open (2) SCOTLAND
47 Tom Medium
C 48 Tom High
49 Crash Cymbal 1
D 50 Tom High High
51 Ride Cymbal 1
E 52 China Cymbal
F 53 Ride Cup
54 Tambourin
G 55 Splash Cymbal
56 Cowbell
A 57 Crash Cymbal 2
58 Vibraslap
59 Ride Cymbal 2
C 60 Brush roll A & Ride
61 Brush roll B & Ride
D 62 Brush roll C & Ride
63 Brush Mix A & Ride
E 64 Brush Mix A long swirl & Ride
F 65 Brush Mix B & Ride
66 Brush Mix B long swirl & Ride
G 67 Brush Tap single hit & Ride
68 Brush Tap single hit & Ride
A 69 Brush Tap single hit & Ride
70 Brush swish & Ride
71 Brush swish & Ride
C 72 Brush roll A & HiHat
73 Brush roll B & HiHat
74 Brush roll C & HiHat
D 75 Brush Mix A & HiHat
E 76 Brush Mix A long swirl & HiHat
F 77 Brush Mix B & HiHat
78 Brush Mix B long swirl & HiHat
G 79 Brush Tap single hit & HiHat
80 Brush Tap single hit & HiHat
81 Brush Tap single hit & HiHat
82 Brush swish & HiHat
83 Brush swish & HiHat
C 84 Stick Roll & HiHat
85 Stick Roll & HiHat
D 86 Stick Rim & HiHat
87 Stick & roll * roll fade & HiHat
E 88 Stick & roll * linear 2 & HiHat
F 89 Stick & roll * linear 3 & HiHat
90 Stick & roll * linear 4 & HiHat
G 91 Stick single stroke & HiHat
92 Stick single stroke & HiHat
A 93 Stick single sroke & HiHat
94 Stick roll accent & HiHat
95 Stick roll no accent & HiHat
C 96 Stick Roll & Ride
97 Stick Roll & Ride
D 98 Stick Rim & Ride
99 Stick & roll * roll fade & Ride
E 100 Stick & roll * linear 2 & Ride
F 101 Stick & roll * linear 3 & Ride
102 Stick & roll * linear 4 & Ride
G 103 Stick single stroke & Ride
104 Stick single stroke & Ride
A 105 Stick single sroke & Ride
106 Stick roll accent & Ride
107 Stick roll no accent & Ride
C 108 SC HiHat Pedal A (3)
109 SC HiHat Pedal B (3)
D 110 SC HiHat Pedal C (3)
111 SC HiHat closed A (3)
E 112 SC HiHat closed B (3)
F 113 SC HiHat open (3)
114 Rim cc56 & Ride cc59
G 115 Claps cc56 & Ride cc59
116 Stick 3 Roll & Ride
A 117 Stick 3 Roll & Ride
118 Stick 3 Roll & HiHat
119 Concert BD and Cymbal
C 120 Concert BD and Cymbal open
121 Concert BD low
D 122 Concert BD
123 Concert BD
E 124 Concert BD
125 Concert Cymbal medium
126 Concert Cymbal open
MAPPING BANK MSB 71 PRG. 122+123
MAPPING DRUMKIT 71 - SAME AS PRG. 123
Prg. 123
Adjust volume of layered sounds
with MIDI controller
cc56 cymbals
cc57 drums
Prg. 122
no Cymbal layer
V3SOUND
PRG. 124
2-4 Concert BD
5-7 Concert BD
8-10 Concert BD
11-13 Concert BD
17-19 Concert BD
20-22 Concert BD
24-36 Tenor Tom
37 Pipe Snare (cc56) + roll (cc57)
38 Pipe Snare (cc56) + roll (cc57)
39-45 Pipe Snare
48-59 Pipe Snare
62-67 Pipe Snare flam
70-73 Pipe Snare 1st
76-79 Pipe Snare roll
81-82 Pipe Snare open roll
84-87 Pipe Band Snare group
89-96 Pipe Band Snare group
98-101 Pipe Band Snare group
108-111 Sound
120-122 OFF

100 accordions
sound pack
sound list
midi implementation
V3SOUND.COM

Prg. Alpin Accordions R
01 HOH Alpina 888
02 HOH Alpina 4+888+16
03 HOH Alpina 4+888
04 HOH Alpina 888+16
05 ZUP Alpin 888
06 ZUP Alpin 88
07 ZUP Alpin 4+88
08 ZUP Alpin 88+16
09 ZUP Alpin 4+88+16
10 ZUP Alpin 8 Reed (Cassotto)
11 ZUP Alpin 8+8 tune med.
12 ZUP Alpin 8+8 tune flat
13 ZUP Alpin 8+8 tune small
14 ZUP Alpin 8+8 tune wide
15 ZUP Alpin 8+16
16 ZUP Alpin 4
French Accordions
17 MAU Musette 888
18 MAU Musette 888+16
19 MAU Musette 4+888
20 MAU Musette 4+888+16
21 HOH 88 
22 HOH 88+16 
23 HOH 816 
24 HOH 4+816 
25 CAV Ve10 88
26 CAV Ve10 88+16
27 CAV Ve10 88+1616
28 CAV Ve10 1616 (Cassotto)
29 CAV Ve10 1616+8
30 CAV Ve10 1616+5th Exm
31 CAV Ve10 88+8 flat Exm 
32 CAV Ve10 88+8 dark Exm 
33 CAV Ve10 4+88 Exm 
34 HOH Musette Fun 888
35 HOH Flash 88
36 HOH Flash 88+16
37 HOH Flash 88+8 flat
38 HOH Flash 88+1616
39 HOH Flash 1616 (Cassotto) 
40 HOH Flash 1616+8 
41 HOH Flash 1616+16 Exm 
42 CAV Vintage 8 Reed
43 CAV Vintage 8 Reed Spc
44 CAV Vintage 4 Reed
45 CAV Vintage 88
46 CAV Vintage 88+8
Italian Accordions R
47 GAL 888 Musette Vintage
48 SCA VI Vintage 8 (Cassotto)
49 SCA VI Vintage 88
50 SCA VI 8+8 flat
51 SCA VI 8+8 flat +
52 SCA VI 8+8 medium
53 SCA VI 8+8+8 medium +
54 SCA VI 8+8+8 wide
55 SCA VI 8+8+8 wide +
56 SCA VI Vintage 4
57 SCA VI Vintage 4+8
58 SCA VI Vintage 4+16 
59 SCA VI Vintage 4+88
60 SCA VI Vintage 8+16 
61 SCA VI Vintage 4+8+16 
62 SCA VI Vintage 88+16 
63 SCA VI Vintage 4+88+16 
64 SCA VI Vintage 16 
65 BAL 888 Musette
66 BUG 16 Reed
67 MEN 888 Retro Musette
68 BAM 8 Reed Spc
69 BAM +SCVI 8+8 (2x Cassotto) Exm
70 BAM +SCVI 8+8 (2x Cassotto) Exm
Cajun
71 HOH 4+8+16
72 HOH 4+8+8+16
73 HOH 8+8
74 HOH 4+8
75 HOH 4+8+8+16 (PEV) Exm
76 HOH 8+8 (PEV) Exm
Accordions Benelux
77 PIM 88
78 ACC 888 Musette
79 ACC 888+8 Musette Exm
German Accordion
80 HOH GOL 88
Austrian Squeeze Box
81 MÜL 888 St. Leonhard
Melodeons & more
82 HOH Corso 888 Vintage
83 WEM 8 Reed
84 WEM 8+8 small
85 WEM 8+8 medium
86 WEM 8+8 wide
87 WEM 8+8+8 small
88 WEM 8+8+8 medium
89 WEM 8+8+8 wide
90 WEM 888
91 WEM 888+8 Exm
92 WEM 8+16
93 SER 88
94 VIC Bandoneon
95 ACD Accordina
Schwyzer Örgeli
96 NUS 888
97 NUS 88
98 NUS 888+8 Exm
99 NUS 888+16 Exm
Accordion Bass
100 SCA VI Bass
101 VIC Bass
102 BUG Bass 16
103 BUG Bass 8
104 BUG Bass 4
105 BUG Bass 2
106 BUG Bass 16+8
107 BUG Bass 16+8+4
108 SCA VI Bass + BUG Bass 16
Accordion Chord
109 SCA VI Chord (Octave break 47/48) (OCB)
110 BUG 4
111 BUG 8
112 BUG 4+8
113 BUG 2+4
Melodeon
114 WEM Melodeon Bass
115 WEM Melodeon Bass less Attack noise
116 WEM Melodeon Chord note 60-71 (OCB)
Schwyzer Örgeli Bass
117 AEM Örgeli Bass
Accordion Drawbar (Exm)
118 V3 Drawbar FULL 888888888
119 V3 Drawbar 888
120 V3 Drawbar 888000678
121 V3 Drawbar 88
122 V3 Drawbar 800008000
123 V3 Drawbar 807800000
Noise and partial
124 V3 Key OFF
125 V3 Attack Layer linear
126 V3 Attack Layer concave
127 V3 Attack Layer convace offset 50
128 Silence
100 ACCORDIONS BANK MSB 72 100 ACCORDIONS BANK MSB 72
USE THIS KEY RANGE
Bass / note number 33-47
Chord / note number 60-71
Legend
Exm Experimental sounds
R Samples change any hit
Spc Bellow change overtone spectrum
PEV One reed slide up by attack
OCB Octave break
ALL BRAND/PRODUCT NAMES ARE
REGISTERED TRADEMARKS OF THEIR
RESPECTIVE HOLDERS
HOH Hohner
ZUP Zupan
MAU Maugein
CAV Cavagnolo
GAL Galanti
SCA Scandalli
BAL Ballone Burini
BUG Bugari
MEN Mengascini
BAM Bugari Armando
PIM Piermaria
ACC Accordiola
MÜL Müller
WEM Weltmeister
SER Serinelli
VIC Victoria
NUS Nussbaumer
AEM Aemmitaler
Cordavox
V3SOUND

Prg. CORDAVOX ELECTRONIC ACC.
01 Clar+Vib 48 long release
02 Clar+Vib 48 medium release
03 Clar+Vib 48 short release
04 Clar+Vib 8 long release
05 Clar+Vib 8 medium release
06 Clar+Vib 8 short release
07 Clar+Vib long release
08 Clar+Vib medium release
09 Clar+Vib short release
10 Mix 1 long release
11 Mix 1 medium release
12 Mix 1 short release
13 Mix 2 long release
14 Mix 2 medium release
15 Mix 2 short release
16 Mix 3 long release
17 Mix 3 medium release
18 Mix 3 short release
19 Mix 4 long release
20 Mix 4 medium release
21 Mix 4 short release
22 Vib flute 48 long release
23 Vib flute 48 medium release
24 Vib flute 48 short release
25 Vib flute 8 long release
26 Vib flute 8 medium release
27 Vib flute 8 short release
28 Vib flute 4+8 long release
29 Vib flute 4+8 medium release
30 Vib flute 4+8 short release
31 Vib flute 8 long release
32 Vib flute 8 medium release
33 Vib flute 8 short release
34 Vib flute LFO 1 long release
35 Vib flute LFO 1 med. release
36 Vib flute LFO 1 short release
37 Vib flute LFO 2 long release
38 Vib flute LFO 2 med. release
39 Vib flute LFO 2 short release
40 Vib flute LFO 3 long release
41 Vib flute LFO 3 med. release
42 Vib flute LFO 3 short release
43 Vib flute 484 long release
44 Vib flute 484 medium release
45 Vib flute 484 short release
46 Vib flute 48 long release
47 Vib flute 48 medium release
48 Vib flute 48 short release
49 Vib flute 4-8 long release
50 Vib flute 4-8 medium release
51 Vib flute 4-8 short release
52 Vib flute 48 LFO 1 long release
53 Vib flute 48 LFO 1 med release
54 Vib flute 48 LFO 1 short rel.
55 Vib flute 48 LFO 2 long release
56 Vib flute 48 LFO 2 med release
57 Vib flute 48 LFO 2 short rel.
58 Vib flute 48 LFO 3 long release
59 Vib flute 48 LFO 3 med release
60 Vib flute 48 LFO 3 short rel.
100 ACCORDIONS BANK MSB 73
V3SOUND
Note Nr.
1 Snare roll
2 Snare roll
3 Drum Stick
4 - 11 Concert bass drum
12 - 23 Concert bass drum
24 - 35 BD
C 36 BD
37 Rim
D 38 Snare
39 Clap
E 40 Snare
F 41 Tom Low Low
42 HiHat closed (2)
G 43 Tom Low
44 HiHat Pedal (2)
A 45 Tom Medium L.
46 HiHat open (2)
47 Tom Medium
C 48 Tom High
49 Crash Cymbal 1
D 50 Tom High High
51 Ride Cymbal 1
E 52 China Cymbal
F 53 Ride Cup
54 Tambourin
G 55 Splash Cymbal
56 Cowbell
A 57 Crash Cymbal 2
58 Vibraslap
59 Ride Cymbal 2
Note Nr.
C 60 Brush roll A
61 Brush roll B
D 62 Brush roll C
63 Brush Mix A
E 64 Brush Mix A long swirl
F 65 Brush Mix B
66 Brush Mix B long swirl
G 67 Brush Tap single hit
68 Brush Tap single hit
A 69 Brush Tap single hit
70 Brush swish
71 Brush swish
C 72 Brush roll A
73 Brush roll B
74 Brush roll C
D 75 Brush Mix A
E 76 Brush Mix A long swirl
F 77 Brush Mix B
78 Brush Mix B long swirl
G 79 Brush Tap single hit
80 Brush Tap single hit
81 Brush Tap single hit
82 Brush swish
83 Brush swish
C 84 Stick Roll
85 Stick Roll
D 86 Stick Rim
87 Stick & roll * roll fade
E 88 Stick & roll * linear 2
F 89 Stick & roll * linear 3
Note Nr.
90 Stick & roll * linear 4
G 91 Stick single stroke
92 Stick single stroke
A 93 Stick single sroke
94 Stick roll accent
95 Stick roll no accent
C 96 Stick Roll
97 Stick Roll
D 98 Stick Rim
99 Stick & roll * roll fade
E 100 Stick & roll * linear 2
F 101 Stick & roll * linear 3
102 Stick & roll * linear 4
G 103 Stick single stroke
104 Stick single stroke
A 105 Stick single sroke
106 Stick roll accent
107 Stick roll no accent
C 108 SC HiHat Pedal A (3)
109 SC HiHat Pedal B (3)
D 110 SC HiHat Pedal C (3)
111 SC HiHat closed A (3)
E 112 SC HiHat closed B (3)
F 113 SC HiHat open (3)
114 Rim
G 115 Claps
116 Stick 3 Roll
A 117 Stick 3 Roll
118 Stick 3 Roll
119 Concert BD
C 120 Concert BD
121 Concert BD low
D 122 Concert BD
123 Concert BD
E 124 Concert BD
125 Concert Cymbal medium
126 Concert Cymbal open
MAPPING DRUMKIT 72

100 organs
sound pack
sound list
midi implementation
V3SOUND.COM
