V7 UPS2URM3000DC-NC-1E User manual

UPS 3000VA SINGLE PHASE
DOUBLE CONVERSION ONLINE
2U R/T LCD USERS MANUAL
UPS2URM3000DC-NC-1E

1
1.1 Rear Panel View
NOTE: Before installation, please inspect the unit for shipping damage.
IEC TYPE
1. Programmable outlets: connect to non-critical loads.
2. Output receptacles: connect to mission-critical loads.
3. AC input cord
4. Network/Fax/Modem surge protection
5. USB communication port
6. RS-232 communication port
7. SNMP intelligent port
8. Emergency power off function connector (EPO)
9. External battery connection (not supported)
1.2 Operation
The UPS is composed of mains input, EMI/RFI filters, rectifier/PFC, inverter, battery charger,
DC-to-DC converter, battery, dynamic bypass, and UPS output.
EMI/RFI
Filters
Battery
Charger Battery
DC-to-DC
Converter
Inverter
Rectifier
/PFC
Input Output
Dynamic
Bypass

2
1.3 Installation
For safety consideration, the UPS is shipped out from factory without connecting battery wires.
Before installation of the UPS, please follow the steps below to re-connect the battery wires.
Rack-Mount Installation
Caution! –DO NOT use the mounting brackets to lift the unit. The mounting brackets
are only for securing the unit to the rack.

3
Tower Installation
1.4 Setup
1. Select a proper location to operate the UPS
The UPS should only be operated indoors in a clean environment, away from windows and
doors. Place on a flat surface away from dust, humidity, high temperatures, liquids, gases,
or corrosive and conductive contaminants.
Maintain a minimum clearance of 100mm from the bottom of the UPS. Be certain to place in
a well-ventilated area; avoid blocking the fan’s air flow by maintaining a minimum clearance
100mm to the front and 300mm in the rear of the UPS.
Operate at or below a maximum altitude of 3000m for normal operation at full load.
2. UPS input connection
Plug the UPS into a two-pole, three-wire, grounded receptacle only. Avoid using extension cords.
For 200/208/220/230/240VAC models: The power cord supplied with this UPS is detachable.
Note: Check if the site wiring fault indicator lights up in LCD panel. It will be illuminated when
the UPS is plugged into an improperly wired utility power outlet (Refer to Troubleshooting section).
Check if there is a circuit breaker against overcurrent and short circuit between the mains and
AC input of the UPS for safe operation. The recommended protection value as following:
Power Input
Spec
200/208/220/230/240VAC models
10A
Note: The LCD display will light up and then go off when the power cord is attached to power,

4
but the UPS is not powered on until the power button is pressed for two seconds (see #7).
3. UPS output connection
There are two kinds of outputs: programmable outlets and general outlets. Connect non-critical
devices to the programmable outlets and critical devices to the general outlets. During power
failure, you may extend the backup time to critical devices by setting shorter backup time for
non-critical devices.
4. Communication connections
Communication ports:
USB port RS-232 port SNMP port
To allow for unattended UPS shutdown/start-up and status monitoring, connect the
communication cable one end to the USB/RS-232 port and the other to the communication port
of your PC. With the monitoring software installed, you can schedule UPS shutdown/start-up and
monitor UPS status through PC.
The UPS is equipped with an SNMP Network card. When installing either SNMP for advanced
communications and monitoring.
5. Network connection
Network/Fax/Phone surge port
Connect a single modem/phone/fax line into the surge protected “IN” outlet on the back panel
of the UPS. Connect another modem/fax/phone line cable to the “OUT” outlet and to the
equipment
6. Disable and enable EPO function
This UPS is equipped with EPO function. Pin 1 and pin 2 closed by default for normal UPS operation.
To activate, remove the protective metal plate and attach to your EPO system.
Note: The EPO function logic can be set up through the LCD settings. Please refer to program
16 in UPS setting for the details.

5
Powering on the UPS
NOTE: The battery will charge fully during the first five hours of normal operation. Full battery
run capability is not possible during the initial charge period.
Press the ON/Mute button on the front panel for two seconds to turn on the power to the UPS.
7. Install software
For optimal computer system protection, install UPS monitoring software to fully configure UPS
shutdown. Please follow steps below to download and install monitoring software.
1. Go to the website https://www.v7world.com/ups-downloads
2. Select ViewPower software for your operating system to download the software.
3. Follow the on-screen instructions to install the software.
1.5 Battery Replacement
Note: This UPS is equipped with internal batteries and only a trained technician should replace
the batteries.
Replace the batteries if icons and are flashing in the LCD display and alarm is sounding
every 2 seconds.
Do not disconnect battery connectors under load. To remove input power to change the batteries,
press the OFF button on the front panel for two seconds to power off the UPS and switch off utility
power where the UPS is connected.
DO NOT DISCONNECT the batteries while the UPS is in Battery mode.
A small arc may occur when connecting the internal batteries. This is not harmful to the UPS or
personnel. Connect the cables quickly and firmly.
Step 1
Step 2
Step 3
Remove front panel.
Disconnect battery wires.
Pull out the battery box by

6
removing two screws on the front
panel.
Step 4
Step 5
Step 6
Remove the top cover of
battery box and replace the
inside batteries.
After replacing the batteries,
put the battery box back to
original location and screw it
tightly.
Re-connect the battery wires.
Step 7
Put the front panel back to the unit.
2.1 Button Operations
Button
Function
ON/Mute
Button
Turn on the UPS: Press and hold ON/Mute button for at least 2 seconds to turn
on the UPS.
Mute the alarm: After the UPS is turned on and in battery mode, press and hold
this button for at least 3 seconds to disable or enable the alarm system. (N/A for
warnings or errors)
Up key: Press this button to display previous selection in UPS setting mode.
Self-test mode: Press ON/Mute buttons for 3 seconds to enter UPS self-testing
while in AC mode, ECO mode, or converter mode.
OFF/Enter
Button
Turn off the UPS: Press and hold this button at least 2 seconds to turn off the
UPS. The UPS will be in standby mode under power normal or transfer to Bypass
mode if the Bypass setting is enabled.
Confirm selection key: Press this button to confirm selection in UPS setting
mode.

7
Select
Button
Switch LCD message: Press this button to change the LCD message for input
voltage, input frequency, input current, battery voltage, battery current, battery
capacity, ambient temperature, output voltage, output frequency, load current
and load percent.
Setting mode: Press and hold this button for 3 seconds to enter UPS setting
mode when in Standby and Bypass mode.
Down key: Press this button to display next selection in UPS setting mode.
ON/Mute
+ Select
Button
Switch to bypass mode: When the main power is normal, press ON/Mute and
Select buttons simultaneously for 3 seconds and the UPS will enter bypass mode.
This will not function if the input voltage is out of range.
Exit setting mode or returning to the last menu: In setting mode, press the
ON/Mute and Select buttons simultaneously for 0.2 seconds to return to the upper
menu. Once in the main menu, exit settings mode by pressing these two buttons
simultaneously.
2.2 LCD Panel
Display
Function
Backup time information
Indicates the estimated backup time.
H: hours, M: minute, S: second.
Configuration and fault information
Indicates the configuration items. Configuration items are listed in detail in
section 2-5.
Indicates the warning and fault codes. Codes are listed in detail in sections
2-7 and 2-8.
Mute operation
Indicates that the UPS alarm is disabled.
Input, Battery, Temperature, Output & Load information
Indicates the input voltage, input frequency, input current, battery voltage,
battery current, battery capacity, ambient temperature, output voltage,
output frequency, load current and load percent.
k: kilo, W: watt, V: voltage, A: ampere, %: percent, ℃: centigrade degree, Hz: frequency
Load information

8
Indicates the load level by 0-24%, 25-49%, 50-74% and 75-100%.
Indicates overload.
Programmable outlets information
Indicates that programmable management outlets are working.
Mode operation information
Indicates the UPS connects to the mains.
Indicates the battery is working.
Indicates charging status
Indicates the bypass circuit is working.
Indicates the ECO mode is enabled.
Indicates the AC to DC circuit is working.
Indicates the PFC circuit is working.
Indicates the inverter circuit is working.
Indicates the UPS is working in converter mode.
Indicates the output is working.
Battery information
Indicates the battery level by 0-24%, 25-49%, 50-74%, and 75-100%.
Indicates low battery.
3.3 Audible Alarm
Battery Mode
Sounds every 5 seconds
Low Battery
Sounds every 2 seconds
Overload
Sounds every second
Fault
Continuously sounding
Bypass Mode
Sounds every 10 seconds
3.4 LCD display wording index
Abbreviation
Display content
Meaning
ENA
Enable
DIS
Disable
ESC
Escape
HLS
High loss
LLS
Low loss

9
AO
Active open
AC
Active close
EAT
Estimated autonomy time
RAT
Running autonomy time
SD
Shutdown
OK
OK
ON
ON
BL
Battery Low
OL
Overload
OI
Over input current
NC
Battery No Connect
OC
Over Charge
SF
Site wiring fault
EP
EPO
TP
Temperature
CH
Charger
BF
Battery Fault
BV
Bypass Out Range
FU
Bypass frequency unstable
BR
Battery Replace
EE
EEPROM error
3.5 UPS Setting
Parameter 1 Parameter 2
There are two parameters to set up the UPS.
Parameter 1: Program alternatives. Refer to
below table.
Parameter 2: Setting options or values for each
program.
01: Output voltage setting
Interface
Setting
Parameter 2: Output voltage
For 200/208/220/230/240 VAC models, you may choose the
following output voltage:
200: presents output voltage is 200Vac
208: presents output voltage is 208Vac
220: presents output voltage is 220Vac
230: presents output voltage is 230Vac (Default)

10
240: presents output voltage is 240Vac
02: Frequency Converter enable/disable
Interface
Setting
Parameter 2: Enable or disable converter mode.
CF ENA: converter mode enable
CF DIS: converter mode disable (Default)
03: Output frequency setting
Interface
Setting
Parameter 2: Output frequency setting.
BAT 50: presents output frequency is 50Hz
BAT 60: presents output frequency is 60Hz
If converter mode is enabled, choose from these frequencies:
CF 50: presents output frequency is 50Hz
CF 60: presents output frequency is 60Hz
04: ECO enable/disable
Interface
Setting
Parameter 2: Enable or disable ECO function.
ENA: ECO mode enable
DIS: ECO mode disable (Default)
05: ECO voltage range setting
Interface
Setting
Parameter 2: Set the acceptable high voltage point and low
voltage point for ECO mode by pressing Down key or Up key.
HLS: High loss voltage in ECO mode in parameter 2.
For 200/208/220/230/240 VAC models, the setting range in
parameter 3 is from +7V to +24V of the nominal voltage.
(Default: +12V)
LLS: Low loss voltage in ECO mode in parameter 2.
For 200/208/220/230/240 VAC models, the setting range in
parameter 3 is from -7V to -24V of the nominal voltage.
(Default: -12V)
06: Bypass enable/disable when UPS is off
Interface
Setting

11
Parameter 2: Enable or disable Bypass function.
ENA: Bypass enable
DIS: Bypass disable (Default)
07: Bypass voltage range setting
Interface
Setting
Parameter 2: Set the acceptable high voltage point and
acceptable low voltage point for Bypass mode by pressing the
Down key or Up key.
HLS: Bypass high voltage point
For 200/208/220/230/240 VAC models:
230-264: setting the high voltage point in parameter 3 from
230Vac to 264Vac. (Default: 264Vac)
LLS: Bypass low voltage point
For 200/208/220/230/240 VAC models:
170-220: setting the low voltage point in parameter 3 from
170Vac to 220Vac. (Default: 170Vac)
08: Bypass frequency range setting
Interface
Setting
Parameter 2: Set the acceptable high frequency point and
acceptable low frequency point for Bypass mode by pressing
the Down key or Up key.
HLS: Bypass high frequency point
For 50Hz output frequency models:
51-55Hz: Set the frequency high loss point from 51Hz to
55Hz. (Default: 53Hz)
For 60Hz output frequency models:
61-65Hz: Set the frequency high loss point from 61Hz to
65Hz. (Default: 63Hz)
LLS: Bypass low Frequency point
For 50Hz output frequency models:
45-49Hz: Set the frequency low loss point from 45Hz to
49Hz. (Default: 47Hz)
For 60Hz output frequency models:
55-59Hz: Set the frequency low loss point from 55Hz to
59Hz. (Default: 57Hz)
09: Programmable outlets enable/disable
Interface
Setting
Parameter 2: Enable or disable programmable outlets.
ENA: Programmable outlets enable
DIS: Programmable outlets disable (Default)
10: Programmable outlets setting

12
Interface
Setting
Parameter 2: Set the backup time limits for programmable
outlets.
0-999: Set the backup time limits in minutes from 0-999 for
programmable outlets which connect to non-critical devices
on battery mode. (Default: 999)
11: Autonomy limitation setting
Interface
Setting
Parameter 2: Set the backup time on battery mode for
general outlets.
0-999: Set the backup time in minutes from 0-999 for general
outlets on battery mode.
DIS: Disable the autonomy limitation and the backup time will
depend on battery capacity. (Default)
Note: Setting to “0”, sets backup time to just 10 seconds.
12: Battery total AH setting
Interface
Setting
Parameter 2: Set the battery total AH of the UPS.
7-999: Setting the battery total capacity from 7-999 in AH.
Please set the correct battery total capacity if external battery
bank is connected.
13: Maximum charger current setting
Interface
Setting
Parameter 2: Set the charger maximum current.
1/2/4/6/8: Set the charger maximum current 1/2/4/6/8 in
Ampere. (Default: 2A)
Note: Set the appropriate charger current based on battery
capacity used. The recommended charging current is
0.1C~0.3C of battery capacity as following table for
reference.
Battery capacity (AH)
Total charging current (A)
7~20
2
20~40
4
40~60
6
60~
8
14: Charger boost voltage setting
Interface
Setting
Parameter 2: Set the charger boost voltage.
2.25-2.40: Set the charger boost voltage from 2.25 V/cell to
2.40V/cell. (Default: 2.36V/cell)
15: Charger float voltage setting

13
Interface
Setting
Parameter 2: Set the charger float voltage.
2.20-2.33: Set the charger float voltage from 2.20 V/cell to
2.33V/cell. (Default: 2.28V/cell)
16: EPO logic setting
Interface
Setting
Parameter 2: Set up the EPO function control logic.
AO: Active Open (Default). When AO is selected as EPO logic,
it will activate EPO function with Pin 1 and Pin 2 in open status.
AC: Active Closed. When AC is selected as EPO logic, it will
activate EPO function with Pin 1 and Pin 2 in closed status.
17: Site fault detection enable/disable
Interface
Setting
Parameter 2: Enable or disable site fault detection. You may
choose the following two options:
ENA: Site fault detection enable (Default)
DIS: Site fault detection disable
18: Display setting for autonomy time
Interface
Setting
Parameter 2: Set the display setting for autonomy time
EAT: If EAT is selected, it will display the remaining autonomy
time. (Default)
RAT: If RAT is selected, it will show accumulated autonomy
time so far.
19: Acceptable input voltage range setting
Interface
Setting
Parameter 2: Set the acceptable high voltage point and
acceptable low voltage point for input voltage range by
pressing the Down key or Up key.
HLS: Input high voltage point
For 200/208/220/230/240 VAC models:
280/290/300: setting the high voltage point in parameter
2. (Default: 300Vac)
LLS: Bypass low voltage point
For 200/208/220/230/240 VAC models:
110/120/130/140/150/160: setting the low voltage
point in parameter 2. (Default: 110Vac)
00: Exit setting
Interface
Setting

14
Exit the setting mode.
3.6 Operating Mode Description
Operating mode
Description
LCD display
Online mode
When the input voltage is within acceptable range,
the UPS will provide pure and stable AC power to
output. The UPS also charges the battery in Online
mode.
ECO mode
Energy saving mode:
When the input voltage is within voltage regulation
range, the UPS will bypass voltage to output for
energy saving. The UPS also charges the battery in
ECO mode.
Frequency
Converter mode
When input frequency is within 40 Hz to 70 Hz, the
UPS can be set to a constant output frequency of
50 Hz or 60 Hz. The UPS still charges the battery
in this mode.
Battery mode
When the input voltage is beyond the acceptable
range or in power failure, the UPS provides power
from battery and the alarm will sound every 5
seconds.
Bypass mode
When input voltage is within acceptable range, but
the UPS is in overload, the UPS will enter bypass
mode or bypass mode can be selected through the
front panel. The alarm will sound every 10
seconds.
Standby mode
The UPS is off and not outputting power. The UPS
still charges the battery in this mode.
Fault mode
If a fault occurs, the ERROR icon and the fault code
will be displayed.
3.7 Faults Code Reference
Fault event
Fault code
Icon
Fault event
Fault code
Icon
Bus start fail
01
x
Battery voltage too high
27
x
Bus over
02
x
Battery voltage too low
28
x
Bus under
03
x
Charger output short
2A
x
Inverter soft start fail
11
x
Over temperature
41
x
Inverter voltage high
12
x
Overload
43

15
Inverter voltage Low
13
x
Charger failure
45
x
Inverter output short
14
x
Over input current
49
x
3.8 Warning indicator
Warning
Icon (flashing)
Code
Alarm
Low Battery
Sounds every 2 seconds
Overload
Sounds every second
Over input current
Sounds 2 beeps every 10 seconds
Battery is not connected
Sounds every 2 seconds
Over Charge
Sounds every 2 seconds
Site wiring fault
Sounds every 2 seconds
EPO enable
Sounds every 2 seconds
Over temperature
Sounds every 2 seconds
Charger failure
Sounds every 2 seconds
Battery fault
Sounds every 2 seconds
(The UPS will shut off)
Out of bypass voltage range
Sounds every 2 seconds
Bypass frequency unstable
Sounds every 2 seconds
Battery replacement
Sounds every 2 seconds
EEPROM error
Sounds every 2 seconds
Note: “Site Wiring Fault” function can be enabled/disabled via software. Please check software
manual for the details.
4. Troubleshooting
If the UPS system does not operate correctly, refer to the table below.
Symptom
Possible cause
Remedy
No indicators or alarms though
mains power is normal.
The AC input power is not
connected
Check if input power cord
firmly connected to the
mains.
The AC input is connected to
the UPS output.
Plug AC input power cord to
AC input correctly.
The icon and the warning code
flash on LCD display and alarm
is sounding every 2 seconds.
EPO function is activated.
Set the circuit in closed
position to disable EPO
function.
The icons of and ,and the
warning code flash on LCD
display. Alarm is sounding every 2
Line and neutral conductors
of UPS input are reversed.
Rotate mains power socket
by 180° and then connect to
UPS system.

16
seconds.
The icons of and and the
warning code flash on LCD
display. Alarm is sounding every 2
seconds.
The internal battery is
incorrectly connected.
Confirm batteries are
properly connected
Fault code 27 is displayed on the LCD
and the alarm is continuously
sounding.
Battery voltage is too high or
there’s a charger fault.
Contact your reseller or
[e-mail]
Fault code 28 is displayed on the LCD
and the alarm is continuously
sounding.
Battery voltage is too low or
there’s a charger fault.
Contact your reseller or
[e-mail]
The icons and and the
warning code flash on LCD
display. Alarm is sounding every
second.
UPS is overloaded
Remove excess loads from
the UPS.
UPS is overloaded. Devices
connected to the UPS are fed
directly by the electrical
network via Bypass.
Remove excess loads from
the UPS.
After repeat overloads, the
UPS is locked in the Bypass
mode. Connected devices
are fed directly by mains.
First, remove excess loads
from UPS. Then shut down
the UPS and restart it.
Fault code 49 is displayed on the LCD
and the alarm is continuously
sounding.
UPS is over input current.
Remove excess loads from
UPS.
Fault code 43 and the icon is
displayed on the LCD and the alarm
is continuously sounding.
The UPS shuts down
automatically because of an
overload of the UPS output.
Remove excess loads from
UPS and restart it.
Fault code 14 is displayed on the
LCD and alarm is continuously
sounding.
The UPS shuts down
automatically because of a
short circuit on the UPS
output.
Check output wiring and if
connected devices have
short circuited
Fault code 01, 02, 03, 11, 12, 13 or
41 is displayed on the LCD and the
alarm is continuously sounding.
A UPS internal fault has
occurred. There are two
possible results:
1. The load is still supplied,
but directly from AC power
via bypass.
2. The load is no longer
supplied by power.
Contact your reseller or
[email protected]
Battery backup time is shorter than
nominal value.
Batteries have not been
fully charged
Charge the batteries for at
least 5 hours and then check
capacity. If the problem
persists, consult your
reseller or contact
[email protected]
Possible batteries defect
Contact your reseller or
[email protected]

17
Fault code 2A is displayed on the
on LCD and the alarm is
continuously sounding.
A short circuit of the
charger output has
occurred.
Check the wiring of a
connected external battery
pack for short-circuited
Fault code 45 is displayed on the on
the LCD display and the alarm is
continuously sounding.
No charger output and
battery voltage is less than
10V/PC.
Contact your reseller or
[email protected]
5. Storage and Maintenance
The UPS system contains no user-serviceable parts. If the battery service life (3~5 years at 25°C
ambient temperature) has been exceeded, the batteries must be replaced. Contact your reseller
or [email protected].
Storage
Prior to storing, charge the UPS for 5 hours. Store the UPS covered and upright in a cool,
dry location. To protect battery performance and limit degradation, recharge the battery in
accordance with the following table:
Storage Temperature
Recharge Frequency
Charging Duration
-25°C - 40°C
Every 3 months
1-2 hours
40°C - 45°C
Every 2 months
1-2 hours
6. Specifications
MODEL (VPN)
UPS2URM3000DC-NC-1E
CAPACITY*
3000VA / 3000W
INPUT
Voltage
Range
Low Line Transfer
160VAC/140VAC/120VAC/110VAC ± 5 %
(based on load percentage 100% - 80 % / 80 % - 70 % / 70 - 60 % / 60 % - 0)
Low Line
Comeback
175VAC/155VAC/135VAC/125VAC ± 5 %
High Line Transfer
300 VAC ± 5 %
High Line
Comeback
290 VAC ± 5 %
Frequency Range
40Hz ~ 70 Hz
Phase
Single phase with ground
Power Factor
≧0.99 @ full load
THDI
≦5% @ 160-265 VAC
THDU < 1.6% @ input and full linear load condition
OUTPUT
Output voltage
200/208/220/230/240 VAC**
AC Voltage Regulation
± 1% (Batt. Mode)
Be sure to deliver the spent battery to a recycling facility or ship it to your dealer
in the replacement battery packing material.

18
Frequency Range
(Synchronized Range)
47 ~ 53 Hz or 57 ~ 63 Hz
Frequency Range
50 Hz ± 0.1 Hz or 60Hz ± 0.1 Hz (Batt. Mode)
Current Crest Ratio
3:1
Harmonic Distortion
≦2 % THD (Linear Load); 4 % THD (Non-linear Load)
Transfer
Time
AC Mode to Batt.
Mode
Zero
Inverter to Bypass
< 4 ms
Waveform (Batt. Mode)
Pure Sinewave
EFFICIENCY
AC Mode
≧91% @ full charged battery
ECO Mode
≧96% @ full charged battery
Battery Mode
≧90%
BATTERY
Battery Type
12V/9AH
Number
6
Recharge Time
3 hours recover to 95% capacity for internal battery@ 2A charging current
Charging Current
Default: 2A, Max: 8A adjustable
Charging Voltage
82.1 VDC ± 1%
PHYSICAL
Dimension, D X W X H (mm)
630 x 438 x 88
Net Weight
(kgs)
With battery
27.5
Without battery
12.4
ENVIRONMENT
Operation Humidity
20-95 % RH @ 0- 40°C (non-condensing)
Noise Level
Less than 50dBA @ 1 Meter (With fan speed control)
MANAGEMENT
Smart RS-232 or USB
Supports Windows® 2000/2003/XP/Vista/2008/7/8/10, Linux, Unix, and MAC
SNMP Network
Power management from SNMP manager and web browser
* Derate capacity to 90% of capacity when the output voltage is adjusted to 200VAC or 208VAC.
*** Product specifications are subject to change without further notice.
6.1 Runtime Chart
Model (VPN)
UPS2URM3000DC-NC-1N
Battery
Load percentage
Minutes
100.00%
2.64
90.00%
3.36
80.00%
4.34
70.00%
5.53
60.00%
7.33
50.00%
9.79
40.00%
13.51
30.00%
19.90

19
20.00%
32.61
10.00%
72.53
7. Instructions & Safety Warnings
7.1 Transportation
Transport the UPS system only in the original package to protect from damage.
7.2 Preparation
Condensation may occur if the UPS is moved directly from cold to warm environments.
The UPS system must be completely dry before being operated. Allow at least two hours
for the UPS system to acclimate to a new environment.
Do not install the UPS near water or wet, high humidity environments.
Do not install the UPS where it will be exposed to direct sunlight or near heat sources.
Avoid blocking ventilation holes in the UPS enclosure.
7.3 Installation
Do not connectappliances or devices which can overloadthe UPS system(e.g., laser printers).
Route cables to avoid stepping on or tripping over them.
Do not connect domestic appliances (such as hair dryers) to the UPS.
Connect the UPS system only to an earth-grounded shockproof outlet which must be
easily accessible and near the UPS system.
Use only VDE-tested, or UL-marked mains cables (e.g., the mains cable of your
computer) to connect the UPS system to the building wiring outlet (shockproof outlet).
Use only VDE-tested, UL-marked power cables to connect the loads to the UPS.
When installing the equipment, ensure that the sum of the leakage current of the UPS
and the connected devices does not exceed 3.5mA.
Temperature Rating - Units are considered acceptable for use in a maximum ambient
of 40°C (104°F).
FOR PLUGGABLE EQUIPMENT, the socket-outlet shall be installed near the equipment
and shall be easily accessible.
CAUTION: The unit is heavy. Lifting the unit requires a minimum of two people.
7.4 Operation
Do not disconnect the mains cable on the UPS system or the building wiring outlet
(shockproof socket outlet) during operations since this would cancel the protective
earthing of the UPS system and of all connected loads.
The UPS system features its own, internal current source (batteries). The UPS output
sockets, or output terminals block may be electrically live even if the UPS system is not
connected to the building wiring outlet.
To fully disconnect the UPS system, first press the OFF/Enter button to disconnect the
mains.
Prevent fluids and other foreign objects from entering the UPS.
The EPO and USB circuits are an IEC 60950-1 safety extra low voltage (SELV) circuit.
This circuit must be separated from any hazardous voltage circuits by reinforced
insulation.
7.5 Maintenance, service, and faults
The UPS system operates with hazardous voltages. Repairs may be carried out only by
