Vaillant VRT 360f Operating and Specification sheet

For the owner and heating engineer
VRT 360f
Operating and Installation Manual
VRT 360f
Room temperature thermostat
GB

2
Contents
Operating and installation manual VRT 360f
Inhaltsverzeichnis
Notes on the documentation . . . . . . 4
Storage of the documents.................... 4
Symbols used........................................... 4
Safety . . . . . . . . . . . . . . . . . . . . . . . . . 5
Operating manual. . . . . . . . . . . . . . . . 6
1
Overview of the equipment . . . . . 6
2 Overview of the display . . . . . . . 7
3 Description of the appliance . . . 8
4 Operation. . . . . . . . . . . . . . . . . . . 8
4.1 Setting the operating modes ...... 9
4.2 Setting the current day and
time ................................................... 12
4.3 Setting timer programmes .......... 13
4.4 Setting the room temperature ... 16
4.5 Setting the hot water
temperature .................................... 18
4.6 Activating special functions........ 19
4.7 Info level........................................... 22
4.8 Changing the battery.................... 23
5 Manufacturer’s warranty and
liability . . . . . . . . . . . . . . . . . . . .25
6 Recycling and disposal. . . . . . . .25

3Operating and installation manual VRT 360f
Contents
GB
Installation instructions . . . . . . . . . .27
7 Notes on the installation and
operation . . . . . . . . . . . . . . . . . . .27
7.1 CE label............................................. 27
7.2 Intended use.................................... 28
8 Safety instructions and regulati-
ons . . . . . . . . . . . . . . . . . . . . . . . .29
8.1 Safety instructions ........................ 29
8.2 Regulations...................................... 30
9 Installation . . . . . . . . . . . . . . . . . 31
9.1 Place of installation....................... 31
9.2 Fitting the receiver........................ 31
9.3 Mounting the room temperature
thermostat....................................... 33
10 Electrical installation. . . . . . . . .35
10.1 Connecting the receiver............... 35
11 Start-up. . . . . . . . . . . . . . . . . . . .36
11.1 Installer level................................... 37
11.2 Service/diagnostics level.............. 41
11.3 Handing over the appliance to
the owner......................................... 43
12 Troubleshooting . . . . . . . . . . . . .44
13 Technical data. . . . . . . . . . . . . . .45
14 Vaillant Service . . . . . . . . . . . . .46

4Operating and installation manual VRT 360f
Notes on the documentation
The following information is intended to
help you throughout the entire
documentation.
Other documents apply in combination
with this installation and operation
manual.
We accept no liability for any damage
caused by failure to observe these
instructions.
Storage of the documents
Please pass on this operating and
installation manual to the owner of the
system in order for him/her to store it so
that it is available whenever it is required.
Symbols used
Please observe the safety instructions in
this manual for the installation of the
appliance.
Danger!
Immediate risk of serious injury
or death
Caution!
Potentially dangerous situation
for the product and environment.
Notes on the documentation

5GBOperating and installation manual VRT 360f
Note!
Useful information and
instructions.
• Symbol for a necessary task
Safety
The room temperature thermostat must
be installed by a suitably qualified
heating engineer, who is responsible for
adhering to the existing standards and
regulations.
We accept no liability for any damage
caused by failure to observe these
instructions.
Notes on the documentation, safety

6Operating manual VRT 360f
Operating manual
1
Overview of the equipment
1
2
Abb. 1.1 Overview of equipment
Key
1 Display
2 Dial (turn and click)
I Info button
F Special functions button
P Programming key/installer level
1 Overview of the device

7GBOperating manual VRT 360f
2 Overview of the display
1
2
3
4
5
6
7
8
9
11
10
Fig. 2.1 Overview of the display
Key
1 Installer level and
Service/Diagnosis level (Chapter 11.1)
2 Info level (see 4.7)
3 Hot water symbol
4 Circulation pump symbol
5 Heating circuit symbol
6 Time/temperature display
7 Days of the week
8 Actual temperature
9 Operating modes (see 4.1)
10 Special functions (see 4.6)
11 Setting timer programmes (see 4.3)
Overview of the display 2

8Operating manual VRT 360f
3 Description of the
appliance
The VRT 360f is a programmable room
temperature thermostat with weekly
programme for heating, hot water and
circulation pump for connection to
Vaillant heating equipment with eBus.
The connection between the room
temperature thermostat and the heating
unit is by radio link.
The VRT 360f enables you to specify the
room temperature using heating
programs. In addition, you can select
special functions such as the party
function, and control the timed
operation of a boiler and a circulation
pump.
4 Operation
The operating principle is based on the
three buttons and an dial (Vaillant "turn
and click“ operating concept).
The display normally shows the current
operating mode (e.g. ), or, if
activated, the special function and the
current room temperature, the day of
the week, the time and the symbol for
heating, hot water and/or the circulation
pump, depending on which is requested.
3 Device description, 4 Operation

9GBOperating manual VRT 360f
4.1 Setting the operating modes
Table 4.1 provides you with an overview
of the operating modes you can select.
The selected operating mode affects the
timer programmes both for heating and
for hot water and the circulation pump.
• When the room temperature
thermostat is in normal display mode.
press the dial once – the symbol for
the selected mode flashes in the
display.
• Turn the dial until the desired
operating mode appears on the
display.
The display switches back to normal
mode after five seconds.
Operation 4

10 Operating manual VRT 360f
Symbol Meaning
Heating Hot water
Automatic:
The operation of the heating circuit changes between
the operation modes Heating and Energy Saving
. The heating circuit symbol is displayed if a heating
requirement is detected.
The operation of the hot water
storage cylinder/circulation
pump changes between
heating/ON and OFF
depending upon the time
programme set on the room
temperature thermostat.
The hot water symbol and the
circulation pump symbol are
displayed if the time window
is active.
Heating:
The heating circuit is operated according to the
room temperature, regardless of the programme set
on the room temperature thermostat. The heating
circuit symbol is displayed if a heating requirement is
detected.
Energy Saving:
The heating circuit is operated according to the
energy saving temperature "ECO“, regardless of the
programme set on the room temperature thermostat.
The heating circuit symbol is displayed if a heating
requirement is detected.
Table 4.1 Operating modes
4 Operation

11GBOperating manual VRT 360f
Symbol Meaning
Heating Hot water
Off:
The heating circuit is off, provided that
the frost protection function (if the room
temperature is below 5°C)
is not activated.
If the frost protection function is activated,
the heating circuit symbol is displayed.
The boiler is not heated up, regardless of
the set timer programme. The circulation
pump is switched off. The hot water
and circulation pump symbols are not
displayed.
Table 4.1 Operating modes (contd.)
Operation 4

12 Operating manual VRT 360f
4.2 Setting the current day and
time
To set the current time and day of the
week with the display in normal mode,
you must perform the following steps:
• Press the dial until a day of the week
starts flashing.
• Turn the dial until you see the current
day of the week.
MO = Monday
TU = Tuesday
WE = Wednesday
TH = Thursday
FR = Friday
SA = Saturday
SU = Sunday
• Press the dial. The hours start flashing.
• Turn the dial until you see the current
hour.
• Press the dial. The minutes start
flashing.
• Turn the dial until you see the current
minute.
The display switches back to normal
mode after five seconds.
If the calendar is activated on the
installer level (see 11.1), you can set the
day, month and year in the same way
after you set the time. This allows
automatic switching from winter to
summer time.
4 Operation

13GBOperating manual VRT 360f
4.3 Setting timer programmes
The room temperature thermostat is
equipped with a basic program (see table
4.2).
Time
window
Current day
/ Block of
days
Start
time
End
time
H1 M0-FR 6:00 22:00
H2 — — —
H3 — — —
H1 SA 7:30 23:30
H2 — — —
H3 — — —
H1 SU 7:30 22:00
H2 — — —
H3 — — —
Table 4.2 Default heating, hot water and
circulation pump programmes
You can adapt the default programmes
to suit your needs. There are six steps to
setting the times you want.
1. Press the programming button P
2.Select the timer programme (heating,
hot water or circulation pump)
3.Select the time window
4.Select the current day or week block
5.Set the start time.
6.Set the end time.
Operation 4

14 Operating manual VRT 360f
You can define three time windows for
each day.
When you press the P button the display
returns to basic mode.
The table below illustrates the individual
steps again, using the example of the hot
water timer programme. If you want to
change the timer programme for heating
or the circulation pump, after pressing
the programming button P, select the
corresponding symbol (heating circuit or
circulation pump) and continue as shown
in the example.
Display Required steps
Press the programming
button P. The cursor (black
triangle) marks the value
which can be changed ( ),
which also flashes.
Turn the dial until the tap
symbol appears.
Press the dial. The cursor
marks the adjustable value
(H1), which also flashes.
Select the desired time
window by turning the dial.
Settings: H1, H2, H3
4 Operation

15GBOperating manual VRT 360f
Display Required steps
Press the dial. The cursor
marks the week block
display, which also flashes.
Select a block programme
or a single day of the week
by turning the dial.
Settings:
MO - SU
MO - FR
SA - SU
MO = Monday
TU = Tuesday
WE = Wednesday
TH = Thursday
FR = Friday
SA = Saturday
SU = Sunday
Display Required steps
Press the dial. The cursor
marks the start time and the
hour display flashes.
Select the start time by
turning the dial. Press
the dial again to set the
minutes.
Press the dial. The cursor
marks the end time and the
hour display flashes.
Select the end time by
turning the dial. Press
the dial again to set the
minutes.
Table 4.3 Setting time windows
Operation 4

16 Operating manual VRT 360f
If necessary, you can switch the room
temperature thermostat from the week
programme to a daily programme.
• With the display in normal mode, press
the F button for about 10
seconds. When you programme time
windows, days of the week will no
longer be displayed.
4.4 Setting the room temperature
The current room temperature is shown
in the basic display.
You can set the room temperature
directly from the basic display.
If the temperature level function is
activated on the installer level (different
temperature settings for each heating
window see Chapter 11.1), the display
shows the currently set room
temperature (T-H1, T-H2, T-H3).
Setting the required room temperature
directly
• Turn the dial (with the display in
normal mode).
The set temperature display
disappears, the sun symbol is
displayed in the operating mode level
and the set room temperature is
displayed in the multi-function level
(e.g. TEMP 20,0 °C).
4 Operation

17GBOperating manual VRT 360f
• You can set the required room
temperature directly (after about 1
second) to the desired value by turning
the dial.
The display switches back to normal
mode after five seconds.
Setting the room temperature for time
windows
(only possible if the "Temperature level"
function is activated on the installer
level - see 11.1). In this case, you can set
different room temperatures for each
time window.
• Press the dial several times until T-H1
appears in the multifunction display
along with a set value. The set value
flashes.
• Turn the dial until you see the room
temperature you want for the time
window H1. The new room temperature
is assigned to all time windows with H1.
• Press the dial. T-H2 is displayed along
with a set value. The set value flashes.
• Turn the dial until you see the room
temperature you want for the time
window H2. The new room
temperature is assigned to all time
windows with H2.
• Press the dial. T-H3 is displayed along
with a set value. The set value flashes.
Operation 4

18 Operating manual VRT 360f
• Turn the dial until you see the room
temperature you want for the time
window H3. The new room
temperature is assigned to all time
windows with H3.
The display switches back to normal
mode after five seconds.
Setting the set-back temperature
"ECO“
• Push the dial until ECO appears.
The set-back temperature is displayed
and starts flashing.
• Turn the dial until the required set-
back temperature is displayed (e.g.
ECO 15 °C).
The display switches back to normal
mode after five seconds.
4.5 Setting the hot water
temperature
You can set the hot water temperature
from the basic display. Please note the
set maximum hot water temperature on
the boiler.
• Push the dial repeatedly until the DHW
display appears. The set value flashes.
• Turn the dial until the required hot
water temperature is displayed (e.g.
DHW 60 °C).
The display switches back to normal
mode after five seconds.
4 Operation

19GBOperating manual VRT 360f
4.6 Activating special functions
You can access the special functions
using the F button. You can activate the
following functions:
Display Required steps
Quick veto
The quick veto function
allows you to adjust the room
temperature for a short time
(until the next time window).
Press the special function
button F - the quick veto
symbol appears in the display
along with the quick veto room
temperature, which also flashes.
Turn the dial until the quick
veto temperature you want is
displayed. The display switches
back to basic mode after 10
seconds and the function is
activated. To deactivate the
function, all you need to do is
press the F button.
Operation 4

20 Operating manual VRT 360f
Display Required steps
Energy-saving function
The energy-saving function lets
you lower the heating for an
adjustable period regardless
of the set heating programme.
Press the special function
button twice and the energy-
saving symbol appears on the
display. You will also see the
time flashing. Now turn the dial
to set the end time up to which
the heating is operated in set-
back mode. The display switches
back to basic mode after 10
seconds and the function is
activated. To deactivate the
function, all you need to do is
press the F button.
Display Required steps
Party function
When you activate the party
function the heating phase is
continued beyond the next set-
back phase. This also applies to
the hot water and circulation
pump programmes. Press the
special function button three
times. The party symbol appears
in the display and the function is
activated after ten seconds.
The function is deactivated
automatically by reaching the
next heating phase.
If you want to deactivate the
function before, just press the F
button. This function can only be
activated in automatic mode .
4 Operation
