Vaillant VRT 360f Operating and Instruction manual

Vaillant VRT360f quick user guide for end users
Operating modes
Timed - heating will operate to the programmed ON and OFF periods.
Constant - heating will operate continuously irrespective of programmed times.
Setback - heating is operating at the “ECO” temperature
OFF - heating is permanently off
Note: The above symbols could be shown together e.g indicates heating is timed and
ON.
Setting the operating mode
From the basic screen press the “Click and Turn” knob one click, one of the operating mode
symbols will flash. Whilst the symbol is flashing rotate the knob to select the desired operating
mode. The operating mode is set and the symbol will stop flashing after 5 seconds.
Setting the target room temperature
From the basic screen rotate the “Click and Turn” knob 1 one click clockwise. The current target
temperature is shown flashing. To adjust the target temperature rotate the knob clockwise to
the new desired target temperature, the display will return to the basic screen in approx 5
seconds.
Override function
From the basic display push the “F” button once. The symbol is displayed together with a
flashing temperature, rotate the knob to set the desired temperature for the override period.
This mode will be active until the next time window. To turn off the override function simply
press the “F” button, the display will revert back to the basic display after approximately 10
seconds.
Note: The time and date should have been set-up by your installer, if necessary refer to
installation manual for details of how to set time & date
Basic Display
Main function “Click
and Turn knob”
“Program”
button
Current room
temp
Operating mode
“Function”
button

Vaillant VRT360f quick user guide for end users
Setting programming periods
1. From basic display push “P” button once then release, screen below in fig 1.0 is shown with
flashing “radiator” symbol.
2. Push knob one click, “H1” flashes, rotate knob to select heating period 1, 2 or 3.
3. Push knob one click “Mo Tu We Th Fr Sa Su” flashes, leave to select all days of the week
with the same programming times or rotate knob to select group of days or individual days.
4. Push knob one click “06:” flashes. Rotate knob clockwise to select ON period hours.
5. Push knob one click “:00” flashes. Rotate knob clockwise to select ON period minutes.
6. Push knob one click “22:” flashes. Rotate knob clockwise to select OFF period hours
7. Push knob one click “:00” flashes. Rotate knob clockwise to select OFF period minutes
8. Repeat steps 2 to 7 for different day selections.
9. Push “P” to exit
The control is now set-up in its basic form. For more advanced
features / settings refer to installation manual.
Fig 1.0
