Vaisala Indigo80 User manual

M212722EN-B
User Guide
Vaisala Handheld Indicator
Indigo80

PUBLISHED BY
Vaisala Oyj
Vanha Nurmijärventie 21, FI‑01670 Vantaa, Finland
P.O. Box 26, FI‑00421 Helsinki, Finland
[phone]
www.vaisala.com
docs.vaisala.com
© Vaisala 2023
No part of this document may be
reproduced, published or publicly
displayed in any form or by any means,
electronic or mechanical (including
photocopying), nor may its contents be
modified, translated, adapted, sold or
disclosed to a third party without prior
written permission of the copyright holder.
Translated documents and translated
portions of multilingual documents are
based on the original English versions. In
ambiguous cases, the English versions are
applicable, not the translations.
The contents of this document are subject
to change without prior notice.
Local rules and regulations may vary and
they shall take precedence over the
information contained in this document.
Vaisala makes no representations on this
document’s compliance with the local
rules and regulations applicable at any
given time, and hereby disclaims any and
all responsibilities related thereto.
This document does not create any legally
binding obligations for Vaisala towards
customers or end users. All legally binding
obligations and agreements are included
exclusively in the applicable supply
contract or the General Conditions of Sale
and General Conditions of Service of
Vaisala.
This product contains software developed
by Vaisala or third parties. Use of the
software is governed by license terms and
conditions included in the applicable
supply contract or, in the absence of
separate license terms and conditions, by
the General License Conditions of Vaisala
Group.
This product may contain open source
software (OSS) components. In the event
this product contains OSS components,
then such OSS is governed by the terms
and conditions of the applicable OSS
licenses, and you are bound by the terms
and conditions of such licenses in
connection with your use and distribution
of the OSS in this product. Applicable OSS
licenses are included in the product itself
or provided to you on any other applicable
media, depending on each individual
product and the product items delivered
to you.

Table of contents
1. About this document.....................................................................................7
1.1 Version information.......................................................................................... 7
1.2 Related manuals................................................................................................7
1.3 Documentation conventions........................................................................... 8
1.4 Trademarks........................................................................................................ 8
2. Product overview............................................................................................ 9
2.1 Introduction to Indigo80..................................................................................9
2.2 Basic features and options.............................................................................. 9
2.3 Indigo80 indicator parts..................................................................................11
2.4 Status LED........................................................................................................ 12
2.5 Safety................................................................................................................ 13
2.5.1 Lithium-ion battery related precautions............................................... 13
2.5.2 AC adapter related precautions............................................................. 14
2.5.3 ESD protection......................................................................................... 14
2.5.4 FCC Part 15 compliance statement........................................................ 15
3. Indigo80 menus and views........................................................................16
3.1 Start-up wizard................................................................................................16
3.2 Main menu........................................................................................................ 16
3.3 Measurement view...........................................................................................17
3.3.1 Editing measurement view..................................................................... 18
3.3.2 Holding values in measurement view....................................................18
3.3.3 Setting measurement limit alarm...........................................................19
3.4 Graph view........................................................................................................21
3.5 Devices menu...................................................................................................21
3.5.1 Overview of calibration and adjustment with Indigo80.....................23
3.6 Data logging menu.........................................................................................24
3.6.1 Viewing and managing data files in Data logging menu................... 25
3.7 Notifications menu......................................................................................... 26
3.8 Indigo80 menu................................................................................................27
3.9 Help menu....................................................................................................... 28
4. Using probes with Indigo80.................................................................... 29
4.1 Connecting probes to Indigo80................................................................... 29
4.2 Configuring probe features with Indigo80 handheld indicator.................31
4.3 Configuring environment settings with Indigo80 handheld indicator.... 32
5. Using Indigo80 with Insight PC software...........................................33
5.1 Vaisala Insight PC software........................................................................... 33
5.2 Connecting Indigo80 to Insight PC software..............................................33
5.3 Insight PC software overview........................................................................35
5.3.1 Indigo80 data files in Insight PC software........................................... 35
Table of contents
3

6. Indigo80 battery........................................................................................... 37
6.1 Indigo80 battery.............................................................................................37
6.1.1 Battery charge level indicator................................................................37
6.1.2 Recharging Indigo80 battery................................................................ 38
6.1.3 Removing battery................................................................................... 38
7. Maintenance and troubleshooting........................................................ 40
7.1 Updating Indigo80 firmware version.......................................................... 40
7.1.1 Updating firmware version with Insight PC software........................ 40
7.1.2 Updating firmware version with file manager......................................41
7.2 Restoring factory default settings................................................................42
7.3 Cleaning Indigo80..........................................................................................43
7.4 Fastening magnetic hanger accessory........................................................ 43
7.5 Troubleshooting............................................................................................. 44
7.5.1 Writing a problem report.......................................................................46
8. Technical data................................................................................................ 47
8.1 Indigo80 specifications................................................................................. 47
8.2 Dimensions......................................................................................................50
8.3 Spare parts and accessories......................................................................... 50
8.4 Maintenance and calibration services........................................................... 51
8.5 Warranty...........................................................................................................51
8.6 Technical support........................................................................................... 52
Appendix A: Recycling instructions...........................................................53
Index................................................................................................................... 57
Indigo80 User Guide M212722EN-B
4

List of figures
Figure 1 Indigo80 handheld indicator..........................................................................9
Figure 2 Indigo80 indicator parts, front and bottom views.................................. 11
Figure 3 Indigo80 main menu.......................................................................................16
Figure 4 Types of measurement views in Indigo80................................................ 17
Figure 5 Measurement view with sensor purge ongoing...................................... 17
Figure 6 Shortcut menu for editing measurement views......................................18
Figure 7 Graph views in Indigo80................................................................................ 21
Figure 8 Devices menu in Indigo80 main menu.......................................................21
Figure 9 Options in Devices menu, HMP7 probe example................................... 22
Figure 10 Indigo80 calibration methods for probes................................................ 23
Figure 11 Data logging menu in Indigo80 main menu. Ongoing
data logging indicated by the animated dots next to the
menu name....................................................................................................... 24
Figure 12 Data logging menu, top level.......................................................................24
Figure 13 Notifications menu in Indigo80 main menu............................................26
Figure 14 Notifications menu with Active and History tabs and
opened notification shown...........................................................................26
Figure 15 Indigo80 menu in the main menu.............................................................. 27
Figure 16 Help menu in Indigo80 main menu............................................................28
Figure 17 Help menu, top level.......................................................................................28
Figure 18 Connecting probes to Indigo80..................................................................30
Figure 19 Connecting Indigo80 to Insight PC software with USB-C cable....... 34
Figure 20 Insight PC software main menu with Indigo80 connected.................35
Figure 21 Data files tab in Insight PC software..........................................................36
Figure 22 Indigo80 indicator dimensions...................................................................50
Figure 23 Materials for recycling................................................................................... 54
List of figures
5

List of tables
Table 1 Document versions (English)............................................................................7
Table 2 Related manuals................................................................................................... 7
Table 3 Vaisala devices compatible with Indigo80....................................................9
Table 4 Indigo80 LED modes......................................................................................... 12
Table 5 Battery charge level indicator.........................................................................37
Table 6 Indigo80 operating environment.................................................................. 47
Table 7 Indigo80 inputs and outputs.......................................................................... 47
Table 8 Indigo80 mechanical specifications.............................................................48
Table 9 Indigo80 battery operation time...................................................................48
Table 10 Indigo80 data logging and user interface specifications.......................49
Table 11 Indigo80 compliance........................................................................................49
Table 12 Vaisala devices compatible with Indigo80.................................................49
Table 13 Indigo80 spare parts and accessories......................................................... 50
Table 14 Materials for recycling...................................................................................... 54
Indigo80 User Guide M212722EN-B
6

1. About this document
1.1 Version information
This document provides instructions for using and maintaining Vaisala Indigo80 Handheld
Indicator.
Table 1 Document versions (English)
Document code Date Description
M212722EN-B May 2023 This document.
Added sections:
•Start-up wizard (page 16)
•Writing a problem report (page 46)
•Recycling instructions (page 53)
Updated sections:
•Related manuals (page 7)
•Basic features and options (page 9)
•Indigo80 indicator parts (page 11)
•Status LED (page 12)
•Main menu (page 16)
•Connecting probes to Indigo80 (page 29)
•Vaisala Insight PC software (page 33)
•Updating Indigo80 firmware version (page 40)
•Spare parts and accessories (page 50)
M212722EN-A March 2023 First version.
1.2 Related manuals
For the latest versions of these documents, see docs.vaisala.com.
Table 2 Related manuals
Document code Name
M212901EN Firmware version compatibility of Indigo80-compatible devices Technical Note
M212723EN Vaisala Indigo80 Handheld Indicator Quick Guide
M212872EN Vaisala Indigo80 Handheld Indicator Safety Guide
M212022EN Vaisala HMP Series with MMP8 and TMP1 User Guide
M212357EN Vaisala DMP Series User Guide
Chapter 1 – About this document
7

Document code Name
M211888EN Vaisala HPP271 Hydrogen Peroxide Probe User Guide
M211972EN Vaisala HPP272 Hydrogen Peroxide, Humidity and Temperature Probe User
Guide
M211435EN Vaisala DMT143 Dew Point Transmitter User Guide
M212849EN Vaisala Indigo300 Transmitter User Guide
M212287EN Vaisala Indigo500 Series Transmitters User Guide
1.3 Documentation conventions
Warning alerts you to a serious hazard. If you do not read and
follow instructions carefully at this point, there is a risk of injury or even death.
WARNING!
Caution warns you of a potential hazard. If you do not read and
follow instructions carefully at this point, the product could be damaged or
important data could be lost.
CAUTION!
Note highlights important information on using the product.
1.4 Trademarks
Vaisalaâis a registered trademark of Vaisala Oyj.
Microsoftâand Windowsâare either registered trademarks or trademarks of Microsoft
Corporation in the United States and other countries.
All other product or company names that may be mentioned in this publication are trade
names, trademarks, or registered trademarks of their respective owners.
Indigo80 User Guide M212722EN-B
8

2. Product overview
2.1 Introduction to Indigo80
Vaisala Indigo80 Handheld Indicator is an industrial-grade portable diagnostics tool for spot-
checking and process monitoring, as well as for configuring, troubleshooting, calibrating, and
adjusting Vaisala Indigo-compatible probes and transmitters.
The Indigo80 indicator has two cable ports by which a combination of two probes or
transmitters can be simultaneously connected to the indicator. Indigo80 can communicate
with most current and future Vaisala probes and transmitters for measuring a wide range of
parameters.
Indigo80 has a multilingual, menu-based user interface that shows live measurement data
both numerically and graphically. The Indigo80 user interface is available in 10 languages.
Indigo80 user guidance is available for download at docs.vaisala.com.
For more information on the Indigo product family, see www.vaisala.com/indigo.
2.2 Basic features and options
• Flexible operation with one or two Vaisala Indigo-compatible probes or transmitters
• Numerical and graphical views of live measurement data
• Intuitive user interface available in 10 languages
• Rechargeable battery
• Data can be logged and transferred to PC via Vaisala Insight PC software (available for
download at www.vaisala.com/insight)
Figure 1 Indigo80 handheld indicator
Table 3 Vaisala devices compatible with Indigo80
Device Measurement type
Vaisala Indigo-compatible devices
HMP1, HMP3, HMP4, HMP5, HMP7, HMP8, HMP9, HMP80L, HMP80N Humidity and
temperature
TMP1 Temperature
Chapter 2 – Product overview
9

Device Measurement type
DMP5, DMP6, DMP7, DMP8, DMP80A, DMP80B Dew point temperature
GMP251, GMP252 Carbon dioxide
HPP271, HPP272 Hydrogen peroxide
MMP8 Moisture in oil
Indigo300, Indigo510, Indigo520 (Host devices)
Other Vaisala devices
HMP60, HMP63, HMP110, HMP110REF, HMP113, HMP115, HMM170 1) Humidity and
temperature
HMP110T, HMP115T, TMP115 1) Temperature
DMT143, DMT143L Dew point temperature
1) Indigo80 compatibility with these devices to be added during 2023.
See Firmware version compatibility of Indigo80-compatible devices Technical
Note (M212901EN) for firmware version compatibility.
More information
‣Indigo80 indicator parts (page 11)
‣Indigo80 menus and views (page 16)
‣Connecting probes to Indigo80 (page 29)
‣Indigo80 battery (page 37)
‣Indigo80 specifications (page 47)
Indigo80 User Guide M212722EN-B
10

2.3 Indigo80 indicator parts
1 2USB
1
2
3
5
6
7
8 9
4
Figure 2 Indigo80 indicator parts, front and
bottom views
1Status indicator LED
2Power on/o and main menu button
3Magnetic hanger at the back of the
device (optional accessory).
Handle with care.
4Ambient light sensor (controls display
brightness)
5Select button for selecting items in the
user interface and opening the
shortcut menu with options to edit
views
6Battery compartment at the back of
the device
7Type label located under the battery.
Also shown in the Indigo80 > About
view of the user interface.
8M12-5F A-coded ports (2 pcs, labeled
and ) for connecting compatible
Vaisala devices
9USB-C port for charging the battery
and connecting Indigo80 to a
computer to transfer data and
configure Indigo80 settings with
Insight PC software
Take the Getting started tour in the Help menu of Indigo80 to familiarize yourself
with the keypad buttons and menus.
More information
‣Indigo80 menus and views (page 16)
‣Indigo80 battery (page 37)
‣Indigo80 specifications (page 47)
Chapter 2 – Product overview
11

2.4 Status LED
1
1Status LED on Indigo80 keypad
Table 4 Indigo80 LED modes
Action/State LED color and behavior
Indigo80 is switched on Green, flashes briefly
USB-C cable connected while Indigo80 is powered on Green, flashes briefly
Indigo80 is connected to a power source and the battery
is charging while the display is o
Green, slow flashing
Indigo80 battery charge level is below 5 % or the battery
is empty
Red, slow flashing
Data logging is ongoing while Indigo80 display is o Green, slow flashing
Error(s) from a probe or transmitter connected to
Indigo80
Red, constant
Indigo80 User Guide M212722EN-B
12

2.5 Safety
Do not modify the unit or use it in ways not described in the
documentation. Modification, improper use, and/or careless handling may lead
to safety hazards, equipment damage, failure to perform according to
specification, decreased equipment lifetime, and/or the warranty becoming
void.
CAUTION!
The optional magnetic hanger of Indigo80 contains a strong
magnet. Handle it with care and keep it away from devices that are sensitive to
magnetic fields (for example, pacemakers, magnetic cards, and mechanical
watches).
CAUTION!
2.5.1 Lithium-ion battery related precautions
Take the following precautions when handling lithium-ion
batteries:
• Do not place the lithium-ion battery in fire or apply heat to the battery.
• Do not damage the battery with a sharp or blunt object, step on the battery,
or otherwise damage the outer casing.
• Do not subject the battery to strong impacts or shocks.
• Do not expose the battery to water or salt water, or allow the battery to get
wet.
• Do not disassemble or modify the battery. The battery contains safety and
protection devices which, if damaged, may cause the battery to generate
heat, rupture, or ignite.
• Do not leave the battery in direct sunlight, or use or store the battery inside
cars in hot weather. Doing so may cause the battery to generate heat,
rupture, or ignite. Using the battery in this manner may also result in
shortened lifespan and loss of performance.
• Never short circuit, reverse polarity, disassemble, damage, or heat the
battery over 100 °C (212 °F).
• DO NOT SPILL WATER ON A BURNING BATTERY. A fire extinguisher must
be used. If an exposed lithium-ion battery catches fire, it will burn even more
violently if it comes into contact with water or even moisture in the air.
WARNING!
The preinstalled Indigo80 battery is not user-replaceable. Using
batteries other than those provided by Vaisala will void the warranty of
Indigo80. Contact your nearest Vaisala Service Center for any battery-related
maintenance needs. See www.vaisala.com/support.
CAUTION!
Chapter 2 – Product overview
13

Remove the battery before shipping Indigo80 to Vaisala for repairs.
For shipping instructions, contact your nearest Vaisala Service Center.
See www.vaisala.com/support.
CAUTION!
Follow local laws and regulations to dispose of used or damaged
lithium-ion batteries in a safe manner.
CAUTION!
2.5.2 AC adapter related precautions
Make sure that the AC adapter you are using to charge Indigo80 is
an isolated power source that fulfills the requirements of one of the following:
• Limited-Energy Circuit (LEC) in accordance with IEC/EN/UL/CSA 61010-1
• Limited Power Source (LPS) in accordance with IEC/EN/UL/CSA 60950-1 or
IEC/EN/UL/CSA 62368-1, Annex Q
• Class 2 supply source that complies with the National Electrical Code (NEC),
NFPA 70, Clause 725.121 and Canadian Electrical Code (CEC), Part I, C22.1.
CAUTION!
For technical requirements of a compatible AC adapter, see Indigo80 specifications
(page 47).
Use the AC adapter only in its specified environmental conditions.CAUTION!
2.5.3 ESD protection
Electrostatic discharge (ESD) can damage electronic circuits. Vaisala products are adequately
protected against ESD for their intended use. However, it is possible to damage the product by
delivering electrostatic discharges when touching, removing, or inserting any objects in the
equipment housing.
To avoid delivering high static voltages to the product:
• Handle ESD‑sensitive components on a properly grounded and protected ESD workbench
or by grounding yourself to the equipment chassis with a wrist strap and a resistive
connection cord.
• If you are unable to take either precaution, touch a conductive part of the equipment
chassis with your other hand before touching ESD‑sensitive components.
• Hold component boards by the edges and avoid touching component contacts.
Indigo80 User Guide M212722EN-B
14

2.5.4 FCC Part 15 compliance statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that the interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by
turning the equipment o and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications to this equipment not expressly approved
by the party responsible for compliance could void the user's authority to
operate the equipment.
CAUTION!
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Chapter 2 – Product overview
15

3. Indigo80 menus and views
Indigo80 has a versatile and intuitive user interface available in 10 languages.
3.1 Start-up wizard
When you take Indigo80 into use for the first time, a start-up wizard prompts you to set the
date, time, and preferred units. You can connect Indigo80 to the Insight PC software for
automatic setup, or you can configure the device manually. The start-up wizard is initiated also
after each firmware update.
After completing the setup, you can take the Getting started tour showing the basics of the
Indigo80 user interface.
More information
‣Indigo80 menu (page 27)
‣Help menu (page 28)
3.2 Main menu
Pressing the button while navigating the Indigo80 menus and views opens the main menu.
1
1
2
3
4
5
Figure 3 Indigo80 main menu
1Devices menu contains, for example,
options related to sensor purge,
calibration, and environment settings
(depending on the connected device).
2Data logging menu for setting logging
interval and duration, and browsing
data files.
3Notifications menu displays
notifications related to Indigo80 and
the connected devices.
4Indigo80 menu for changing the
settings of Indigo80 (for example,
date, time, and language) and viewing
device information.
5Help menu contains a Getting started
tour showing the key features of
Indigo80, as well as instructions for
sending devices to Vaisala for
calibration and maintenance.
Indigo80 User Guide M212722EN-B
16

3.3 Measurement view
The versatile measurement view of Indigo80 can be edited to show multiple types of views
and comparisons of measurement data from connected devices.
To access the measurement view, press and select Home in the Indigo80 main menu.
For more information on editing options, see Editing measurement view (page 18). The graph
view associated with the measurement view is introduced in Graph view (page 21).
1 2 3
5
4
Figure 4 Types of measurement views in Indigo80
1Measurement view with four measurement parameters from one probe shown.
2Measurement view with two measurement parameters from two probes shown.
3Comparison view showing the measured values from two probes and their dierence
(indicated by the delta symbol).
4Parameter list view showing all the output parameters available from the connected
probes.
5The bars on the right indicate the number of views stacked vertically. Use the
and buttons on the keypad to move between views.
A pause in normal measurement activity (for example, because of sensor purge or unavailable
readings) is indicated by the caution symbol, a textual notification, and yellow font. The font
turns back to white once the measurement is stable again.
Figure 5 Measurement view with sensor purge ongoing
Chapter 3 – Indigo80 menus and views
17

3.3.1 Editing measurement view
You can add, edit, and delete the measurement views in Indigo80. Press while in the
measurement view to open the shortcut menu for editing the views.
1
2
3
4
Figure 6 Shortcut menu for editing measurement views
1Two types of templates are available for new views (for examples of dierent types of
measurement views, see Figure 4 (page 17)):
•Default: allows you to add a maximum of 11 new vertically-stacked views. The total
number of views in the stack is 12. Each view fits a maximum of four measurement
parameters.
•Comparison: allows you to add a maximum of 10 new vertically-stacked views. The
comparison template is available only when two probes are connected to
Indigo80.
2Edit view: you can add new parameters into an existing view (space allowing), or delete
parameters from a view.
3Delete view deletes the active measurement view or comparison view, as well as the
related graph views.
4Restore default views deletes all created custom views and restores the default views,
which vary depending on the type and number of probes connected to Indigo80.
The number of new views that can be added is higher for probes with just one output
parameter, for example, GMP252. For multiparameter probes, such as HMP7, the parameter list
views at the bottom of the stack reserve up to three views of the total, allowing for fewer new
views to be added.
More information
‣Graph view (page 21)
3.3.2 Holding values in measurement view
With the Hold values function you can freeze the measurement view, for example, for taking a
photo of the readings. Date and time are shown on the bottom of the display.
Indigo80 User Guide M212722EN-B
18

1. While in the measurement view, press to open the shortcut menu.
2. Select Hold values.
The measurement view freezes and the altered state is indicated by a yellow frame and
the text hold in the bottom right corner of the display.
3. Exit the view by pressing or .
3.3.3 Setting measurement limit alarm
You can set a one-time measurement limit alarm for any one parameter output by your probe.
When the measured value exceeds or falls below the set limit, this triggers a visual and audible
alarm. 1) Note that you can set the alarm for one parameter from one probe at a time.
1. While in the measurement view, press to open the shortcut menu.
2. Select Set alarm > Parameter.
1) Turn sounds on in Indigo80 settings to activate the audible alarm.
Chapter 3 – Indigo80 menus and views
19

3. All output parameters from the connected probe are shown in the list. If you have two
probes connected, use the arrow buttons to switch between the lists showing the
parameters from each probe. Press to select a parameter and exit the list view.
4. Set values for Activation and Limit of the alarm.
5. Select Turn alarm on to activate the alarm.
6. A notification is shown and sounded when the alarm is activated.
7. Select OK to turn o the alarm.
To turn o an alarm that has not yet activated, select Set alarm in the shortcut menu and
select Turn alarm o.
Indigo80 User Guide M212722EN-B
20
