VIP-148L IP Talkback Horn

INTRODUCTION

The VIP-148L IP Talkback Horn enables two-way

handsfree voice access to a single location over

an IP-based network. This allows a page zone

extension anywhere on the network. The horn

audio level is electronically adjusted via

software. A call switch input connection is

provided for call initiation, and a line level

Auxiliary Input allows connection to a local audio

source. Power is provided to the VIP-148L via a

Power over Ethernet (PoE) switch meeting the

802.3af specification.

SPECIFICATIONS

Access Methods

PBX, FXO Port w/VIP-811

POTS telephone set w/VIP-811

FXS Port w/VIP-821

SIP telephone system

Features

RJ-45 for network connection

LED Status Indicator

Network activity LEDs

Power over Ethernet (PoE) 802.3af

compatible

Aux input for background music

Dimensions/Weight VIP-148L

Horn - 7.38” H x 10.0” W x 10.4” D

(18.75cm x 25.4cm x 26.42cm)

Network Interface – 9.13” H x 4.5” W x 1.5” D

(23.19cm x 11.43cm x 3.81cm)

Weight: 5.60 lbs. (2.54 kg)

Nominal Power Requirements

Via 802.3af (PoE) Ethernet Switch: Class 3

Environment

VIP-148L Network Interface:

Temperature: 0 to +40° C

Humidity: 0 to 85% non-precipitating

VIP-148L Horn:

Suitable for indoor or outdoor installation

Packing List

Qty Item

1 VIP-148L Network Interface

1 VIP-148L Horn

1 VSP Document

4 Wood Screws

4 Rubber Pads

1 “C” Clamp

1 VM-186 RJ-45 Connector

Precautionary Designations

FCC Information

This equipment has been tested and found to

comply with the limits for a Class A digital

device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide

reasonable protection against harmful

interference when the equipment is operated

in a commercial environment. This

equipment generates, uses and can radiate

radio frequency energy and if not installed

and used in accordance with the instruction

manual, may cause harmful interference to

radio communications. Operation of this

equipment in a residential area may cause

harmful interference in which case the user

will be required to correct the interference at

his own expense.

INSTALLATION

Operation:

Provides talkback intercom via Network

connection to customer telephone system or

stand alone telephone set. Interface to customer

telephone system can be via SIP registration,

FXO port or FXS port (additional equipment

required in all cases). The optional call button

may be programmed to initiate a call to one of the

above telephone system interfaces. When the

call is answered, a hands-free communications

path is established to the horn.

Mounting (Network Interface)

The VIP-148L Network Interface is designed for

wall or table mounting and must be within 100

meters of the network switch.

Mounting (Horn)

The VIP-148L Horn is designed for most FD

electrical box or wall mounting and must be within

300 meters of the VIP-148L Network Interface.

See NEMA OS 3-2002 sec.1.2.3.5 for FD box

specifications.

Attaching Speaker to Base

NOTE: For ease of installation, the base can be

attached to the speaker before or after the base

is mounted.

Loosen position adjustment knob

Insert the ball of the base into the socket of

the speaker

Tighten the position adjustment knob

These horns should be mounted 15 to 20 feet

above the floor to allow for best sound

distribution. The units can be mounted to a wall,

a beam or an electrical box.

Mount the base to a wall using the two holes

provided. Knockout holes are provided for

punch out should additional holes be desired.

A "C" clamp is provided with the horns to

allow mounting to a beam. Place the bolt

through the hole in the bottom of the base to

secure the "C" clamp to the beam (See

Figure 1). It is suggested that the horn be

mounted to the underside of the "I" beam to

provide maximum positioning adjustments.

Connection to an electrical backbox is

accomplished by channeling wire through the

ball of the base and making appropriate

connections. The base has holes punched

for a double-gang square box, but by

punching out additional knockout holes, the

base can be mounted to a single-gang or

octagon box (See Figure 2).

The horns may be rotated or moved up and down

to obtain the desired position by loosening the

position adjustment knob (See Figures 1 and 2)

at the bottom of the unit approximately one turn.

Make required adjustments, retighten knob.

ALCOMVVIP-148L

AUX

STATUS

ACT

LINK

CALL IN SWITCH

NORMAL OPEN

MOMENTARY CLOSED

(OPTIONAL)

RJ45 NETWORK

CONNECTION

FRONT SIDE

AUX

INPUT

STANDARD

RJ45 PATCH CABLE

(T568A or T568B)

PAGING HORN

VM-186

RJ45

WHITE/GREEN

GREEN

WHITE/BROWN

BROWN

BLUE

WHITE/BLUE

BLUE

WHITE/ORANGE

ORANGE

WHITE/GREEN

GREEN

WHITE/BROWN

BROWN

WHITE/BLUE

BLUE

WHITE/ORANGE

ORANGE

Network Interface:

Table: Provided with the VIP-148L Network

Interface are four rubber stick on pads. Peel

pads off their carrier backing and place at the four

corners of the bottom of the unit.

Wall: Using the wood screws provided, secure

the VIP-148L Network Interface to the wall.

Power Connections

The only method of powering a VIP-148L

Network Interface is via a Power over Ethernet

(PoE) switch or power injector meeting the

802.3af specification. Make all required signal

connections before connecting to Ethernet switch

or power injector meeting the 802.3af

specification.

Network Connection

The VIP-148L Network Interface has one RJ-45

Ethernet network connector and one RJ-45 horn

connector.

Use a standard Ethernet patch cables to connect

the VIP-148L to an Ethernet switch.

Signal Connections

Connect RJ-45 patch cable using EIA/TIA 568A

or 568B Standard to the horn connector of the

VIP-148L Network Interface, then connect to VM-

186 RJ-45 connector. Connect the Brown and

White/Brown pair to the horn.

If desired, a normally-open call button may be

connected to the Blue, White/Blue pair of the

horn RJ-45 connector. The VM-186 RJ-45

connector provides easy access these

connections.

Aux input

Aux input on the VIP-148L Network Interface

accepts line level audio such as background

music and broadcasts it through the horn. During

announcements, the aux input is muted and

remains muted until the call is terminated.

Status Indicator Lights

The VIP-148L Network Interface has 2 status

indication lights on the side panel:

LINK: Indicates 100 Mbit Ethernet connection

when illuminated. No activity indicates 10 Mbit

connection.

ACT: Indicator flashes to indicate network

activity.

Setup

Information specific to your application will need

to be programmed into the VIP-148L using a

computer. The PC used for programming should

be connected to the same subnet as the

VIP-148L. Setup will be done using the IP

Solutions Setup Tool. The IP Solutions Setup

Tool is available for download on the Valcom

website at www.valcom.com/vipsetuptool.

TECHNICAL ASSISTANCE

Assistance in troubleshooting is available from

the factory when problems are encountered.

Call (540) 563-2000 and press 1 for Technical

Support or visit our website at

http://www.valcom.com.

Valcom equipment is not field repairable.

Valcom, Inc. maintains service facilities in

Roanoke, VA.

Should repairs be necessary, attach a tag to the

unit clearly stating your company name, address,

phone number, contact person and the nature of

the problem. Send the unit to:

Valcom, Inc.

Repair & Return Dept.

5614 Hollins Road

Roanoke, Va. 24019-5056
