Valcom VIP-997 User manual

1 947605
CAUTION: To reduce the risk of electric shock,
Do not remove cover (or back).
No user serviceable parts inside.
Refer servicing to qualified service personnel.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol indicates that dangerous
voltage constituting a risk of electric
shock is present within this unit.
This symbol indicates that there are
important operating and maintenance
instructions in the literature accompanying
this unit.
ISSUE 1
VIP-997
INTERIOR / EXTERIOR IP STROBE
INTRODUCTION
The VIP-997 Interior/Exterior IP Strobe
private mode notification appliance provides
bright strobe functionality with both power and
activation provided by the IP network. Multiple
strobes may be synchronized to flash in
unison.
SPECIFICATIONS
Features
Cost effective and versatile solution to
applications requiring visual alerts or strobes
Power over Ethernet (PoE) 802.3af
compatible
Night Ring functionality in conjunction with
other Valcom IP speakers
Synchronized strobing when used with
additional VIP-997 strobes
Activation Methods
Valcom Group Page
SIP Phone Call
Dimensions / Weight
9.0"H x 7.8"W x 5.5"D
(22.86cm H x 19.8cm W x 13.97cm D)
3.3 lbs. (1.5 kg)
Nominal Power Requirements
Via 802.3af PoE Ethernet Switch 6W
Environment
Temperature: - 40° to +70° C
Humidity: 0 to 85% non-precipitating
These products are intended for use with a UL
Listed power source marked “Class 2” or
“LPS” rated 24VDC, or 48VDC (PoE).
PoE and all interconnected ITE are intended
for intra-building.
Precautionary Designations
WARNING: To Reduce The Risk Of
Fire Or Electric Shock. Do Not Expose
This Apparatus To Rain Or Moisture.
AVERTISSEMENT: Afin de réduire les
risques d'incendie ou de décharge
électrique, évitez d'exposer le système
à la pluie ou à l'humidité.
Apparatus shall not be exposed to
dripping or splashing and no objects
filled with liquids, such as vases, shall
be placed on the apparatus.
L’appareil ne doit pas être exposé à
des égouttements et éclaboussures et
aucun Objet Rempli de liquide, comme
vase, ne doit être placé sur l’appareil.
FCC Information
This equipment has been tested and found to
comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference when the equipment is
operated in a commercial environment.
This equipment generates, uses and can
radiate radio frequency energy and if not
installed and used in accordance with the
instruction manual, may cause harmful
interference to radio communications.
Operation of this equipment in a residential

2 947605
area may cause harmful interference in
which case the user will be required to
correct the interference at his own
expense.
INSTALLATION
Operation
The VIP-997 provides private mode
notification via network connection. Activation
of the strobe is triggered by including the
VIP-997 as a member of a Valcom IP Paging
group. The VIP-997 can also operate as a
visual Night Ring device in conjunction with a
SIP PBX and can provide audio Night Ring to
other Valcom IP speakers when activated.
Interface to customer telephone system can
be via SIP registration to a Voice over IP
(VoIP) telephone system, or FXO port (when
used with a Valcom Enhanced Station Port).
Mounting
The VIP-997 is designed for double-gang
electrical box mounting, or can be attached
directly to a solid surface. The VIP-997 is
labeled with an arrow indicating the UP
direction and the VIP-997 must be installed in
that orientation. (Figure 2)
If mounting to an outlet box (Figure 3), confirm
the outlet box is securely installed following
the outlet box manufacturer’s directions. If
installing directly to a solid surface, note the
information shown in Figure 4 for secure
mounting to stud walls. For other types of wall
construction, use appropriate fasteners.
Network Connection
A weatherproof connector for the premise
ethernet cable is pre-assembled to the
VIP-997 strobe. Use a standard ethernet
cable to connect the strobe to the local
network.
IMPORTANT: If using a pre-terminated
ethernet cable, verify the RJ45 cable end will
fit through the End Cap opening of the
weatherproof connector. If a boot is used
around the RJ45 connector, it must not extend
more than 35mm from the end of the RJ45
connector.
To connect the premise cable (shown in
Figure 1),unscrew the End Cap [1] and
Threaded Barrel [3] from the open end of the
connector. Remove the Rubber Bushing [2]
from the Threaded Barrel. Insert the ethernet
cable from the network through the End Cap
and Threaded Barrel and place the Rubber
Bushing around the ethernet cable between
the End Cap and Barrel.
Insert the network cable RJ45 connector into
the RJ45 jack in the Main Barrel [5]. Confirm
the Gasket [4] is in place, then insert the
Threaded Barrel into the Main Barrel and
tighten. Slide the Rubber Bushing into the end
of the Threaded Barrel, then screw the End
Cap onto the Threaded Barrel and tighten.
Power Connections
The only method of powering the VIP-997 is
via a Power over Ethernet (PoE) switch or
power injector meeting the 802.3af
specification. Make all required signal
connections before connecting to Ethernet
switch or power injector meeting the 802.3af
specification.
IMPORTANT SAFETY INFORMATION
CONSIGNES DE SÉCURITÉ IMPORTANTES
1. Read these instructions.
Lisez ces instructions.
2. Keep these instructions.
Conservez ces instructions.
3. Heed all warnings.
Respectez tous les avertissements.
4. Follow all instructions.
Suivez toutes les instructions.
5. Do not use this apparatus near water.
Ne pas utiliser cet appareil près de l'eau.
6. Clean only with dry cloth.
Nettoyer avec un chiffon sec.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
Ne pas bloquer les ouvertures de ventilation. Installer formément aux instructions du
fabricant.
8. Do not install near any heat sources such as radiators, heat registers, stoves or other
apparatus (including amplifiers) that produce heat.
Ne pas installer à proximité de sources de chaleur telles que radiateurs, registres de
chaleur, poêles ou autres appareils (y compris les amplificateurs) produisant de la chaleur.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A grounding type plug has two blades and a
third grounding prong. The wide blade and the third prong are provided for your safety. If
the provided plug does not fit into your outlet consult an electrician for replacement of the
obsolete outlet.
Ne pas contourner le dispositif de sécurité de la fiche polarisée ou de mise à la terre. Une
fiche polarisée possède deux lames dont une plus large que l'autre. Une fiche de terre a
deux lames et une troisième broche de mise à la terre. La lame large et la troisième
broche sont fournies pour votre sécurité. Si la fiche fournie ne rentre pas dans votre prise,
veuillez consulter un électricien pour le remplacement de la prise obsolète.
10.Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles and the point where they exit from the apparatus.
11.Only use attachments/accessories specified by the manufacturer.
N'utilisez que des fixations / accessoires spécifiés par le fabricant.
12. Use only with the cart, stand, tripod, bracket or table specified
by the manufacturer or sold with the apparatus. When a cart is
used, use caution when moving the cart/apparatus combination
to avoid injury from tip-over.
Utilisez uniquement avec le chariot, stand, trépied, support ou table spécifié par le
fabricant ou vendu avec l'appareil. Quand un chariot est utilisé, Soyez prudent lorsque
vous déplacez l'ensemble chariot / appareil pour éviter des blessures dues au
renversement.
13. Unplug this apparatus during lightning storms or when unused for a long period of time.
Débranchez cet appareil pendant les orages ou lorsqu'il n'est pas utilisé pendant une
longue période de temps.
14. Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way. Such as when the power supply cord or plug is
damaged, liquid has been spilled, objects have fallen into the apparatus or the
apparatus has been exposed to rain or moisture and does not operate normally or has
been dropped.
Confiez toute réparation à un personnel qualifié. Une réparation est nécessaire lorsque
l'appareil a été endommagé de quelque façon. Parexemple lorsque le cordon
d'alimentation ou la fiche est endommagé, du liquide a été renversé, si des objets sont
tombés dans l'appareil ou le appareil a été exposé à la pluie ou à l'humidité et ne
fonctionne pas normalement ou s'il est tombé.

947605
3
Setup
Information specific to your application will
need to be programmed into the VIP-997
using a computer. The PC used for
programming should be connected to the
same subnet as the VIP-997. Setup will be
done using the IP Solution Setup Tool.
Download the latest version of the free IP
Solutions Setup Tool from the Valcom web
site at www.valcom.com/vipsetuptool
TECHNICAL ASSISTANCE
Assistance in troubleshooting is available from
the factory. Call [phone] and press 1
for Technical Support or via email at
[e-mail].
When requesting assistance, you should
include all available information. General
information and troubleshooting procedures
are available on the Valcom website at
www.valcom.com.
Valcom equipment is not field repairable.
Valcom, Inc. maintains service facilities in
Roanoke, VA.
Should repairs be necessary, attach a tag to
the unit clearly stating your company name,
address, phone number, contact person and
the nature of the problem. Send the unit to:
Valcom, Inc.
Repair & Return Dept.
5614 Hollins Road
Roanoke, Va. 24019-5056
WARRANTY
Warranty information may be found on our
website at www.valcom.com/warranty
Figure 1. Barrel Connection
Figure 2. Label for Proper Mounting

4 947605
OR EQUAL
MOUNTING BRACKET CAN BE DIRECTLY ATTACHED TO WALL SURFACE OR ATTACHED TO THE APPROPRIATE OUTLET BOX
OUTLET
SCREW PAN HEAD 8-32 x 3/8
BOX
BELL 5333-0
FOR THE APPLICATION.
MOUNTING BRACKET
FROM PREVIOUS STEP. TAKE CAUTION NOT TO PINCH THE CABLES OR COUPLER.
GASKET
OUTDOOR
OR EQUAL
:
TIGHTEN FOR WATER TIGHT SEAL. SLIDE STROBE HOUSING OVER MOUNTING BRACKET, ALIGN HOLES AND REPLACE (4) 8-32 SCREWS
NOTE
NOTE:
REMOVE STROBE FROM PACKAGING. REMOVE (4) 8-32 SCREWS THAT HOLD THE MOUNTING BRACKET IN PLACE.
SAVE THE SCREWS TO RE-MOUNT THE STROBE TO THE MOUNTING BRACKET LATER.
SECURE THE MOUNTING BRACKET TO WALL WITH APPROPRIATE HARDWARE.
CONNECT CUSTOMER RJ45 CONNECTOR (POE)TO OUTDOOR COUPLER. MAKE SURE GASKETS ARE IN PLACE AND
INDOOR
OUTLET
BOX
RACO 683SP
SCREW PAN HEAD 6-32 x 5/8
FIGURE 1. INSTALLATION
Figure 3. Connecting to Outlet Box
Figure 4. Mounting to Wall
