Valcom VP-2024 User manual

VSP-VP-2024
Issue 7
1947274
VP-2024
-24 VOLT POWER SUPPLY
INTRODUCTION
These instructions contain the specifications and
information necessary to install, operate and maintain
the VP-2024, -24 Volt DC Power Supply, offered by
Valcom, Inc.
"WARNING: To reduce the risk of fire or
electric shock, do not expose this appliance to
rain or moisture."
"WARNING: Shock Hazard -Do Not Open."
"AVIS: Risque de Choc Electrique ne pas
Ouvrir."
SPECIFICATIONS
Description
The VP-2024 is a fully regulated-24VDC, 2 Amp,
power supply. The primary is protected by a fuse; the
2 Amp output is electronically protected. The output
is floating with respect to ground. The regulator will
maintain -24 Volts +/-2 Volts over the rated range of
input voltages and output loads. Short circuit
protection is provided.
Application
•Valcom page control units
•Valcom one-way amplified speaker assemblies
•Any application where -24VDC filtered "talk
battery" is required
Features
•Regulated -24VDC "A" battery
•Full current limiting
•Over voltage protection
•Floating output
•Fully electronic supply
•UL listed
Capacity
•Current 2 Amps at 25 degrees C
Dimensions/Weight
•3.30" H x 9.50" W x 6.00" D
(8.38cm H x 24.13cm W x 15.24cm D)
•6.0 lbs. (2.72 kg)
Power Requirements
•Input voltage 105 to 120VAC, 60Hz, 90 Watts
max
Output Characteristics
•-24VDC regulated +/-2 Volts
•"A" battery
•Ripple 10 millivolts RMS max
•(2) 1 Amp outputs
INSTALLATION
Mounting
The VP-2024 should be wall mounted within seven
feet of an AC receptacle. A cold water pipe or earth
ground should be connected to the local ground
screw terminal using 12 AWG or larger ground wire.
If a two wire adapter is used, make sure the ground
tab is bonded to the local electrical ground.

2
Precautionary Designations
Wiring
When using the VP-2024 with Valcompage
equipment, a strap should be added from the local
ground terminal to the ground output. Refer to Figure
1 for connections to a Valcom page control unit.
When installing Valcom one-way amplified horns,
connect the white and black wires of the horn to the
power supply -24V and GND terminals respectively.
When installing Valcom one-way speakers, connect
the -24V and GND terminals of the speaker to the
corresponding power supply terminals.
TECHNICAL ASSISTANCE
When trouble is reported, verify that AC power is
being supplied to the unit.
To test the power supply, remove all output
connections and measure the output voltage with a
meter. If no voltage is measured, replace the unit.
Assistance in troubleshooting is available from the
factory. When calling, you should have a VOM and a
test set available and be calling from the job site. Call
[phone] and ask for Technical Support, or call
[phone] for Valcom 24-hour Faxback System or
visit our website at http://www.valcom.com.
Valcom equipment is not field repairable. Valcom, Inc.
maintains service facilities in Roanoke, VA. Should
repairs be necessary attach a tag to the unit clearly
stating your company name, address, phone number,
contact person and the nature of the problem. Send
the unit to: Valcom, Inc.
Repair and Return Dept.
5614 Hollins Road
Roanoke, VA 24019-5056
TROUBLESHOOTING CHART
PROBLEM ACTION TO BE TAKEN
1. No Output
2. Blows Fuses
a. Verify AC present at receptacle.
b. Check for blown fuse.
a. Verify total equipment power consumption does not exceed 2 Amps.
b. Disconnect AC while making power connections.
CAUTION: To reduce the risk of electric shock,
Donotremovecover.
No user serviceable parts inside.
Refer servicing to qualified service personnel.
This symbol indicates that dangerous
voltageconstituting a risk of electric
shock is present within this unit.
This symbol indicates that there are
important operating and maintenance
instructions in the literature accompanying
this unit.
CAUTION
RISK OF ELECTRIC SHOCK
DONOT OPEN

3
-24VDC, 1 Amp
GND
-24VDC, 1 Amp
GND
Earth or
Cold Water
Pipe Ground VP-2024 POWER SUPPLY
Figure 1 -Power Connections to Valcom Page Control Units
VALCOM LIMITED WARRANTY
Valcom, Inc. warrants its products to be free from defects in materials and workmanship under conditions of normal use and service
for a period of one year from the date of shipment. The obligation under this warranty shall be limited to the replacement, repair or
refund of any such defective device within the warranty period, provided that:
1. inspection by Valcom, Inc. indicates the validity of the claim,
2. the defect is not the result of damage, misuse, or negligence after the original shipment;
3. the product has not been altered in any way or repaired by others and that factory sealed units are unopened (A service
charge plus parts and labor will be applied to units defaced or physically damaged),
4. freight charges for the return of products to Valcom are prepaid,
5. all units ‘out of warranty’ are subject to a service charge. The service charge will cover minor repairs (Major repairs will be
subject to additional charges for parts and labor).
This warranty is in lieu of and excludes all other warranties, expressed or implied, and in no event shall Valcom, Inc. be liable
for any anticipated profits, consequential damages, loss of time or other losses incurred by the buyer in connection with the
purchase, operation, or use of the product.
This warranty specifically excludes damage incurred in shipment. In the event a product is received in damaged condition, the
carrier should be notified immediately. Claims for such damage should be filed with the carrier involved in accordance with the
F.O.B. point.
