ORCHARD LOW PROFILE SERIES OWNER’S MANUAL
PO Box 220 | 2507 Tully Road | Hughson, CA 95326 | 800-426-5615
www.valleytoolmfg.com
Orchard Low Prole Series


CALIFORNIA PROPOSITION 65
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
ADVERTENCIA: Cáncer y Dãno Reproductivo - www.65Warnings.ca.gov.
Orchard Low Prole Series
Table Of Contents
Introducon
Thank You 1
Warranty 2
Safety
Operaonal Safety 3-4
Maintenance Safety 4
Basic Operaon
Aaching to Power Unit 5
Starng / Running / Shut Down 5-6
Adjustments & Maintenance
Cut Height / Wear Components / Cleaning 7-8
Lubricaon 9-10
Transport
Transport / Removal / Storage 11
Quesons
Frequently Asked Quesons 12

www.vrisimo.com
Thank You
Dear Customer,
Thank you for purchasing a Vrisimo aachment.
This manual has been prepared to acquaint
you with the operaon, adjustment and
maintenance of your new aachment. It was
carefully designed and manufactured under the
highest industrial standards to give you years of
dependable service. Read this manual carefully
and fully understand the operaon of the
machine before aempng to operate it. Vrisimo
Flail Mowers & Shredders reserves the right to
make changes in design and specicaons, and/
or to make addions to or improvements in its
product without imposing any obligaon upon
itself to install them on its products previously
manufactured. If at any me you require
addional informaon, consult your authorized
dealer or the customer service department.
ATTENTION
The safety of the operator was one of the
primary concerns of Vrisimo Flail Mowers &
Shredders when designing this aachment.
Shielding, simple adjustments and other
safety features were built into this aachment
whenever possible. Be sure you and the people
working for you read and understand this
manual. All machinery should be operated only
by responsible persons who have been trained
to operate in a safe manner and have read and
understand this manual.
IMPORTANT TO PURCHASER
Customer Ownership Registraon
Prior to acceptance of the equipment, thoroughly
check o the pre-delivery checklist with the sales
representave. Be sure you fully understand the
operaon, adjustment and safety rules as outlined
in this manual.
Vrisimo Flail Mowers & Shredders is solely
owned by Valley Tool and Manufacturing.
Have industrial applicaons? Own a skid steer
or mini excavator? For our full line of industrial
equipment visit: www.valleytoolmfg.com
PO Box 220 | 2507 Tully Road | Hughson, CA 95326
1-800-426-5615
www.valleytoolmfg.com
1

www.vrisimo.com
Warranty
For a period of 12 months from date of delivery
of product to the original user/owner, Valley Tool
& Mfg. warrants each product to be free from
manufacturing defects, subject to the limitaons
contained in this policy.
This warranty does not apply to defect caused, in
whole or in part, by unreasonable use while in the
possession of the user, including, but not limited
to: failure to properly set up product; failure to
provide reasonable and necessary maintenance;
normal wear; roune tune ups or adjustments;
improper handling or accidents; operaon at
speed or load condions contrary to published
specicaon; improper or insucient lubricaon;
improper storage. This warranty is also not a
guarantee that the performance of each product
will meet the expectaons of the purchaser.
Valley Tool & Mfg. shall not be liable for
consequenal damages of any kind, including,
but not limited to: consequenal labor costs or
transportaon charges in connecon with the
replacement or repair of defecve parts; lost me
or expense which may have accrued because
of said defects. In no event shall Valley Tool &
Mfg. total liability hereunder exceed the product
purchase price.
Valley Tool & Mfg. makes no warranty with
respect to trade accessories or any components
or accessory of the product which was not
manufactured by Valley Tool & Mfg., including
any purchased components of any kind. These
are subject to the warranes of their respecve
manufacturers. The warranty will be considered
void if the product or any part of the product is
modied or repaired in any way not expressly
authorized by Valley Tool & Mfg., or if closed
components are disassembled prior to return.
Closed components include, but are not limited
to: gearboxes, hydraulic pumps, motors, cylinders,
and actuators.
Our obligaon under the warranty is expressly
limited, at our opon, to the replacement or repair
atValleyTool & Mfg., of Hughson CA, or at a service
facility designated by us, or such part or parts as
inspecon shall disclose to have been defecve.
We are not responsible for unauthorized repairs
or replacements. Warranty must be pre-approved.
Authorized parts will be sent to dealer UPS at
no charge. Any implied or statutory warranes,
including any warranty merchantability or tness
for a parcular purpose, are expressly limited to
the duraon of this wrien warranty. We make
no other express or implied warranty, nor is
anyone authorized to make any on our behalf.
This warranty cannot be extended, broadened,
or changed except in wring by an authorized
ocer of Valley Tool & Mfg. No warranty will be
processed without the mely registraon of the
signed “Delivery Report”.
Travel me of mechanics and transportaon of
the product to the authorized service dealer
for warranty work are the responsibility of the
aachment owner.
Valley Tool & Mfg oers the most reasonable and
dealer -friendly return policy in the market. We will
accept returns within 30 days of original receipt.
All returns must be approved by Valley Tool &
Mfg and a return authorizaon number must be
issued prior to return shipment. Returns must be
received in “like-new” condion and with all of
the original factory packaging including manuals.
Addional charges will apply if an item is received
that is not in “like-new” condion or that is not in
original factory packaging. Aer a return has been
fully inspected by our sta, refunds will issued less
shipping charges and any other possible damage
fees. Please allow up to 30 business days for your
account refund credit to be processed.
Please direct all return-related quesons to
sales@valleytoolmfg.com.
2

Failure to heed any of these warnings may result in
personal injury or death.
A. Operaonal Safety
Before operang this machinery read the owner’s
manual thoroughly.
Do NOT operate this machine without proper
training. It is the Owner’s responsibility to ensure
all Operators are properly trained in the appropriate
language.
Use OSHA approved eye, ear and head protecon to
protect the Operator from ying debris and noise.
Avoid wearing loose clothing as it can inadvertently
be drawn into moving parts. Never use drugs or
alcohol before or during operaon of this machine.
Only operate this machine when it is in good working
order on an appropriate power unit that is in good
working order, and with all guards and safety devices
in place and funconing.
Be aware of the machine’s weight and its eect on
the stability of the power unit.
Use ashing warning lights when operang on
highways, except when prohibited by law.
Always inspect area to be worked to ensure that the
jobsite is free from obstacles and debris that could
injure the operator or damage the machine.
Operate at a safe speed (typically 0-5 mph) in
consideraon of the local terrain, moving slower
when operang on or near slopes, ditches or drop-
os.
Avoid running the machine along the ground in rocky
areas as this could create dangerous discharge.
Keep bystanders and children clear of the work area
during operaon as debris can be discharged in a
dangerous manner. The minimum safe distance from
discharge is 100 .
Never allow children or other persons to ride on this
mower.
Be aware that this machine may be wider than the
power unit, and cauon should be used to avoid
clipping or running over trees, signs or posts that may
be in the way of the machine.
Avoid operaon that would allow hydraulic lines to be
pinched or severed. In the event of a hydraulic leak,
hydraulic uid may have sucient force to penetrate
skin. Hydraulic injecon injury requires immediate
medical aenon.
Avoid sharp turns or fully liing mower with PTO
engaged. This will produce knocking in the PTO sha
and accelerated wear of drive train components. The
drum should not be rotang when the deck is fully
lied.
www.vrisimo.com
Safety
3

Be aware of the risks of equipment and grass res.
To migate those risks:
• Do not smoke or have an open ame in the work
area.
• Do not operate in areas that have been freshly
burned or are sll burning.
• Do not allow clippings/debris to collect near
hydraulic components or bearings.
• Avoid areas with high re risk: dry grass, brush or
trees.
Operaon of this machine should be stopped
immediately if the Operator’s vision becomes
obscured by the discharge of debris and dust. Also
avoid operang this machine in unusually foggy or
dusty condions or at night.
Keep away from the machine unl all the energy has
dissipated. This includes the complete stopping
of the drum’s rotaon as well as the dissipaon of
pressure in the hydraulic lines.
In the event that a failure does occur during operaon
or if the machine begins to produce excessive noise
or vibraon, shut the machine down immediately and
repair before connued use.
In addion to the design and conguraon of
equipment, hazard control and accident prevenon
are dependent upon the awareness, concern and
prudence and requires suitable training of personnel
involved in the operaon, transport, maintenance
and storage of equipment.
B. Maintenance Safety
Before performing maintenance on this machine read
the owner’s manual thoroughly.
Maintenance should only be performed by properly
trained individuals. It is the owner’s responsibility
to ensure all individuals involved in maintaining the
machine are properly trained in the appropriate
language.
Be sure to inspect all safety devices before each use.
If safety devices are worn in such a way that they can
no longer properly perform their guarding funcon
contact your nearest Vrisimo dealer for replacements.
Maintain all safety decals and make sure they are
visible to the operator. If decals are worn, contact
your nearest Vrisimo dealer for replacements.
Replace cracked or broken blades with new ones. Do
not aempt to weld damaged blades. This can cause
damage that could result in the blade being thrown
from the shredder.
Wear gloves and eye protecon and exercise care
when handling blades as they can be sharp. Also be
alert to worn or damaged surfaces that could have
sharp edges.
Disengage PTO, shut o engine and allow all
movement to stop before leaving the operator’s
posion to adjust, lubricate, clean or unclog the
machine. Do not try to uncouple hydraulic hoses
unless the pressure has adequately dissipated.
Before working on or underneath the machine, place
wheel chocks in front and back of power unit’s res
or treads and under each end of the aachment to
prevent accidental lowering of the machine. Also,
remove the ignion key from the power unit and
allow all movement to stop before beginning work.
www.vrisimo.com
Safety
4

www.vrisimo.com
Basic Operaon
A. Aaching to the Power Unit
The person that is aaching your Vrisimo product
should be familiar with the aachment and remov-
al of equipment from a 3-point hitch and be able to
do so safely.
Aachment should be performed on at ground
away from obstrucons. During aachment, keep
hands out of pinch points and away from the blades
to avoid injury.
The tractor PTO should be disengaged and re-
moved completely before trying to aach Power
Unit to the mower, failure to do so could result in
damaging the PTO sha.
1. Back the tractor so the li links arms are in-line
with the mower’s hitch pins.
2. Shut o engine and disengage PTO. Block trac-
tor wheels before you place yourself between
the tractor and the mower.
3. Aach the tractor’s le and right li links to the
corresponding hitch pins of the mower. Secure
both connecons with lynch pins.
4. Adjust sway chains or bars so there is a mini-
mum of side slack. Be sure the stabilizers are
ght.
5. Aach the tractor’s top link to the “A” frame of
the mower. Adjust the link out to the approxi-
mate desired cung height.
6. Aach PTO sha between tractor and mower.
Remember, tube end goes to the mower and
bar end goes to the tractor.
7. Do not raise the mower while the PTO is en-
gaged, since this will cause the PTO sha to
bind or even break, and may cause injury to the
operator.
B. Starng Procedure
1. Check that the aachment is in the down posi-
on and that the blades are not in contact with
ground. Start engine and set throle to idle.
Never engage the PTO with the motor above
idle speed.
2. With the motor at low RPM engage the PTO
output.
3. Slowly bring the throle up to operang RPM.
If the Aachment produces excessive noise or
vibraon, disengage the PTO and shut down
the Power Unit immediately. Determine the
cause of the problem and correct it before
connuing with its operaon. Maximum PTO
speed is 540 RPM.
4. Aachment is ready for operaon.
5

www.vrisimo.com
Basic Operaon
C. Running Your Aachment
1. Determine ground speed based on terrain and
material being cut. This will typically fall within
the 0-5 mph range.
2. Adjust the hitch to the approximate desired
cung height.
3. Posion skid shoes between 1/2-3” o the
ground; skid shoes are not meant to run on the
ground.
4. The mower and skid shoes should be level
with the ground, the height of the mower can
be adjusted with the back gauge roller which
runs along the ground and works in conjuncon
with top link.
5. Make sure PTO sha is properly aached.
6. With the PTO disengaged, operate li arms
through enre range of moon. Check for bind-
ing, booming, uncoupling, or contact with at-
tachment.
D. Shut Down Procedure
1. When work is completed, disengage the PTO
sha and posion it for storage or transport
(See the “Storage and Transport” secon for
details on proper storage). Shut o Power Unit
and set parking brake, wait for the aachment
to stop rotang.
2. Visually inspect the PTO sha, all the bearings
and gearbox for excessive heat or leaks.
Li Arm Pin
Adjustable Top Link Pin
Skid Shoe
Back Roller Mount Plate
6

www.vrisimo.com
Adjustments & Maintenance
Note: Before performing maintenance, ensure all
moon has stopped and that the Power Unit is
powered down with ignion key removed. Before
working on or underneath the mower, place blocks on
both sides of the Power Unit’s res and underneath
both ends of the mower to prevent accidental
lowering of the machine.
A. Cut Height Adjustments
1. The cung height of the mower can be adjusted
by shortening and lengthening the adjustable
top link.
2. The enre weight of the mower should be on
the back gauge roller. The skid shoes should be
adjusted so there is 1/2”-3” clearance between
them and the ground. The shoes are for added
protecon against tree roots, ridges or borders
and are not designed to slide on the ground.
Adjust the back gauge roller by removing the
bolts from both back roller mount plates, seng
to the correct height, and reinstalling bolts.
B. Wear Components
Wear components such as knives, belts and
bearings may wear at dierent rates. Each should
be inspected for wear independently.
Belt Tension
1. Belt adjustment is done by ghtening the idler
adjusng rod which pushes the top pulley into
the belts. On a new machine, aer 1-2 hours
of operaon, ghten the drive belts so there is
1/4” to 3/8” give with 8 pounds of force.
Knives
1. When individual knives, bolts orspacers become
worn or damaged they must be replaced with
hardware saved from your previous knife
replacement. Replacing an individual staon
with new hardware could cause the cuer drum
to run out of balance. When replacing hardware
at all the staons, some old hardware should be
saved to replace future broken hardware.
2. Replacing the complete knife assembly is done
by removing the hanger rod. Re-insert hanging
rod inserng a new knife assembly at each
staon.
3. To replace the knife only, rotate the 7/16”
D-Ring unl slot is exposed. Disconnect from
quick connect changer. Replace the knife and
reconnect knife to D-Ring then proceed to
connect D-Ring back to quick connect changer
repeat this process unl completed.
C. Cleaning The Mower
1. Check for excessive grease in bearing areas on
the pulley side of the mower. Make sure grease
is not allowed into the belt areas.
2. Clean any clippings from the gearbox areas,
pulley areas and anywhere else that is prone to
excessive heat where re can start.
3. Clean the inside of the mower with a pressure
washer make sure the inside of the mower is
kept free from mud and compact grass. Mud
built up on the cuer drum can cause imbalance.
4. Preserve damaged decals or replace them if
they are unreadable. Decal kits can be obtained
from your local Vrisimo dealer.
7

www.vrisimo.com
Adjustments & Maintenance
Belt Tension
Top Pulley
Tension Adjustment
Boom Pulley
Quick Connect Hanger
Hanger Rod
D-Ring
Scoop Knives
Cuer Drum / Knives
PTO Sha
Boom Pulley
Top Pulley
Top Sha
Backroller Adjustment
Gearbox
Cut Height Adjustment
8

Adjustments & Maintenance
D. Lubricaon
Cuer Drum
1. There are two Grease zerk ngs to lubricate
per bearing housing. There is an outer and inner
zerk on each side of the mower.
2. Valley Tool recommends greasing with NLGI 2
ISO VG100. Any lithium based NLGI Grade 2
grease that is ISO 100 VG and of high quality
will work. DO NOT use grease designed for
tractor pins and bushings.
3. The CD-3001 is factory assembled with grease
for over 300 hours of operaon, and only
requires 6 pumps of grease every 300 hours
of operaon. Use of a pneumac grease guns
is not recommended as it is dicult to control
the amount of grease being applied. While it
is not necessary to “run-in” the bearing with
each grease interval, if an excessive amount of
grease has been applied the risk of failure can
be migated by allowing the bearing another
“run-in” period.
Back Roller
1. The back roller uses a four bolt ange style
bearing. There is one on either side of the back
roller. Grease daily as the back roller is exposed
to the most debris.
2. The The back roller bearing uses NLGI 1.5 ISO
VG460 grease and should be greased aer each
me used. Depending on condions back roller
bearings may require more or less grease.
Top Sha
1. All top sha bearings and yokes need to be
greased weekly with NLGI 1.5 ISO VG460.
PTO
1. Grease daily as the PTO sha can not be over
greased. PTO sha and tractor can be damaged
if run dry. PTO sha will bind up and not
telescope in and out properly.
2. The PTO sha should be greased with any
standard grease as long as it is NLGI 1.5 ISO
VG460.
Gearbox
1. Check gearbox oil level periodically and rell as
required. Replace gearbox oil every 300 hours.
2. Use quality SAE 80W-90 gear oil. Be sure
gearbox is in level posion and remove side
plug to ll.
Drive Side
Labyrinth / Outer
Top Sha Bearing
Bearing / Inner
9
www.vrisimo.com
Drivesha Slides
Cuer Drum Labyrinth
Cuer Drum Bearing
Driveshaft Yokes
Backroll Bearings
Top Sha Bearings
LUBRICATION FLUID HRS
NLGI 1.5 ISO VG460
NLGI 2 ISO VG100
NLGI 2 ISO VG100
NLGI 1.5 ISO VG460
NLGI 1.5 ISO VG460
NLGI 1.5 ISO VG460
10
300
Gearbox SAE 80W-90 300
10
10
10
10
Maintenance Table

Adjustments & Maintenance
10 www.vrisimo.com
KINEMATIC VISCOSITY cSt
TEMP DEG C TEMP DEG C
NAME NLGI GRADE 40 100
CHEVRON DELO EP2
PH66 DYNALIFE 220
SCHAEFFER 219
PH66 MULTIPLEX 150
MYSTIK JT-6 SYNTHETIC 100
MOBILITH SHC100
SHELL GADUS S2 V100 2
LUBRIPLATE EMB-3
SCHAEFFER 228
PH66 MULTIPLEX FS460
MOBILITH SHC460
SHELL GADUS S3 V460D 2
MYSTIK JT-6 SYNTHETIC 460
MYSTIK JT-6 MULTIPURPOSE
PH66 MULTIPLEX 460
2
2
2
2
2
1.5
2
2
2
1.5
2
2
2
2
2
226
220
142
144
100
100
100
100
555
460
460
460
460
460
415
20.7
18
14.6
10.8
16.3
16.3
14
14
36.5
48.3
55.6
61
59.1
59.1
26.8
Grease Comparison
0
100
200
300
400
500
600
30 50 70 90 110
VISCOSITY cSt
TEMP DEG C
Grease Viscosity vs. Temp
SCHAEFFER 228
PH66 MULTIP LEX FS460
MOBILITH SHC460
SHELL GADUS S3 V460D 2
MYSTIK JT-6 SYNTHETIC 460
MYSTIK JT-6 MULTIP URPOSE
PH66 MULTIP LEX 4 60
CHEVRON DELO EP2
PH66 DYNAL IFE 220
MYSTIK JT-6 SYNTHETIC 100
MOBILITH SHC100
SCHAEFFER 219
SHELL GADUS S2 V100 2
Maintenance Locaons
We understand that you have a lot of opons when it comes to
choosing your grease.
Any selecon from the Blue Group of greases are equivalent, and
any selecon from the Orange Group of greases are equivalent.

Transport, Removal and Storage
E. Transport, Removal and Storage
Disengage PTO and shut o engine allowing all
movement to stop before leaving the operators
posion to adjust, lubricate, clean or unclog the
machine.
Before working on or underneath the mower, place
wheel chocks on both sides (front and rear) of
Power Unit res and under each end of the mower
to prevent accidental lowering of the machine.
Also remove the ignion key from the Power Unit
and allow all movement to stop before beginning
work.
1. Transport on Power Unit
PTO must be disengaged, unit lied o the ground.
2. Transport on Trailer
Use chain down locaons even if unit is sll
aached to tractor, secure PTO sha into the PTO
rack.
3. Removal
• Place aachment on ground with enre weight
resng on mower.
• Remove the adjustable top link from the tractor
and mower.
• Disconnect the drive sha from the tractor and
mower.
• Remove the safety pins from the lower three
point arm pin locaon and disconnect the arms
4. Storage
• Place mower in clean, level, dry place.
• Put the drive sha away in a clean, dry place.
• Clean the mower thoroughly (See “Cleaning
your Mower” secon for details).
• Relax belt tension (See “Adjustments &
Maintenance” secon for details).
• Lubricate the mower as recommended (See
“Lubricaon” secon for details).
• Check oil level in gearbox and ll as required
(See “Lubricaon” secon for details).
• Check for worn parts and replace so you
will be ready to mow when necessary. (see
“Adjustments & Maintenance” secon).
Transport On Power Unit
Unit Lied Off Ground
Transport On Trailer
PTO Rack
Chain Down Locaons
Removal
Adjustable Top Link
Lower Arm Pins
Disconnect Drive Sha
11
www.vrisimo.com

Frequently Asked Quesons
12 www.vrisimo.com
Q. When I am replacing gear oil, how much should
I add?
A. When replacing gear oil, ll from the Upper
Fing. When oil level reaches Lower Middle
Fing, the box is full.
Q. Are there any advantages to reversing cuer
drum rotaon?
A. Whether reversing cuer drum is advantageous
depends on the applicaon. In most, normal
rotaon is a reverse rotaon. This means that
the cuer drum rotates in a fashion that would
throw grass or clippings towards the tractor.
The advantage to reversing rotaon would be in
industrial applicaons such as along freeways,
in places with large amounts of debris (i.e.
plasc, metal, rocks), or using a front mount
applicaon. There are typically no advantages
in the grade of cut you will get.
Q. How do I reverse cuer drum rotaon?
A. To reverse cuer drum rotaon, un-mount the
gearbox from its default posion, remove the
safety cover from the other sha of the gearbox
and rotate the gearbox so that the previously
covered sha is the one that will be driven by
the PTO. Install the safety covers.
Note: Scoop knives must be rotated to
accommodate for a reversed cuer drum rotaon.
Q. How do I replace my knives?
A. See the “Adjustments & Maintenance” secon
for detailed informaon.
Q. When connecng my PTO sha, can I put it on
either way or should a specic side go to the
mower/shredder and the other to the Power
Unit?
A. The PTO shas are side specic. The tube half
of the PTO sha goes to the mower and the bar
half of the PTO sha goes to the Power Unit.
Lower Middle Fing
Upper Fing
Drain


Orchard Low Prole Series Parts Book
14 www.vrisimo.com

1
3
2
2
Top Sha1⅜” x 27½” Center Mount
Top Sha1⅜” x 22” Center Mount
Top Sha1⅜” x 16” Center Mount
DESCRIPTION MODEL QTY P/N
LP2144-LP2180
LP2108-LP2132
LP2084-LP2096
05996
06049
06000
1
1
1
1
1
1
Top ShaExtension
Bearing 1-3/8" Pillow Block
6 SPL x 6SPL Universal Assembly
Cross Repair Kit
ALL
ALL
ALL
ALL
05218
TS-1300
DS-2227
DS-2230
1
1
1
1
3
4
5
Double Spline Sha ALL DS-222616
2
Parts: Top Sha Assembly
4
6
5
15
www.vrisimo.com

Parts: Pulley Assembly
32
2
1
4 3 5
2
Retainer Bushing - Top 1⅜”
DESCRIPTION MODEL QTY P/N
ALL
ALL
ALL
TL-15401
Retaining Bushing - Lower 27⁄16” 4G ALL TL-15501
4
Belt 4-Band 4-B62 B-192213
Pulley 7.4” OD 4B P-146122
Top Sha Bearing ALL TS-13062
5
1
16 www.vrisimo.com

Parts: Cuer Drum Assembly
5
1
2
3
4
Quick Connect Changer
Hanger Rod
Wire Guard (Not Shown)
7⁄16” D-Ring
Standard Scoop Knife
DESCRIPTION MODEL
ALL
ALL
ALL
ALL
ALL
CD-3005
4
2
See
Below
See
Below
See
Below
Assembly - Cuer Drum ALL See Below1
4
5
3
2
1
17
www.vrisimo.com
This manual suits for next models
8
Table of contents
Other Valley Tool Farm Equipment manuals
