Valor Fires Carlton User manual

5131712/04
This guide should be read in conjunction with the installer and owner guides
supplied with the heater.
This guide is intended to help you install your Electric Suite. Please read carefully
before installing. However, if further information is required, our
Valor Fires Technical Helpline will be pleased to help.
Telephone [phone] (National call rates apply in the United Kingdom)
In the Republic of Ireland call 0044 844 8711 565.
© Baxi Heating U.K. Limited 2010.
Carlton or
Matlock
Electric Suite.
INSTALLATION GUIDE
Important: Please keep your guide in a safe place for future reference.
This suite is intended for use with electric heaters only. It must never be
used with a gas fire.

© Baxi Heating U.K. Limited 2010. Page 2
© Baxi Heating U.K. Limited 2010.
All rights reserved. No part of this publication may be reproduced in any material form
(including photocopying), stored in any medium by electronic means (including in any
retrieval system or database) or transmitted, in any form or by any means, whether
electronic, mechanical, recording or otherwise, without the prior written permission of
the copyright owner.
Applications for the copyright owner's permission to reproduce any part of this
publication should be made, giving details of the proposed use, to the following
address: The Company Secretary, Baxi Heating UK Limited, Brooks House,
Coventry Road, Warwick, CV34 4LL
Warning: Any person who does any unauthorised act in relation to a copyright work
may be liable to criminal prosecution and civil claims for damages.
If you require further assistance, the Valor Fires Technical Helpline will be pleased
to help.
Please telephone [phone] (local rates apply in the United Kingdom). In the
Republic of Ireland please telephone [phone].
Valor Fires, Erdington, Birmingham B24 9QP.
www.firesandstoves.co.uk
Because our policy is one of constant development and improvement, details may vary slightly from
those given in this publication
INSTALLATION GUIDE

© Baxi Heating U.K. Limited 2010. Page 3
SAFETY
Always read this guide in conjunction with the guide supplied with the heater.
Always switch off electric power when not needed.
HANDLING AND UNPACKING
Before continuing any further with the installation of this suite please read the
following:
Important instructions.
The approximate lifting weight of the suite components without the fret and
fascia fitted is as below:
Mantle / surround with heater 18.5kg
Hearth 3.5kg
Total 22kg
This suite is heavy. We therefore recommend that two people should be
sufficient to lift it. If fitting or moving the suite alone we recommend the use of
suitable lifting apparatus.
When lifting always keep your back straight. Bend your legs and not your back.
Avoid twisting at the waist. It is better to reposition your feet.
Avoid upper body / top heavy bending. Always bend from the knees rather than
the waist. Do not lean forward or sideways whilst handling.
Always grip with the palm of the hand. Do not use the tips of fingers for support.
Always keep the suite as close to the body as possible. This will minimise the
cantilever action.
Use gloves to provide additional grip.
Always use assistance if required.
UNPACKING THE SUITE
The lower fascia trim, fixing kit, coals / pebbles and installer guide for the heater are
supplied at the back of the surround. Remove these before locating the surround
assembly.
Fit the trims and firefront as in the guide supplied with the heater.
INSTALLATION GUIDE

CONTENTS
DIMENSIONS
© Baxi Heating U.K. Limited 2010.
INSTALLATION GUIDE
Figure 1. Contents (Items are not to scale).
Figure 2. Dimensions (Heater fascia may differ from that shown)
Page 4

ASSEMBLING THE HEARTH AND SURROUND.
The installation of this Surround / Mantle and hearth requires a reasonable level
of DIY skills.
Please read this guide thoroughly before commencing installation and if in
doubt, seek help from a competent person.
Do I need any tools?
You will need the following tools :
A Pozidrive / Phillips / cross head screwdriver. This should have a number 2 size
tip.
A power drill (preferably with hammer action) and a suitably sized masonry drill bit
for the wall plugs supplied.
How to assemble the suite.
Step 1
The top of the hearth has four round
holes. Locate and screw the cam bolts
into these holes as in figure 3.
Step 2
The bottom of the mantle / surround has four
holes that line up with those in the hearth. Lift
and locate the surround / mantle onto the cam
bolts. Insert and tighten the four cam locks as in
figure 4.
Page 5
INSTALLATION GUIDE
© Baxi Heating U.K. Limited 2010.
Figure 3.
Figure 4.

Step 3. Fitting the wall fixing brackets.
There are two styles of wall fixing bracket. Only one style will be supplied with the
suite.
Flat bracket.
The brackets may already be
secured to the suite. If not, follow
the below:
Place the wall fixing brackets
along the outside edge of the legs
as shown in figure 5. Ensure that
the two fixing holes in the brackets
are positioned in the centre of the
leg. The surround may split if the
fixing holes are not central. Secure
in place using four (D) screws.
Angled bracket.
The brackets may already be
secured to the suite. If not, follow
the below:
Place the wall fixing brackets
along the inside edge of the legs
as shown in figure 5. Secure in
place using four (D) screws.
Step 4. Securing the Suite assembly.
Position the suite in place. Mark the positions of the bracket holes on the wall.
Move the suite aside and drill suitable sized holes. Insert the wall plugs (E). Position
the suite in place and secure using four (F) screws.
Note: The wall plugs are only suitable for brick or block walls. For timber framed walls
covered in plaster board we recommend the use of heavy duty cavity fixings.
Fit the trims and firefront as in the guide supplied with the heater.
© Baxi Heating U.K. Limited 2010.
INSTALLATION GUIDE
Page 6
Figure 5.
