Valor Heartbeat Oxysafe 426 User manual

600A562/03
HEARTBEAT
Radiant-Convector Gas Fire
MODEL 426
(GC 32 811 40)
OWNER GUIDE
This Owner Guideis intended to helpyou care for your Valor gas fire.
Please read carefully before using your gas fire and keep for future reference.
This Owner Guide gives sufficient details to enable your gas fire to be operated and
maintained.
IMPORTANT.
Please keep your Owner Guide in a safe place together with the
Installer Guide.

2
Thank you for choosing Valor.
All valor gas fires are designedto meet the most stringent quality,
performance andsafety requirements to provide our customers with
many years’ trouble-free service.
Your owner guide aims to improve your understanding and
appreciationofyourValorgasfirebyproviding simpleand
informative instructions to ensure that you benefit from the excellent
performance and features it has to offer.
Ifyourequirefurtherassistanceoranyadviceabout gas ingeneral,
theValor AdviceLine will be pleased to help.
Please telephone[phone] (local call rates apply in the United
Kingdom).
FOR OTHER USEFUL TELEPHONE
NUMBERS SEE INSIDE BACK COVER.
Page
PART 1: SAFETY 3
•Important information
PART 2: OPERATING INSTRUCTIONS 4
•How to light your fire
•How to turn your fire off
•The Flame Sensing Device
•Gas Consumption
PART 3: MAINTENANCE 5-6
•Cleaning your fire
•Debris in Flue/Chimney
•General Servicing
This fire is for use with natural gas (G20) in the United Kingdom (GB)
and the Republic of Ireland (IE).
It is a radiant-convector gas fire
and must not be used for any other purpose.
CONTENTS
CUSTOMER CARE

3
DO
•Have the fire installed by a competent person. In the United
Kingdom, installation must be in accordance with the latest
edition of the Gas Safety (installation & use) Regulations.
In the Republic of Ireland, installation must be in accordance
with all national and local regulations in force.
•Have the chimney swept prior to installation if it was
previously used for solid fuel the fire.
•Have the fire installed in accordance with the installation
instructions
•Provide a minimum clearance of 150mmabove the top of the
outer case to any shelf made of wood or other combustible
material where the shelf is not more than 150mm deep.
For a shelf deeper than 150mm, add 12.5mm to the clearance
for every 25mm of additional shelf depth.
•Provide a suitable guardwhich complies with BS6539 or
6778 for the protectionof young children,the elderly and the
infirm. Such a guard is also recommended for the protection
of pet animals. (Although this fire conforms to all the
applicable standards, it is a heating appliance and certain parts
of its surface will become hot.)
Note: The glass panel and apron together act as a fireguard conforming
to BS 1945:1971 and satisfythe HeatingAppliance
(Fireguard) (Safety) Regulations 1991.
•Switchthe fire offand allow to cool before attemptingto
clean, service, etc.
•Wait three minutes before attempting to relight if the fire is
switched off or if the flames are extinguishedfor any reason.
(Your fire is fitted with a safety device which will
automatically shut off the gas supply to the fire if, for any
reason, the flames go out.)
•Get advice about the suitability of any wall covering near your
fire. Soft wall coverings (e.g. embossed vinyl, etc.) which have
a raised pattern, are easily affected by heat. They may,
therefore,scorch or become discoloured whenclose to a
heating appliance. Please bear this in mind whenever you are
considering redecorating.
•Provide a minimum clearance of 100mmbetween the outer
case sides and any corner wall or other projection. Please bear
this in mind if ever you are considering altering the room.
•Contact the Valor AdviceLineon 0345 626 341 withany
enquiries you may have (local call rates apply in the United
Kingdom).
DON’T
•Put any paper or other material on the fire.
•Hang clothing, towels or any other fabricsover the fire.
•Fill in the space behind the case.
•Use the fire with a damaged coal piece or with the coal
incorrectly positioned.
•Use the fire if the glass window is damaged.
PART 1: SAFETY
CAUTION
IF YOU SMELL GAS...
•DON’T TURN ELECTRICAL SWITCHES ON OR
OFF
•DON’T SMOKE OR USE NAKED FLAMES
•DO OPEN DOORS AND WINDOWS TO GET RID
OF THE GAS
•DO TURN OFF THE GAS AT THE METER
•DO CALL THE GAS EMERGENCY SERVICE - IN
THE PHONE BOOK UNDER “GAS”
PLEASE NOTE
W
hen operating your fire for the first time, some vapours ma
y
be given off which may cause a slight odour and could possibly
set off any smoke alarms in the immediate vicinity. These
v
apours are quite normal with new appliances. They are totall
y
harmless and will disa
pp
ear after a few hours use.

4
HOW TO LIGHT YOUR VALOR GAS FIRE
The control is shown in Figure 1.
•Depress the controlknob and turn partially to the 1/IGN
position until you feel some resistance.
•Keep the knob depressed at this position for a few seconds to
allow gas to flow to the burner.
•While keepingthe knob depressed, turn to the 1/IGN position.
While turning, a spark should light the pilot.
•Keep the knob depressed at the 1/IGN position for a further
10 seconds then release it. The centre section of the coal will
be alight at this position.
•Depress the control knob slightly and turn it to your desired
burner setting.
•The control knob should be depressed slightly before turning
whenever you are changing the burner setting.
•The burner settings are;
1/IGN...........Centre section on low. Outer sections off.
2....................Centre section fully on. Outer sections off.
3....................Centre section fully on. Outer sections on low.
4....................Centre section fully on. Outer sections fully on.
•If the spark ignition fails, the fire can be lit manually by
inserting a lighted taper below the glass window and into the
centre of the coal (as shown in figure 2), and depressing the
control knob at the1/IGN position.
•We recommendthat the fire isset at position 4 forthe first 10
minutes after lighting to warm up the chimney and so obtain
full efficiency quickly.
Note: If the fire goes out while setting the control, repeat the full
lighting procedure.If the fire repeatedly goes out,have the fire
serviced.
HOW TO TURN OFF YOUR VALOR GAS FIRE
•Partially depress the control knob and turn clockwise to OFF. Release the knob.
•Wait at least 3 minutes after turning the fire offbefore relighting.
THE FLAME SENSING & SPILLAGE MONITORING SYSTEM
•For your safety, this appliance is fitted with a device which will automatically shut
off the gas supply to the fire if the pilot flame goes out. It will also shut off the gas
supply if the flue is blocked causing spillage of fumes, or if there is insufficient
ventilation to the fire.
•This device incorporates a probe which senses that the heat from the pilot flame
is correct. If this probe is cool, the device will prevent any gas flow unless the
controlknob iskept depressed at the 1/IGN position.
•If the flames go out, or if for any reason the fire is turned off, always wait at least 3
minutes before attempting to relight.
•If this device starts to shut off the gas frequently please get expert advice from the
Valor AdviceLineon 0345 626341 (localcallrates apply in the United Kingdom).
GAS CONSUMPTION
This gas fire has a maximumgas input of 5.77kW (Gross).
The fire has a low setting of 0.8kW (gross) output and a high setting of 3.55kW
(gross) output. To calculate the running cost of this gas fire, multiply the gas
consumption (heat input) by the cost of gas which you will find on your gas bill.
GAS COST RUNNING
CONSUMPTION OF GAS COST
(HEAT INPUT)
PART 2: OPERATING INSTRUCTIONS
Figure2 Lighting with a taper
X=
Figure 1 The Control

5
CLEANING YOUR VALOR GAS FIRE
To maintain the high performance and quality finish of your Valor fire, please follow
these guidlines:
•Before attempting to clean the fire,please remember to turn off the fire and wait
for the appliance to cool. The fire will retain heat for some time before cleaning
can begin.
•If any pieces of debris are found in the fire box, have the chimney inspected
before further use.
Metal Parts
•Clean the metal parts with a slightly damp cloth and then dry.
•Do not use abrasive cleaners as these will scratch the fire surface.
Window Glass
•Remove any stains on the window with a non-abrasive cleaner such as
a ceramic hob cleaner. Do not use abrasive cleaners.
•The fire has been designed to so that you can remove the window
without having to call in a service engineer. This allows you to clean
the inside of the window.
To remove the window:
1. Unscrew and remove the two knurled screws which are under the
outer case canopy (see figure 3).
2. Pull the top of the window surround forward (see figure 4).
3. Lift the window surround up to clear the slots inthe case apron
(see figure 4). Put the surround in a safe place.
4. Unscrew and remove the knurled screws at the bottom corners of
the window frame (see figure 5).
5. Lift the window up to clear the top edge of the fire box (see
figure 5). Put the window in a safe place.
6. Replace the window and surround after cleaning.
•Make sure that the top of the window frame is fully hooked
over the top edge of the fire box.
•Make sure that the outside edges of the window surround
sides are inside the outer case
Figure 5 Window removal
Figure 4 Window surround removal
PART 3: MAINTENANCE
Figure 3 Knurled screws

6
Ceramic Coal
•This product uses a fuel effect piece containing Refractory Ceramic
Fibres (RCF), which are man-made vitreous silicate fibres. Excessive
exposure to this materialmay causetemporary irritation to eyes, skin
and respiratory tract.Consequently,it makes sense to take care when
handling this article to ensure that the release of dust is kept to a
minimum.
•Although light coatings of soot are usually burnt off during normal
use, the coal may benefit from occasional cleaning.
•Should any soot accumulation become excessive, the fuel effect piece
should be removed from the fire for cleaning. Cleaning should be
carried out in a well ventilated area or in the open air by gently
brushing with the pieces held away from your face so that you avoid
inhaling the dust. We do not recommend the use of a normal domestic
vacuum cleaner which may blow dust back into the air.
•The coal canbe liftedout of the fire box when the window surround
and glass have been removed as described on page 5.
•When replacing the coal, make sure that it rests on the ledges at the
sides of the fire box and that its back face is touching the back of the
fire box (see figure 6).
•Replace the window and surround after cleaning.
-Make sure that the top of the window frame is fully hooked over
the top edge of the fire box.
-Make sure that the outside edges of the window surroundsides
are inside the outer case.
DEBRIS IN FLUE / CHIMNEY
•In order to achieve high levels of personal safety and performance efficiency it is
essential that the opening at the back (i.e. the flue)of the fire is kept clear of any
form of obstruction.
•If the chimney has previously been user for solidfuel fires,or is of normal
construction, deposits of mortar and soot can fall and accumulate until the flue
becomes blocked or restricted.
•The chimney should be checked annually to ensure continued clearance of the
combustion products and that no dangerous build up of debris has occurred.
•For advice on servicing your Valor fire, call Valor Service on 0121 386 6203
GENERAL SERVICING
•The fire should be serviced regularly to ensure good mechanical operation. This
servicing can be carriedout either by a Valor Service engineer or a CORGI
registered installer.
•If you require your fire to be serviced, please contact Valor Service on 0121 386
6203 and quote the following details;
a) - model name
b) - model no.
c) - appliance serial no. (To be found on a label near the bottom of the right side of
the case.)
•If you wish to replace any of the owner replaceable parts listed below, please
contact Valor Sales on 0121 386 6260 for your nearest stockist of these parts.
Description Part No.
Ceramic coal 558809
Window unit 522209
Knurled screw for window unit 558819
Window surround 558829
Knurled screw for window surround 558839
•When fitting replacement parts, follow the instructions contained in this guide.
N.B. It is important that only Valor approved parts are used for maximum safety.
Figure 6 Coal location

7
a) Your Post Code.
b) Type of fire.
c) Model/Name.
d) Serial Number.
e) The fault, problem or request.
General advice about gas and your gas fire:
VALOR ADVICELINE 0345 626341.
To report faults or arrange for your fire to be serviced:
VALOR SERVICE 0121 386 6203.
To order spares or for sales information:
VALOR SALES 0121 386 6260.
CALLERS IN THE REPUBLIC OF IRELAND
Call 0044 121 373 8111
USEFUL TELEPHONE NUMBERS
To help us quickly help you, please try to have the
followin
g
information available before
y
ou contact us:

8
© Valor Heating
Safety First.
Valor fires are CE Approved and designed to meet the appropriate British Standards
and Safety Marks.
Quality and Excellence.
At the heart of every Valor fire.
All Valor fires are manufactured to the highest standards of quality and excellence and
are manufactured undera BS EN ISO9001 quality system acceptedby the British
Standards Institute.
The Highest Standards
Valor is a member of the Society of British Gas Industries which works to ensure
high standards of safety, quality and performance.
Careful Installation
Valor is a Corgi registered company. All our gas fires must be
installed by a competent Corgi Registered Installer in accordance
with our Installer Guide and should not be fitted directly on to a
carpet or floor of combustible material.
Valor Heating, Erdington, Birmingham B24 9QP
Because our policy is one of constant development and improvement, details may vary slightly
from those given in this publication.
